F F C C C C - - T T E E S S T T R R E E P P O O R R T T REPORT NO.: 42467/5/200F FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 2 of 16 FCC listed testlab acc. to Section 2.948 of the FCC - Rules in compliance with the requirements of ANSI C63.4 - 2001 Product : WB Radio Product Class : Communication Receiver (Super Hetrodyne) Brand Name : JENSEN Model : MR-625 Additional Model : L-40, XD-20 Importer : BEST TEAM INDUSTRIES LIMITED FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 3 of 16 TABLE OF CONTENTS 1. Cover sheet 2. Introduction 3. Table of Contents 4. Laboratory Report 5. Summary of Testresults 6. Test Equipment List 7. Radiated Emission Testprocedure (> 30MHz) 8. Radiated Emission Testprocedure (9kHz – 30MHz) 9-12. Interference Radiation (Datasheet) 13. Notes for Radiation Measurement (acc. to ANSI C63.4 - 2001) 14-15. Interference Voltage (Datasheet) 16. Notes for Voltage Measurement (acc. to ANSI C63.4 - 2001) FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 4 of 16 LABORATORY - REPORT APPLICANT: ADDRESS: BEST TEAM INDUSTRIES LIMITED Rm 1407 Wealth Commercial Centre 48 Kwong Wa Street, MongKok Kowloon, HONG KONG DATE OF SAMPLE RECEIVED: 2005-06-03 DATE OF TESTING: 2005-06-17 DESCRIPTION OF SAMPLE: Product: WB Radio Product class: Communication Receiver (Super Hetrodyne) Brand name: JENSEN Model no.: MR-625 Additional model no.: L-40, XD-20 Rating: AC/DC Adaptor, Input : AC120V 60Hz, Output : DC 6V, or DC 6V ('C' Size Battery x 4) for Radio and DC 1.5V ('AAA' Size Battery x 1) for Clock INVESTIGATIONS REQUESTED: Measurements to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B – ‘Unintentional Radiators’ RESULTS: See the attached test sheets CONCLUSIONS From the measurement data obtained, the tested sample was considered to have COMPLIED with the requirements for the relevant clauses of Federal Communications Commission Rules as specified above. _____________________________ Authorized Signature Remark: 1. Purpose of those tests in this report is to provide the applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under the FCC Equipment Authorization Program. The tests themselves are not Approval Tests. 2. The conducted emissions test (if applicable) has considered the limits in Sections 15.107 and 15.207 adopted under FCC 02-157 (ETDocket 98-80). The product may be marketed after July 11, 2005, and is not affected by the 15.37(j) transition provisions. FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 5 of 16 Summary of Test Results Interference Radiation: Test result: O.K. Test data: See attached data sheet Interference Voltage: Test result: O.K. Test data: See attached data sheet PHOTOGRAPH OF THE SAMPLE FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 6 of 16 TEST EQUIPMENT LIST Equipment Manufacturer Model Serial No. Remark Test Receiver Rohde & Schwarz ESH 3 863497/015 150KHz – 30MHz Test Receiver Rohde & Schwarz ESH 3 892580/006 9KHz – 30MHz Test Receiver Rohde & Schwarz ESVP 860688/022 25MHz – 1,000 MHz Test Receiver Rohde & Schwarz ESVP 863512/012 25MHz – 1,000 MHz Test Receiver Rohde & Schwarz ESHS30 839667/002 9KHz – 30MHz Test Receiver Rohde & Schwarz ESVS30 828525/006 25MHz – 1000MHz Spectrum Analyzer with Q. Peak Advantest R3132 140101852 9KHz – 3GHz Spectrum Analyzer with Q. Peak Tektronix 2712 B023006 0.15MHz – 1000MHz Interface for Spectrum 2712 Tektronix TD3F14A -- -- Impulse Limiter Rohde & Schwarz ESH-3-Z2 -- -- Artificial Mains Network (LISN) Schwarzbeck NSLK 8127 8127312 2 x 10A, 50Ω, 50μH 9KHz-30MHz Artificial Mains Network (LISN) Schwarzbeck NSLK 8127 8127309 2 x 10A, 50Ω, 50μH 9KHz-30MHz Antenna System Schwarzbeck BBA 9106 / UHALP 9107 -- 30MHz – 1000MHz Antenna Mast System Schwarzbeck AM9104 -- Max. 4 meters height Loop Antenna Rohde & Schwarz HFH2-Z2 871336/48 9KHz-30MHz Turntable with Controller Drehtisch DT312 -- φ120 cm FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 7 of 16 Radiated Emission Testprocedure (> 30MHz) Equipment under test (on turntable) Test receiver ESVP R & S Required test distance: 3m Antenna system Schwarzbeck BBA 9106/ UHALP 9107 FCC – Test Report No. 42467/5/200F Date: 2005-06-23 Page 8 of 16 Radiated Emission Test Procedure ( 9kHz – 30MHz) Test distance : 3 m Loop antenna HFH2-Z2 Rohde & Schwarz Equipment under test (on turntable) Test Receiver ESH3 Rohde & Schwarz 141 U1 Interference Radiation Date : 2005-06-23 According: FCC Part 15 Subpart B (15.109)Page 9 of 16 IECC Ref:42467/5/200F Model:MR-625 Test Equipment Applicant:BEST TEAM INDUSTRIES LIMITED Receiver: ESVP Rohde & Schwarz Antenna: Schwarzbeck BBA 9106 Ser.Nr.:1 and UHALP 9107 Oper. Mode:FM Mode InterFreq:10.7 MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction - factor (dB) Testresult dBμV/m Limit dB(μV/m) 89.8100.5120H10.430.443.5 201.0218H16.534.543.5 301.53<16H16.3<32.346.0 402.04<16H18.3<34.346.0 502.55<16H19.7<35.746.0 603.06<16H20.9<36.946.0 703.57<16H22.4<38.446.0 804.08<16H23.8<39.846.0 904.59<16H25.1<41.146.0 98.3109.0120H11.731.743.5 218.0218H17.035.046.0 327.03<16H16.8<32.846.0 436.04<16H18.8<34.846.0 545.05<16H20.2<36.246.0 654.06<16H21.7<37.746.0 763.07<16H23.2<39.246.0 872.08<16H24.7<40.746.0 981.09<16H26.2<42.254.0 108.0118.7120H12.732.743.5 237.4218H17.435.446.0 356.13<16H17.5<33.546.0 474.84<16H19.4<35.446.0 593.55<16H20.8<36.846.0 712.26<16H22.6<38.646.0 830.97<16H24.1<40.146.0 949.68<16H25.8<41.846.0 The measurements indicate that the test unit meets the FCC requirements. 141 U1 Interference Radiation Date : 2005-06-23 According: FCC Part 15 Subpart B (15.109)Page 10 of 16 IECC Ref:42467/5/200F Model:MR-625 Test Equipment Applicant:BEST TEAM INDUSTRIES LIMITED Receiver: ESVP Rohde & Schwarz Antenna: Schwarzbeck BBA 9106 Ser.Nr.:1 and UHALP 9107 Oper. Mode:FM Mode InterFreq:10.7 MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics …
