Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 2 | 15C | 5.75 GHz - 5.79 GHz | 79.00 mW |
Modular TypeLimited Single Modular ApprovalConfidentialityLong Term Grant NotesPower listed is the maximum peak (5745-5825 MHz) and maximum combined peak (5755-5795 MHz) conducted output power as indicated in the filing. Approval is limited to OEM installation only, and the host in which this module is integrated should provide stable 3.3 VDC power to this module through regulator circuit. This device and its antennas must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. The only antennas approved for use with this module are those documented in the filing, and must be installed in the manner specified therein. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must
not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual
instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5755 to 5795 MHz. This device must be professionally installed.
