TQ8-AN340ETANCAR AVN

 Warnings and Cautions  Key Product Features  Component Names and Functions  Using the System for the First Time 1 General  Even when receiving route guidance from the Navigation system, please abide by actual traffic and road regulations. Following only the Navigation route guidance may lead to violations of actual traffic and road regulations and lead to traffic accidents.  When checking the current vehicle speed, first check the speedometer rather than the speed displayed within the Navigation.  Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents.  Do not operate the Navigation system while driving, such as entering POIs or conducting route searches. Such acts could lead to accidents. Park the vehicle before operating the device.  Do not disassemble, assemble, or modify the AVN system. Such acts could result in accidents, fire, or electric shock.  Using phone features while driving may distract drivers from paying attention to traffic conditions and result in traffic accidents. Use phone features only after the vehicle has been parked. Safety Warnings  Heed caution not to spill water or introduce foreign objects into the device. Such acts could lead to smoke, fire, or product malfunction.  Please refrain from use if the screen is blank or no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (fires, electric shock) or product malfunctions.  Do not touch the antenna during thunder or lightening as such acts may lead to lightning induced electric shock.  Do not stop or park in parking-restricted areas to operate the product. Such acts could lead to traffic accidents. The video screen will not operate when the vehicle is in motion. For your safety, first park the vehicle to watch or view the screen.  Some Non-video features may also not operate when the vehicle is in motion. These features will operate only when the vehicle has been parked. Warnings and Cautions In some instances, the navigation may provide guidance through restricted areas. Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. In addition, some features may not work for your safety when the vehicle is in motion. These features will operate only when the vehicle has been parked. Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to accidents. Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.) If you want to change the position of device installation, please inquire with your place of purchase or service maintenance center. Technical expertise is required to install or disassemble the device. Safety Cautions Turn on the car ignition before using this device. Do not operate the Audio Video Navigation system for long periods of time with the ignition turned off as such operations may lead to battery discharge. Upon using the Audio Video Navigation system for more than 10 minutes with the car engine turned off, the following warning will be displayed. After 10 minutes, the warning will be displayed for 5 seconds every 1 minute. Do not subject the device to severe shock or impact Direct pressure onto the front side of the monitor may cause damage to the LCD or touch screen. When cleaning the device, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents (alcohol, benzene, thinners, etc.) as such materials may damage the device panel or cause color/quality deterioration. When experiencing product malfunctions, inquire with your place of purchase or service maintenance center. Warnings and Cautions Key Product Features This device is an all-in-one Driver Information System equipped with a multifunctional DVD player, Navigation, Bluetooth Handsfree, Blue Link and various other features. The WIDE VGA LCD provides a high quality resolution to both driver and passengers while the powerful and rich sound system adds to driving enjoyment. Display Wide TFT-LCD Display Provides high quality video through a Wide TFT-LCD Display using an LED Back Light AV Support for various Media Formats • Support for various media formats, including HD Radio, XM Radio, Audio/MP3/Video CD, DVD, AUX • Supports USB, iPod, and Bluetooth Audio Streaming modes Jukebox Supports copy and play of music, video, image stored within USB into Jukebox (internal memory) mode (Max. 30GB) Gracenote When playing music, automatically receives detailed music information, such as song name, artist, album, and genre and displays on the screen (Audio CD, USB, Jukebox modes supported) Navigation Voice Guidance • Voice route guidance to safely and conveniently reach set destinations • Various map scales that enables drivers to accurately view map and surrounding areas Traffic Information • Displays traffic congestion information on the map •Provides route guidance optimized according to traffic conditions ZAGAT Information • Provides restaurant information by synchronizing with ZAGAT data within the Search by POI feature Etc Bluetooth Handsfree Convenient use of Bluetooth Handsfree by using buttons within the steering remote controller Front Central Controller 8-directional jog-dial controllers for convenient control and access to various system features XM Data Provides Weather, Traffic, Sports, Stock related information Blue Link Provides Downloaded POI, ECO Driving, Gas Station, Location sharing and various other features No. Name Details 1 DISC-IN LED Displays the DISC insert state 2 DISC OUT DISC eject key 3 DISC Insert Slot DISC insert/eject s…

Text truncated - open the document above for the full version.

