UVO SYSTEM USER'S MANUAL Congratulations on the Purchase of your new UVO system! Your new UVO system allows you to enjoy various audio and multimedia features through the main audio system. For the latest information about this product or other KIA products and accessories, visit http: www.KIA.com Please read this manual to get the full benefit of the system. These operating instructions are designed to ensure that you can operate the UVO system in a safe and convenient way. We recommend that this manual be kept in the car so that it will be easier for you to find information in case of an emergency. If you cannot find the information you need in this manual or in the “Troubleshooting” section, your local authorized retailer will be pleased to clarify any inquiries you may have with the system or operations. KIA Motors recommends the use of only parts and accessories that have been tested and approved by KIA Motors in terms of function, safety and suitability. iPod Ⓡ iPod Ⓡ is a registered trademark of Apple, Inc. Bluetooth Ⓡ The Bluetooth Ⓡ word mark and logos are registered trademarks owned by Bluetooth Ⓡ SIG, Inc. and any use of such marks by Kia is under license. A Bluetooth Ⓡ enabled cell phone is required to use Bluetooth Ⓡ wireless technology. Microsoft is a registered trademark of Microsoft Corporation in the United States and/or other countries. zune Ⓡ zune Ⓡ is a registered trademark of Microsoft Corporation in the United States and or other countries. Copyright(c) 2011 KIA Motors. All Rights Reserved. The making of unauthorized copies of copy-protected material, including computer programs, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. Preface Table of contents 3 contentscontents WARNING & SAFETY INFORMATION Safety Symbols ......................................................... 7 FCC Information ... ................................................... 7 Safety Precautions ................................................... 8 PART 1 GETTING STARTED Controls and Features Control Panel ............................................................ 10 Steering Wheel ......................................................... 12 Basic Features System Power ... ...................................................... 14 1. Turning System Power On ........................... 14 2. Turning System Power Off ........................... 14 Select Display Language .................................... 15 Resetting and Initializing UVO system ... ...... 15 1. Resetting the system .................................... 15 2. Initializing the system ... ................................. 16 Sound and Display Settings Sound Settings ......................................................... 17 1. FADER/BALANCE .......................................... 17 2. TONE ..................................................................... 18 3. Touch Screen Beep ... .................................... 18 4. Speed Dependent Volume Control ... ...... 18 5. Power Bass (Optional) ... .............................. 19 Display Settings ... ................................................... 20 1. Setting Brightness ... ....................................... 20 ● Automatic Brightness Control .................. 20 ● Manual Brightness Control ........................ 20 Turning Display On and Off ... ........................... 21 Turn Text Scroll On and Off ... ........................... 22 Setting the Clock ...................................................... 23 1. Time Setting ... ................................................... 23 2. Clock Type ... ...................................................... 23 3. Clock Display ...................................................... 23 ● Analog Clock ................................................... 23 ● Digital Clock ...................................................... 23 Table of contents 4 Table of contents Table of contents PART 2 AUDIO FEATURES FM/AM MODE FM/AM Mode Screens and Features ............ 26 Listening to the FM/AM radio ... ........................ 27 1. Selecting a broadcast frequency ............... 27 ● Selecting through SEEK .............................. 27 ● Selecting through manual search ... ...... 28 ● Selecting through preset ... ........................ 28 2. Storing presets ................................................... 28 3. Scanning FM/AM broadcast frequencies ... ... 29 4. Preset Scan ......................................................... 29 SIRIUS MODE SIRIUS Mode Screen and Features ............... 30 Listening to the SIRIUS radio ... ........................ 30 1. Selecting a SIRIUS channel ........................ 30 ● Selecting through SEEK .............................. 30 ● Selecting through manual search ... ...... 31 ● Selecting through preset ... ........................ 31 ● Selecting through channel search ......... 31 ● Selecting through SIRIUS category list ...... 32 2. Using Skip ............................................................ 32 3. Storing preset ... ................................................ 33 4. Viewing SIRIUS channel information ...... 33 MEDIA MODE Common Features ... ............................................. 34 ● Play/Pause ... ................................................... 34 ● REW/FF ... ......................................................... 34 ● Jump ... ............................................................... 35 ● Using Repeat ................................................... 35 ● Using Shuffle ................................................... 35 AUDIO CD MODE Cautions upon handling Audio CDs ............... 36 AUDIO CD Mode Screen and Features ... ... 38 Inserting/Ejecting a Disc ....................................... 38 1. Inserting a Disc ... ............................................. 38 2. Ejecting a Disc ........................…

Text truncated - open the document above for the full version.

