T7OUZ400SINGLE BAND CDMA MOBILE PHONE

Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 59 of 61 Appendix F – USER’S Manual 0 SKY 6400 User Manual - Be familiar with user’s precautions. - This user manual may be changed for the purpose of perfo rmance improvement, without prior notification to users. - For good culture of mobile phone, set your mobi le phone to the Vibration mode in public places. 1 User’s Precautions This is intended to protect user’s sa fety and prevent damage to properties. Be familiar with the user manual before use. * Do not lend your own phone to others. * If your phone requires After Sales service, cont act our designated customer service center. * If your phone is lost or stolen, report to your service provider immediately. * This product should not be equipped with any separate equipment that may cause a chan ge in its original performance as produc t type is registered. Warning Explosion Area You can use high frequency devices at construction site in order to explode explosive by remote co ntrol. Do not use the phone o r attach the accessories when you are at a gas station, a gas leakage hazardous area, and a ch emical storage or on a deck of a ship. Keep th e phone and the accessories away from inflammable material s because the spark at hazardous area may ca use fire or explosion. (Follow all instru ctions and signals within the area.) Phone and Electronic hardware Turn the phone off at transportation facilities or specific ar ea (e.g. airplane and hospital) where phones are prohibited from being used because it may cause accident or affect electronic medical devi ces. (Follow instructions of each organization.) 2 Electromagnetic wave information Phones transmit and receive high frequency (RF energy) with power on. International organizations have made standards and recom mendations regarding effects of this RF energy on human body. To comply with this standard, use cert ified accessories if you use your phone. If you do not use certified acce ssories, you may not keep safe because you violate electromagnetic wave-related criteria. Using phone while driving Be familiar with related laws while driving. * Keep your eye on driving * Do not use phone for safety while driving. * Stop your car for call, if necessary. Precautions for installation of handsfree Do not install handsfree set at a place where driving is interfer ed, or within the expansion of airbag in a vehicle equipped wi th airbag, or at place where human body may be directly injured. * Note that if dedicated earphones are not used, you cannot hear dial tone. Battery Use If you apply excessive forces with charged batteries in your pocke t or bag, or give a shock with sharp things, the phone may ca use generation of heat, fire or explosion. For further informat ion, refer to’ Precautions for Battery Use’. 3 Safety Rules How to use Antennas Hold your phone in the same way as general phone and do not touch antenna while calling. Because the phone may deteriorate call quality and transmit excessive power. If you change antenna illegally, the phone may be damaged and you cannot be provided wi th service for free. Data-related information While repairing or upgrading the phone, if required, keep importa nt data separately to ensure that data saved in the phone cann ot be cleared. Note that phone manufacturer shall not assume the responsibility for damage due to data loss. Check label for submersion check If phone or battery is waterlogged, label color is changed. Be ca reful in using your phone because you cannot be provided with service for free if the phone is out of order. 4 Information on User’s Safety and Effective Use of Phone * Do not apply excessive forces to assemble charging connecti on of a portable charger – It may cause abnormal charging or damag e. * Do not use damaged power cord or plug, loose outlet – it may cause electric shock or fire. * Do not pull out cord or touch power plug with your hands wet – it may cause electric shock or fire. * Do not bend power cord with excessive force, or make sure the power cord cannot be damaged under heavy materials - it may cau se electric shock or fire. * Do not directly connect + and - terminal outside the charger or battery – It may cause fire or explosion. * Do not charge the battery with unauthorized power (unauthorized generator, illegal charger) - It may cause fire or explosion. * Do not receive or make a call while the phone is being charged (o r with your hands wet) - it may cause electric shock or fire . * Keep the external connector away from baby – it may cause electric shock. * Do not drop charger or battery, or give too much shock – It may cause fire or explosion. * Do not hold the string and swing the phone. You may have yourself or others injured wh en it is slipped out from your hand. 5 How to Use and Manage Phone * Do not disassemble, remodel or repair the phone at random, and contact designated customer serv ice center if the phone requir es repair. * Keep the phone away from infants or pet. It may caus e damage to product, and result in explosion or fire. * Do not turn the phone by holding string, if any. * Do not bend the phone or give any external shock. * Do not sit down with your phone in back pocket. * Keep the phone away from magnetic materials, such as credit card and bankbook. * Keep the phone away from metals in your bag. * Do not put the phone in stove, microwave ov en, heating cooker, and high pressure vessel. * Use the phone within -20°C ~ 50°C, and do not keep the phone at too high or low temperature. * Do not clean the phone with poiso nous chemical or strong detergent. * When using the phone flash, do not use directly for man’ s or animal’s eyes. It may cause damage to eyesight. * Make sure that the phone ring cannot get st uck in the door of bus, subway or car. * If allergy, itch, swell or eczema occurs due to paint or metal of the phone, stop using the phone and see a doctor. * Do not paint the phone. It may cause malfunction, or dama…

Text truncated - open the document above for the full version.

