MPE CALCULATION For HYUNDAI MOBIS CO., LTD – ; Model: AC1B0DKAN FCC ID: TQ8-AC1B0KDAN RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 / 47 CFR §2.1091 EUT Frequency Band: 2402 – 2480 MHz Limits for General Population/Uncontrolled Exposure in the band of: 1500 – 100,000 MHz Power Density Limit: 1.0mW/ cm 2 ; Equation: S = PG / 4πR 2 or R = √PG / 4πS Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ Low Channel (2402 MHz): Power =-0.14 dBm, Antenna Gain =1.07 dBi, Prediction distance 20cm S = 0.0002 mW/cm 2 Result The Above Result had shown that Device complied with 1.0 mW/cm 2 Power density requirement for distance of 20cm. Completed By : Jong Suk LEE Date : July 25, 2011

FCC PT.15.247 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1107FR24 Date of Issue: July 22, 2011 EUT Type: CAR AUDIO FCC ID : TQ8-AC1B0DKAN IC: 5074A-AC1B0DKKN Page 2 of 45 Version TEST REPORT NO. DATE DESCRIPTION HCTR1107FR24 July 22, 2011 First Approval Report FCC PT.15.247 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1107FR24 Date of Issue: July 22, 2011 EUT Type: CAR AUDIO FCC ID : TQ8-AC1B0DKAN IC: 5074A-AC1B0DKKN Page 3 of 45 Table of Contents 1. GENERAL INFORMATION ....................................................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................................. 4 3. TEST METHODOLOGY ............................................................................................................................ 5 3.1 EUT CONFIGURATION ............................................................................................................. 5 3.2 EUT EXERCISE ......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ............................................................................................. 5 3.4 DESCRIPTION OF TEST MODES ............................................................................................ 5 4. INSTRUMENT CALIBRATION .................................................................................................................. 6 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1 FACILITIES ................................................................................................................................ 6 5.2 EQUIPMENT .............................................................................................................................. 6 6. ANTENNA REQUIREMENTS.................................................................................................................... 6 7. SUMMARY OF TEST RESULTS............................................................................................................... 7 8. FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1 PEAK POWER ........................................................................................................................... 8 8.2 BAND EDGES MEASUREMENT ............................................................................................ 12 8.3 FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 15 8.4 NUMBER OF HOPPING FREQUENCY .................................................................................. 20 8.5 TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 23 8.6 SPURIOUS EMISSIONS.......................................................................................................... 27 8.6.1 CONDUCTED SPURIOUS MEASUREMENT.................................................................. 27 8.6.2 RADIATED SPURIOUS EMISSIONS .............................................................................. 34 8.6.3 RECEIVER SPURIOUS EMISSIONS............................................................................... 42 8.6.4 RADIATED RESTRICTED BAND EDGE MEASUREMENTS......................................... 43 8.7 POWERLINE CONDUCTED EMISSIONS............................................................................... 44 9. LIST OF TEST EQUIPMENT................................................................................................................... 45 FCC PT.15.247 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1107FR24 Date of Issue: July 22, 2011 EUT Type: CAR AUDIO FCC ID : TQ8-AC1B0DKAN IC: 5074A-AC1B0DKKN Page 4 of 45 1. GENERAL INFORMATION Applicant Name: HYUNDAI MOBIS CO., LTD. Address: 80-9, Mabook-Dong, Giheung-Gu Yongin-shi Gyunggi-Do, 446-912 South Korea FCC ID: TQ8-AC1B0DKAN IC: 5074A-AC1B0DKKN EUT: CAR AUDIO FCC Model name(s): AC1B0DKAN Additional Model name(s): AC110DKMG, AC110DKMN, AC110DKGE, AC110DKGG IC Model name(s): AC1B0DKKN Date(s) of Tests: June 15, 2011 ~ June 24, 2011 Contact Person: Name: Seung Keun, Jeon Phone #: +82-31-288-5232 Fax #: +82-31-899-1788 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type CAR AUDIO FCC Model Name AC1B0DKAN FCC Additional Model(s) AC110DKMG,AC110DKMN,AC110DKGE,AC110DKGG IC Model Name AC1B0DKKN Power Supply DC 12 V Frequency Range 2402 MHz - 2480 MHz (Bluetooth) Transmit Power -0.14 dBm(0.97 mW) Modulation Type GFSK(Normal), PSK(EDR) Modulation Technique FHSS Number of Channels 79Channels Antenna Specification Manufacturer: AUTO INDUSTRIAL Co.,Ltd. Antenna type: PCB Antenna Peak Gain : 1.07 dBi 15.247 Requirements for Bluetooth transmitter※ ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudorandomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individ…
