TN9-SG3000Self-Guard

Micro-sized, Portable, Wireless, Covert DVR Professional Version: SG-1000/ SG-2000/ SG-3000 This product is registered with electromagnetic wave standards and can be used for any place including residential area. Thank you for purchasing this Self-Guard product. - Before using it, be sure to read the precautions contained in the User’s Guide. - Keep the User’s Guide in a safe place for future reference. - For the most up-to date information about this product, visit our official website at http://www.STARNEXinternational.com/ . Unpacking Check to make sure that all of the items shown below are included with your Self- Guard. If something is missing, contact your dealer as soon as possible. (SG-300/SG-310) 3 – Contents – INTRODUCTION ----------------------------------------------------------------------------------- 6 1. Precautions --------------------------------------------------------------------------------------- 6 2. Features ------------------------------------------------------------------------------------------- 11 3. Specifications and Comparison of each Model ------------------------------------------ 14 4. Applications --------------------------------------------------------------------------------------- 16 QUICK START GUIDE -------------------------------------------------------------------------- 17 1. Charging the Battery ---------------------------------------------------------------------------- 17 2. Turning the Self-Guard On and Off --------------------------------------------------------- 17 3. To Configure Clock Settings ------------------------------------------------------------------ 17 4. To Record a Moving Image ------------------------------------------------------------------- 18 5. To Playback a Moving Image ---------------------------------------------------------------- 19 6. BLUETOOTH (SG-3000 Only) ----------------------------------------------------------------- 22 GETTING READY -------------------------------------------------------------------------------- 24 1. Self-Guard -------------------------------------------------------------------------------------- 24 2. Docking Station -------------------------------------------------------------------------------- 29 GENERAL GUIDE -------------------------------------------------------------------------------- 31 I. Functions ------------------------------------------------------------------------------------------ 31 I-1. RECORD ------------------------------------------------------------------------------------ 31 I-2. CAMERA ------------------------------------------------------------------------------------ 33 I-3. SEARCH ------------------------------------------------------------------------------------- 34 I-4. OPTION -------------------------------------------------------------------------------------- 40 4-1. Camera Set ------------------------------------------------------------------------------ 41 4-2. Record Set ------------------------------------------------------------------------------- 45 4-3. Search Set ------------------------------------------------------------------------------- 52 4-4. Date/Time Set ------------------------------------------------------------------------- 55 4-5. Remote Set ----------------------------------------------------------------------------- 56 4 4-6. Sensor Set ------------------------------------------------------------------------------- 63 4-7. USB Set ---------------------------------------------------------------------------------- 65 4-8. MEMORY Set --------------------------------------------------------------------------- 67 4-9.Others -------------------------------------------------------------------------------------- 69 4-9-1. Password Set --------------------------------------------------------------------- 70 4-9-2. EXT MON Set ------------------------------------------------------------------- 72 4-9-3. Power Set ------------------------------------------------------------------------- 72 4-9-4. Alarm Set -------------------------------------------------------------------------- 77 4-9-5. SG-921 Set ----------------------------------------------------------------------- 81 4-9-6. Language ------------------------------------------------------------------------- 81 4-9-7. Upgrade --------------------------------------------------------------------------- 81 4-9-8. Default Set ------------------------------------------------------------------------- 82 4-9-9. SG Name -------------------------------------------------------------------------- 82 I-5. TRANSMIT ----------------------------------------------------------------------------------- 84 I-6. BLUETOOTH (SG-3000 Only) ------------------------------------------------------------- 85 II. Remote Access and Data Search/Playback Program --------------------------------- 90 II-1. How to Install ------------------------------------------------------------------------------- 91 II-2. Remote Monitor and Save -------------------------------------------------------------- 97 II-3. Remote File Playback -------------------------------------------------------------------- 98 II-4. Remote File Copy ------------------------------------------------------------------------- 99 II-5. File Search and Playback ------------------------------------------------------------- 100 II-6. Other Functions --------------------------------------------------------------------------- 101 III. Others ----------------------------------------------------------------------------------------------- 106 III-1. Button Camera ---------------------------------------------------------------------------- 106 Trouble Shooting Guide ---------------------------------------------------------------------- 107 (*SG is short for Self-Guard) 5 << Important Notice >> 9 The contents of this manual are subject to change without notice. 9 STARNEX CO., LTD. has the responsibilities as the manufacturer of Self- Guard to tell to each distributor th…

Text truncated - open the document above for the full version.

