TQ5-MA132Vehicle Audio System

Compass Systems, Inc.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Jan 03, 2023
Application Purpose: Original Equipment
Date of Application: Jan 03, 2023
Equipment Note: Vehicle Audio System
Frequency Range: 2402.00000000 - 2480.00000000
Company: Compass Systems, Inc.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

对折基准线 Owner’s Manual for Users USB/AUX/BLUETOOTH WITH FM/AM RADIO Any Abnormal Operation or interference of frequency, the radio may get caused malfunction. If so, RESET the radio by press and hold both MODE and 5DIR- buttons about 5seconds simultaneously. !!!!!!!!!! ATTENTION !!!!!!!!!! 1 Table of Contents Table of Contents ------------------------------------------------------------------------------- 1 Bluetooth Summary --------------------------------------------------------------------------- 2 Identification of Controls and Functions ------------------------------------------- 3 Operating Instructions -------------------------------------------------------------------- 4-5 Radio Section Operation -------------------------------------------------------------------- 6 USB Operation ------------------------------------------------------------------------------- 7~8 AUX Input -------------------------------------------------------------------------------------------- 9 Bluetooth Operation -------------------------------------------------------------------- 10-13 Reset Function and Precautions ----------------------------------------------------- 14 Specifications ---------------------------------------------------------------------------------- 15 Before operating the unit, please read this manual thoroughly and retain it for future reference. 2 Bluetooth Summary The BLUETOOTH features are subject to Bluetooth Ver. 5.0 The Bluetooth technology is a wireless connection with a short range. That is, the cellular phone must be in between 30cm to 1 meter close to the car audio system (in the vehicle). The integrated Bluetooth module in your audio unit allows the hands-free use of a phone via a Bluetooth connection. The cellular phone can remain in the bag or the glove compartment, while you have both hands free for steering. The Bluetooth feature allows for: - Automatic phone connection - Caller ID display - Re-dialing for last call number - Call transfer & pairing - DSP Echo / Noise cancelling - A2DP (Audio streaming) - AVRCP (Music play control via phone) - Battery level indicator (phone dependent) - Network level indicator (phone dependent) - Microphone included (Built in to the Audio Unit) IMPORTANT NOTES: Keeping well your phone connection with Bluetooth technology, followings are recommended. - Talking better close to the Audio Unit. - Off road driving or opening window, higher speed (over 30Km) should be heard loud noise whilst phone conversation. - Talking the call through out the speaker phone with other hand free kits must be heard loud noise or unclear talks. - Air conditioner or heater may cause interruption noise to be heard. - Cell phone are not too close to the audio unit to avoid GSM noise caused. (No closer than 30CM to the radio unit). - Extreme weather may cause not to work the Bluetooth function in the audio unit. Identification of Controls and Functions 1. Power ON/OFF, Volume UP/DOWN button 2. Manual UP/DOWN Tuning, File Search, SEL button 3. MODE button, Audio Mute button 4. Call & Pair button 5. Call End button 6. Station Preset 1, Display button 7. Station Preset 2 8. Station Preset 3, Repeat Play button 9. Station Preset 4, Random Play button 10. Station Preset 5, Directory Down button 11. Station Preset 6, Directory Up button 12. BSM (Best Station Memory) button, Scan Play button 13. Auto Tune Up, Seek Up button 14. Auto Tune Down, Track Down button 15. USB Connector 16. AUX IN Jack 17. MIC Hole 3 1 12 3 2 4 5 14 13 7 8 9 11 10 15 616 17 20 Operating Instructions 1-1. Power On/Off button Press Power button (1) to turn the unit on or off. 1-2. Volume Up/Down Control knob Turn VOL knob (1) right to increase the volume level; Turn VOL knob (1) left to decrease the volume. After 5 seconds the display will return to the previous display mode. 1-3. System Setting Press and hold the VOL knob (1) for longer than 2 seconds to enter system settings. Then each time you press the knob, LCD displays as below: Note: If there is no operation within 5s, it will auto memory the last displayed setting. 1.3.1 Initial Volume Level Set Up I-VOL is the volume level the unit will play at when next turned on. To adjust I-VOL level, press and hold VOL button (1) for longer than 2 seconds. The current I-VOL level will show on the display panel. Then turn button (1) right or left to adjust the I-VOL level. 1.3.2 CLOCK ON/OFF Control, CLOCK Adjustment The CLOCK was default at off status. To turn CLOCK ON, short press VOL again while it displaying I-VOL, it will show CLOCK OFF on the display panel, then turn VOL knob to display CLOCK ON. With CLOCK ON selected, it will show the CLOCK on the display panel after unit powered off. With CLOCK ON selected, press VOL knob again, it will display the clock with the Hour blinking, turn VOL knob right or left to adjust hour. Simply press VOL again and turn the knob to adjust minute. Note: Clock can only be adjusted after CLOCK ON selected. Due to time tolerance, the clock display on the Audio Unit might have little difference. 1.3.3 CONTRAST Adjustment Turn VOL knob while CONTRAST displays to adjust the contrast of the LCD display. 1.3.4 AREA Selection (Wrong AREA Selection may cause Poor Radio reception) To select a Area, repeat short press VOL until AREA display, then turn the knob right or left to select area among USA, EUROPE, ASIA, LATIN, JAPAN. 1.3.5 Delete Bluetooth Device With more than one Bluetooth Device paired, you can delete the paired device on unit. The DEL DEVICE menu will only display when it has Bluetooth connection established. Long press VOL knob then repeat short press it until DEL DEVICE displays, turn the knob so select DEL DEVICE YES and push the knob. It will display the paired list by turning VOL knob, press the knob again at desired device name to delete it. I-VOL --> CLOCK --> CONTRAST --> AREA --> DEL DEVICE 4 对折基准线 Operating Instructions 2. Menu Selection This button can adjust the sound effect and other things. Each time …

