TQ8-AM1A1C6ANDIGITAL CAR AUDIO SYSTEM

4 1 Features of your vehicle ■ CD Player K_UMa_B3.0:NC 1/8/2015 1:13 PM Page 1 Features of your vehicle 24 SYSTEM CONTROLLERS AND FUNCTIONS Audio Head Unit 1. (EJECT) • Ejects the disc. 2. • Convert to Radio mode. • Each time the key is pressed,the mode is changed in order of FM1, FM2, AM, XM1, XM2, XM3. 3. • Convert to Media Mode • Each time the key is pressed, the mode is changed in order of CD, USB(iPod ® ), AUX, My Music, BT Audio. 4. • Converts to Phone mode ❈When a phone is not connected, the connection screen is displayed. 5. POWER/VOL knob • Power : Press to turn power on/ off. • Volume : Turn left/right to control volume. 6. • When pressed shortly(under 0.8 seconds) - Radio mode : plays previous/next frequency. - Media (CD/USB/iPod ® /My Music) modes : changes the track, Song(file) • When pressed and held (Over 0.8 seconds) - Radio mode : continuously changes the frequency. Upon release, plays the current frequency. - Media(CD/USB/iPod ® /My Music) modes : rewinds or fast forwards the track or file - During a Handsfree call, controls the call volume. 7. • HD RADIO™ : Channel Change • XM RADIO™ : Category Search • CD/USB/MP3 mode : Search Folder 8. RESET • Forced system termination and sys- tem restart. CAT FOLDER SEEK TRACK PHONE MEDIA RADIO K_UMa_B3.0:NC 1/8/2015 1:14 PM Page 2 4 3 Features of your vehicle 9. • Turns the monitor display on/off. 10. • Shortly press the key(under 0.8 seconds) : Display time screen • Press and hold the key(over 0.8 seconds) : Move to the time setting mode 11. • Radio Mode : previews all receiv- able broadcasts for 5 seconds each • Media (CD/USB/My Music) modes : previews each song (file) for 10 seconds each. 12. • Converts to Setup mode. 13. TUNE knob • Radio mode : turn to change broad- cast frequencies. • Media (CD/USB/iPod ® /My Music) modes : turn to search tracks/chan- nels/files. 14. DISC-IN LED • LED that indicates whether a disc is inserted. CLOCK SETUP SCAN DISP K_UMa_B3.0:NC 1/8/2015 1:14 PM Page 3 Features of your vehicle 44 Steering remote controller 1. VOLUME • Used to control volume. 2. MUTE • Mutes audio volume. 3. SEEK • When pressed shortly (under 0.8 sec- onds) - Radio mode : searches broadcast frequencies saved to presets. - Media(CD/ USB/ iPod ® / My Music/ BT Audio) modes : changes the track, file or chapter. • When pressed and held (over 0.8 sec- onds) - Radio mode, automatically search- es broadcast frequencies and channels - Media(CD/USB/iPod ® /My Music) modes, rewinds or fast forwards the track or song(file) - BT Audio mode may not be sup- ported in some mobile phones. 4. MODE • Each time this key is pressed, the mode is changed in order of FM1➟FM2➟AM➟XM1➟XM2➟XM3 ➟CD➟USB or iPod ® ➟AUX➟My Music➟BT Audio • If the media is not connected or a disc is not inserted, corresponding modes will be disabled. 5. • When pressed shortly - Starts voice recognition - When selecting during a voice prompt, stops the prompt and converts to voice command wait- ing state • When pressed and held (over 0.8 sec- onds) - Ends voice recognition K_UMa_B3.0:NC 1/8/2015 1:14 PM Page 4 4 5 Features of your vehicle 6. • When pressed shortly - When pressed in the phone screen, displays call history screen - When pressed in the dial screen, makes a call - When pressed in the incoming call screen, answers the call - When pressed during call waiting, switches to waiting call (Call Waiting) • When pressed and held (over 0.8 sec- onds) - When pressed in the Bluetooth ® Wireless Technology Handsfree wait mode, redials the last call - When pressed during a Bluetooth ® Wireless Technology Handsfree call, switches call back to mobile phone (Private) - When pressed while calling on the mobile phone, switches call back to Bluetooth ® Wireless Technology Handsfree (Operates only when Bluetooth ® Wireless Technology Handsfree is connected) 7. • Ends phone call K_UMa_B3.0:NC 1/8/2015 1:14 PM Page 5 Features of your vehicle 64 RADIO MODE Basic Mode Screen 1. Mode Display Displays currently operating mode. 2. Frequency Displays the current frequency. 3. Preset Displays current preset number [1] ~ [6]. 4. Preset Display Displays preset buttons. 5. Info Displays broadcast information. 6. HD Changes HD Radio channels. 7. A.Store Automatically saves frequencies with superior reception to Preset buttons. K_UMa_B3.0:NC 1/8/2015 1:14 PM Page 6 ✽NOTICE - USING CDs • This device has been manufac- tured to be compatible with soft- ware bearing the following logo marks. • Do not clean discs with chemical solutions, such as record sprays, antistatic sprays, antistatic liq- uids, benzene, or thinners. • After using a disc, put the disc back in its original case to prevent disc scratches. • Hold discs by their edges or with- in the center hole to prevent dam- ages to disc surfaces. • Do not introduce foreign sub- stances into the disc insert/eject slot. Introducing foreign substances could damage the device interior. • Do not insert two discs simultane- ously. • When using CD-R/CD-RW discs, differences in disc reading and playing times may occur depend- ing on the disc manufacturer, pro- duction method and the recording method as used by the user. (Continued) (Continued) • Clean fingerprints and dust off the disc surface (coated side) with a soft cloth. • The use of CD-R/CD-RW discs attached with labels may result in disc slot jams or difficulties in disc removal. Such discs may also result in noise while playing. • Some CD-R/CD-RW discs may not properly operate depending on the disc manufacturer, produc- tion method and the record method as used by the user. If problems persist, trying using a different CD as continued use may result in malfunctions. • The performance of this product may differ depending on the CD- RW Drive Software. • Copy-protected CDs such as S- type CDs may not function in the device. DATA discs cannot be played. (However, such discs may still operate but will do so abnor- mally.) (Continued) (Continued) • Do not use abnormally shaped discs (8cm, heart-shaped,…

