TQ8-ACB10GWGGDIGITAL CAR AUDIO SYSTEM

User manual FCC ID: ACB10GWGG Audio system 56 AUDIO (Without Touch Screen) (1)AUDIO button • Press to display the radio/media mode selection window. • When the mode selection window dis- plays, turn the [TUNE] knob to select the desired mode and then press the knob. • When the Mode popup is not selected in [MENU/CLOCK] Mode popup, press the [AUDIO] button on the control panel to change the mode. Each time you press the [AUDIO] but- ton on the control panel, the mode switches to radio  media in order. (2 ) PHONE button • Press to start connecting a mobile phone via Bluetooth. • After a Bluetooth phone connection is made, press to access the Bluetooth phone menu. (3)FAV button • While listening to the radio, press to move to next page of the preset list. (4)POWER button/VOL knob • Press to turn the system on or off. • Turn to the left or right to adjust the sys- tem sound volume. (5)SEEK/TRACK button • Change the station/track/file. • While listening to the radio, press and hold to search for a station. • While playing media, press and hold to rewind or fast forward (except for the Bluetooth audio mode). System layout – control panel ❈The actual features in the vehicle may differ from the illustration. K_QLe 19PE_4.0V[EE,EG]AUD_NVVH003:YF eng 4c-Audio.qxd 6/14/2018 2:15 PM Page 6 Audio system 75 (6)MENU button/CLOCK button • Press to access the menu screen for the current mode. • Press and hold to access the time setup screen. (7) TUNE knob/FI LE knob/ENTER button • While listening to the radio, turn to adjust the frequency. • While playing media, turn to search for a track/file (except for the Bluetooth audio mode). • During a search, press to select the current track/file. (8)Number buttons (1 RPT~ 4 BACK) • While listening to the radio, press to lis- ten to a saved radio station. • While listening to the radio, press and hold to save the current radio station to the preset. • In the USB/Bluetooth audio modes, press the [1 RPT] button to change the repeat play mode. Press the [2 SHFL] button to change the shuffle play mode. • Press the [4 BACK] button to return to the previous screen (except for the radio preset list). ❈The actual features in the vehicle may differ from the illustration. K_QLe 19PE_4.0V[EE,EG]AUD_NVVH003:YF eng 4c-Audio.qxd 6/14/2018 2:15 PM Page 7 Audio system 58 System layout – steering wheel remote control (Bluetooth ® equipped model) ❈The actual features in the vehicle may differ from the illustration. (1)MUTE button • Press to mute or unmute the sys- tem. • During a call, press to mute or unmute the microphone. • While playing media, press to pause or resume playback. (2)MODE button • Press to switch between radio and media modes. • Press and hold to turn the system on or off. (if equipped) (3)Volume lever • Push up or down to adjust the volume. (4)Up/Down lever • Change the station/track/file. • While listening to the radio, push to listen to the previous/next saved radio station. • While listening to the radio, push and hold to search for a station. • While playing media, push and hold to rewind or fast forward (except for the Bluetooth audio mode). (5)Call/Answer button • Press to start connecting a mobile phone via Bluetooth. • After a Bluetooth phone connec- tion is made, press to access your call history. Press and hold to dial the most recent phone number. When a call comes in, press to answer the call. • During a call, press to switch between the active call and the held call. Press and hold to switch the call between the system and the mobile phone. (6)Call end button K_QLe 19PE_4.0V[EE,EG]AUD_NVVH003:YF eng 4c-Audio.qxd 6/14/2018 2:15 PM Page 8 Audio system 95 WARNING - About driving •Do not operate the system while driving. Driving while distracted may result in a loss of vehicle control, potentially leading to an accident, severe personal injury, or death. The driver’s primary responsibility is the safe and legal operation of a vehicle, and any handheld devices, equipment, or vehicle systems which divert the dri- ver’s attention from this responsibility should never be used during operation of the vehicle. (Continued) (Continued) • Avoid watching the screen while driving. Driving while distracted may lead to a traffic accident. Stop your vehicle in a safe location before using functions that require multiple operations. • Stop your vehicle first before using your mobile phone. Using a mobile phone while driving may lead to a traffic accident. If necessary, use the Bluetooth Handsfree feature to make calls and keep the call as short as possible. • Keep the volume low enough to hear external sounds. Driving without the ability to hear external sounds may lead to a traffic accident. Listening to a loud volume for a long time may cause hear- ing damage. WARNING - About handling the system • Do not disassemble or modify the system. Doing so may result in an accident, fire, or electric shock. • Do not allow liquids or foreign substances to enter the sys- tem. Liquids or foreign sub- stances may cause noxious fumes, a fire, or a system mal- function. • Stop using the system if it malfunctions, such as no audio output or display. If you continue using the system when it is malfunctioning, it may lead to a fire, electric shock, or system failure. • Do not touch the antenna dur- ing thunder or lightning because such an act may cause electric shock. K_QLe 19PE_4.0V[EE,EG]AUD_NVVH003:YF eng 4c-Audio.qxd 6/14/2018 2:15 PM Page 9 Audio system 510 ✽NOTICE • If you experience any problems with the system, contact your place of purchase or dealer. • Placing the audio system within an electromagnetic environment may result in noise interference. CAUTION - About operating the system • Use the system with the engine running. Using the system for a long time when the engine is stopped may dis- charge the battery. • Do not install unapproved products. Using unapproved products may cause an error while using the system. System errors caused by installing unapproved prod- uct…

Text truncated - open the document above for the full version.

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 Letter of Declaration Product Equality We, Hyundai MOBIS Co., Ltd., as a manufacturer of following models, hereby declare that they have the following differences in supported features. Information of Variant Models ModelModel NameLOCALBTUIRDSDABSXMHDHANDLEFM/AM Code Basic ModelACB10GWGGGeneralOGENXXXXLHDA1 Variant Models ACB10GWDGDomesticOGENXXXXLHDA1 ACB11GWGGGeneralOGENOXXXLHDA1 ACB10GWGNGeneralOGENXXXXLHDA2 ACB10GWEGEuropeOGENXXXXLHDA1 ACB10GWEPEuropeOGENXXXXLHDA8 ACB11GWEPEuropeOGENOXXXLHDA8 AU210GWRPRussiaOGENOXXXLHDA8 ACB10GTMGMiddle EastOGENXXXXLHDA1 ACB11GTMGMiddle EastOGENOXXXLHDA1 ACB10GTMNMiddle EastOGENXXXXLHDA2 ACB10GTEGColombiaOGENXXXXLHDA5 ACB10GTEPEuropeOGENXXXXLHDA1 AU211GTEPEuropeOGENXXXXLHDA8 AU211GTFNMexicoOGENOXXXLHDA2 ACB11GTEPEuropeOGENOXXXLHDA8 ACB12GTEPEuropeOGENOOXXLHDA8 Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 CODEBANDFREQUENCY RANGESTEPLOCAL A1 FM 87.5-108.0㎒100㎑ DOM/GEN AM 531-1 602㎑9㎑ A2 FM 87.5-107.9㎒200㎑ NA/GEN AM 530-1 710㎑10㎑ A3 FM 87.5-108.0㎒50㎑ EU AM 522-1 620㎑9㎑ A4 FM 76.0-90.0㎒100㎑ JAPAN AM 522-1 629㎑9㎑ A5 FM 87.5-107.9㎒100㎑ COLOMBIA AM 530-1 710㎑10㎑ A6 FM 87.5-107.9㎒200㎑ GUAM AM 531-1 701㎑9㎑ A7 FM 76.1-107.9㎒100㎑ BRAZIL AM 530-1 710㎑10㎑ A8 FM 87.5-108.0㎒100㎑ EU AM 522-1 620㎑9㎑ _________________________ Seung Hoon Choe Representative Hyundai MOBIS Co., Ltd.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Hyundai MOBIS Co., Ltd. Address 203, Teheran-ro, Gangnam-gu, Seoul, 135-977, Korea Grantee Code TQ8 FCC ID -ACB10GWGG Authorized Contact Name Seung Hoon Choe Contact Email [email protected] Contact Phone +82-31-260-0098 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2020-05-07 Print Name: Seung Hoon Choe Title: Senior Researcher *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Hyundai MOBIS Co., Ltd. 203, Teheran‐ro, Gangnam‐gu, Seoul, 135-977, Korea Tel. 82‐31‐260‐0092 April 28, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Letter of Authorization We, Hyundai MOBIS Co., Ltd. hereby authorize SGS Korea Co., Ltd. (Joohee Park, Hyunchae You) to act on our behalf in all matters of certification. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Ant i‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). Any and all acts carried out by SGS Korea on our behalf shall have the same effect as acts of our own. This authorization is valid until further written notice. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd.