Text truncated - open the document above for the full version.

Attestation Statements

Company We, CompassSystems,Inc. (Companyname) certifytheproduct:VehicleAudioSystem AnditemNo.:MA132 ， MA122 Theirelectricalcircuitdesign,layout,componentsusedandinternalwiringareidentical, OnlytheItemnumberraredifferent. Date:2022.12.27 JobTitle(representative): Mananger Signature:

Cover Letter(s)

CompassSystems,Inc. ToWhomItMayConcern: Thisletterservesasanofficialrequestforconfidentialityundersections0.457and0.459 ofCFR47.Wehaverequestedthatth Date：2022.12.27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 R E: CONFIDENTIALITY REQUEST FOR (Vehicle Audio System/ MA132，MA122 FCC IDTQ5-MA132 e Schematics Blockdiagram Operationdescription Name：Patrick.Cho_ Title：Manange requiredtobesubmittedwiththisapplicationbepermanentlywithheldfrompublic review. Thesematerialscontaintradesecretsandproprietaryinformationandarenotcustomarily releasedtothepublic.Thepublicdisclosureofthisinformationmightbeharmfultothe companyandprovideunjustifiedbenefitstoour Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, <Signature> r

Cover Letter(s)

CompassSystems,Inc. (Date) ： 2022.12.27 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorize(BlueAsiaofTechnicalServices(Shenzhen) Co.,Ltd.）toactonourbehalfinallmattersrelatingtoapplicationforequipmentauthorization, <Signature including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely > Name：Patrick.Cho_ Title ： Mananger

External Photos

ModelNO: MA132 ModelNO:MA122

ID Label/Location Info

FCCID:TQ5-MA132

Internal Photos

MODELNO: MA132

RF Exposure Info

SARevaluation ProductName: VehicleAudioSystem FCCID: TQ5-MA132 TestStandard: KDB447498D04GeneralRFExposure Guidancev01 Accordingto447498D04InterimGeneralRFExposureGuidancev01 StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-ghead orbodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,by measurementornumericalsimulation,isnotrequiredwhenthecorrespondingSARExclusion Thresholdcondition,listedbelow,issatisfied. CalculatedResultandLimit(WORSECASEISASBELOW) BT Directional antennaGain (Numeric) PeakOutput Power(mW) Limit(mW)TestResult 0.69dBi(1.172) 2.822 (GFSK2441) 3060Compiles