While playing ▶Shortly push the controller left/right (under 0.8 seconds) or shortly press the [SEEK], [TRACK] key to select the previous/next song. Notice • The title/artist info may not be supported in some mobile phones. •Play/Pause, Previous/Next function may not be supported in some mobile phones. Selecting Bluetooth Audio Bluetooth Audio BT Audio Auto Playlist mode can be exited by starting a different AV mode or by pressing [Exit Auto Playlist] within [MENU]. Press the [MENU] key ▶Select [Auto Playlist] The Auto Playlist feature is supported only within DISC CD, USB Audio, and Jukebox Audio modes. Notice • Auto Playlist is a Gracenote feature and will operate only after song information has been checked. List of songs similar with the current song is displayed. Once the desired song is selected, then Auto Playlist mode will operate. Press Back to cancel viewing Auto Playlist. Exiting Auto Playlist Auto Playlist Auto Playlist Auto Playlist 3 Navigation Before Use Starting Navigation Searching Destinations Route Menus Navigation Settings GPS Information Safety Cautions •For safety, some functions will be inactive while the vehicle is in motion. Buttons that cannot be operated will be inactive. •Roads names and POI information may not always be completely updated. Some places may not include up-to-date information. •The route displayed for destination guidance is a reference that will take you to the vicinity of your destination. •The navigation system uses GPS information, various sensors, road map data, and other related information to display the current position. Errors may occur if the satellite is transmitting inaccurate signals or if which can only two or less satellite signals can be received. Errors which occur in such conditions cannot be corrected. •The current position may become displayed on at a place somewhat different from your actual location. The car position mark may differ from the actual location due to the state of the GPS satellites or the vehicle (driving location and conditions). In addition, the car position mark can become deleted from the actual position when driving on roads different from the map data, such as newly constructed roads. •Even if the car position mark on the map is different, map matching or GPS info are used to automatically update the current position. (In such cases, up to several minutes may be required.) Before Use Navigation Some roads, site names, facility information and fare rates may have changed after map data development and may differ with actual road conditions. About the Map If 100m is displayed on the left side of the map, this represents a map scale of 1/10,000. Icons displayed on the map may be different with actual conditions. Also, display of multiple icons may be displayed under one mark. Unlicensed copying of the map in any form, in full or in part, is strictly prohibited. 1. Download the update file from http://www.mapnsoft.com to your computer then unzip it. 2. Move the update files to the root of your USB. 3. To learn more, refer to the ‘System Update’ section of this user’s manual. Information • Turn the controllerleft/right to change the scale. Navigation Levelmi / ftkm / m 1150 ft50 m 2300 ft100 m 3700 ft200 m 40.25 mi400 m 50.5 mi800 m 61 mi1.6 km 72 mi3.2 km 84 mi6.4 km 98 mi12 km 1016 mi25 km 1132 mi50 km 1264 mi100 km 13130 mi200 km 14250 mi400 km About Map Scale Actual distance About Map Icons About Map DB About Map Updates During destination guidance, voice guidance willbe provided whenyoureachanintersectionorarenear yourdestination. About Voice Guidance <Example of voice guidance during destination guidance> - Example of voice guidance when arriving at the destination -In front of an intersection -Upon entering a toll road ※Please use voice guidance only as a reference to assist in your driving. Information •The above voice guidance examples are normal cases. However, the actual voice guidance may differ depending on the road type. •If the car position is not accurately measured, then voice guidance may not be given, or may be given later or improperly. •It is possible to adjust the Navigation guidance volume. Guidance when using other modes Voice guidance will continue even when converting from the navigation screen to a different mode screen. Information Even when voice guidance has been muted, destination guidance will continued to be provided. You are near your destination. Voice guidance will end. Turn right in about 700m. Right turn ahead. Right turn ahead. You are entering a motorway. Toll gate ahead. Navigation Basic Mode Screen 1 2 3 6 4 7 8 9 10 11 12 13 14 15 16 No.NameDetails 1Car direction and Scale Map direction and GPS reception state and scale display 2Lane Info Recommended lanes taking the following intersection and expected route into consideration 3Preliminary Guidance Displays direction, ETA, remaining time and distance from current position to the destination 4Speed Limit Displayed at all times when driving on roads with speed limits 5Car Position Mark Displays the current vehicle position and direction 6Remaining DistanceRemaining distance until next turn 7NAVI HomeDisplays the Navi menu screen 8MENU Destination, Route and NAVI Setup, GPS Info list 9Guidance ModeChanges the right Navi screen mode 10Cancel RouteCancels the currently set route 11Traffic Enters the Traffic List screen. Provides traffic information for areas nearby the current position and current route. Detour routes can be calculated in the existence of traffic conditions (Construction, Incident, Accident). 12Map ModeSets map display mode 13POIDisplaysthe POI list 14Navigation VolumeControls navi voice guidance volume 15MuteMutes navivoice guidance 16Add to My Places Add my places and user cameras to the current position 17Route OptionsUsed to recalculateroute to the destination 17 Navigation 5 7 Press the [MAPVOICE] key within any mode while using to system to display the current position, vicinity and the curren…