54 PART 2. AUDIO FEATURES PART 2 AUDIO FEATURES Selecting iPod music 1. Selecting through song Up/Down Press the SEEK TRACK ∧ or SEEK ∨ TRACK keys on the control panel or the ∧ or ∨ keys on the steering wheel controller to play the desired song. Note ●  If the SEEK ∨ TRACK key on the Control panel or ∨ key on the steering wheel controller is pressed and released after the song has played for more than 3 seconds, the start of the current song will begin playing. If the song has been playing for less than 3 seconds, the start of the previous song will begin playing. 2. Selecting through manual search 1. T urn the TUNE knob on the control panel in clockwise or counter-clockwise direc- tion. Each click will display information about the selected song. 2. P ress the TUNE knob to play the selected song. 3. Selecting from the list 1 . Press the Menu button. 2. Press the Now Playing button. 3. Press the name of the song from the list. The file will automatically start playing. Note ●  In the iPod list screen, the TUNE knob can also be used to select the desired song. 4. B y Artists, Albums, Genres, Songs, Podcasts, Composers, Audiobooks 1 . Press the Menu button. PART 2. AUDIO FEATURES 55 PART 2 AUDIO FEATURES 2. C hoose the category through which you wish to select. iPod mode allows you to select by Playlists, Artists, Albums, Genres, Songs, Podcasts, Composers and Audiobooks. Viewing song information When listening to your iPod, you can browse through song details and information. 1 . Press the Album art icon. 2. T he song information (Artist, Title, Album, Genre) for the current iPod song will be displayed. 3. P ress the button to return to the previous screen. Note ●  Songs in the iPod can be properly played in UVO system only when they have been downloaded through iTunes. ●  If you receive a call or SMS while playing music from the iPhone, the music may not properly be restored after the call or SMS. In this case, reconnect the iPhone. ●  After upgrading the iPod or iPhone firmware, reboot the iPod or iPhone and connect with the UVO system for normal operation. ●  Songs cannot be copied from iPod or iPhone to JUKEBOX. 56 PART 2. AUDIO FEATURES PART 2 AUDIO FEATURES zune MODE About zune 1. Trademark zune ® is a registered trademark of Microsoft Corporation in the United States and or other countries. 2. Connecting your zune Device Connect your zune device as shown in the picture. zune Mode Screen and Features 1 Mode Display D isplays that the current mode is zune mode. 2 Menu D isplays the categories and song lists for the zune. 3 Repeat I f Repeat is operating, the current song will be repeated and the corresponding icon will be displayed. 4 Shuffle I f Shuffle is operating, the songs will be played in random order and the corre- sponding icon will be displayed. 5 Sound E nters Sound Setup. 6 Play Time D isplays the play time. 7 Artist name D isplays the artist name. 8 Song Title D isplays the song title. 9 Album Art Icon W hen pressed, displays information about the current song (artist, title, album and other information). 10 Current/Total Track Number D isplays the current track number and total number of tracks on the current playing list. 1 2345 6 7 9 10 8 PART 2. AUDIO FEATURES 57 PART 2 AUDIO FEATURES Listening to your zune 1. C onnect zune device or press the MEDIA key on the control panel if zune device has already been connected. 2. W hen a song is playing and you wish to pause, press the ll button next to the progress bar. Press the ▶ button to restart the song. Note ●  When connecting some external media formats, the system requires time for media indexing. In the case of zune files, the system will take 60ms/song. ●  Songs cannot be copied from zune to JUKEBOX. Selecting zune music 1. Selecting through song up/down Press the SEEK TRACK ∧ or SEEK ∨ TRACK keys on the control panel or the ∧ or ∨ keys on the steering wheel controller to play the desired song . Note ●  If the SEEK ∨ TRACK key on the Control panel or ∨ key on the steering wheel controller is pressed and released after the song has played for more than 3 seconds, the start of the current song will begin playing. If the song has been playing for less than 3 sec- onds, the start of the previous song will begin playing. 2. Selecting through manual search 1. T urn the TUNE knob on the control panel in clockwise or counter-clockwise direc- tion. Each click will display information about the selected song. 2. P ress the TUNE knob to play the selected song. 3. Selecting from the list 1. P ress the Menu button. 2. Press the Now Playing button. 58 PART 2. AUDIO FEATURES PART 2 AUDIO FEATURES 3. P ress the name of the song from the list. The song will automatically start playing. 4. B y Songs, Genres, Albums, Artists, Playlists 1. P ress the Menu button. 2. C hoose the category through which you wish to select. zune mode allows you to select by Songs, Genres, Albums, Artists, and Playlists. Viewing song information When listening to your zune, you can browse through song details and information. 1. P ress the Album art icon. 2. T he song information (Artist, Title, Album, Genre) for the current MP3 song will be displayed. 3. P ress the button to return to the pre- vious screen. PART 2. AUDIO FEATURES 59 PART 2 AUDIO FEATURES AUX MODE AUX Mode Screen 1 Mode Display Displays that the current mode is AUX mode. 2 AUX Status D isplays the AUX connection status 3 Sound E nters Sound Setup. Connecting an AUX media device Connect a cable from the headphone jack on your AUX device to the jack located in your vehicle. Note ●  Connecting your AUX device with the vehi- cle will not provide power to your AUX device. If you plan on using your AUX device for long periods of time, make sure to charge with a cigarette jack power adaptor or a sep- arate USB cable. Listening to AUX media 1. C onnect an AUX device or press the MEDIA key on the control panel if the AUX device has already been connected. 2. O nce in AUX mode, the connected…

