TOR-C-65Access Point / Sensor

Industry Canada Statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme a la norme CNR-210 d’Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositifne doit pas produire de brouillage prejudiciable, et (2) ce dispositif doit ac- cepter tout brouillage re , y compris un brouillage susceptible de provoquer un fonctionne- ment indesirable. Caution: (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) high-power radars are allocated as primary users (i.e. priority users) of the bands 5250- 5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or dam- age to LE-LAN devices. Avertisement: (i)les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont reserves uniquement pour une utilisation a l’interieur afin de reduire les risques de brouillage prejudiciable aux systemes de satellites mobiles utilisant les memes canaux; (ii)De plus, les utilisateurs devraient aussi etre avises que les utilisateurs de radars de haute puissance sont designes utilisateurs principaux (c.-a-d., qu’ils ont la priorite) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouil- lage et/ou des dommages aux dispositifs LAN-EL. FOR MOBILE DEVICE USAGE (>20cm/low power) Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. Declaration d’exposition aux radiations: Cet equipement est conforme aux limites d’exposition aux rayonnements IC etablies pour un environnement non controle. Cet equipement doit @tre installe et utilise avec un mini- mum de 20 cm de distance entre la source de rayonnement et votre cmps. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera- tion. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reaso- able protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in ac- cordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the re- ceiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsi- ble for compliance could void the user’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other an- tenna or transmitter. For operation within 5.15 ~ 5.25GHz / 5.47 ~5.725GHz frequency range, it is restricted to indoor environment. The band from 5600-5650MHz will be disabled by the software during the manufacturing and cannot be changed by the end user. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. FOR MOBILE DEVICE USAGE (>20cm/low power) Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. FOR COUNTRY CODE SELECTION USAGE (WLAN DEVICES) Note: The country code selection is for non-US models only and is not available to all US models. Per FCC regulations, all Wi-Fi products marketed in the US must be fixed to US operation channels only.

C-65 AirTight Access Point / Sensor Quick Start Guide Package Contents You should have received the following components in your C-65 package. Wall-Mount Accessories C-65 Ceiling-Mount Accessories Ceiling Mount: AirTight logo facing the floor. Wall Mount: AirTight logo facing away from the wall. Mounting the C-65 Attach the ceiling mount accessories to the device and slide it on to the T-rail mounting hardware affixed to the ceiling. Affix the mounting screws to the wall and hook the device on to the screws. Getting the C-65 Online Step 1: Power up If using PoE, plug one end of the Ethernet cable into the PoE switch or injector and plug the other end into the Ethernet + PoE port (LAN) on the C-65. Make sure the PoE source you are using is turned ON. OR As an alternative to PoE, insert the power adapter plug into an AC power outlet and the other end into the power input port on the C-65. Warning: If not using PoE, make sure you use only an AC power adapter supported by the C-65 access point (AP). Step 2: Connect to the network If you are using PoE, then the C-65 should already be connected to your network. If you are not using PoE, then plug one end of the Ethernet cable into an Ethernet jack on your network and the other end into the Ethernet port (LAN) on the C-65. Step 3: Check the LED status Wait for a few minutes till the Power LED turns solid ORANGE and Ethernet (LAN) turns solid GREEN, which indicates that the C-65 is online and operational. Power 2.4 GHz 5.0 GHz LAN Troubleshooting After the C-65 is powered ON and connected to Ethernet, if the status of LAN (Ethernet) is not Solid Green, it indicates that the AP is not able to function normally. The following guidelines may help you to quickly diagnose and fix the problem. LED Status What does it mean? PowerEthernet (LAN)2.4 GHz5.0 GHz OffOffOffOff Not powered on or it is in the process of starting up Solid OrangeOffAnyAnyNo active Ethernet link 1 Solid OrangeFast Blink GreenAnyAnyDid not receive a valid IP address via DHCP 2 Solid OrangeSlow Blink GreenAnyAny Unable to connect to the AirTight Cloud Services or AirTight Server 3 1. Make sure that the Ethernet cable is correctly plugged into the LAN port on the C-65 and the other end of the cable is plugged into an Ethernet jack or a port on a switch that is turned ON. 2. If the C-65 did not receive a valid IP address from the DHCP server, make sure that a DHCP server is ON and available on the VLAN/subnet to which the AP is connected. If the AP still fails to get a valid IP address, you can reboot it once to see if that resolves the problem. 3. If you are using AirTight Cloud Services, make sure that Internet connectivity is available from the VLAN/subnet to which the AP is connected. Check if the required ports for AP and Server communication – UDP 3851 and default HTTP (TCP port 80) – are open on the Firewall. If you are using a Proxy, Web accelerator or URL content filtering, make sure the settings allow communication between the AP and AirTight Cloud Services. After following these guidelines, if you are still unable to resolve the problem, contact the local AirTight Sales Engineer or 24/7 AirTight Technical Support. Tel: +1 (650) 641 0027 Email: [email protected] AirTight Networks, Inc. 339 N. Bernardo Avenue #200, Mountain View, CA 94043 T +1.877.424.7844 T 650.961.1111 F 650.961.1169 www.airtightnetworks.com [email protected] AirTight C-65 Quick Setup Guide [Doc ID: ATN-QS-0615-001-00-EN] © 2014 AirTight Networks, Inc. All rights reserved. AirTight Networks and the AirTight Networks logo are trademarks, and AirTight is a registered trademark of AirTight Networks, Inc. All other trademarks mentioned herein are properties of their respective owners. Specifications are subject to change without notice. Comprehensive Cloud-Managed Wi-Fi