Text truncated - open the document above for the full version.

HYUNDAI MOBIS CO., LTD. 80-9,tˆ‰––’Tk–•ŽSGnŒœ•ŽTnœG€–•Ž•TšSGn œ•ŽŽTk–Gz–œ›Gr–™ŒˆG 44]-912 Date: August 13, 2012 ATTESTATION STATEMENT FCC ID : TQ8-AN310ETMG This device contains an embedded Bluetooth device that HYUNDAI MOBIS CO.,LTD. confirms compliance with the following Part 15 regulations. 15.247(a)(1) the hopping sequence must be pseudo random all Channels are used equally on average the receiver input bandwidth is approximately equal to the transmit bandwidth the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. Jong Tae Kim HYUNDAI MOBIS CO.,LTD

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526 -1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 HYUNDAI MOBIS CO.,LTD. August 13, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, HYUNDAI MOBIS CO.,LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): CAR AVN, AN310ETMG We affirm that between SIEMIC and HYUNDAI MOBIS CO.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Jong Tae Kim/ Senior Research Engineer HYUNDAI MOBIS CO.,LTD. 80-9, Mabook-Dong, Giheung-Gu Yongin-shi , Gyunggi-Do South Korea 446-912 FCC ID : TQ8-AN310ETMG

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 HYUNDAI MOBIS CO.,LTD. August 13, 2012 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TQ8 -AN310ETMG We hereby request confidential treatment of information accompanying this application as outlined below: COMNFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description CONFIDENTIAL 1 Block Diagram 2 Schematics 3 Operational Description SHORT-TERM CONFIDENTIAL (180 day) 4 External Photos 5 Internal Photos 6 Test -Setup Photos 7 User ’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerel y, Jong Tae Kim / Senior Research Engineer HYUNDAI MOBIS CO., LTD. 80-9, Mabook-Dong, Giheung-Gu Yongin-shi, Gyunggi-Do South Korea 446-912

FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 6 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 6 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 6 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 4 / 6 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 5 / 6 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 6 / 6

FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 3 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 1.1 PRODUCT LABEL FCC Model FCC EUT Type Serial No : AN310ETMG : TQ8-AN310ETMG : CAR AVN : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Including interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. 80-9, Mabook-Dong, Giheung-Gu, Yongin-Shi, Gyunggi-Do, 446-912 Korea MADE IN KOREA FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 3 FCC Model FCC EUT Type Serial No : AN310ETGG : TQ8-AN310ETMG : CAR AVN : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Including interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. 80-9, Mabook-Dong, Giheung-Gu, Yongin-Shi, Gyunggi-Do, 446-912 Korea MADE IN KOREA FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 3 1.2 Label Location Drawing The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Figure 1.2 LABEL LOCATION LABEL

FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 4 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 5 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 6 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 7 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 8 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 9 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 10 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 11 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 12 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 13 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 14 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 15 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 16 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 17 / 18 FCC ID: TQ8-AN310ETMG HCT CO., LTD. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 18 / 18 BT Antenna BT Module