Test Report

ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page1of9 TestingReport CustomerName:AudioLinkCo.,Ltd. ProductName:VehicleAudioSystem SampleModel:MA132 、 MA122 ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-1979 IssueDate:2022.11.29 Engineer:Date: Auditor:Date: Approver:Date: ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page2of9 Version VersionNo.DateDescriptionFormulateApproval A02022.11.29Forthefirsttime,formulateJacksonEason Contents 1.GeneralInformation.........................................................................................................................3 1.1Generalinformationoftestinginstitutions...........................................................................3 1.2Testingprinciple...................................................................................................................3 1.3Testequipment......................................................................................................................4 1.4Testenvironment...................................................................................................................4 1.5Statement..............................................................................................................................4 2.SampleInformation.........................................................................................................................5 2.1Clientinformation.................................................................................................................5 2.2DescriptionofEUT(S)..........................................................................................................5 2.3EUTappearance....................................................................................................................6 2.4EUTsetupphotooffreespaceOTAtesting.........................................................................6 3.TestResults......................................................................................................................................7 3.1Teststandard.........................................................................................................................7 3.2Testuncertainty.....................................................................................................................7 3.3Testdata................................................................................................................................8 3.3.1Typicalfreespaceefficiencyandgain......................................................................8 3.3.2Typicalfreespaceradiationpattern...........................................................................8 （Thefollowingisblank）................................................................................................................9 ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page3of9 1.GeneralInformation 1.1Generalinformationoftestinginstitutions Name ShenzhenRFI-LABCommunicationTechnologyCo.,Ltd. Address 10/FA,LingyunBld,LiufangRd,BaoanDistrict,SZ Tel 13682621346 E-mail [email protected] Equipment Alltheequipmentusedinthereportisfixedin 10/FA,LingyunBld,LiufangRd,BaoanDistrict,SZ 1.2Testingprinciple ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page4of9 1.3Testequipment EquipmentModelNo.SerialNo.Manufacturer Calibration date Next calibration date 16probe microwave chamber 3*3*2.5 RFI-LAB-RF -A00 SUNYIELD2021.3.152023.3.14 Network Analyzer E5071C RFI-LAB-RF -A02 Agilent 2022.5.132023.5.12 1.4Testenvironment Temperature 24.4°C Humidity 58%RH Pressure 100.14kPa 1.5Statement (1)Thetestresultsinthereportareonlyapplicabletothetestedsamplesandthetestedsamples workundertheenvironmentdescribedinthereport. (2)OnlyShenzhenRFI-LABCommunicationTechnologyCo.,Ltd.havetherighttomodifythe report,andthemodificationinformationshallbeannotatedintherevisionform. (3)Anyobjectiontothisreportshallberaisedwithin30daysafterformalconfirmationofthe report. (4)Thisreportisinvalidifthereisanyevidencethatthesampleinformationprovidedisfalsified. (5)Thereportisinvalidwithoutthesignatureoftheauditorandapprover. ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page5of9 2.SampleInformation 2.1Clientinformation Name AudioLinkCo.,Ltd. Address LeftSideofFloor4,BuildingB,No.2,LilianRoad,LianhuCommunity, TangxiaTown,DongguanCity,GuangdongProvince,523719,China. Contacts / Tel / E-mail / Manufacturer AudioLinkCo.,Ltd. 2.2DescriptionofEUT(S) ProductName VehicleAudioSystem SampleModel MA132、MA122 Size / SerialNo. / TestItem Antennagain;Radiationpatternandefficiency FrequencyRange 2400MHz-2500MHz ReceivedDate 2022.11.28 TestDate 2022.11.28 Remark ThelengthoftheRFcableis40mm ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page6of9 2.3EUTappearance 2.4EUTsetupphotooffreespaceOTAtesting Planform Frontview ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page7of9 3.TestResults 3.1Teststandard NameParameterMethodStandardno. Mobile communication antenna Antennagain Genericspecification forantennasusedinthe mobilecommunications GB/T 9410-2008 Radiationpattern Antenna Radiationefficiency IEEEStandardTest ProceduresforAntennas ANSI/IEEEStd 149-1979 Gainanddirectivity 3.2Testuncertainty TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingthe inclusionfactorofK=2andthe95%confidenceleveltoexpresstheextended uncertainty. ItemUncertainty Antennagain±1dB Radiationefficiency±10% ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page8of9 3.3Testdata 3.3.1Typicalfreespaceefficiencyandgain 3.3.2Typicalfreespaceradiationpattern (1)X-ZPlane: (2)Y-ZPlane: Frequency/MHz 24002410242024302440245024602470248024902500 PeakGain/dBi 0.690.21-0.23-0.94-1.49-2.12-3.00-3.73-4.44-5.31-6.11 Efficiency/% 18.9617.3415.4813.7112.0110.668.957.586.595.684.77 ReportNo.:RFI-LAB-RF-202211-KK39 QP030-E11 Page9of9 (3)X-YPlane: (4)TypicalFreeSpace3DRadiationPatternat2400MHz: -------------------------------------------------End------------------------------------------------ （Thefollowingisblank）