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. 82-3 1-2 60-0 092 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Hyundai MOBIS Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04- 1705. This provision will give Hyundai MOBIS Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short-Term 4 External Photos 5 Internal Photos 6 Test -Setup Photos 7 User ’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd. Request of Confidentiality for FCC ID: TQ8-ACB10GWGG April 28, 2020

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

FCC LABEL Information Model Name: ACB10GWGG, ACB10GWDG, ACB11GWGG, ACB10GWGN, ACB10GWEG, ACB10GWEP, ACB11GWEP, AU210GWRP, ACB10GTMG, ACB11GTMG, ACB10GTMN, ACB10GTEG, ACB10GTEP, AU211GTEP, AU211GTFN, ACB11GTEP, ACB12GTEP Hyundai MOBIS Co., Ltd. FCC ID:TQ8-ACB10GWGG FRONT TOP Non-removable LABEL LABEL LOCATION Hyundai MOBIS Co., Ltd. This device complies with part 15 of the FCC rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. MANUFACTURED BY HYUNDAI MOBIS PRODUCT LABEL

Internal photos of EUT Internal view of EUT Top view of Main PCB Bottom view of Main PCB Top view of Sub PCB1 Bottom view of Sub PCB1 Top view of LCD Bottom view of LCD View of Antenna & Module Pattern Antenna Bluetooth Module