Report No.: 140717E01 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 140717E01 Page 2 Model No.: MU18-R120150-A1 Report No.: 140717E01 Page 3 Report No.: 140717E01 Page 4

(Fig.1) FCC ID: TOR-C-65 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Back Side: Label Here 246000001098A UL LABEL EAP1018A1-FLF-FW Carry AUG07'14 Lin AUG07'14 01 59.60 mm 29.60 mm 59.60 mm 29.60 mm 5.08 mm 5.08 mm This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2460000010XXA R01 XX XX Made in XXX FCC ID:XXXX IC:XXXXXXX Protected by one or more U.S. and international patents. Please see www.airtightnetworks.com/patents for more details. 2460000010XXA R01 XX XX Made in XXX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID:XXXX IC:XXXXXXX test-1test-2 246000001098A R01 XX XX Made in XXX 自印 區塊 騎縫線 C-65 此條碼請確 認為可讀取 CAN ICES-3(B)/NMB-3(B) Model:C-65

Report No.: 140717E01 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 140717E01 Page 2 Report No.: 140717E01 Page 3 Report No.: 140717E01 Page 4 Report No.: 140717E01 Page 5 Report No.: 140717E01 Page 6

Report No.: SA140717E01 1 of 10 Report Format Version 5.0.1 RF EXPOSURE REPORT REPORT NO.: SA140717E01 MODEL NO.: C-65 FCC ID: TOR-C-65 RECEIVED: July 17, 2014 TESTED: Aug. 08, 2014 ISSUED: Aug. 25, 2014 APPLICANT: AirTight Networks Inc. ADDRESS: 339 N Bernardo Ave, Mountain View, CA 94043, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA140717E01 2 of 10 Report Format Version 5.0.1 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 7 Report No.: SA140717E01 3 of 10 Report Format Version 5.0.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140717E01 Original release Aug. 25, 2014 Report No.: SA140717E01 5 of 10 Report Format Version 5.0.1 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA140717E01 6 of 10 Report Format Version 5.0.1 5. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: For 2.4G WLAN used Ant. No. Transmitter Circuit Brand Part No. Antenna Gain(dBi) <including cable loss> Frequency range (MHz ~ MHz) Antenna Type Connecter Type Cable Length (mm) 1 Chain (0) LYNwave ALA140-05102A-0000004.42 2412~2483 PCB-DipoleIPEX 85 2 Chain (1) ALA140-05102A-0000014.39 170 For 5G WLAN used Ant. No. Transmitter Circuit Brand Part No. Antenna Gain(dBi) <including cable loss> Frequency range (MHz ~ MHz) Antenna Type Connecter Type Cable Length (mm) 1 Chain (0) LYNwave ALA140-091025-000000 4.39 5150~5825 PCB-DipoleIPEX 70 2 Chain (1) ALA140-091025-000001 4.84 160 Report No.: SA140717E01 7 of 10 Report Format Version 5.0.1 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247 (2.4GHz) 802.11b FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 292.634 7.42 20 0.32141 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 7.42dBi. 802.11g FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 347.353 7.42 20 0.38150 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 7.42dBi. 802.11n (HT20) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 227.854 7.42 20 0.25026 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 7.42dBi. 802.11n (HT40) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2422 - 2452 109.794 7.42 20 0.12059 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 7.42dBi. Report No.: SA140717E01 8 of 10 Report Format Version 5.0.1 For 15.247 (5GHz) 802.11a FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/…

Text truncated - open the document above for the full version.