Test Report

Page 1 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd. Add:No.41,SouthofBeihuanRoad,ShangwuCommunity,ShiyanSubdistrict,Bao’anDistrict,Shenzhen,Guangdong,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: VehicleAudioSystem BrandMark: N/A ModelNo.: MA132 Extensionmodel: MA122 ReportNumber: BLA-EMC-202211-A6402 FCCID: TQ5-MA132 DateofSampleReceipt: 2022/11/28 DateofTest: 2022/11/28to2022/12/15 DateofIssue: 2022/12/16 TestStandard: 47CFRPart15,SubpartC15.247 TestResult:Pass Preparedfor: CompassSystem,INC. #1403AceTechnoTower8,219-17,Kuro-Dong,Kuro-SeoulSouthKorea Preparedby: BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd. No.41,SouthofBeihuanRoad,ShangwuCommunity,ShiyanSubdistrict, Bao’anDistrict,Shenzhen,Guangdong,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2022/12/16 ReportNo.:BLA-EMC-202211-A6402 Page 2 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002022/12/16Original ReportNo.:BLA-EMC-202211-A6402 Page 3 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................5 2GENERALINFORMATION.........................................................................................................................6 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................6 4TESTENVIRONMENT................................................................................................................................7 5TESTMODE................................................................................................................................................7 6MEASUREMENTUNCERTAINTY..............................................................................................................7 7DESCRIPTIONOFSUPPORTUNIT..........................................................................................................8 8LABORATORYLOCATION.........................................................................................................................8 9TESTINSTRUMENTSLIST........................................................................................................................9 10CONDUCTEDBANDEDGESMEASUREMENT......................................................................................11 10.1LIMITS................................................................................................................................................................11 10.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................11 10.3TESTDATA...........................................................................................................................................................12 11DWELLTIME.............................................................................................................................................13 11.1LIMITS................................................................................................................................................................13 11.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................13 11.3TESTDATA...........................................................................................................................................................14 12HOPPINGCHANNELNUMBER...............................................................................................................15 12.1LIMITS................................................................................................................................................................15 12.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................15 12.3TESTDATA...........................................................................................................................................................15 13CARRIERFREQUENCIESSEPARATION...............................................................................................16 13.1LIMITS................................................................................................................................................................16 13.