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000562 Page:2of58 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) INDEX Table of ContentsPage 1. General Information ---------------------------------------------------------------------------------3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emission ------11 3. 20㏈Bandwidth ------------------------------------------------------------------------------------ 31 4. Maximum Peak Conducted Output Power ----------------------------------------------------36 5. Carrier Frequency Separation --------------------------------------------------------------------38 6. Number of Hopping Frequencies ----------------------------------------------------------------41 7. Time of Occupancy(Dwell Time) -----------------------------------------------------------------45 8. Antenna Requirement ------------------------------------------------------------------------------58 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000562 Page:3of58 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.: +82 31 688 0901 Fax No.: +82 31 688 0921 1.2. Details of Applicant Applicant:Hyundai Mobis Co., Ltd. Address:203, Teheran-ro, Gangnam-gu, Seoul, South Korea, 135-977 Contact Person:Choe, Seung-hoon Phone No.:+82 31 260 0098 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product DIGITAL CAR AUDIO SYSTEM Model Name ACB10GWGG Variant Model Names ACB10GWDG, ACB11GWGG, ACB10GWGN, ACB10GWEG, ACB10GWEP, ACB11GWEP, AU210GWRP, ACB10GTMG, ACB11GTMG, ACB10GTMN, ACB10GTEG, ACB10GTEP, AU211GTEP, AU211GTFN, ACB11GTEP, ACB12GTEP Power Supply DC 14.4 V Frequency Range 2 402㎒~ 2 480㎒(Bluetooth) Modulation Technique GFSK, π/4DQPSK, 8DPSK Number of Channels 79 channels (Bluetooth) Antenna Type Pattern antenna Antenna Gain -0.01㏈i SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000562 Page:4of58 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.5. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due Signal GeneratorR&SSMR40100272Jun. 07, 2019AnnualJun. 07, 2020 Signal GeneratorR&SSMBV100A255834Jun. 10, 2019AnnualJun. 10, 2020 Spectrum AnalyzerR&SFSV30103454Nov. 27, 2019AnnualNov. 27, 2020 Spectrum AnalyzerAgilentN9020AMY53421758Sep. 11, 2019AnnualSep. 11, 2020 Bluetooth TesterTESCOMTC-3000C3000C000142Nov. 26, 2019AnnualNov. 26, 2020 Directional CouplerKRYTAR152613162412Sep. 20, 2019AnnualSep. 20, 2020 High Pass Filter Wainwright Instrument GmbH WHK3.0/18G-10SS344May 21, 2019AnnualMay 21, 2020 High Pass Filter Wainwright Instrument GmbH WHNX7.5/26.5G-6SS15Jun. 07, 2019AnnualJun. 07, 2020 Low Pass FilterMini-CircuitsNLP-1200+V9500401023-2Jun. 05, 2019AnnualJun. 05, 2020 Power SensorR&SNRP-Z81101341Jun. 12, 2019AnnualJun. 12, 2020 DC Power SupplyR&SHMP2020020089489May 21, 2019AnnualMay 21, 2020 PreamplifierH.P.8447F2944A03909Aug. 07, 2019AnnualAug. 07, 2020 Signal Conditioning Unit R&SSCU-1810117Jun. 12, 2019AnnualJun. 12, 2020 PreamplifierMITEQ Inc.JS44-18004000-35-8P1546891May 13, 2019AnnualMay 13, 2020 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 15191519-039Aug. 22, 2019BiennialAug. 22, 2021 Bilog Antenna Schwarzbeck Mess-Elektronik VULB 9163396Mar. 21, 2019BiennialMar. 21, 2021 Horn AntennaR&SHF906100326Feb. 14, 2020AnnualFeb. 14, 2021 Horn Antenna Schwarzbeck Mess-Elektronik BBHA 9170BBHA9170431Sep. 10, 2018BiennialSep. 10, 2020 Test ReceiverR&SESU26100109Feb. 18, 2020AnnualFeb. 18, 2021 Turn TableInnco systems GmbHDS 1200 SN/AN.C.R.N/AN.C.R. ControllerInnco systems GmbH CONTROLLER CO3000-4P CO3000/963/383 30516/L N.C.R.N/AN.C.R. Antenna MastInnco systems GmbHMA4640-XP-ET MA4640/536/383 30516/L N.C.R.N/AN.C.R. Anechoic ChamberSY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/AN.C.R.N/AN.C.R. Coaxial CableSUCOFLEX104 (3 m)MY3258414Jan. 28, 2020 Semi- annual Jul. 28, 2020 Coaxial CableSUCOFLEX104 (10 m)MY3145814Jan. 28, 2020 Semi- annual Jul. 28, 2020 Coaxial CableRosenbergerLA1-C006-1500131014 04/20Feb. 23, 2020 Semi- annual Aug. 23, 2020 Coaxial CableRosenbergerLA1-C006-1500131014 06/20Feb. 23, 2020 Semi- annual Aug. 23, 2020 Coaxial CableRosenbergerLA1-C006-1500131014 11/20Feb. 23, 2020 Semi- annual Aug. 23, 2020 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000562 Page:5of58 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.6. Declaration by the Manufacturer - Adaptive Frequency Hopping is supported and use at least 20 channels. 1.7. Information about the FHSS characteristics: 1.7.1. Pseudorandom Frequency Hopping Sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is 1 600 hops/s. 1.7.2. Equal Hopping Frequency Use The channels of this system will be used eq…

