TQ8-AC1B0TMKNDIGITAL CAR AUDIO SYSTEM

4157 Features of your vehicle ✽ NOTICE If you install an aftermarket HIDheadlamp, your vehicle's audio andelectronic device may malfunction. AntennaRoof antenna Your vehicle uses a roof antenna toreceive both AM and FM broadcastsignals. AUDIO SYSTEM OANNMM2901 CAUTION Before entering a place with a low height clearance or a car wash, remove the antenna by rotating it counterclockwise. If not, the antenna may be dam- aged. Features of your vehicle 158 4 Steering wheel audio control (if equipped) The steering wheel may incorporateaudio control buttons. MODE (1)Press the button to change audiosource.PRESET/SEEK ( / ) (2) The SEEK/PRESET button has dif-ferent functions based on the systemmode.For the following functions the buttonshould be pressed for 0.8 second ormore.RADIO modeIt will function as the AUTO SEEKselect button.CD/USB/iPod ® mode It will function as the FF/REW button.If the SEEK/PRESET button ispressed for less than 0.8 second, itwill work as follows in each mode. RADIO modeIt will function as the PRESET STA-TION buttons.CD/USB/iPod ® mode It will function as TRACK UP/DOWNbutton. VOLUME (VOL+/-) (3)• Push the lever upward (+) to increase the volume. • Push the lever downward (-) to decrease the volume. MUTE (4)• Press the button to mute the sound.• Press the button to turn off the microphone during a telephone call. Detailed information for audio controlbuttons are described in the followingpages in this section. CAUTION Do not operate audio remote control buttons simultaneously. ODM042327 4159 Features of your vehicle How vehicle audio worksAM and FM radio signals are broad-cast from transmitter towers locatedaround your city. They are intercept-ed by the radio antenna on your vehi-cle. This signal is then processed bythe radio and sent to your vehiclespeakers.When a strong radio signal hasreached your vehicle, the preciseengineering of your audio systemensures the best possible qualityreproduction. However, in somecases the signal coming to your vehi-cle may not be strong and clear. This can be due to factors, such asthe distance from the radio station,closeness of other strong radio sta-tions or the presence of buildings,bridges or other large obstructions inthe area. AM broadcasts can be received atgreater distances than FM broad-casts. This is because AM radiowaves are transmitted at low fre-quencies. These long distance, lowfrequency radio waves can follow thecurvature of the earth rather thantravelling straight. In addition, theycurve around obstructions resultingin better signal coverage. ቍቋᆲ JBM001 FM reception ቍቋᆲ ቍቋᆲ JBM002 AM reception Features of your vehicle 160 4 FM broadcasts are transmitted athigh frequencies and do not bend tofollow the earth's surface. Becauseof this, FM broadcasts generallybegin to fade within short distancesfrom the station. Also, FM signals areeasily affected by buildings, moun-tains, and obstructions. This can leadto undesirable or unpleasant listen-ing conditions which might lead youto believe a problem exists with yourradio. The following conditions arenormal and do not indicate radiotrouble: • Fading - As your vehicle moves away from the radio station, thesignal will weaken and sound willbegin to fade. When this occurs,we suggest that you select anotherstronger station. • Flutter/Static - Weak FM signals or large obstructions between thetransmitter and your radio can dis-turb the signal causing static orfluttering noises to occur. Reducingthe treble level may lessen thiseffect until the disturbance clears. • Station Swapping - As an FM sig- nal weakens, another more power-ful signal near the same frequencymay begin to play. This is becauseyour radio is designed to lock ontothe clearest signal. If this occurs,select another station with astronger signal. • Multi-Path Cancellation - Radio signals being received from sever-al directions can cause distortionor fluttering. This can be caused bya direct and reflected signal fromthe same station, or by signalsfrom two stations with close fre-quencies. If this occurs, selectanother station until the conditionhas passed. JBM003 FM radio station ቍቋᆲ JBM004 JBM005 4161 Features of your vehicle Using a cellular phone or a two- way radio When a cellular phone is used insidethe vehicle, noise may be producedfrom the audio system. This does notmean that something is wrong withthe audio equipment. In such a case,try to operate mobile devices as farfrom the audio equipment as possi-ble. Caring for disc• If the temperature inside the car is too high, open the car windows to venti-late before using the system. • It is illegal to copy and use MP3/WMA files without permission.Use CDs that are created only bylawful means. • Do not apply volatile agents, such as benzene and thinner, normalcleaners and magnetic spraysmade for analogue disc onto CDs. • To prevent the disc surface from getting damaged, hold CDs by theedges or the center hole only. • Clean the disc surface with a piece of soft cloth before playback (wipeit from the center to the outsideedge). • Do not damage the disc surface or attach pieces of sticky tape orpaper. • Make certain only CDs are insert- ed into the CD player (Do not insertmore than one CD at a time). • Keep CDs in their cases after use to protect them from scratches or dirt. CAUTION When using a communication system such as a cellular phone or a radio set inside the vehicle, a separate external antenna must be fitted. When a cellular phone or a radio set is used with an internal antenna alone, it may interfere with the vehi- cle's electrical system and adversely affect safe operation of the vehicle. WARNING Do not use a cellular phonewhile driving. Stop at a safelocation to use a cellular phone. Features of your vehicle 162 4 • Depending on the type of CD- R/CD-RW CDs, certain CDs maynot operate normally according tothe manufacturing companies. Insuch circumstances, continueduse may cause malfunctions toyour audio system. ✽ NOTICE - Playing an IncompatibleCopy Protected Audio CD So…

