TD5-PROFESSIONALCOMPUTER

MANUAL Professional Contents Notices.......................................... .................................... .................. A Safety information ............................................ .................................. B Specification summary .......................................... ............................. C About this guide............ ............................................. ........................ D Chapter 1: Product introduction 1.1 Central Processing Unit(CPU)............ ......................................... 1 1.1.1 Overview.................. .................................... ...................... 1 1.1.2 Installing the CP U............................... .............................. 2 1.2 System memory.. ............................................. ............................. 3 1.2.1 DIMM sockets lo cation................... .................................. 3 1.2.2 Memory configur ations.................... ................................. 3 1.2.3 Installing a DI MM............................ ................................ 4 1.3 Expansion slots... ............................................. ............................. 5 1.3.1 PCI slots...... ............................................. ......................... 5 1.3.2 AGP slot.......... ............................................. ..................... 5 1.4 Jumpers.................... ............................................. ......................... 6 1.5 Connectors.................. ............................................. ...................... 8 1.5.1 Rear panel conn ectors..................... .................................. 8 1.5.2 Internal connec tors.............................. .............................. 9 B A NoticesFederal communications Commission StatementThis device complies with FCC Rules pa rt 15. Operation is subject to the following two conditions: · This device may not cause harmful interference, and · This device must accept any interfer ence received including interference that may cause undesired operation. This equipment has been tested and fo und to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with manufacturer’s instructions, may ca use harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · increase the separation between the equipment and receiver. · Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experien ced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations.Changes or modifications to this unit not expressly approved by theParty responsible for compliance c ould void the user ’s authority to Operate this equipment Canadian Department of Communications StatementThis digital apparatus does not exc eed the Class B limits for radio noise emissions from digital apparatus set out in the Radio InterferenceRegulations of the Canadian Department of Communications. This class B digital apparatus complies with Canadian ICES-003. Safety informationElectrical safety • To prevent electrical shock haza rd, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure thatthe power cables for the devices are unplugged before the signalcables are connected. If Possible, disconnect all power cables from the existing system before you add a device. • Before connecting or removing sign al cables from the motherboard, ensure that all power cables are unplugged. • Seek professional assistance befo re using an adapter or extension cord. These devices could interrupt the grounding circuit. • Make sure that your power supply is set to the correct voltage in your area. If you are not sure about th e voltage of the electrical outlet you are using, contact your local power company. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer. Operation safety • Before installing the mo therboard and adding devices on it, carefully read all the manuals that came with the package. • Before using the product, make sure all cables are correctly connected and the power cables are not damage d. If you detect any damage, contact your dealer immediately. • To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry. • Avoid dust, humidity, and temperatur e extremes. Do not place the product in any area where it may become wet. • Place the product on a stable surface. • If you encounter technical problems with the product, contact aqualified service techni cian or your retailer. C D specification summary*CPU Socket 478 for Intel Pentium 4 Northwood/Willamette processor Intel Hyper-Threading technology ready New power design for next generation Intel Prescott CPUChipset SiS661 FX SiS963LFront Slide Bus (FSB) 800/533/400 MHzMemory 2 x 184-pin DDR DIMM sockets for up to 2GB memory Supports PC3200/2700/2100 unbuffered non-ECC DDR DIMMs.Expansion slots 1 x AGP 8x/4x ( 1.5V only ) 3 x PCIVGA SiS Real 256E integrated graphicsStorage 2 x Ultra ATA 133, PLO Mode 0~4Audio ADI AD1888 6-channel audio CODECLAN Integrated MAC with VIA 6103L 10/1…

Text truncated - open the document above for the full version.

External Photos (FCC ID: TD5-PROFESSIONAL)

FCC ID label location information (FCC ID : TD5-PROFESSIONAL)

FCC ID label sample FCC ID : TD5-PROFESSIONAL Tested to Comply with FCC Standards This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos (FCC ID : TD5-PROFESSIONAL)