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000563 Page:2of7 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) INDEX Table of ContentsPage 1. General Information --------------------------------------------------------------------------------3 2. RF Exposure Evaluation --------------------------------------------------------------------------6 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000563 Page:3of7 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone:+82 31 688 0901 FAX:+82 31 688 0921 1.2. Details of Applicant Applicant:Hyundai Mobis Co., Ltd. Address:203, Teheran-ro, Gangnam-gu, Seoul, South Korea, 135-977 Contact Person:Choe, Seung-hoon Phone No.:+82 31 260 0098 1.3. Details of Manufacturer Company:Same as applicant Address:Same as applicant 1.4. Description of EUT Kind of Product DIGITAL CAR AUDIO SYSTEM Model Name ACB10GWGG Variant Model Names ACB10GWDG, ACB11GWGG, ACB10GWGN, ACB10GWEG, ACB10GWEP, ACB11GWEP, AU210GWRP, ACB10GTMG, ACB11GTMG, ACB10GTMN, ACB10GTEG, ACB10GTEP, AU211GTEP, AU211GTFN, ACB11GTEP, ACB12GTEP Power Supply DC 14.4 V Frequency Range 2 402㎒~ 2 480㎒(Bluetooth) Modulation Technique GFSK, π/4DQPSK, 8DPSK Number of Channels 79 channels (Bluetooth) Antenna Type Pattern antenna Antenna Gain -0.01㏈i SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000563 Page:4of7 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.5. Information of Variant Models ModelModel NameLOCALBTUIRDSDABSXMHDHANDLEFM/AM Code Basic ModelACB10GWGGGeneralOGENXXXXLHDA1 Variant Models ACB10GWDGDomesticOGENXXXXLHDA1 ACB11GWGGGeneralOGENOXXXLHDA1 ACB10GWGNGeneralOGENXXXXLHDA2 ACB10GWEGEuropeOGENXXXXLHDA1 ACB10GWEPEuropeOGENXXXXLHDA8 ACB11GWEPEuropeOGENOXXXLHDA8 AU210GWRPRussiaOGENOXXXLHDA8 ACB10GTMGMiddle EastOGENXXXXLHDA1 ACB11GTMGMiddle EastOGENOXXXLHDA1 ACB10GTMNMiddle EastOGENXXXXLHDA2 ACB10GTEGColombiaOGENXXXXLHDA5 ACB10GTEPEuropeOGENXXXXLHDA1 AU211GTEPEuropeOGENXXXXLHDA8 AU211GTFNMexicoOGENOXXXLHDA2 ACB11GTEPEuropeOGENOXXXLHDA8 ACB12GTEPEuropeOGENOOXXLHDA8 CODEBANDFREQUENCY RANGESTEPLOCAL A1 FM 87.5-108.0㎒100㎑ DOM/GEN AM 531-1 602㎑9㎑ A2 FM 87.5-107.9㎒200㎑ NA/GEN AM 530-1 710㎑10㎑ A3 FM 87.5-108.0㎒50㎑ EU AM 522-1 620㎑9㎑ A4 FM 76.0-90.0㎒100㎑ JAPAN AM 522-1 629㎑9㎑ A5 FM 87.5-107.9㎒100㎑ COLOMBIA AM 530-1 710㎑10㎑ A6 FM 87.5-107.9㎒200㎑ GUAM AM 531-1 701㎑9㎑ A7 FM 76.1-107.9㎒100㎑ BRAZIL AM 530-1 710㎑10㎑ A8 FM 87.5-108.0㎒100㎑ EU AM 522-1 620㎑9㎑ SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000563 Page:5of7 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.6. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0005632020.04.20Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000563 Page:6of7 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2. RF Exposure Evaluation 2.1. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) 2.1.1. Friis transmission formula: Pd = (Pout*G)/(4*pi*R 2 ) Where Pd = power density in㎽/㎠ Pout = output power to antenna in㎽ G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in㎝ Pd the limit of MPE, 1㎽/㎠. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Frequency Range (㎒) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (㎽/㎠) Average Time (A) Limits for Occupational/Controlled Exposure 0.3-3.06141.63*1006 3.0-301842/f4.89/f*900/f 2 6 30-30061.40.1631.06 300-1 500--f/3006 1 500-100 000--56 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.346141.63*10030 1.34-30824/f2.19/f*180/f 2 30 30-30027.50.0730.230 300-1 500--f/150030 1 500-100 000 -- 1.030 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000563 Page:7of7 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2.1.2. Test Result of RF Exposure Evaluation Test Item：RF Exposure Evaluation Data Test Mode：Normal Operation 2.1.3. Output Power into Antenna & RF Exposure Evaluation Distance - Maximum tune up tolerance Frequency (㎒) Output Average Power to Antenna (㏈m) Antenna Gain (㏈i) Power Density at 20㎝ (㎽/㎠) Limits (㎽/㎠) 2 402 ~ 2 4804-0.010.000 4991 Note; - The power density Pd (5th column) at a distance of 20㎝calculated from the friis transmission formula is far below the limit of 1㎽/㎠. - This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. - This equipment should be installed and operated with minimum 20㎝between the radiator and your body. - The antenna gain of this transmitter is less than 6㏈i and must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC. - According to KDB 447498 D01 RF Exposure Guidance 4.1.d, Output Average Power to Antenna applied Maxi…

Text truncated - open the document above for the full version.

Test setup photos of EUT 1. Orthogonal plane of EUT - The testing was set in the below orthogonal plane and measured. X-axis 2. Photo of Radiated Spurious Emission Test (Below 1㎓) 3. Photo of Radiated Spurious Emission Test (Above 1㎓)
