41 Features of your vehicle How vehicle audio worksAM and FM radio signals are broad-cast from transmitter towers locatedaround your city. They are intercept-ed by the radio antenna on your vehi-cle. This signal is then processed bythe radio and sent to your vehiclespeakers.When a strong radio signal hasreached your vehicle, the preciseengineering of your audio systemensures the best possible qualityreproduction. However, in somecases the signal coming to your vehi-cle may not be strong and clear. This can be due to factors, such asthe distance from the radio station,closeness of other strong radio sta-tions or the presence of buildings,bridges or other large obstructions inthe area. AM broadcasts can be received atgreater distances than FM broad-casts. This is because AM radiowaves are transmitted at low fre-quencies. These long distance,lowfrequency radio waves can follow thecurvature of the earth rather thantravelling straight. In addition, theycurve around obstructions resultingin better signal coverage. ቍቋᆲ ቍቋᆲ JBM002 AM reception ቍቋᆲ JBM001 FM reception Features of your vehicle 2 4 FM broadcasts are transmitted athigh frequencies and do not bend tofollow the earth's surface. Becauseof this, FM broadcasts generallybegin to fade within short distancesfrom the station. short distances fromthe station. Also, FM signals are eas-ily affected by buildings, mountains,and obstructions. This can lead toundesirable or unpleasant listeningconditions which might lead you tobelieve a problem exists with yourradio. The following conditions arenormal and do not indicate radiotrouble: • Fading - As your vehicle moves away from the radio station, thesignal will weaken and sound willbegin to fade. When this occurs,we suggest that you select anotherstronger station. • Flutter/Static - Weak FM signals or large obstructions between thetransmitter and your radio can dis-turb the signal causing static orfluttering noises to occur. Reducingthe treble level may lessen thiseffect until the disturbance clears. • Station Swapping - As an FM sig- nal weakens, another more power-ful signal near the same frequencymay begin to play. This is becauseyour radio is designed to lock ontothe clearest signal. If this occurs,select another station with astronger signal. • Multi-Path Cancellation - Radio signals being received from sever-al directions can cause distortionor fluttering. This can be caused bya direct and reflected signal fromthe same station, or by signalsfrom two stations with close fre-quencies. If this occurs, selectanother station until the conditionhas passed. JBM003 FM radio station JBM005 ቍቋᆲ JBM004 43 Features of your vehicle Using a cellular phone or a two- way radio When a cellular phone is used insidethe vehicle, noise may be producedfrom the audio system. This does notmean that something is wrong withthe audio equipment. In such a case,try to operate mobile devices as farfrom the audio equipment as possi-ble. Caring for disc• If the temperature inside the car is too high, open the car windows toventilate before using the system. • It is illegal to copy and use MP3/WMA files without permis-sion. Use CDs that are createdonly by lawful means. • Do not apply volatile agents, such as benzene and thinner, normalcleaners and magnetic spraysmade for analogue disc onto CDs. • To prevent the disc surface from getting damaged, hold CDs by theedges or the center hole only. • Clean the disc surface with a piece of soft cloth before playback (wipeit from the center to the outsideedge). • Do not damage the disc surface or attach pieces of sticky tape orpaper. • Make certain only CDs are insert- ed into the CD player (Do not insertmore than one CD at a time). • Keep CDs in their cases after use to protect them from scratches ordirt. CAUTION When using a communication system such as a cellular phone or a radio set inside the vehicle, a separate external antenna must be fitted. When a cellular phone or a radio set is used with an internal antenna alone, it may interfere with the vehi- cle's electrical system and adversely affect safe operation of the vehicle. WARNING Do not use a cellular phonewhile driving. Stop at a safelocation to use a cellular phone. Features of your vehicle 4 4 • Depending on the type of CD- R/CD-RW CDs, certain CDs maynot operate normally according tothe manufacturing companies. Insuch circumstances, continueduse may cause malfunctions toyour audio system. ✽ NOTICE - Playing an Incompatible Copy Protected AudioCD Some copy protected CDs, which donot comply with international audioCD standards (Red Book), may notplay on your car audio. Please notethat inabilities to properly play acopy protected CD may indicatethat the CD is defective, not the CDplayer. NOTE:Order of playing files (folders) :1. Song playing order : to sequentially. 2. Folder playing order :❋ If no song file is contained in thefolder, that folder is not displayed. 45 Features of your vehicle CAUTION • Operating the device while driving could lead to acci- dents due to a lack of atten- tion to external surroundings. First park the vehicle before operating the device. • Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to acci- dents. • Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.) (Continued) WARNING • Do not stare at the screen while driving. Staring at thescreen for prolonged periodsof time could lead to trafficaccidents. • Do not disassemble, assem- ble, or modify the audio sys-tem. Such acts could result inaccidents, fire, or electricshock. • Using the phone while driving may lead to a lack of attentionof traffic conditions andincrease the likelihood ofaccidents. Use the phone feature after parking the vehi-cle. • Heed caution not to…
