TDQ080187Gun Diode Microwave Transmitter

012-04630G MICROWAVE OPTICS Instruction Manual and Experiment Guide for the PASCO scientific Model WA-9314B Includes Teacher's Notes and Typical Experiment Results            !""#"$%&$!""'(    )*   + ! ,  i 012-04630GMicrowave Optics Table of Contents SectionPage Copyright, Warranty, and Equipment Return ................................................... ii Introduction ...................................................................................................... 1 Equipment ......................................................................................................... 1 Initial Setup ...................................................................................................... 3 Accessory Equipment ....................................................................................... 3 Assembling Equipment for Experiments .......................................................... 5 Experiments Experiment 1: Introduction to the System ............................................ 7 Experiment 2: Reflection ................................................................... 11 Experiment 3: Standing Waves - Measuring Wavelengths ............... 13 Experiment 4: Refraction Through a Prism ....................................... 17 Experiment 5: Polarization ................................................................ 19 Experiment 6: Double-Slit Interference ............................................ 21 Experiment 7: Lloyds Mirror ............................................................. 23 Experiment 8: Fabry-Perot Interferometer ........................................ 25 Experiment 9: Michelson Interferometer .......................................... 27 Experiment 10: Fiber Optics .............................................................. 29 Experiment 11: Brewster's Angle ...................................................... 31 Experiment 12: Bragg Diffraction ..................................................... 33 Teacher's Guide .............................................................................................. 35 Appendix ........................................................................................................ 45 Schematic Diagrams ....................................................................................... 46 Replacement Parts List ................................................................................... 47 ➤➤ ➤➤ ➤ This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. this device may not cause harmful interference. 2. this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Pasco Scientific could void the user's author- ity to operate the equipment. ii Microwave Optics012-04630G Copyright Notice The PASCO scientific 012-04630E Model WA-9314B Microwave Optics manual is copyrighted and all rights reserved. However, permission is granted to non-profit educational institutions for reproduction of any part of the manual providing the reproductions are used only for their laboratories and are not sold for profit. Reproduction under any other circumstances, without the written consent of PASCO scientific, is prohibited. Limited Warranty PASCO scientific warrants the product to be free from defects in materials and workmanship for a period of one year from the date of shipment to the customer. PASCO will repair or replace at its option any part of the product which is deemed to be defective in material or workman- ship. The warranty does not cover damage to the product caused by abuse or improper use. Determination of whether a product failure is the result of a manufacturing defect or improper use by the customer shall be made solely by PASCO scientific. Responsibility for the return of equipment for warranty repair belongs to the customer. Equipment must be properly packed to prevent damage and shipped postage or freight prepaid. (Damage caused by improper packing of the equipment for return shipment will not be covered by the warranty.) Shipping costs for returning the equipment after repair will be paid by PASCO scientific. Copyright, Warranty, and Equipment Return Please—Feel free to duplicate this manual subject to the copyright restrictions below. Equipment Return Should the product have to be returned to PASCO scientific for any reason, notify PASCO scientific by letter, phone, or fax BEFORE returning the product. Upon notification, the return authorization and shipping instructions will be promptly issued. ➤ ➤ ➤ ➤ ➤ NOTE: NO EQUIPMENT WILL BE ACCEPTED FOR RETURN WITHOUT AN AUTHORIZATION FROM PASCO. When returning equipment for repair, the units must be packed properly. Carriers will not accept responsibility for damage caused by improper packing. To be certain the unit will not be damaged in shipment, observe the follow- ing rules: ➀The packing carton must be strong enough for the item shipped. ➁Make certain there are at least two inches of packing material between any point on the apparatus and the inside walls of the carton. ➂Make certain that the packing material cannot shift in the box or become compressed, allowing the instrument come in contact with the packing carton. Address:PASCO scientific 10101 Foothills Blvd. Roseville, CA 95747-7100 Phone:(916) 786-3800 FAX:(916) 786-3292 email:[email protected] web:www.pasco.com Credits This manual edited by: Dave Griffith Teacher’s guide written by: Eric Ayars 1 012-04630G Microwave Optics Microwave Transmitter with Power Supply Introduction           Gunn Diode Transmitter The Gunn Diode Microwave Transmitter provides 15 mW of coherent, linearly polarized microwave output at a wavelength of 2.85 cm. The unit consists of a Gunn di- ode in a 10.525 GHz resonan…

Text truncated - open the document above for the full version.