UZONE wireless Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: T70UZ400 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematic Diagram Parts List Operating Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name : LEE KWANG Title : Principal Engineer

Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 46 of 61 Appendix C – EUT Photographs ● Front Side View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 47 of 61 ● Rear Side View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 48 of 61 ● Right Side View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 49 of 61 ● Left Side View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 50 of 61 ● Top Side View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 51 of 61 ● Bottom Side View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 52 of 61 ● Keypad Side View of EUT

Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 42 of 61 Appendix A - Labelling Requirement The sample label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. *** The following paragraph specified in the user manual. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 53 of 61 ● Inside View of EUT Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 54 of 61 ● Front View of Main Board Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 55 of 61 ● Rear View of Main Board Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 56 of 61 ● Adapter View of EUT

Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 61 of 61 Appendix H – Tune up Procedure Test Configuration of Equipment under Test The EUT has been tested under continuous transmitting mode. All tests are performed at Low channel , Middle channel, High channel. The field strength of spurious radiation emission for CDMA was measured at EUT stand-up position (H mode) and lie down position (E1 , E2 mode). During all testings, EUT is in link mode with Base Station emulator (8960 Series 10) at maximum power level.(ALL up bits Mode) Frequency range has been investigated : Radiated emission has been measured from 30MHz to 12.75GHz. Setting the Base Station 1) System ID : 2222 2) Network ID : 65535 3) Primary Call Channel : 363

