Features of your vehicle 1304 ✽✽ NOTICE If you install an aftermarket HID headlamp, your vehicle's audio and electronic device may malfunction. Antenna Roof antenna Your vehicle uses a roof antenna to receive both AM and FM broadcast signals. This antenna is removable. To remove the antenna, turn it coun- terclockwise. To install the antenna, turn it clockwise. AUDIO SYSTEM OHM048154 ■Type A■Type B CAUTION Before entering a place with a low height clearance or a car wash, remove the antenna by rotating it counterclockwise. If not, the antenna may be dam- aged. 4131 Features of your vehicle Steering wheel audio control (if equipped) The steering wheel may incorporate audio control buttons. 1. VOLUME (VOL+/-) • Push the lever upward (+) to increase the volume. • Push the lever downward (-) to decrease the volume. 2. PRESET/SEEK (/) The SEEK/PRESET button has dif- ferent functions based on the system mode. For the following functions the button should be pressed for 0.8 second or more. RADIO mode It will function as the AUTO SEEK select button. CD/USB/iPod mode It will function as the FF/REW button. If the SEEK/PRESET button is pressed for less than 0.8 second, it will work as follows in each mode. RADIO mode It will function as the PRESET STA- TION buttons. CD/USB/iPod mode It will function as TRACK UP/DOWN button. 3. MODE Press the button to change audio source. - FM(1~2) ➟ AM ➟ SAT(1~3) ➟ CD ➟ USB AUX(iPod) FM... 4. MUTE (if equipped) • Press the button to mute the sound. • Press the button to turn off the microphone during a telephone call. Detailed information for audio control buttons are described in the following pages in this section. OMD040139N OMD040139 ■Type A ■Type B CAUTION Do not operate audio remote control buttons simultaneously. Features of your vehicle 1324 ■■ CD Player : AC100A5KN, AC180A5KN, AC110A5KN, AC1B2A5KN, AC180A5AN, AC181A5AN, AC1B0A5AN, AC1B1A5AN, AC103A5GG, AC110A5GG ❋No logo will be shown if the Bluetooth ® Wireless Technology feature is not supported. 4133 Features of your vehicle SYSTEM CONTROLLERS AND FUNCTIONS ❈Display and settings may differ depending on the selected audio. Audio Head Unit 1.(EJECT) • Ejects the disc. 2. • Changes to FM/AM/XM mode. • Each time the key is pressed, the mode is changed in order of FM1 ➟ FM2 ➟AM ➟XM1 ➟XM2 ➟XM3. (❈For XM Radio equipped Model) • Each time the key is pressed,the mode is changed in order of FM1 ➟FM2 ➟AM. ❈In Setup>Display, the radio pop up screen will be displayed when [Mode Pop up] is turned . When the pop up screen is dis- played, use the TUNE knob or keys ~ to select the desired mode. 3. • Changes to CD, USB MP3, iPod, BT MP3, AUX modes. • Each time the key is pressed, the mode is changed in order of CD, USB, iPod, AUX, My Music, BT Audio(hif equipped). ❈In Setup>Display, the media pop up screen will be displayed when [Mode Pop up] is turned . When the pop up screen is dis- played, use the TUNE knob or keys ~ to select the desired mode. 4.(❈For Bluetooth ® Wireless Technology equipped Model) • Operates Phone Screen ❈When a phone is not connected, the connection screen is displayed. PHONE 51 On MEDIA 61 On RADIO Features of your vehicle 1344 5., • Radio Mode : Automatically search- es for broadcast frequencies. • CD, USB, iPod, My Music modes - Shortly press the key (under 0.8 seconds): Moves to next or previ- ous song (file) - Press and hold the key (over 0.8 seconds): Rewinds or fast-for- wards the current song. • BT Audio mode : Moves to next or previous song(file) 6. PWR/VOL knob •Power : Turns power On/Off by pressing the knob •Volume : Sets volume by turn- ing the knob left/right 7.~ (Preset) • Radio Mode: Saves frequencies (channels) or receives saved fre- quencies (channels) • CD, USB, iPod, My Music mode - : Repeat - : Random • In the Radio, Media, Setup, and Menu pop up screen, the number menu is selected. 8. • Each time the button is shortly pressed (under 0.8 seconds), it sets the screen Off ➟Screen On ➟ Screen Off ❈Audio operation is maintained and only the screen will be turned Off. In the screen Off state, press any key to turn the screen On again. DISP 2 1 61 TRACK SEEK 4135 Features of your vehicle 9. • Radio Mode - Shortly press the key (under 0.8 seconds): Previews each broadcast for 5 seconds each. - Press and hold the key (over 0.8 seconds): Previews the broadcasts saved in Preset ~ for 5 seconds each. ❈Press the key again to continue listening to the current frequency. ❈XM Radio does not support the Preset scan feature. • CD, USB, iPod mode - Shortly press the key (under 0.8 seconds): Previews each song (file) for 10 seconds each ❈Press the key again to continue listening to the current song (file). 10. • Shortly press the key (under 0.8 seconds) : Moves to the Display, Sound, Clock, Phone, System set- ting modes • Press and hold the key (over 0.8 seconds) : Move to the Time set- ting screen 11. • Displays menus for the current mode. 12., • Radio Mode - XM RADIO : Category Search • MP3, CD, USB mode : Folder Search • iPod mode: Moves to parent folder ❈May differ depending on the selected audio. 13.TUNE knob • Radio mode : Changes frequency by turning the knob left/right • CD, USB, iPod mode: Searches songs (files) by turning the knob left/right ❈When the desired song is displayed, press the knob to play the song. • Moves focus in all selection menus and selects menus. FOLDER CAT MENU SETUP CLOCK SCAN SCAN 61 SCAN Features of your vehicle 1364 Audio Head Unit 14. • Changes to FM mode. • Each time the key is pressed, the mode changed in order of FM1 ➟ FM2 ➟AM 15. • Changes to XM mode. • Each time the key is pressed, the mode changed in order of XM1 ➟ XM2 ➟XM3 SAT FM/AM 4137 Features of your vehicle DISPLAY SETTINGS Press the key Select [Display] through TUNE knob or key Select menu through TUNE knob Mode Pop up [Mode Pop up] Changes / selection mode • During On state, press the or key to display the mode change pop up screen. Text Scroll [Text Scroll] Set / •: Maintains scroll •: Scrolls on…
