T7MPW1900CA1900MHz OPTICAL DAS REPEATER

1 / 37 PW1900-C User Manual Kisan Telecom 2010. 04 2 / 37 Content 1. Introduction....................................................................................................................................................................5 1.1. General Introduction.....................................................................................................................................5 2. Network configuration of system.......................................................................................................................5 2.1. Network configuration.................................................................................................................................5 3. System Specifications................................................................................................................................................6 3.1. General Specifications..................................................................................................................................6 3.2. System specifications....................................................................................................................................7 3.2.1. Frequency allocation........................................................................................................................7 3.2.2. System Specifications......................................................................................................................7 4. Mechanical Specifications.......................................................................................................................................8 4.1. PW1900-C MHU..............................................................................................................................................8 4.1.1. Mechanical Design............................................................................................................................8 4.1.2. Dimension..........................................................................................................................................10 4.1.3. Mechanical specification............................................................................................................11 4.1.4. Descriptions of PW1900-C MHU............................................................................................11 4.1.5. Port Configuration.........................................................................................................................12 4.1.6. Module Composition....................................................................................................................14 4.1.7. Function of modules.....................................................................................................................15 4.1.8. PSU........................................................................................................................................................ 16 4.2 . PW1900-C RU................................................................................................................................................18 4.2.1. Mechanical Design.........................................................................................................................18 4.2.2. Dimension..........................................................................................................................................19  RU System Size  470(L) X 230(W) X 300(D) mm................................................................19 4.2.3. Mechanical Specification............................................................................................................19 4.2.4. Description of PW1900-C RU...................................................................................................20 4.2.5. Port Configuration.........................................................................................................................21 4.2.6. Module Composition....................................................................................................................21 4.2.7. Function of Modules....................................................................................................................23 5. Block Diagram............................................................................. 6. Administration Program (RptMan1900).......................................................................................................25 6.1. System Requirement..................................................................................................................................25 6.2. Cable connection.........................................................................................................................................25 6.3. Screen................................................................................................................................................................26 6.4. Status Display................................................................................................................................................26 3 / 37 6.5. Control Policy.................................................................................................................................................27 6.6. Menu..................................................................................................................................................................27 6.7. Toolbar...............................................................................................................................................................28 6.8. Progrm operation........................................................................................................................................29 6.8.1. Initiating communication................................................................................…

Text truncated - open the document above for the full version.

Kisan Telecom Co., Ltd. 2F, Segi Bldg., 66-2 Bangyi-Dong Songpa-Gu, Seoul, 138-828, Korea Tel. +82 2-3433-8341 Fax +82 2-3433-8316 April 9, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: T7MPW1900CA. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Kisan Telecom Co., Ltd. LTA Co.,LTD. (Contact Person) Contact name: LEE, Kyung-Taek Position: Manager Phone:(82)31-323-6008 E-mail: [email protected] Pan Soo Kim / Senior Manager Kisan Telecom Co., Ltd.

Kisan Telecom Co., Ltd. 2F, Segi Bldg., 66-2 Bangyi-Dong Songpa-Gu, Seoul, 138-828, Korea Tel. +82 2-3433-8341 Fax +82 2-3433-8316 April 9, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Kisan Telecom Co., Ltd. FCC ID : T7MPW1900CA Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Kisan Telecom Co., Ltd.. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Kisan Telecom Co., Ltd.. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name Schematics CONF APPENDIX T7MPW1900CA SCH DIA.pdf Parts list CONF APPENDIX T7MPW1900CA PL.pdf Block diagram CONF APPENDIX T7MPW1900CA BLK DIA.pdf CONFIDENTIAL Operational description CONF APPENDIX T7MPW1900CA OpDes.pdf External Photos SHORT-TERM CONF T7MPW1900CA EXT Photo.pdf Internal Photos SHORT-TERM CONF T7MPW1900CA INT Photo.pdf Test-Setup Photos SHORT-TERM CONF T7MPW1900CA Test Photo.pdf SHORT-TERM CONFIDENTIAL User’s Manual SHORT-TERM CONF T7MPW1900CA Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Pan Soo Kim / Senior Manager Kisan Telecom Co., Ltd. .

FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 3 RU - Front RU - Rear FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 3 RU - TOP RU - BOTTOM FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 3 RU - Left RU - Right

FCC ID: T7MPW1900CA Copyright Ⓒ 2010, LTA Co., Ltd. SAMPLE LABEL & LOCATION

FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 13 Internal photo FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 13 Interface B'd - Interface B'd A'ssy FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 13 PSU - MPS-J761(29V) FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 13 EMI Filter - CA5-V43 Arrester - Arrester FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 5 of 13 RF Module - HPA FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 6 of 13 Combiner - RRCOM FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 7 of 13 RF Modem - NKCM-340S FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 8 of 13 Optic Module - Duo SOU FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 9 of 13 RF Module - RLNA FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 10 of 13 RF Module - RRBS FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 11 of 13 RF Module - RFBS FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 12 of 13 CPU FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 13 of 13 Diplexer

Kisan Telecom Co., Ltd. 2F, Segi Bldg., 66-2 Bangyi-Dong Songpa-Gu, Seoul, 138-828, Korea Tel. +82 2-3433-8341 Fax +82 2-3433-8316 TUNE-UP PROCEDURE Test configuration of Equipment under test The EUT was tested under all applicable modulation which were PCS CDMA All tests were performed at Low, Middle and High channel . During the test, the RF output of the EUT was connected to the Power meter or Spectrum Analyzer. The Input of the EUT was connected to the Signal Generator (E4438C). All tests were performed just before at the shutdown point The Radiated emission was estimated from 30MHz ~ 20GHz. Test Setup: 1) Getting start - The EUT’s input was directly connected to the Signal Generator by MHU - The EUT’s output was connected to the Spectrum Analyzer through the attenuator. - EUT Power on. - Wait the EUT to check the isolation. - Set the modulation of the Signal Generator. - Signal Generator power on and adjust the output level. - Set the RBW and VBW and other setting of the Spectrum Analyzer. 2) Modulation type by each test item - PCS CDMA: RF Output power, Occupied bandwidth, Spurious Emissions ant Antenna Terminals, Band-edge test - CW : Radiated spurious emission test 3) Spectrum RBW and VBW setting by each modulation - CDMA set RBW and VBW with 30KHz. 4) EUT Gain and Signal Generator output level - During the all test, The EUT gain was 60dBm and Signal Generator’s output level was approximately from –20dBm to –10dBm.

FCC ID: S7AZBLINXZS10 ATTACHMENT ** MPE Calculations ** The MPE calculation for this exposure is shown below. Limits for Occupational/Controlled Exposure The peak radiated output power (EIRP) is calculated as follows: Maximum permissible exposure is Freq. (MHz)/1500 = MPE mW/cm 2 1930 MHz/1500 = 1.287 mW/cm 2 The following calculations determine at what distance from the antenna the power density is =1.287 mW/cm 2 Tx output power = 40.76 dBm numeric Gain = 11.22 dBi EIRP of TX and Antenna = 51.98 dBm 51.98 dBm=157.8 Watts or 157761 mW MPE Calulation Estimated safe separation: R = √(PG / 4π1.287) R = √(11912*11.22 / 4π1.287) R = 103.16Cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The minimum safe distance for Occupational/Controlled exposure is 103.16cm for the antenna when installed. This is the worst case for the downlink. The maximum antenna gain stated is for the downlink. This product is installed by trained professionals in outdoor applications only