Non-Conformities FCC ID: TDQ080187 (CKC CS Ref # 2 011-91548-04) The items listed below represent requests for infor mation following review of this application for cer tification under United States (FCC) regulations. Further question may arise pending review of responses to t hese items. OK ID # Non-Conformity or Comment Submitted Respons e Respondent / Date of Response X 1 Please provide a block diagram meeting the req uirements of 2.1033(b)(5). The block diagram should indicate th e major device features, in functional block form. Frequencies us ed must be shown at each functional block. Exhibit provided Steve Miller 3/1/11 X 2 Please provide an operational description meet ing the requirements of 2.1033 (b)(4). The description should provide deta ils of the device operation augmenting the block diagram. (The FCC c larifies that a users manual is not a substitute for the operationa l description). Exhibit provided Steve Miller 3/1/11 X 3 While Steve Miller was granted authorization t o sign documents on behalf of the authorized individual, Wayne Grant, t he confidentiality letter was signed by David Stogner. Please either have Steve or Wayne sign the confidentiality letter or provide an authorization letter for David (signed by either Steve or Wayne). Updated letter provided. Steve Miller 3/1/11 x 4 Please provide an updated users manual includi ng the required users manual statements in 15.19 and 15.21 (see below). Because of the size of the product, the statement required by 15.1 9(a)(3) may be placed in the manual in accordance with 15.19(a)(5) . Updated users manual provided. Steve Miller 3/2/11 x 5 Please provide details of 15.31(e) Voltage Var iations presently missing from the report 91548-2. Clarification provided: testing performed, however no variation was observed. CKC AB 3/1/11 x 6 The ID Labels provided state the FCC ID on the label indicating the "receiver." Please clarify on which product the FC C ID is placed by providing a clarifying statement and photo of the l abel placement. Note: the FCC ID must be placed on the transmitting device, not the receiver. The ID label drawings provided are of a two part label. The transmitter part is cut out from the receiver part. The portion cut out leaves a ‘hole’ in the receiver part of the label for its meter. The FCC ID is on the transmitter part only Steve Miller 3/1/11

               !  ! "   # # # ! ! ! ##$!  %##&$#!       #'''' # # !# !!(                  ''   #&     # #& $$        $

This report c written cons e TE S CERT #803 803.05 ontains a total of ent of CKC Laborat STING 3.01, 803.02, 5, 803.06 33 pages and ma tories, Inc. Gun M Te FCC Part 1 This test rep testing perfo of ISO/IEC 1 CKC Laborato We strive t o sound, adapt our custome processes, bu ay be reproduced PASCO TEST Diode Mi Model: WA ested To The 15 Subpart C Repor Date of issu port bears th ormed herein 17025 under ories, Inc. o create long‐t tive, customer ers’ unique EM ut rather as th in full only. Partia O Scien REPORT FO crowave T A‐9314B/W e Following S C Sections 1 rt No.: 91548 ue: February 1 e accreditati o meets the tes the applicab term, trust ba r first testing MC challenges, e reason we a al reproduction m ntific OR Transmitte WA‐9801 Standards: 15.207 and 1 ‐2 1, 2011 on symbol ind st and reporti ble scope of sed relations h services. We , not as an int are in business may only be done er 15.245 dicating that ing requireme EMC testing hips by provid embrace each terruption to . with the the ents for ding h of set Page 2of 33 Report No.: 91548‐2 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 15.207 AC Conducted Emissions................................................................................................................................ 7 15.225(b)/2.1046 RF Power Output ........................................................................................................................ 15 2.1049(I) Occupied Bandwidth ................................................................................................................................ 17 15.245 Blockedge .................................................................................................................................................... 19 15.245(b)(1),(b)(3)/15.209/2.1053 Field Strength of Spurious Radiation ............................................................... 21 Supplemental Information .......................................................................................................................... 32 Measurement Uncertainty ...................................................................................................................................... 32 Emissions Test Details .............................................................................................................................................. 32 Page 3of 33 Report No.: 91548‐2 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: PASCO Scientific 10101 Foothills Blvd. Roseville, CA 95747 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Steve Miller Project Number: 91548 Customer Reference Number: 137525 DATE OF EQUIPMENT RECEIPT: February3, 2011 DATE(S) OF TESTING: February3, 2011 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4of 33 Report No.: 91548‐2 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 1120 Fulton Place Fremont, CA 94539 Site Registration & Accreditation Information Location CB # Japan Canada FCC Fremont US0082 R‐2160, C2332 & T‐228 3082B‐1 958979 Page 5of 33 Report No.: 91548‐2 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C Description Test Procedure/Method Results Conducted Emissions FCC Part 15 Subpart C Section 15.207 /ANSIC63.4 (2003)Pass RF Power Output FCC Part 15 Subpart C Section 15.245(b)/2.1046Pass Occupied Bandwidth FCC Part 15 Subpart C Section2.1049(I)Pass Blockedge FCC Part 15 Subpart C Section 15.245Pass Field Strength of Spurious Radiation FCC Part 15 Subpart C Section 15.245(b)(1)(b)(3…
