TQ8-ADB10S2AN0DISPLAY CAR SYSTEM

1 [This guide covers specifications for all vehicle models, including optional specifications, and is based on the latest version of system software. [Your system's functions and specifications are subject to change without prior notice for performance improvement. [The functions and services described in this guide are subject to change without prior notice for performance improvement. If the system software is updated, the screenshots in this guide may appear different than the actual images on the system. [You can view the up-to-date information about changed functions and services from the web manual. [The functions and services described in this guide may differ from those provided in your vehicle. For precise information related to your vehicle, refer to the owner's manual or catalog of your vehicle. [Your system is not compatible with the system software for regions outside of the country of purchase. Available information for users Car Infotainment System Quick Reference Guide (Print) This guide contains basic information to use your system including component names and functions. To use your system correctly and safely, read this guide before use. Car Infotainment System User's Manual (Web) This guide is a web manual you can access by scanning a QR code in the Quick Reference Guide or on your system′s screen. This guide introduces your system's functions and explains how to use them. Car Infotainment System User's Manual DISPLAY CAR SYSTEM 2 Symbols used in this guide Warning Indicates important information related to user safety. Failure to follow warnings may result in death or serious personal injury. Caution Indicates important information related to user safety. Failure to follow cautions may result in personal injury, or damage or malfunction your vehicle. Note Indicates helpful information for convenient use. (if equipped) Indicates descriptions for optional features, which may not be available on your specific vehicle depending on the model or trim level. This guide covers specifications for all vehicle models, including optional specifications. It may include descriptions for features that are not equipped in your vehicle or are unavailable for your vehicle model. Safety warnings For safety, follow the instructions below. Failure to do so may increase the risk of a traffic accident, which may result in death or personal injury. ÜAbout driving Avoid watching the screen while driving. •Driving while distracted may lead to a traffic accident. •Stop your vehicle in a safe location before using functions that require multiple operations. Stop your vehicle first before using your mobile phone. •Using a mobile phone while driving may lead to a traffic accident. •If necessary, use the Bluetooth Handsfree feature to make calls and keep the call as short as possible. Keep the volume low enough to hear external sounds. •Driving without the ability to hear external sounds may lead to a traffic accident. •Listening to a loud volume for a long time may cause hearing damage. ÜAbout handling the system Do not disassemble or modify the system. •Doing so may result in an accident, fire, or electric shock. Do not allow liquids or foreign substances to enter the system. •Liquids or foreign substances may cause noxious fumes, a fire, or a system malfunction. Stop using the system if it malfunctions, such as no audio output or display. •If you continue using the system when it is malfunctioning, it may lead to a fire, electric shock, or system failure. 3 ÛNote If you experience any problems with the system, contact one of our authorized service centers. Safety cautions For safety, follow the instructions below. Failure to do so may result in personal injury or damage to the system. ÝAbout operating the system Use the system with the engine running. •Using the system for a long time when the engine is stopped may discharge the battery. Do not install unapproved products. •Using unapproved products may cause an error while using the system. •System errors caused by installing unapproved products are not covered under the warranty. ÝAbout handling the system Do not apply excessive force to the system. •Excessive pressure on the screen may damage the LCD panel or the touch panel. When cleaning the screen or button panel, make sure to stop the engine and use a soft, dry cloth. •Wiping the screen or buttons with a rough cloth or using solvents (alcohol, benzene, paint thinner, etc.) may scratch or chemically damage the surface. If you attach a liquid-type air freshener to the fan louver, the surface of the louver may become deformed due to the flowing air. ÛNote If you experience any problems with the system, contact one of our authorized service centers. 4 1 System overview Component names and functions 1-2 Control panel 1-2 Steering wheel remote control 1-3 Rear seat remote control (if equipped) 1-4 Turning the system on or off 1-5 Turning on the system 1-5 Turning off the system 1-6 Using the touch screen 1-6 Getting to know the Home screen 1-8 Getting familiar with the Home screen layout 1-8 Changing the Home screen widgets 1-9 Changing the Home screen menu icons 1-9 Getting to know the All Menus screen 1-10 Getting familiar with the All Menus screen layout 1-10 Rearranging the All Menus screen 1-10 Using Favorites 1-11 Adding favorite items 1-11 Rearranging the items in Favorites 1-11 Deleting favorite items 1-11 2 Useful functions Using phone projection 2-2 Connecting your Android smartphone via Android Auto 2-2 Connecting your iPhone via Apple CarPlay 2-4 Getting to know the driving assistance screen 2-6 Rear view screen 2-6 Steering-interactive camera 2-7 Surround view monitor (if equipped) 2-7 Using the climate control system (if equipped) 2-9 Viewing driving information 2-10 3 Radio Listening to the radio 3-2 Turning on the radio 3-2 Changing the radio mode 3-2 Scanning for available radio stations 3-2 Searching for radio stations 3-3 Saving radio stations 3-3 Listening to saved radio st…

Text truncated - open the document above for the full version.