Text truncated - open the document above for the full version.

HYUNDAI MOBIS CO., LTD. 80-9,tˆ‰––’Tk–•ŽSGnŒœ•ŽTnœG€–•Ž•TšSGn œ•ŽŽTk–Gz–œ›Gr–™ŒˆG 44]-912 Date: August 13, 2012 ATTESTATION STATEMENT FCC ID : TQ8-AC230JGAN This device contains an embedded Bluetooth device that HYUNDAI MOBIS CO.,LTD. confirms compliance with the following Part 15 regulations. 15.247(a)(1) the hopping sequence must be pseudo random all Channels are used equally on average the receiver input bandwidth is approximately equal to the transmit bandwidth the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. Jong Tae Kim HYUNDAI MOBIS CO.,LTD

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526 -1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 HYUNDAI MOBIS CO.,LTD. August 13, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 US A Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, HYUNDAI MOBIS CO.,LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): CAR AUDIO, TQ8-AC230JGAN We affirm that between SIEMIC and HYUNDAI MOBIS CO.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Jong Tae Kim/ Senior Research Engineer HYUNDAI MOBIS CO.,LTD. 80-9, Mabook-Dong, Giheung-Gu Yongin-shi , Gyunggi-Do South Korea 446-912 FCC ID : TQ8-AC230JGAN

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 HYUNDAI MOBIS CO.,LTD. August 13, 2012 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TQ8 -AC230JGAN We hereby request confidential treatment of information accompanying this application as outlined below: COMNFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description CONFIDENTIAL 1 Block Diagram 2 Schematics 3 Operational Description SHORT-TERM CONFIDENTIAL (180 day) 4 External Photos 5 Internal Photos 6 Test -Setup Photos 7 User ’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Jong Tae Kim / Senior Research Engineer HYUNDAI MOBIS CO., LTD. 80-9, Mabook-Dong, Giheung-Gu Yongin-shi, Gyunggi-Do South Korea 446-912

FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 6 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 6 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 6 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 4 / 6 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 5 / 6 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 6 / 6

FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 2 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 1.1 PRODUCT LABEL FCC Model FCC EUT Type Serial No : AC230JGAN : TQ8-AC230JGAN : CAR AUDIO : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. 80-9, Mabook-Dong, Giheung-Gu, Yongin-Shi, Gyunggi-Do, 446-912 Korea MADE IN KOREA FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 2 1.2 Label Location Drawing The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Figure 1.2 LABEL LOCATION LABEL

FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 4 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 5 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 6 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 7 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 8 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 9 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 10 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 11 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 12 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 13 / 14 FCC ID: TQ8-AC230JGAN HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 14 / 14 BT Antenna BT Module