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................16 13.3TESTDATA...........................................................................................................................................................16 1420DBBANDWIDTH...................................................................................................................................17 14.1BLOCKDIAGRAMOFTESTSETUP......................................................................................................................17 14.2TESTDATA...........................................................................................................................................................17 15CONDUCTEDPEAKOUTPUTPOWER..................................................................................................18 ReportNo.:BLA-EMC-202211-A6402 Page 4 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15.1LIMITS................................................................................................................................................................18 15.2BLOCKDIAGRAMOFTESTSETUP.......................................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202211-A6402 Page 31 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] Remark: 1.FinalLevel=ReceiverReadlevel+Correctfactor 2.Correctfactor=AntennaFactor+CableLoss–PreamplifierFactor 3.Theemissionlevelsofotherfrequenciesareverylowerthanthelimitandnotshowintestreport. ReportNo.:BLA-EMC-202211-A6402 Page 32 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 17RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section6.10.5 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 17.1LIMITS Frequency(MHz) Field strength(microvolts/meter) Measurement distance(meters) 0.009-0.4902400/F(kHz)300 0.490-1.70524000/F(kHz)30 1.705-30.03030 30-881003 88-2161503 216-9602003 Above9605003 Remark:Theemissionlimitsshownintheabovetablearebasedonmeasurementsemployinga CISPRquasi-peakdetectorexceptforthefrequencybands9-90kHz,110-490kHzandabove1000 MHz.Radiatedemissionlimitsinthesethreebandsarebasedonmeasurementsemployingan averagedetector,thepeakfieldstrengthofanyemissionshallnotexceedthemaximumpermitted averagelimitsspecifiedabovebymorethan20dBunderanyconditionofmodulation. ReportNo.:BLA-EMC-202211-A6402 Page 33 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 17.2BLOCKDIAGRAMOFTESTSETUP 17.3PROCEDURE a.Forbelow1GHz,theEUTwasplacedonthetopofarotatingtable0.8metersabovethegroundata3 or10metersemi-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionofthe highestradiation. b.Forabove1GHz,theEUTwasplacedonthetopofarotatingtable1.5metersabovethegroundata3 meterfully-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionofthehighest radiation. c.TheEUTwasset3or10metersawayfromtheinterference-receivingantenna,whichwasmountedon thetopofavariable-heightantennatower. d.Theantennaheightisvariedfromonemetertofourmetersabovethegroundtodeterminethe maximumvalueofthefieldstrength.Bothhorizontalandverticalpolarizationsoftheantennaaresetto makethemeasurement. e.Foreachsuspectedemission,theEUTwasarrangedtoitsworstcaseandthentheantennawastuned toheightsfrom1meterto4meters(forthetestfrequencyofbelow30MHz,theantennawastunedto heights1meter)andtherotatabletablewasturnedfrom0degreesto360degreestofindthemaximum reading. f.Thetest-receiversystemwassettoPeakDetectFunctionandSpecifiedBandwidthwithMaximumHold Mode. g.IftheemissionleveloftheEUTinpeakmodewas10dBlowerthanthelimitspecified,thentesting couldbestoppedandthepeakvaluesoftheEUTwouldbereported.Otherwisetheemissionsthatdidnot have10dBmarginwouldbere-testedonebyoneusingpeak,quasi-peakoraveragemethodasspecified andthenreportedinadatasheet. ReportNo.:BLA-EMC-202211-A6402 Page 34 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] h.TesttheEUTinthelowestchannel,themiddlechannel,theHighestchannel. i.TheradiationmeasurementsareperformedinX,Y,ZaxispositioningforTransmittingmode,andfound theXaxispositioningwhichitistheworstcase. j.Repeataboveproceduresuntilallfrequenciesmeasuredwascomplete. Remark1:Level=ReadLevel+CableLoss+AntennaFactor-PreampFactor Remark2:Forfrequenciesabove1GHz,thefieldstrengthlimitsarebasedonaveragelimits.However, thepeakfieldstrengthofanyemissionshallnotexceedthemaximumpermittedaveragelimitsspecified abovebymorethan20dBunderanyconditionofmodulation.Fortheemissionswhosepeaklevelis lowerthantheaveragelimit,onlythepeakmeasurementisshowninthereport. ReportNo.:BLA-EMC-202211-A6402 Page 35 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 17.4TESTDATA [TestMode:TXlowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202211-A6402 Page 36 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXlowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202211-A6402 Page 37 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202211-A6402 Page 38 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202211-A6402 Page 39 