Compliance Certification Services (Shenzhen) Inc. Report No.: SZ050810B01-RP FCC ID: TB5PA8010UR Date of Issue:September 8, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 30 Rev. 00 FCC 47 CFR PART 74 SUBPART H TEST REPORT For UHF Wireless Microphone PA-8010UR/ PA-8010Q/ PA-8010UD/ PA-8010UDR/ SE-808/ SE-900/ SE-3000/ SE-1360/ SE-2019/ SE-2022 Trade Name: N/A Issued to ENPING SOUND-EXPLORER ACOUSTICS SCIENCE AND TECHNOLOGY EXPAND CO., LTD. (PROSOUND TECHNOLOGY CORP) PINGSHI INDUSTRIAL ESTATE ENPING CITY GUANGDONG PROVINCE CHINA Issued by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 6, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No.: SZ050810B01-RP FCC ID: TB5PA8010UR Date of Issue: September 8, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.....................................................................................................................5 3.2 EUT EXERCISE.................................................................................................................................5 3.3 GENERAL TEST PROCEDURES..........................................................................................................5 3.4 MODIFICATION...............................................................................................................................5 3.5 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS......................................................6 3.6 DESCRIPTION OF TEST MODES........................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES 8 5.2 EQUIPMENT.....................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING...............................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT......................................................................................................9 6.2 SUPPORT EQUIPMENT ..............................................................................................................9 7. FCC PART 74 REQUIREMENTS............................................................................................. 10 7.1 MAXIMUM TRANSMITTER POWER .....................................................................................10 7.2 MODULATION CHARACTERISTICS .....................................................................................13 7.3 FREQUENCY TOLERANCE MEASUREMENT ......................................................................18 7.4 EMISSION BANDWIDTH MEASUREMENT ..........................................................................22 7.5 UNWANTED RADIATION .......................................................................................................27 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................................... 30 Compliance Certification Services (Shenzhen) Inc. Report No.: SZ050810B01-RP FCC ID: TB5PA8010UR Date of Issue: September 8, 2005 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: ENPING SOUND-EXPLORER ACOUSTICS SCIENCE AND TECHNOLOGY EXPAND CO., LTD. (PROSOUND TECHNOLOGY CORP) PINGSHI INDUSTRIAL ESTATE ENPING CITY GUANGDONG PROVINCE CHINA Equipment Under Test: UHF Wireless Microphone Tr a d e N a m e : N/A Model: PA-8010UR/ PA-8010Q/ PA-8010UD/ PA-8010UDR/ SE-808/ SE-900/ SE-3000/ SE-1360/ SE-2019/ SE-2022 Date of Test: May 20-July 05, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 74 Subpart H No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 74H. The test results of this report relate only to the tested sample EUT identified in this report. Reviewed and Approved by: Clinton Kao Manager of the EMC testing Division Compliance Certification Services (SZ) Inc. Compliance Certification Services (Shenzhen) Inc. Report No.: SZ050810B01-RP FCC ID: TB5PA8010UR Date of Issue: September 8, 2005 Page 4 Rev. 00 2. EUT DESCRIPTION Product UHF Wireless Microphone Trade Name N/A Model Number PA-8010UR/ PA-8010Q/ PA-8010UD/ PA-8010UDR/ SE-808/ SE-900/ SE-3000/ SE-1360/ SE-2019/ SE-2022 Model Discrepancy The same products have the different model names. Remark: This submittal(s) (test report) is intended for FCC ID: TB5PA8010UR filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 95, Subpart C Rules. Compliance Certification Services (Shenzhen) Inc. Report No.: SZ05…
