Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 2 | 15C | 5.75 GHz - 5.79 GHz | 16.00 mW |
Modular TypeLimited Single Modular ApprovalConfidentialityLong Term Grant NotesOutput Power listed is peak conducted, either on a single port or the maximum combined on all ports as indicated in the filing. Approval is limited to OEM installation only, and the host in which this module is integrated should provide stable 3.3 VDC power to this module through regulator circuit. This device must be professionally installed.
The only antennas approved for use with this module are those documented in the filing, and must be installed in the manner specified therein. This device approved for use in products which operate as a mobile transmitting device with respect to Rule Part 2.1091. This modular device and its antenna must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with the FCC multitransmitter policy. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. OEM integrators must be provided with antenna installation instructions. Compliance of this module in its final configuration is the responsibility of Grantee. Separate approval is required for portable configurations with respect to Rule Part 2.1093. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 3T3R Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5755 to 5795 MHz.