Ref. : LR500191004B Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 26 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: April 01 ~ 11 2010 Test Report S/N: LR500191004B Test Site : LTA CO., LTD. FCC ID APPLICANT Te s t R e p o r t FCC Part 24(E) Certification Classification : PCS Licensed Transmitter Manufacturing Description : 1900MHz Optical DAS Repeater Manufacturer : Kisan Telecom Co., Ltd. Model name : PW1900-C Test Device Serial No.: : Identification FCC Rule Part(s) : §24(E), §2 Downlink : 1930~1990MHz (PCS CDMA) Uplink : N/A (Optical) Max. RF Output Power : 10W Type Modulation OQPSK (PCS CDMA) Emission Designators: : F9W Data of issue : April 12, 2010 This test report is issued under the authority of: The test was supervised by: Kyung-Taek LEE, Technical Manager Hyun-Chae You, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 T7MPW1900CA Kisan Telecom Co., Ltd. Ref. : LR500191004B Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 26 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 DESCRIPTION OF TESTS -------------------------------------------------------------------------- 3.2.1 Rower Output ----------------------------------------------------------------------------------- 3.2.2 OCCUPIED BANDWIDTH -------------------------------------------------------------------- 3.2.3 SPURIOUS EMISSION AT ANTENNA TERMINAL -------------------------------------- 3.2.4 FIELD STRENGTH OF SPURIOUS RADIATION ---------------------------------------- 3.2.6 FREQUENCY STABILITY -------------------------------------------------------------------- 3.3 TEST DATA --------------------------------------------------------------------------------------------- 3.3.1 RF POWER OUTPUT --------------------------------------------------------------------------- 3.3.1 Occupied Bandwidth ----------------------------------------------------------------------------- 3.3.2 Spurious Emisstion at Antenna Terminal ----------------------------------------------------- 3.3.2 FIELD STRENGTH OF SPURIOUS RADIATION ---------------------------------------- 3.3.3 FREQUENCY STABILITY --------------------------------------------------------------------- 3.4 CONNCLUSION ---------------------------------------------------------------------------------------- 3.5 TEST PLOTS ------------------------------------------------------------------------------------------- APPENDIX APPENDIX 1 TEST EQUIPMENT USED FOR TESTS ------------------------------------------ 3 4 5 6 6 6 6 6 7 8 9 10 11 12 13 14 25 Ref. : LR500191004B Copyright ○ c 2010, LTA Co., Ltd. Page 3 of 26 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2010-09-30 ECT accredited Lab. RRL KOREA KR0049 2011-06-20 EMC accredited Lab. FCC U.S.A 610755 2011-04-22 FCC filing VCCI JAPAN R2133, C2307 2011-06-21 VCCI registration IC CANADA IC5799 2010-05-03 IC filing Ref. : LR500191004B Copyright ○ c 2010, LTA Co., Ltd. Page 4 of 26 2. Information’s about test item 2-1 Client Company name : Kisan Telecom Co., Ltd. Address : 2F, Segi Bldg., 66-2 Bangyi-Dong Songpa-Gu, Seoul, 138-828, Korea Telephone : +82-2-3433-8341 Facsimile : +82-2-3433-8316 2-2 Equipment Under Test (EUT) Classification : PCS Licensed Transmitter Trade name : Optical DAS Repeater Model name : PW1900-C Serial number : Identification Date of receipt : April 01, 2010 EUT condition : Pre-production, not damaged Downlink : 1930~1990MHz (PCS CDMA) Uplink : N/A (Optical) Frequency Tolerance : ±0.0002 ppm Emission Designators : F9W Power Input : 120Vac 2-3 Tested frequency Frequency (CH) TX (MHz) Low (25) 1931.25 Mid (550) 1960.00 High (1175) 1988.75 Ref. : LR500191004B Copyright ○ c 2010, LTA Co., Ltd. Page 5 of 26 3. Test Report 3.1 Summary of tests Parameter Status Transmitter Requirements RF Power Output C Occupied Bandwidth C Spurious Radiation at Antenna Terminal C Field Strength of Spurious Radiation C Frequency Stability C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2 : The data in this test report are traceable to the national or international standards. Ref. : LR500191004B Copyright ○ c 2010, LTA Co., Ltd. Page 6 of 26 3.2 DESCRIPTION OF TESTS 3.2.1 RF Power Output Power output shall be measured at the RF outut terminals when the transmitter is adjusted in accordance with the tune-up procedure to give the values of current and voltage on circuit elements as specified.The electrical characteristics of the radio frequency load attached to the output terminals when this test is made shall be stated 3.2.2 Occupied Bandwidth The transmitter output is connected to the spectrum analyzer. The RBW is set to 1% of the Emission bandwidth. The VBW is set to 3 times the RBW. The sweep time is coupled. The 99% power bandwidth was measured with a calibrated spectrum analyzer. 3.2.3 Spurious Emission at Antenna Terminal The level of the carrier and the various conducted sp…

Text truncated - open the document above for the full version.

FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 1 of 2 Radiated Emission FCC ID: T7MPW1900CA Copyright ○ c 2010, LTA Co., Ltd. Page 2 of 2 Conducted Emission