UZONE wireless Co., Ltd. Page 1 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 SAR Evaluation Report FCC ID : T7OUZ400 Project Reference No. : NK2GR131 Product Type : Single Band CDMA Mobile Phone Brand Name : SKY MOBILE Model : SKYmobile 6400 Tested According to : IEEE Standard C95.1 / OET Bulletin 65 Supplement C Tested Period : June. 13 . 2006 to June. 16 . 2006 Tested by Minchul.Shin date : June. 19 . 2006 Verified by Seonteag.Jin date : June. 19 . 2006 This test results are only related to the item tested. This test report is only limited to the client company and the product. This report must not be used by the client to claim product endorsement by any agency of the U.S. Government. Lab Address : Nemko Korea Co., Ltd 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Gyunggi-Do, Korea Phone : 82-31-322-2333 Fax : 82-31-322-2332 UZONE wireless Co., Ltd. Page 2 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 Contents of This Report 1. General Information 4 1.1 Applicant 4 1.2 Manufacturer 4 1.3 Description of Device 4 2. General Test Condition 5 2.1 Location 5 2.2 Operating Environment 5 2.3 Test Frequency 5 2.4 Support Equipment 5 3. Description of Test Equipment 6-10 4. SAR Measurement Procedure 10-11 5. Definition of Reference Points 12 5.1 Ear Reference Point 12 5.2 Handset Reference Points 13 6. Test Configuration Positions 14 6.1 Cheek/Touch Position 14 6.2 Ear/Tilt 15°Position 15 6.3 Body-worn and Other Configurations 16 7. Measurement Uncertainty 17 8. System Verification 18 8.1 Tissue Verification 18 8.2 Test System Validation 19 8.3 Measurement Result of Test Data (Head Validation) 20 8.4 Measurement Result of Test Data (Muscle Validation) 21 9. Device Test Conditions 22 9.1 Procedures used to Establish Test Signal 22 9.2 SAR Measurement Conditions for CDMA2000 22-24 10. SAR Measurement Results 25 10.1 SAR Measurement Result(Right Head Touch Position) 26-29 10.2 SAR Measurement Result (Right Head Tilt Position) 30-31 10.3 SAR Measurement Result (Left Head Touch Position) 32-35 10.4 SAR Measurement Result (Left Head Tilt Position) 36-37 UZONE wireless Co., Ltd. Page 3 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 10.5 SAR Measurement Result (Muscle–15mm Distance- Position) 38-42 10.6 SAR Measurement Result (Muscle–15mm Distance- with Headset) 43-44 11. SAR Test Equipment 45 12. References 46 Appendix A SAR Definition 47-48 Appendix B Probe Calibration 49-57 Appendix C Dipole Calibration 58-63 Appendix D Photographs of EUT 64-68 UZONE wireless Co., Ltd. Page 4 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 1.General Information 1.1 Applicant Company Name: UZONE wireless Co.,Ltd. Company Address: 5F, Jungmin B/D, 97-4, Imae-Dong, Bundang-Gu, Seongnam-City, Kyunggi-Do, Korea Phone/Fax: Phone: +82-31-779-8041 Contact Name: Kwang, Lee 1.2 Manufacturer Company Name: ROSE Telecom Co., Ltd. Company Address: 2F, Chungrok ldg. 721-29 Yeoksam-dong, Kangnam-gu, Seoul, Korea Phone/Fax: Phone: +82-31-779-8041 Contact Name: Kwang, Lee 1.3 Description of Device Category: Single Band CDMA Mobile Phone Model Name: SKYmobile 6400 Brand Name: SKY MOBILE Serial Number: 0000123 Frequency of Operation Tx : 824MHz ~ 849MHz, Rx : 869MHz ~ 894MHz RF Output Power (Conducted) 23.28dBm Modulation/Demodulation OQPSK/QPSK Channel Spacing 1.23MHz Receiver Sensitivity -104dBm Power Supply Li-ion Battery: 3.7V DC, 1100mAh Phone Type Folder Type Antenna Type Inverted F Antenna Dimensions 87(open:163)(H) X44(W) X 17(T)mm Weight 85g(with Battery) Remarks: - UZONE wireless Co., Ltd. Page 5 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 2. General Test Condition 2.1 Location Nemko Korea 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Gyunggi-Do Phone : 82-31-322-2333 , Fax : 82-31-322-2332 2.2 Operating Environment Parameters Recording during test Accepted deviation Ambient temperature 20 ~22°C 15 ~ 30°C Relative humidity 40 ~65% 20 ~ 75% 2.3 Test Frequency CDMA (Head) CDMA ( Muscle) Test Channel Test Frequency (MHz)Test Channel Test Frequency (MHz) 1013 824.70 1013 824.70 363 835.89 363 835.89 777 848.31 777 848.31 2.4 Support Equipment Equipment Manufacturer Model Name Serial Number - - - - UZONE wireless Co., Ltd. Page 6 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 3. Description of Test Equipment 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, H/P computer, nearfield probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the H/P computer with Windows XP system and SAR Measurement Software DASY4, LCD monitor, mouse and keyboard. The Stäubli Robot is connected to the cell controller to allow software manipulation of the robot. A Data Acquisition Electronic (DAE) circuit that performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detection, collision detection, etc. Is connected to the Electro-Optical Coupler (EOC). The EOC performs the conversion from the optical into digital electric signal of the DAE and transfers data to the measurement server. UZONE wireless Co., Ltd. Page 7 of 68 FCC ID : T7OUZ400 SAR Report Reference No.: NK2GR131 System Electronics The DAE4 consists of a highly sensitive electrometer-grade preamplifier with autozeroing, a channel and gain-switching multiplexer, a fast 16-bit AD-converter and a…

Text truncated - open the document above for the full version.

Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 1 of 61 Nemko Korea CO., Ltd. 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Gyunggi-Do, KOREA TEL:+82 31 322 2333 FAX:+82 31 322 2332 FCC EVALUATION REPORT FOR CERTIFICATION Applicant : UZONE wireless Co., Ltd. Dates of Issue : June, 21, 2006 4F Jungmin B/D 97-4 Imaedong, Bundanggu, Test Report No. : NK2GR130 Seongnam-City, Kyunggi-do,Korea (463-829) Test Site : Nemko Korea Co., Ltd. FCC ID Brand Name CONTACT PERSON Applied Standard: FCC 47 CFR Part 22H & Part 2 Test Procedure: ANSI C63.4 , TIA/EIA 603 Equipment Class: Public Mobile Services EUT Type: Single Band CDMA Mobile Phone The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-2003. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested By : S. Lee Reviewed By : H.H. Kim Engineer Manager & Chief Engineer T7OUZ400 SKY MOBILE UZONE wireless Co.,Ltd. 4F Jungmin B/D 97-4 Imaedong,Bundanggu, Seongnam-City,Kyunggi-do,Korea Mr. KWANG LEE Telephone No. :82-31-779-8053 Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 2 of 61 TABLE OF CONTENTS 1. Scope 4 2. Introduction (Site Description) 5 3. Test Conditions & EUT Information 6 4. Measuring Instrument Calibration 8 5. Summary of Test Results 9 6. Recommendation / Conclusion 9 7. Test Equipment 10 8. Description of Test 11 8.1 Conducted Emission 11 8.2 Radiated Emission 12 8.3 Effective Radiated Power / Equivalent Isotropic Radiated Power 13 8.4 Radiated Spurious & Harmonic Emission 14 8.5 Occupied Bandwidth / 26dB Emission Bandwidth 16 8.6 Spurious and Harmonic Emissions at Antenna Terminal 17 8.7 Frequency Stability / Temperature Variation 19 9. Test Data 20 9.1 Effective Radiated Power (ERP) 20 9.2 Conducted Output Power 21 9.3 Occupied Bandwidth / 26dB Emission Bandwidth 21 9.4 Radiated Spurious & Harmonic Emission 22 9.5 Frequency Stability / Temperature Variation 24 9.6 AC Power LINE Conducted Emissions 26 10. Emission Designator 31 11. Test Plots 32 Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 3 of 61 Appendix A: Labelling Requirement 42 Appendix B: Photographs of Test Set-up 43 Appendix C: EUT Photographs 46 Appendix D: Schematic Diagram 57 Appendix E: Block Diagram 58 Appendix F: USER’S Manual 59 Appendix G: Operational Description 60 Appendix H: Turn up Procedure 61 Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 4 of 61 1. Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under FCC Part 22. Responsible Party : Contact Person : Manufacturer : UZONE wireless Co.,Ltd. Mr. KWANG LEE Tel : 82-31-779-8053 ROSE Telecom Co.,Ltd. 2F,CHUNGROK Idg. 721-29 Yeoksam-dong, Kangnam-gu, Seoul, Korea (135-920) z FCC ID: T7OUZ400 z Model: SKYmobile 6400 z Brand Name: SKY MOBILE z EUT Type: Single Band CDMA Mobile Phone z Electric Rating: DC3.7V, 1100mA z Equipment Class: z Classification: z Applied Standard: z Test Procedure(s): z Dates of Test: z Place of Tests: z Test Report No.: Intentional Radiators Licensed Portable Transmitter Held to Ear (PCE) FCC 47 CFR Part 22H & Part2 ANSI C63.4 (2003), TIA/EIA603 June 13, 2006 to June 20, 2006 Nemko Korea Co., Ltd. NK2GR130 Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 5 of 61 2. Introduction (Site Description) The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-2003) was used in determining radiated and conducted emissions emanating from UZONE wireless Co.,Ltd. FCC ID : T7OUZ400 These measurement tests were conducted at Nemko Korea Co., Ltd. The site address is 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, GyungGi-Do, KOREA The area of Nemko Korea Corporation Ltd. Test Site is located in a mountain area at 80 kilometers (48 miles) southeast and Incheon International Airport (Incheon Airport), 30 kilometers (18miles) south-southeast from central Seoul. It is located in the valley surrounded by mountains in all directions where ambient radio signal conditions are quiet and a favorable area to measure the radio frequency interference on open field test site for the computing and ISM devices manufactures. The detailed description of the measurement facility was found to be in compliance with the requirements of §2.948 according to ANSI C63.4 2003. Fig. 1. The map above shows the Seoul in Korea vicinity area. The map also shows Nemko Korea Corporation Ltd. and Incheon Airport. Nemko Korea Co., Ltd. 300-2, Osan-Ri, Mohyun-Myun, Yongin-City GyungGi-Do,KOREA 449-852 Tel)+82-31-322-2333 Fax)+82-31-322-2332 Test Report No.: NK2GR130 UZON wireless Co., Ltd. FCC ID : T7OUZ400 Page 6 of 61 3. Test Conditions & EUT Information Operating During Test The EUT was tested at the lowest channel, middle channel and the highest channel with the maximum RF Power and all data recorded in the report. Environmental Conditions Temperature 20°C ~ 25°C Relative Humidity 45% ~ 65% Description of EUT Frequency Range Tx : 824.70MHz ~ 848.31MHz Rx : 869.70MHz ~ 893.31MHz Output Power 0.528W ERP (27.23dBm) Emission Designator 1M25F9W Type of Oscillation PLL Synthesizer & VCTCXO(19.2MHz) Modulation Method Tx : OQPSK / Rx : QPSK Number of channels 20CH Frequency Tolerance ±0.00025%(2.5ppm) Antenna Type Inverted F Ante…
