T9E-WD1803-04-05Remote Control Car

User manual: 1. Charging the battery: - Connect the battery pack connector to the charger connector - Connect the charger to a plug outlet. - In case of abnormal heating(45 degrees Celsius or higher), stop charging immediately. - To store the battery in good condition, keep the model running until the model stops before storage. - This charger is exclusive for the RACING TRUCK battery pack, Do not use it for any other purpose. 2. Preparing the transmitter for use. - Turn both the steering and throttle to normal - Install 8 AA size batteries in the transmitter. 3. Preparing the chassis. - Installing the antenna Feed the antenna through the antenna pipe, then, install the antenna pipe on the chassis as shown. - Installing the battery Open the battery box and put in the battery pack. - Connect the battery connector to the body connector installing the battery Close the battery box cover with a pin. 4. Preparing before driving - Fully extend antenna - Switch on transmitter - Switch on the model - Adjustment of a Throttle Trim - Adjustment of a Steering Trim

FCC ID: T9E-WD1803-04-05 Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmf ul interference, and (2) this device must accept any interference received, includeing interference that may cause undesired operation. Change or modifications not express ly approved by the party responsible for complian ce could void user ’s sauthority to operate the equipment. 4cm 1.7cm

Report No.: SZEMO060601368RFF Page: 1 of 9 FCC ID: T9E-WD1803-04-05 Authorized Signature: Robinson Lo Laboratory Manager This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. Member of the SGS Group (SGS SA) SGS-CSTC Standards Technical Services Ltd. No.198 Kezhu Road, Science Town Economic& Technology Development District Guangzhou, China 510663 Telephone: +86 (0) 20 8215 5555 Fax: +86 (0) 20 8207 5059 Email: [email protected] FEDERAL COMMUNICATIONS COMMISSION Registration number: 556682 TEST REPORT Application No. : SZEMO060601368RF(SGS SZ NO.: SZTYR060601744/EL) Applicant: Manufacturer: Experience Enterprises Woddon Industrial Limited FCC ID: T9E-WD1803-04-05 Fundamental Frequency : 27.145MHz Equipment Under Test (EUT): EUT Name: Remote Control Cars Model No.: Labelled Age Grading: Country of Origin: Country of Destination: (1)WD1803/1804/1805 For ages over 8 China USA Standards: FCC PART 15, SUBPART C : 2006 Section 15.227 Date of Receipt: 26 June 2006 Date of Test: 27 June to 30 June 2006 Date of Issue: 07 July 2006 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. FCC ID: T9E-WD1803-04-05 Report No.: SZEMO060601368RFF Page: 2 of 9 SGS-CSTC Standards Technical Services Ltd. 2 Test Summary Test Test Requirement Stanadard Paragraph Result Radiated Emission (30MHz to 1000MHz) FCC PART 15 :2006 Section 15.227 PASS Occupied Bandwidth FCC PART 15 :2006 Section 15.215 PASS * Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radiated Frequency. * The EUT passed the test after modification specified below detailed in the picture. 1, Added a 10pF capacitance to the antenna in parallel connection and connected it to the ground. 2, Added a 56pF capacitance to the C35 in parallel connection and connected it to the ground. FCC ID: T9E-WD1803-04-05 Report No.: SZEMO060601368RFF Page: 3 of 9 SGS-CSTC Standards Technical Services Ltd. 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 TEST SUMMARY..............................................................................................................................................2 3 CONTENTS........................................................................................................................................................3 4 GENERAL INFORMATION.............................................................................................................................4 4.1 CLIENT INFORMATION.................................................................................................................................4 4.2 DETAILS OF E.U.T......................................................................................................................................4 4.3 DESCRIPTION OF SUPPORT UNITS.............................................................................................................4 4.4 TEST LOCATION..........................................................................................................................................4 4.5 OTHER INFORMATION REQUESTED BY THE CUSTOMER............................................................................4 4.6 TEST FACILITY.............................................................................................................................................5 5 TEST RESULTS................................................................................................................................................6 5.1 TEST INSTRUMENTS....................................................................................................................................6 5.2 E.U.T. OPERATION.....................................................................................................................................6 5.3 TEST PROCEDURE & MEASUREMENT DATA...............................................................................................6 5.3.1 Radiated Emissions.............................................................................................................................6 5.3.2 Occupied Bandwidth........................................................................................................................8-9 FCC ID: T9E-WD1803-04-05 Report No.: SZEMO060601368RFF Page: 4 of 9 SGS-CSTC Standards Technical Services Ltd. 4 General Information 4.1 Client Information Applicant Name: Experience Enterprises Applicant Address: 156 North Jefferson, Chicago, IL, 60661, USA 4.2 Details of E.U.T. EUT Name: Remote Control Cars Item No.: (1)WD1803/1804/1805 Power Supply: 12.0V DC (8*1.5V ‘AA’ Size Batteries) for Tx. Power Cord: N/A- 4.3 Description of Support Units…