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] Remark: 1.FinalLevel=ReceiverReadlevel+Correctfactor 2.Correctfactor=AntennaFactor+CableLoss–PreamplifierFactor 3.Theemissionlevelsofotherfrequenciesareverylowerthanthelimitandnotshowintestreport. ReportNo.:BLA-EMC-202211-A6402 Page 40 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 18ANTENNAREQUIREMENT TestStandard47CFRPart15,SubpartC15.247 TestMethodN/A 18.1CONCLUSION StandardRequirement: Anintentionalradiatorshallbedesignedtoensurethatnoantennaotherthanthatfurnished bytheresponsiblepartyshallbeusedwiththedevice.Theuseofaantennathatusesa uniquecouplingtotheintentionalradiator,themanufacturermaydesigntheunit permanentlyattachedantennaorofansothatabrokenantennacanbereplacedbythe user,buttheuseofastandardantennajackorelectricalconnectorisprohibited. EUTAntenna: TheantennaisintegratedonthemainPCBandnoconsiderationofreplacement.Thebest casegainoftheantennais0.69dBi. ReportNo.:BLA-EMC-202211-A6402 Page 41 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 19CONDUCTEDSPURIOUSEMISSIONS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.6&Section11.11 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 19.1LIMITS Limit: Inany100kHzbandwidthoutsid…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202211-A6402 Page 61 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdgeNVNT2-DH12480MHzAnt1No-HoppingRef BandEdgeNVNT2-DH12480MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 62 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdgeNVNT3-DH12402MHzAnt1No-HoppingRef BandEdgeNVNT3-DH12402MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 63 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdgeNVNT3-DH12480MHzAnt1No-HoppingRef BandEdgeNVNT3-DH12480MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 64 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ReportNo.:BLA-EMC-202211-A6402 Page 65 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdge(Hopping) ConditionModeFrequency (MHz) AntennaHopping Mode MaxValue (dBc) Limit (dBc) Verdict NVNT1-DH12402Ant1Hopping-56.86-20Pass NVNT1-DH12480Ant1Hopping-55.91-20Pass NVNT2-DH12402Ant1Hopping-57.28-20Pass NVNT2-DH12480Ant1Hopping-53.03-20Pass NVNT3-DH12402Ant1Hopping-53-20Pass NVNT3-DH12480Ant1Hopping-50.34-20Pass BandEdge(Hopping)NVNT1-DH12402MHzAnt1HoppingRef BandEdge(Hopping)NVNT1-DH12402MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 66 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdge(Hopping)NVNT1-DH12480MHzAnt1HoppingRef BandEdge(Hopping)NVNT1-DH12480MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 67 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdge(Hopping)NVNT2-DH12402MHzAnt1HoppingRef BandEdge(Hopping)NVNT2-DH12402MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 68 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdge(Hopping)NVNT2-DH12480MHzAnt1HoppingRef BandEdge(Hopping)NVNT2-DH12480MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 69 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdge(Hopping)NVNT3-DH12402MHzAnt1HoppingRef BandEdge(Hopping)NVNT3-DH12402MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 70 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BandEdge(Hopping)NVNT3-DH12480MHzAnt1HoppingRef BandEdge(Hopping)NVNT3-DH12480MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202211-A6402 Page 71 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ReportNo.:BLA-EMC-202211-A6402 Page 72 of 93 BlueAsiaTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ConductedRFSpuriousEmission ConditionModeFrequency(MHz)AntennaMaxValue(dBc)Limit(dBc)Verdict NVNT1-DH12402Ant1-47.44-20Pass NVNT1-DH12441Ant1-47.36-20Pass NVNT1-DH12480Ant1-46.02-20Pass NVNT2-DH12402Ant1-46.95-20Pass NVNT2-DH12441Ant1-47.6-20Pass NVNT2-DH12480Ant1-47.18-20Pass NVNT3-DH12402Ant1-43.76-20Pass NVNT3-DH12441Ant1-44.09-20Pass NVNT3-DH12480Ant1-35.29-20Pass Tx.SpuriousNVNT1-DH12402MHzAnt1Ref Tx.SpuriousNVNT1-DH12402MHzAnt1Emission ReportNo.:BLA-EMC-202211-A6402 Page 73 of…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Patrick Cho

[email protected]82-2-2109-8660Fax: 82-2-2109-8661

Technical Contact

BlueAsia of Technical Services(Shenzhen) Co.,Ltd.Sweet Liang

[email protected]18124567264

Building C, No. 107, Shihuan Road, Shiyan Sub-Dist · Shenzhen · China

Test Firm

BlueAsia of Technical Services (Shenzhen)Blue Zheng

[email protected]+86 755-23059481-815

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.82 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures.