MPE CALCULATION For HYUNDAI MOBIS CO., LTD – ; Model: AC230JGAN FCC ID: TQ8-AC230JGAN RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 / 47 CFR §2.1091 EUT Frequency Band: 2402 – 2480 MHz Limits for General Population/Uncontrolled Exposure in the band of: 1500 – 100,000 MHz Power Density Limit: 1.0mW/ cm 2 ; Equation: S = PG / 4πR 2 or R = √PG / 4πS Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ Low Channel (2402 MHz): Power = -3.95 dBm, Antenna Gain = 0.1 dBi, Prediction distance 20cm S = 0.000082 mW/ cm 2 Result The Above Result had shown that Device complied with 1.0 mW/cm 2 Power density requirement for distance of 20cm. Completed By : Jong Suk LEE Date : August 13, 2012

FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR10 Date of Issue: August 13, 2012 EUT Type: CAR AUDIO FCC ID : TQ8-AC230JGAN Page 2 of 71 Version TEST REPORT NO. DATE DESCRIPTION HCTR1208FR10 August 13, 2012 - First Approval Report FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR10 Date of Issue: August 13, 2012 EUT Type: CAR AUDIO FCC ID : TQ8-AC230JGAN Page 3 of 71 Table of Contents 1. GENERAL INFORMATION ....................................................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................................. 4 3. TEST METHODOLOGY ............................................................................................................................ 5 3.1 EUT CONFIGURATION ............................................................................................................. 5 3.2 EUT EXERCISE ......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ............................................................................................. 5 3.4 DESCRIPTION OF TEST MODES ............................................................................................ 5 4. INSTRUMENT CALIBRATION .................................................................................................................. 6 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1 FACILITIES ................................................................................................................................ 6 5.2 EQUIPMENT .............................................................................................................................. 6 6. ANTENNA REQUIREMENTS.................................................................................................................... 6 7. SUMMARY OF TEST RESULTS ............................................................................................................... 7 8. FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1 PEAK POWER ........................................................................................................................... 8 8.2 BAND EDGES .......................................................................................................................... 15 8.3 FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 22 8.4 NUMBER OF HOPPING FREQUENCY .................................................................................. 30 8.5 TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 34 8.6 SPURIOUS EMISSIONS .......................................................................................................... 41 8.6.1 CONDUCTED SPURIOUS EMISSIONS .......................................................................... 41 8.6.2 RADIATED SPURIOUS EMISSIONS .............................................................................. 52 8.6.3 RADIATED RESTRICTED BAND EDGES ...................................................................... 60 8.7 POWERLINE CONDUCTED EMISSIONS ............................................................................... 70 9. LIST OF TEST EQUIPMENT ................................................................................................................... 71 FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR10 Date of Issue: August 13, 2012 EUT Type: CAR AUDIO FCC ID : TQ8-AC230JGAN Page 4 of 71 1. GENERAL INFORMATION Applicant Name: HYUNDAI MOBIS CO., LTD. Address: 80-9, Mabook-Dong, Giheung-Gu Yongin-shi Gyunggi-Do, 446-912 South Korea FCC ID: TQ8-AC230JGAN EUT: CAR AUDIO FCC Model name(s): AC230JGAN Additional Model name(s): AC2A0JGKN, AC231JGAN Date(s) of Tests: July 27, 2012 ~ August 03, 2012 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type CAR AUDIO FCC Model Name AC230JGAN Additional Model Name AC2A0JGKN, AC231JGAN Power Supply DC 12 V Frequency Range 2402 - 2480 MHz (Bluetooth) Transmit Power -3.95 dBm(0.40 mW) BT Operating Mode Nomal, EDR, AFH Modulation Type GFSK(Normal), π/4DQPSK and 8DPSK(EDR) Modulation Technique FHSS Number of Channels 79Channels, Minimum 20 Channels(AFH) Antenna Specification Manufacturer: CSR Antenna type: Inverted F Antenna Antenna gain: 0.1 dBi ※ 15.247 Requirements for Bluetooth transmitter ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudo-randomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR10 Date of Issue: August 13, 2012 EUT Type: CAR AUDIO FCC ID : TQ8-AC230JGAN Page 5 of 71 3. TEST METHODOLOGY The me…