Report No.: RF140717E01 1 of 111 Report Format Version 5.2.1 FCC TEST REPORT (15.247) REPORT NO.: RF140717E01 MODEL NO.: C-65 FCC ID: TOR-C-65 RECEIVED: July 17, 2014 TESTED: July 25 to Aug. 08, 2014 ISSUED: Aug. 25, 2014 APPLICANT: AirTight Networks Inc. ADDRESS: 339 N Bernardo Ave, Mountain View, CA 94043, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140717E01 2 of 111 Report Format Version 5.2.1 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 9 3. GENERAL INFORMATION ................................................................................... 10 3.1 GENERAL DESCRIPTION OF EUT ..................................................................... 10 3.2 DESCRIPTION OF TEST MODES ....................................................................... 13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 17 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 18 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 20 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 21 4. TEST TYPES AND RESULTS (FOR 2.4GHz, 2.400 ~ 2.4835GHz BAND) ........... 23 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 23 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 23 4.1.2 TEST INSTRUMENTS .......................................................................................... 23 4.1.3 TEST PROCEDURES .......................................................................................... 24 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 24 4.1.5 TEST SETUP ....................................................................................................... 24 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 25 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 26 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 28 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 30 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 30 4.2.2 TEST INSTRUMENTS .......................................................................................... 31 4.2.3 TEST PROCEDURES .......................................................................................... 32 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 32 4.2.5 TEST SETUP ....................................................................................................... 33 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 33 4.2.7 TEST RESULTS ................................................................................................... 34 4.3 6DB BANDWIDTH MEASUREMENT ................................................................... 47 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT ................................................. 47 4.3.2 TEST INSTRUMENTS .......................................................................................... 47 4.3.3 TEST PROCEDURE ............................................................................................. 47 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 47 4.3.5 TEST SETUP ..................................…

Text truncated - open the document above for the full version.

Report No.: RF140717E01-1 1 of 65 Report Format Version 5.2.1 FCC TEST REPORT (15.407) REPORT NO.: RF140717E01-1 MODEL NO.: C-65 FCC ID: TOR-C-65 RECEIVED: July 17, 2014 TESTED: July 28 to Aug. 08, 2014 ISSUED: Aug. 25, 2014 APPLICANT: AirTight Networks Inc. ADDRESS: 339 N Bernardo Ave, Mountain View, CA 94043, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140717E01-1 2 of 65 Report Format Version 5.2.1 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 19 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 20 4. TEST TYPES AND RESULTS .............................................................................. 22 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 22 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 22 4.1.2 TEST INSTRUMENTS .......................................................................................... 22 4.1.3 TEST PROCEDURES .......................................................................................... 23 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 23 4.1.5 TEST SETUP ....................................................................................................... 23 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 24 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 25 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 27 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 29 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 29 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 29 4.2.3 TEST INSTRUMENTS .......................................................................................... 30 4.2.4 TEST PROCEDURES .......................................................................................... 31 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 31 4.2.6 TEST SETUP ....................................................................................................... 32 4.2.7 EUT OPERATING CONDITION ............................................................................ 32 4.2.8 TEST RESULTS ................................................................................................... 33 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 43 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 43 4.3.2 TEST INSTRUMENTS .......................................................................................... 44 4.3.3 TEST PROCEDURE ............................................................................................. 44 4.3.4 DEVIATION FROM TEST STANDARD ...........…

Text truncated - open the document above for the full version.

Report No.: 140717E01 1 of 4 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Mode 1) Report No.: 140717E01 2 of 4 CONDUCTED EMISSION TEST (Mode 2) Report No.: 140717E01 3 of 4 RADIATED EMISSION TEST (Below 1GHz) Report No.: 140717E01 4 of 4 RADIATED EMISSION TEST (Above 1GHz)