Text truncated - open the document above for the full version.

HYUNDAI MOBIS CO., LTD. 203 Teheran-ro, Gangnam-gu, Seoul, Korea, 135-977 Date: January 20, 2015 Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: TQ8-AM1A1C6AN including signing of all documents relating to these matters. Any and all acts carried out by DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from HYUNDAI MOBIS CO., LTD. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seung Hoon Choe Manager

DT&C Co., Ltd. 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935 Date: January 20, 2015 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

HYUNDAI MOBIS CO., LTD. 203 Teheran-ro, Gangnam-gu, Seoul, Korea, 135-977 Date: January 20, 2015 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: TQ8-AM1A1C6AN To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, HYUNDAI MOBIS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give HYUNDAI MOBIS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Seung Hoon Choe Manager

Hyundai Mobis Co., Ltd. #203, Teheran-ro, Gangnam-gu, Seoul, 135-977 Republic of Korea Tel. 82-31-288-5232 / Fax. 82-31-280-2764 Date : January 20, 2015 Subject: Letter of Declaration Dear Sirs, We declare that additional model due to the additional exporter. There is no difference in Hardware and Software between Basic model and family models. Basic model name Family models name AM1A1C6AN AM111C6GN Sincerely yours, __________________________________ Seoug-Hoon, Choe /Manager /Hyundai MOBIS Co., Ltd.

FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. Page 3 / 3 View 3

FCC ID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase Label locate Top side This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation of the device. - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label.

FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 1 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 2 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 3 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 4 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 5 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 6 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 7 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 8 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 9 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 10 FCCID: TQ8-AM1A1C6AN Copyright Ⓒ 2015, DT&C Co., Ltd. View 11 <Module> <Antenna>

-~ - -±&dBm ) - - The MPE calculation for this exposure is shown below. ▪=+- =+ == - ▪S=- = = MHz MPE Calculations :(Bluetooth) HYUNDAI MOBIS Co., Ltd. FCCID: TQ8-AM1A1C6AN Frequency range :2402MHz2480 dBmMin. Measured RF output power :dBm Target Power & Tolerance :dBm 2.59 2.001.50.5 Maximum antenna peak gain :dBi Maximum output power for the calculation :3.50dBm dB (Max. 3.50 3.5 EIRPPGNote 3.50dBm3.50dBi The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. P = Power input to the antenna(dBm) 7.00dBm5.012mWG = Power gain of the antenna(dBi) Power density at the specific separation EIRP / ( 4 R 2 π ) Note 5.012 / ( 4 X 20 2 X π )S = Maximum power dencity(mW/cm 2 ) The maximum permissible exposure(MPE) of the general population/Uncontrolled for this device is 1.0 mW/cm 2 . 0.000998 mW/cm 2 EIRP = Equivalent Isotropic Radiated Power(mW) R = Distance to the center of the radiation of the antenna(20cm) Conclusion : The exposure condition of this device is compliant with FCC rules. TRF-RF-206(01)140415