OPERATION AND STANDARDS DEPARTMENT Bangpoo Industrial Estate Soi 8, Sukhumvit Road Km.37, 975 Moo 4, Praeksa, Muang, Samutprakarn 10280 Tel. +66 2709 4860-8 Fax. +66 2324 0917-8 TEST CERTIFICATE [ Personal Computer # 1 ] Page 1 / 9 This document is certified only on the tested sample. Prohibit to reproduce some part of them without permission from the Operation and Standards Department. FT 002(E)-1/05-47 Report No. G0535(E)/48 Operation No. 4804BG546 Name and address of customer SVOA Public Co., Ltd 279 Moo 7 Ratburana Rd., Ratburana, Ratburana, Bangkok Thailand 10140 Tel: +66 2462 5827 Ext. 2511 Fax: +66 2462 7141 Sample description Personal Computer “SVOA” CPU Pentium4 3.2 GHz 17” SVOA Monitor 1 set with mouse and keyboard Sample No. BG546 Sample characteristic and condition Normal Sample receipted date April 26, 2005 Test date May 24, 2005 Test standard FCC Part 15 Class B Test report Details of the test report as shown on the following pages Certified by ( Mr. Thossaphorn Udomsinsirikul ) Group Manager Electromagnetic Compatibility Test Group (Mr.Udomsak Kanjanarajit) Senior Section Manager Operation and Administration Manager Test personnel : PP.(DSi.) OPERATION AND STANDARDS DEPARTMENT Report No. : G0546(E)/48 Operation No. : 4804BG535 TEST REPORT [ Personal Computer #1 ] Page 2 / 9 This report is certified only on the tested sample. Prohibit to reproduce some part of them without permission from the Operation and Standards Department. Tested by ...................... Certified by ...................... FT 003(E)-1/05-47 TEST EQUIPMENTS Radiated Disturbance Measurement 30 MHz – 1 GHz Order TEST ITEM I.D number Calibration dated 1 EMI Receiver HP8542E EMC 1011 31-12-2004 2 Bilog Antenna, 2310 EMC 1003 24-08-2004 3 Horn Antenna, 3115 TISI.603/1-9 19-07-2004 4 TOYO EMI Software, EPS/RE EMC 3002 - 5 Cable Path 10 m Chamber Path 10 m - 18-02-2005 Conducted Disturbance Measurement 450 kHz – 30 MHz Order TEST ITEM I.D number Calibration dated 1 EMI Receiver HP8542E EMC 1001 31-12-2004 2 LISN # NNB42 S/N 0001 EMC 1008 26-07-2004 3 TOYO EMI Software, EPS/CE EMC 3001 - 4 Cable Path Shielded Room - 18-02-2005 AUX EQUIPMENT Order TEST ITEM Model 1 Inkjet Printer, CANON BJ S500 TEST REQUIREMENT TEST REQUIREMENTS EUT CE RE Personal Computer 9 9 CE: Conducted disturbance measurement RE: Radiated disturbance measurement TEST RESULT CONCLUSION TEST RESULT TEST METHOD CE RE FCC Part 15 Class B P P Remark P: The test result complied with the limit specified in the test requirement X: The test result didn’t comply with the limit specified in the test requirement N/A: No need to be tested OPERATION AND STANDARDS DEPARTMENT Report No. : G0546(E)/48 Operation No. : 4804BG535 TEST REPORT [ Personal Computer #1 ] Page 3 / 9 This report is certified only on the tested sample. Prohibit to reproduce some part of them without permission from the Operation and Standards Department. Tested by ...................... Certified by ...................... FT 003(E)-1/05-47 TEST CONDITIONS Operation Mode - A : EMC test software was used for operating. Standard rues for judging compliance testing result for emission testing (According to the NIS 81) Pass Case A The measured result is within the limit, even when extended by the uncertainty interval. The product therefore complies with the specification. Unjudge in Case B The measured result is below the upper limit, but by a margin less than half of the uncertainty interval; it is therefore not possible to state compliance based on the 95% level of confidence. However, the result indicates that compliance is more probable than non- compliance. Unjudged in Case C The measured result is above the upper limit, but by a margin less than half of the uncertainty interval; it is therefore not possible to state non-compliance based on the 95% level of confidence. However, the result indicates that non- compliance is more probable than compliance. Fail Case D The measured result is beyond the upper limit, even when extended downwards by half of the uncertainly interval. The product therefore does not comply with the specification. OPERATION AND STANDARDS DEPARTMENT Report No. : G0546(E)/48 Operation No. : 4804BG535 TEST REPORT [ Personal Computer #1 ] Page 4 / 9 This report is certified only on the tested sample. Prohibit to reproduce some part of them without permission from the Operation and Standards Department. Tested by ...................... Certified by ...................... FT 003(E)-1/05-47 EUT DESCRIPTION Table of EUT Description General Description EUT Name Personal Computer Model SVOA Pentium4 3.2 GHz Technical Description Voltage 230 Volt 50 Hz Clock/Oscillator 3.2 GHz Cables Ref Cable type Shield Length (meters) Ferrite Connector Connection Point 1 Connection Point 2 1 Power Line No 1.5 m No AC CPU Case AC Main 2 Power Line No 1.5 m No AC Monitor Case AC Main OPERATION AND STANDARDS DEPARTMENT Report No. : G0546(E)/48 Operation No. : 4804BG535 TEST REPORT [ Personal Computer #1 ] Page 5 / 9 This report is certified only on the tested sample. Prohibit to reproduce some part of them without permission from the Operation and Standards Department. Tested by ...................... Certified by ...................... FT 003(E)-1/05-47 EUT SET UP Figure 1 Test set up for radiated disturbance measurement Figure 2 Test set up for conducted disturbance measurement OPERATION AND STANDARDS DEPARTMENT Report No. : G0546(E)/48 Operation No. : 4804BG535 TEST REPORT [ Personal Computer #1 ] Page 6 / 9 This report is certified only on the tested sample. Prohibit to reproduce some part of them without permission from the Operation and Standards Department. Tested by ...................... Certified by ...................... FT 003(E)-1/05-47 TEST SET UP Conducted Emission The Conducted emission measurement was performed with EMI receiver to observe the emission characteristic and identify the frequency of emission that has the highest amplitude relative to limit by operating the EU…

Text truncated - open the document above for the full version.

Test set-up photos (FCC ID : TD5-PROFESSIONAL) Test set up for radiated disturbance measurement Test set up for conducted disturbance measurement