<Bluetooth Module>

STARNEX CO., LTD. #804, E&C Venture Dream Tower III, Guro-Sam-Dong, Guro-Gu, Seoul, Korea 152-719 TEL: +82-2-837-9700, FAX: +82-2-837-9050 http://www.starnex.co.kr Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, STARNEX CO., LTD. requests confidentiality for the following products: FCC ID Number Product Title / Model TN9-SG3000 Self-Guard / SG-3000 For the product stated above, we request that the following information be held confidential: 1) Schematic diagrams 2) Bill of materials (Part List) No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain STARNEX CO., LTD. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, Mingee, Lee / Principal Research Engineer

SK TECH CO., LTD. Page 1 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 External Photographs of EUT <Photograph 1: All of the items including Self-Guard View> SK TECH CO., LTD. Page 2 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 2: Front View> <Photograph 3: Rear View> SK TECH CO., LTD. Page 3 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 4: External Top View> <Photograph 5: External Bottom View > SK TECH CO., LTD. Page 4 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 6: View of Battery Separation> <Photograph 7: View of AC Adaptor> SK TECH CO., LTD. Page 5 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 8: View of Docking Station> SK TECH CO., LTD. Page 6 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 9: View of External Antenna>

FCC ID Label Location & Sample LABEL LOCATION: Label is attached on the REAR of the product LABEL Drawing: LABEL LOCATION Self-Guard STARNEX CO., LTD. FCC ID : TN9-SG3000 Model No.: SG-3000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. “ 당해 무선설비는 운용 중 전파혼신 가능성이 있음” Made in Korea 62 mm 25 mm 인증번호: STA-SG3000

SK TECH CO., LTD. Page 1 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 Internal Photographs of EUT <Photograph 1: Cover Removed> SK TECH CO., LTD. Page 2 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 2: Main Board View> SK TECH CO., LTD. Page 3 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 3: RF Board View> SK TECH CO., LTD. Page 4 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 4: Camera Module View> SK TECH CO., LTD. Page 5 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 5: LCD Module View> SK TECH CO., LTD. Page 6 of 6 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Photograph 6: Docking Station View>

Antenna description Model Name ALA131C3 Manufacturer AMOTECH CO., LTD. Antenna Location Internal (Chip Antenna) Max. Gain -2.29 dBi Dimension (L × W × D) 11.0mm ×3.0mm × 1.2mm Picture of the antenna Radiation Pattern Antenna description Model Name HW-T2450D4-RSMA (Reverse SMA Type) Manufacturer Hanwool Technology Antenna Location External (Dipole Antenna) Max. Gain 2.95 dBi Dimension (L) 195mm Picture of the antenna Radiation Pattern

Operational Description This product, SG-3000, is a Bluetooth device. The product operates in 2400 to 2483.5 MHz band. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. The control signals and data in the Bluetooth Module (Model No.:HBH1X1M) are modulated and processed and then pass the PA in it. They will be transmitted from External Antenna or Internal Antenna (Chip Antenna) through the Switch (U2: MASWSS0115) to another Bluetooth device. The RF signal from other Bluetooth devices is received via Antennas. And they go through internal Switch (U2) into the Bluetooth Module. The power settings and crystal trim are stored in internal flash. The product is powered from a Li-ion battery and uses an Dipole Antenna or Chip Antenna selectively according to the usage. No external ground is required. Specifications SECTION DESCRIPTION REMARKS Internal Storage Device Built-In Flash memory: 128 MB (up to 1 GB) Memory Expansion Flash Memory Card: 128MB – 1GB RS-MMC Extensive Storage Device & Data Backup USB Memory Stick, USB HDD Built-In 1 CCD Color (up to 2EA) 307,200 pixels Camera External NTSC/PAL (4EA) Recording Resolution NTSC/PALup to 640 x 480 pixels Display Speed NTSC/PAL25 fps Recording Speed NTSC/PAL12 fps @240 x 240 pixels Light Sensitivity (Built-In Color Camera) 1 Lux [email protected] CCD Audio Input/Output 2 Built-In Microphones and 1 Speaker, 1 Audio Input Audio Detection TV(A/V) Output Built-In Color LCD, Monitor(NTSC/PAL) 1.8 Inch 128x160 pixels Search(Playback) Date/Time, Motion, Sensor Compression Method Optimized Algorithm for Security Storage Capacity High Quality (1-2 days) Medium Quality (2-5 days) Low Quality (5-10 days) 128MB, @1fps, 240x240pixels (Indoor Use) Display Date/Time/Frame Lens (Built-In Color Camera) Angle(56 Degrees), Unlimited Focus Pin-Hole Lens Motion Detection Digital Image Processing, External Signal Input(PIR Sensor Etc.) Remote Access LAN Wireless Communication Bluetooth Source of Power Rechargeable Li- Polymer Battery (3.7VDC, 1400mAh), Adaptor (5V DC, 2A) Recording Time (Battery) Normal Mode (4.5 hours) Power Saving Mode (up to 24 hours) Ultra Power Saving Mode (up to 3 days) Dimensions: 85(W) × 55(H) ×22(D) mm Weight(Including Battery) : 116g(4.09oz) 3.34(W) × 2.16(H) × 0.86(D) inch Humidity: Under 80% Operating Temperature: -10 °C to + 50 °C (14°F to 122 °F)