Text truncated - open the document above for the full version.

Hyundai Mobis Co., Ltd. #679-4, Yeoksam-dong, Gangnam-gu, Seoul, 135-977 Korea Tel. 82-31-288-5232 / Fax. 82-31-280-2764 Date: 2013-01-07 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. UL CCS Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Feel.Jeong and of SGS Korea Co., Ltd and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Feel.Jeong of SGS Korea Co., Ltd on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Hyundai Mobis Co., Ltd. #679-4, Yeoksam-dong, Gangnam-gu, Seoul, 135-977 Korea Tel. 82-31-288-5232 / Fax. 82-31-280-2764 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jong-Tae Kim/ Manager Hyundai MOBIS Co., Ltd.

Hyundai Mobis Co., Ltd. #679-4, Yeoksam-dong, Gangnam-gu, Seoul, 135-977 Korea Tel. 82-31-288-5232 / Fax. 82-31-280-2764 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: TQ8-AC1B0TMKN To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. - Schematics - Block Diagram - Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments: - External Photos - Internal Photos - Test Setup Photos - User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Jong-Tae Kim/ Manager Hyundai MOBIS Co., Ltd.

External photos of EUT Top view of EUT Bottom view of EUT Front view of EUT Rear view of EUT Side view of EUT

FCC Label 1. FCC Label Drawing - Model 1: AC1B0TMAN - Model 2: AC110TMGN FCC Model No: AC1B0TMAN FCC ID: TQ8-AC1B0TMKN This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Including interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. MADE IN KOREA FCC Model No: AC110TMGN FCC ID: TQ8-AC1B0TMKN This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Including interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. MADE IN KOREA - Model 3: AC110TMGG 2. FCC Label Location Top side of EUT FCC Model No: AC110TMGG FCC ID: TQ8-AC1B0TMKN This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Including interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. MADE IN KOREA

Internal photos of EUT Top view of LCD Bottom view of LCD Top view of Controller Board #1 Bottom view of Controller Board #1 Top view of Controller Board #2 Bottom view of Controller Board #2 Top view of CD Player Bottom view of CD Player Top view of Main Board Bottom view of Main Board Top view of Bluetooth Module Top view of Bluetooth Antenna Bluetooth Antenna Bluetooth Module