HYUNDAI MOBIS CO., LTD. 203 Teheran-ro, Gangnam-gu, Seoul, Korea, 135-977 Date: Apr 28, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Guenki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: TQ8-ADB10S2AN0 including signing of all documents relating to these matters. Any and all acts carried out by Guenki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from HYUNDAI MOBIS CO., LTD. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seung Hoon Choe Manager

HYUNDAI MOBIS CO., LTD. 203 Teheran-ro, Gangnam-gu, Seoul, Korea, 135-977 Date: Apr 28, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: TQ8-ADB10S2AN0 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, HYUNDAI MOBIS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give HYUNDAI MOBIS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Seung Hoon Choe Manager

Hyundai Mobis Co., Ltd. #203, Teheran-ro, Gangnam-gu, Seoul, 06141 Republic of Korea Tel. 82-31-260-2707 / Fax. 82-31-280-2764 Date: February 12, 2020 Subject: Letter of Declaration FCC ID: TQ8-ADB10S2AN0 Dear Sirs, Family model added only LTE function compare with Basic model. The approved module(FCC ID: YZP-VL3010) is installed in the product. There is no difference of electrical performance and circuit performance. Basic model name Family models name ADB10S2AN ADB40S2AN This is the difference of the model used in the exporting country. There is no difference of electrical performance and circuit performance. Basic model name Family models name ADB10S2AN ADB20S2AN, ADB10S1GG, ADB11S1GG, ADB12S1GG, ADB13S1GG, ADB10S1MG, ADB10S1GN, ADB10S1GL, ADB10S1GP, ADB11S1MG, ADB12S1MG, ADB10S1EG, ADB12S1EG, ADB10S1EP, ADB11S1EP, ADB12S1EP, ADB13S1EP, ADB14S1EP, ADBC0S1EP, ADBC1S1EP, ADB10S1UA, ADB10S1RP, ADB20S2FN Sincerely yours, __________________________________ Seoug-Hoon, Choe / Representative / Hyundai MOBIS Co., Ltd.

FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3

SAMPLE LABEL & LOCATION MODEL: ADB40S2AN 14.4 V 4 Ω10 A AM 531 ~ 1602 kHz MADE IN KOREA This device complies with part 15 of the FCC Rules. O peration is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. UNDER LICENSE OF STAAR S.A. , BRUXELLS BELGIUM: DOLBY NOISE REDUCTION MANUFACTURED UNDER LICENSE FROM DOLBY LABORATORIES LICENSING CORPORATION. "DOLBY" AND THE DOUBLE-D SYMBOL ARE TRADEMARKS OF DOLBY LABORATORIES LICENSING CORPORATION MANUFACTURED : HYUNDAI MOBIS CO., LTD. Copyright Ⓒ 2020, DT&C Co., Ltd. FM 87.5 ~ 108 MHz FCC ID: TQ8-ADB10S2AN0 Contains FCC ID: YZP-VL3010 FCC ID: TQ8-ADB10S2AN0 Model: ADB40S2AN

FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 <SUBPCB Module> FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 5

FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 6 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 7 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 8 <MAIN PCB Module> FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 9 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 10

FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 11 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 12 FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 13 <BT Antenna> <WLAN Antenna> FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 14 < SUBPCB Module > FCC ID : TQ8-ADB10S2AN0 Model : ADB10S2AN0 Copyright Ⓒ 2020, DT&C Co., Ltd. View 15 < MAIN PCB Module >

FCC ID: TQ8-ADB10S2AN0 Model: ADB10S2AN0 RF function or Mode Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) Bluetooth(1Mbps) 2402.00 ~ 2480.00 2.50 -0.18 2.32 1.707 0.0004 1.000 Bluetooth(2,3Mbps) 2402.00 ~ 2480.00 -2.50 -0.18 -2.68 0.540 0.0002 1.000 ~~~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 1.707 S= Maximum power density(mW/cm 2 ) 0.0004 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the anten n MPE Calculation : Bluetooth Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below.Note: Please refer to the operation description for Max tune-up power. FCC ID: Model: ADB10S2AN0 Mode(Worst case) Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) 802.11b 2412.00 ~ 2462.00 11.50 -0.01 11.49 14.093 0.0029 1.000 802.11a 5180.00 ~ 5240.00 9.00 -0.61 8.39 6.903 0.0014 1.000 802.11a 5260.00 ~ 5320.00 9.00 -0.18 8.82 7.621 0.0016 1.000 802.11a 5500.00 ~ 5720.00 8.00 -0.77 7.23 5.285 0.0011 1.000 802.11n(HT20) 5745.00 ~ 5825.00 7.50 -0.18 7.32 5.396 0.0011 1.000 ~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : TQ8-ADB10S2AN0 MPE Calculation : WLAN Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below.Note: Please refer to the operation description for Max tune-up power. ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 6.903 S= Maximum power density(mW/cm 2 ) 0.001 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the anten n ▪▪ RF function or mode(Worst case) BT + WLAN(2.4GHz) 1.0000 WLAN 2.4GHz 0.0004 0.0032 - 0.0004 0.0032 ----- 0.0036 BT Σ of MPE ratios 2.4GHz 0.0004 2.4GHz 0.0032 - - -- Power Density (mW/cm2) - Band(Worst case) MPE ratio (Power Density/Requirement) Requirement (mW/cm2) 1.0000 Worst case(MPE ratio) Worst case for simultaneous operations The exposure condition of this device is compliant with FCC rul es. Conclusion : Σ of MPE ratios ≤ 1 ▪ Requirment = - Model: ADB10S2AN0 - TQ8-ADB10S2AN0 FCC ID: RF Exposure Compliance for simultaneous operations