SK TECH CO., LTD. Page 1 of 43 SKTTRT-070327-009 FCC ID: TN9-SG3000 Certificate of Compliance Test Report No.: SKTTRT-070327-009 KOLAS No.: KT191 Applicant: STARNEX CO., LTD. Applicant Address: #804, E&C Venture Dream Tower III, Guro-Sam-Dong, Guro-Gu, Seoul, Korea 152-719 Manufacturer: STARNEX CO., LTD. Manufacturer Address: #804, E&C Venture Dream Tower III, Guro-Sam-Dong, Guro-Gu, Seoul, Korea 152-719 Device Under Test: Self-Guard FCC ID: TN9-SG3000 Model Name: SG-3000, SG-300, SG-310 Brand/Trade Name: - Receipt No.: SKTEU07-0025 Date of receipt: Jan. 4, 2007 Date of Issue: Mar. 27, 2007 Location of Testing: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Procedure: ANSI C63.4, FCC Public Notice DA 00-705 (March 2000) Test Specification: 47CFR, Part 15 Rules FCC Equipment Class: DSS - Part 15 Spread Spectrum Transmitter Test Result: The above-mentioned device has been tested and passed. Tested & Reported by: Chang-Min, Moon 2007. 03. 27 Approved by: Jong-Soo, Yoon 2007. 03. 27 Signature Date Signature Date Other Aspects: - Abbreviations: · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ ¾ This test report is not permitted to copy partly and entirely without our permission. ¾ This test result is dependent on only equipment to be used. ¾ This test result is based on a single evaluation of submitted samples of the above mentioned. ¾ This test report is the accredited testing items by Korea Laboratory Accreditation Scheme, which signed the ILAC-MRA. SK TECH CO., LTD. Page 2 of 43 SKTTRT-070327-009 FCC ID: TN9-SG3000 >> CONTENTS << 1. GENERAL ··························································································································· 4 2. TEST SITE ··························································································································· 4 2.1 Location ······················································································································ 4 2.2 List of Test and Measurement Instruments ································································· 5 2.3 Test Date ····················································································································· 5 2.4 Test Environment ········································································································ 5 3. DESCRIPTION OF THE EQUIPMENT UNDER TEST ·············································· 6 3.1 Rating and Physical Characteristics ··········································································· 6 3.2 Equipment Modifications ··························································································· 6 3.3 Submitted Documents ································································································· 6 4. MEASUREMENT CONDITIONS ··················································································· 7 4.1 Description of test configuration ················································································ 7 4.2 List of Peripherals ·······································································································7 4.3 Type of Used Cables ··································································································· 8 4.4 Uncertainty ················································································································· 8 5. TEST AND MEASUREMENTS ························································································ 9 5.1 ANTENNA REQUIREMENT ··················································································· 9 5.1.1 Regulation ············································································································ 9 5.1.2 Result ···················································································································9 5.2 MAXIMUM PEAK OUTPUT POWER ································································ 10 5.2.1 Regulation ·········································································································· 10 5.2.2 Test Procedure ··································································································· 10 5.2.3 Test Results ········································································································ 10 Table 1: Measured values of the Maximum Peak Output Power (Conducted) ································· 10 Figure 1: Plot of the Maximum Peak Output Power (Conducted)······················································· 11 5.3 CARRIER FREQUENCY SEPARATION ···························································· 13 5.3.1 Regulation ·········································································································· 13 5.3.2 Test Procedure ··································································································· 13 5.3.3 Test Results ········································································································ 13 Table 2: Measured values of the Carrier Frequency Separation (Conducted) ································· 13 Figure 2: Plot of the Carrier Frequency Separation (Conducted) ........................................................ 14 5.4 20dB CHANNEL BANDWIDTH ············································································ 16 5.4.1 Regulation ·········································································································· 16 5.4.2 Test Procedure ··································································································· 16 5.4.3 Test Results ········································································································ 16 Table 3: Measured values of the 20dB Channel Bandwidth (Conducted)········································ 16 Figure 3: Plot of the 20dB Channel Bandwidth (Con…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 3 SKTTRT-070327-009 FCC ID: TN9-SG3000 Test set up photos <View of Conducted RF power measurement > SK TECH CO., LTD. Page 2 of 3 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Radiated Emissions - Front View> External Antenna <Radiated Emissions - Rear View> External Antenna SK TECH CO., LTD. Page 3 of 3 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Radiated Emissions - Front View> Internal Antenna <Radiated Emissions - Rear View> Internal Antenna SK TECH CO., LTD. Page 4 of 3 SKTTRT-070327-009 FCC ID: TN9-SG3000 <Conducted Emissions - Front View> <Conducted Emissions - Rear View>