Report Number:F690501/RF-RTL006116-1Page:2of61 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371www.ee.sgs.com/korea INDEX Table of ContentsPage 1. General Information ---------------------------------------------------------------------------------3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emission ------7 3. 20㏈Bandwidth and 99% BW ------------------------------------------------------------------- 30 4. Maximum Peak Output Power -------------------------------------------------------------------38 5. Hopping Channel Separation ---------------------------------------------------------------------40 6. Number of Hopping Frequency ------------------------------------------------------------------43 7. Time of Occupancy(Dwell Time) -----------------------------------------------------------------47 8. Antenna Requirement ------------------------------------------------------------------------------61 Report Number:F690501/RF-RTL006116-1Page:3of61 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371www.ee.sgs.com/korea 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - Wireless Div. 3FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 (Lab) - Wireless Div. 1FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 (Chamber) All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone:+82 31 428 5700 FAX:+82 31 427 2371 1.2. Details of Applicant Applicant:Hyundai MOBIS Co., Ltd. Address:80-9, Mabook-Dong, Giheung-Gu Yongin-Shi, Gyunggi-Do, 446-912, South Korea Contact Person:Kim, Jong-Tae Phone No.:+82 31 260 0092 1.3. Description of EUT Kind of Product DIGITAL CAR AUDIO SYSTEM Model Name FCC: AC1B0TMAN (Alt: AC110TMGN, AC110TMGG) IC: AC1B0TMKN (Alt: AC110TMKN) Serial Number N/A Power Supply DC 14.4 V (Used on vehicle battery) Frequency Range 2 402㎒~ 2 480㎒ Modulation Technique GFSK, π/4DQPSK, 8DPSK Number of Channels 79 Antenna Type Chip antenna Antenna Gain 3.5㏈i 1.4. Declaration by the manufacturer - Adaptive Frequency Hopping is supported and use at least 20 channels - The SAR was not evaluated according to Appendix A of KDB 447498 D01 General RF Exposure Guidance v05. Report Number:F690501/RF-RTL006116-1Page:4of61 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371www.ee.sgs.com/korea 1.5. Information about the FHSS characteristics: 1.5.1. Pseudorandom Frequency Hopping Sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is 1 600 hops/s. 1.5.2. Equal Hopping Frequency Use All Bluetooth units participating in the piconet are time and hop-synchronized to the channel. 1.5.3. System Receiver Input Bandwidth Each channel bandwidth is 1㎒ 1.5.4. Equipment Description 15.247(a)(1) that the rx input bandwidths shift frequencies in synchronization with the transmitted 15.247(g): In accordance with the Bluetooth Industry Standard, the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) system. 15.247(h): In accordance with the Bluetooth Industry Standard, the system does not coordinate it channels selection/ hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. 1.6. Alternative models Model nameInformation AC1B0TMAN - Basic model - Bluetooth, XM, TMU, Use North America BAND, North America exterior AC110TMGN - Same to basic model but it is different below function - Bluetooth, Use North America BAND, Normal exterior AC110TMGG - Same to basic model but it is different below function - Bluetooth, Use Normal BAND, Normal exterior AC1B0TMKN - Same to basic model but it is different below function - Bluetooth, XM, Use North America BAND, Normal exterior AC110TMKN - Same to basic model but it is different below function - Bluetooth, Use North America BAND, North America exterior Report Number:F690501/RF-RTL006116-1Page:5of61 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371www.ee.sgs.com/korea 1.7. Test Equipment List EquipmentManufacturerModelS/NCal DateCal IntervalCal Due. Signal GeneratorR&S SMR40100540 Aug. 23, 2012AnnualAug. 23, 2013 Spectrum AnalyzerAgilentN9030AUS51350132Oct. 30, 2012AnnualOct. 30, 2013 Bluetooth TesterTESOMTC-3000B3000B6300…

Text truncated - open the document above for the full version.

Test setup photos of EUT A. Photo of Field Strength & Spurious Emission Test for Bluetooth
