TLBTFY3094TRC Toy

LEDS Terminal D1,D2,D3 and Q1 switching for D4 MIC Amplifier Q2,Q3 Voltage reset UTC8130-5 TX IC (W55RFS27T1B) Y3094 Transmitter block diagram (TX) JETTA COMPANY LIMITED Y1 49.860MHZ Micro controller (W588S020) ANT 49.860MHZ BATTERY (DC6V) Control keys S1~S11 S P E A K E R Amplifier Q4 Control Signal Terminal D7,D8,D9 mic X X Tx IC power switching Q5,R7 Voltage drop D10,D5

FCC ID: TLBTFY3094T Ophoto1 Ophoto2 FCC ID: TLBTFY3094T Ophoto3 Ophoto4 FCC ID: TLBTFY3094T Ophoto5 Ophoto6 FCC ID: TLBTFY3094T Ophoto7

FCC ID:TLBTFY3094T THE FIRST YEARS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label siz e76mm(L)x13mm(W) label will be engraved on the samples

FCC ID: TLBTFY3094T Iphoto1 Iphoto2 FCC ID: TLBTFY3094T Iphoto3 Iphoto4 FCC ID: TLBTFY3094T Iphoto5 Iphoto6 FCC ID: TLBTFY3094T Iphoto7 Iphoto8

FCC ID: TLBTFY3094T Technical Description : The brief circuit description is listed as follows : - W55RFS27T1B and associated circuit act as 49.860 MHz Oscillator, Encoder and Modulator. - W588S020 and associated circuit act as Microcontroller. - UTC8130-5 and associated circuit act as Voltage Reset. - Q2, Q3 and associated circuit act as Amplifier for the Microphone. - Q4 and associated circuit act as Amplifier for the Speaker. - D1 ~ D4 act as LEDs. - Q5 and associated circuit act as Power Supply Control for W55RFS27T1B. - S1 ~S11 act as Control Keys. Antenna Used : A permanent wire antenna has been used.

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • The evaluation data of the report will be kept for 3 years from the date of issuance. FCC ID : TLBTFY3094T Jetta Company Limited Application For Certification (FCC ID: TLBTFY3094T) Transmitter Sample Description : Gentle Vibrations 3 In 1 Crib Soother Model : Y3094 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-2004] 05181871 WL/at September 8, 2005 INTERTEK TESTING SERVICES FCC ID: TLBTFY3094T i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: TLBTFY3094T ii MEASUREMENT/TECHNICAL REPORT Jetta Company Limited - MODEL: Y3094 FCC ID: TLBTFY3094T September 8, 2005 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-1- 2004 Edition] provision. Report prepared by: Wilbur Ng Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone: 852-2173-8502 Fax: 852-2742-9149 INTERTEK TESTING SERVICES FCC ID: TLBTFY3094T iii Table of Contents 1.0 General Description................................................................................................ 2 1.1 Product Description ............................................................................................. 2 1.2 Related Submittal(s) Grants................................................................................. 2 1.3 Test Methodology................................................................................................ 3 1.4 Test Facility ......................................................................................................... 3 2.0 System Test Configuration..................................................................................... 5 2.1 Justification.......................................................................................................... 5 2.2 EUT Exercising Software ..................................................................................... 5 2.3 Special Accessories............................................................................................. 5 2.4 Equipment Modification ....................................................................................... 6 2.5 Support Equipment List and Description .............................................................. 6 3.0 Emission Results .................................................................................................... 8 3.1 Field Strength Calculation .................................................................................... 9 3.1 Field Strength Calculation (cont’d) ..................................................................... 10 3.2 Radiated Emission Configuration Photograph .................................................... 11 3.3 Radiated Emission Data .................................................................................... 12 4.0 Equipment Photographs ....................................................................................... 15 5.0 Product Labelling .................................................................................................. 17 6.0 Technical Specifications....................................................................................... 19 7.0 Instruction Manual ................................................................................................ 21 8.0 Miscellaneous Information................................................................................... 23 8.1 Measured Bandwidth......................................................................................... 24 8.2 Discussion of Pulse Desensitization................................................................... 25 8.3 Calculation of Average Factor ............................................................................ 26 8.4 Emission Test Procedures ................................................................................ 27 8.4 Emission Test Procedures (Cont’d).................................................................... 28 INTERTEK TESTING SERVICES FCC ID: TLBTFY3094T iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf Test Report Average Factor af.pdf INTERTEK TESTING SERVICES FCC ID: TLBTFY3094T 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: TLBTFY3094T 2 1.0 General Description 1.1 Product Description The equipment under test (EUT) is a transmitter for a RC Toy Vibrator operating at 49.860 MHz which is controlled by a crystal. The EUT is…