MPE CALCULATION For HYUNDAI MOBIS CO., LTD – ; Model: AN310ETMG FCC ID: TQ8-AN310ETMG RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 / 47 CFR §2.1091 EUT Frequency Band: 2402 – 2480 MHz Limits for General Population/Uncontrolled Exposure in the band of: 1500 – 100,000 MHz Power Density Limit: 1.0mW/ cm 2 ; Equation: S = PG / 4πR 2 or R = √PG / 4πS Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ Mid Channel (2402 MHz): Power = 2.31 dBm, Antenna Gain = 1.0 dBi, Prediction distance 20cm S = 0 .000426 mW/cm 2 Result The Above Result had shown that Device complied with 1.0 mW/cm 2 Power density requirement for distance of 20cm. Completed By : Jong Suk Lee Date : August 13, 2012

FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR16 Date of Issue: August 14, 2012 EUT Type: CAR AVN FCC ID : TQ8-AN310ETMG Page 2 of 74 Version TEST REPORT NO. DATE DESCRIPTION HCTR1208FR16 August 14, 2012 - First Approval Report FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR16 Date of Issue: August 14, 2012 EUT Type: CAR AVN FCC ID : TQ8-AN310ETMG Page 3 of 74 Table of Contents 1. GENERAL INFORMATION ....................................................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................................. 4 3. TEST METHODOLOGY ............................................................................................................................ 5 3.1 EUT CONFIGURATION ............................................................................................................. 5 3.2 EUT EXERCISE ......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ............................................................................................. 5 3.4 DESCRIPTION OF TEST MODES ............................................................................................ 5 4. INSTRUMENT CALIBRATION .................................................................................................................. 6 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1 FACILITIES ................................................................................................................................ 6 5.2 EQUIPMENT .............................................................................................................................. 6 6. ANTENNA REQUIREMENTS.................................................................................................................... 6 7. SUMMARY OF TEST RESULTS............................................................................................................... 7 8. FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1 PEAK POWER ........................................................................................................................... 8 8.2 BAND EDGES.......................................................................................................................... 15 8.3 FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 22 8.4 NUMBER OF HOPPING FREQUENCY .................................................................................. 30 8.5 TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 34 8.6 SPURIOUS EMISSIONS.......................................................................................................... 41 8.6.1 CONDUCTED SPURIOUS EMISSIONS .......................................................................... 41 8.6.2 RADIATED SPURIOUS EMISSIONS .............................................................................. 52 8.6.3 RADIATED RESTRICTED BAND EDGES ...................................................................... 63 8.7 POWERLINE CONDUCTED EMISSIONS............................................................................... 73 9. LIST OF TEST EQUIPMENT................................................................................................................... 74 FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR16 Date of Issue: August 14, 2012 EUT Type: CAR AVN FCC ID : TQ8-AN310ETMG Page 4 of 74 1. GENERAL INFORMATION Applicant Name: HYUNDAI MOBIS CO., LTD. Address: 80-9, Mabook-Dong, Giheung-Gu Yongin-shi Gyunggi-Do, 446-912 South Korea FCC ID: TQ8-AN310ETMG EUT: CAR AVN FCC Model name(s): AN310ETMG Additional Model name(s): AN310ETGG Date(s) of Tests: July 26, 2012 ~ July 30, 2012 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type CAR AVN FCC Model Name AN310ETMG Additional Model Name AN310ETGG Power Supply DC 12 V Frequency Range 2402 - 2480 MHz (Bluetooth) Transmit Power 2.31 dBm(1.70 mW) BT Operating Mode Nomal, EDR, AFH Modulation Type GFSK(Normal), π/4DQPSK and 8DPSK(EDR) Modulation Technique FHSS Number of Channels 79Channels, Minimum 20 Channels(AFH) Antenna Specification Manufacturer: AMOTECH Co., Ltd. Antenna type: PCB+Cable Assembly Antenna Peak Gain : 1.0 dBi 15.247 Requirements for Blue※tooth transmitter ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudo-randomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1208FR16 Date of Issue: August 14, 2012 EUT Type: CAR AVN FCC ID : TQ8-AN310ETMG Page 5 of 74 3. TEST METHODOLOGY The measurement procedure des…

Text truncated - open the document above for the full version.
