TQ8-ATC42S2ANCar Audio System

1 [ This guide covers specifications for all vehicle models, including optional specifications, and is based on the latest version of system software. [ The design and specification of the system may change without prior notice for performance improvement. [ In order to improve the product performance, the functions and services in this manual are subject to change without notice. In case of software update, the screens in this manual may differ from actual ones on the product. [ For more information about the functions and services updated for performance improvement, access the online user's manual. [ Functions and services in this manual may differ from those in the actual vehicle. For more details, refer to the owner’s manual or brochure of your vehicle. [ Your system is not compatible with the system software and map data for regions outside of the country of purchase. Car Infotainment System User’s Manual 2 Available materials for operation Quick Reference Guide Provided in the format of a booklet. It provides brief information of the system, including basic controls and main functions. User's Manual on Web To see the information while using the system, press Menu > User's Manual on Web (QR Code). By scanning the QR code with your smartphone, you can access the online user's manual. 3 Symbols in this User’s Manual Warning Indicates very important information directly related to user safety. Failure to follow instructions may cause serious injury. Caution Indicates important information directly related to user safety. Failure to follow instructions may cause minor injury or vehicle damage or breakdown. Note Indicates helpful information for operation of the product. If equipped Indicates descriptions for optional features, which may not be available on your specific vehicle depending on the model or trim level. This guide covers specifications for all vehicle models, including optional specifications. It may include descriptions for features that are not equipped in your vehicle or are unavailable for your vehicle model. HEV only Displays only the functions that can be used in a hybrid vehicle. PHEV only Displays only the functions that can be used in a plug-in hybrid vehicle. EV only Displays only the functions that can be used in an electric vehicle. 4 Be sure to keep the following instructions. Otherwise, it may cause serious injury or accident. Ý Driving Obey all traffic laws while driving. • Relying solely on the navigation system may cause violation of traffic rules and regulations, resulting in an accident. In order to check the vehicle speed, see the speedometer first, not the speed on the navigation system. • The speed on the navigation system may differ from actual vehicle speed. While driving, refrain from watching the screen. • An accident may occur by negligence in keeping your eyes forward. • To manipulate the screen or buttons requiring multiple steps, be sure to stop your vehicle. To use your mobile phone, first stop your vehicle. • When you use your mobile phone while driving, it may disperse your attention, resulting in an accident. • If necessary, use handsfree (Bluetooth) calling when driving and minimize the call time. Make sure that the volume of the phone is sufficiently low so that the external sound is audible. • When you drive with no external sound present may cause a traffic accident. • When you drive for a long time with a loud audio volume, it may affect your hearing. For emergency services (e.g. hospital, fire station), do not rely solely on the navigation system. • Some emergency services may not be included in the navigation map. Check relevant information in advance to stay prepared for an emergency. Ý System handling Do NOT arbitrarily disassemble or modify the system. • It may cause an accident, fire, or electric shock. Exercise caution to make sure that no liquid or foreign materials enter the system. • It may cause smoke generation, fire ignition, or system failure. When the screen is not displayed, the volume is muted, or other system failures occur, immediately stop using the system. • Otherwise, it may cause fire, electric shock, or fatal system failure. AA If you experience any problems with the system, contact your place of purchase or dealer. Safety Warnings 5 Ü System handling Do NOT apply excessive force to the system. • When you apply excessive pressure to the screen, the LCD panel or touch panel may get damaged. To clean the screen or button panel, first turn off the vehicle and then use a dry, soft cloth to wipe it. • Do not wipe using a rough or hard cloth, chemical fiber, organic solvent (e.g. alcohol, benzene, thinner), or air freshener. The panel surface may become scratched or damaged due to a chemical reaction. When you install an air freshener on the air conditioner vent, the surface may be deformed due to leakage. AA If you experience any problems with the system, contact your place of purchase or dealer. Be sure to keep the following instructions. Otherwise, it may cause minor injury or system damage. Ü Operation Use the system with the vehicle started. • When you use the system for a long time with the vehicle stopped, it may cause battery discharge. Do NOT arbitrarily install an unauthorized aftermarket product in your vehicle. • Using unapproved products may cause an error while using the system. • System errors caused by installing unapproved products are not covered under the warranty. Safety Precautions 6 Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information. You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com website at: https://www.hyundaiusa.com/owner-privacy-policy.aspx If you would like to receive a hard copy of our Vehicle Owner Privacy Policy, please contact our Customer …

Text truncated - open the document above for the full version.

Date: March 12, 2020 Hyundai MOBIS Co., Ltd. 20 3 Teheran-ro, Gangnam-gu, Seoul, Kore a, 135-977 DTS-UNII Device Declaration Letter To whom it may concern We have declared below featured for FCC equipment authorization, Device FCC ID: TQ8-ATB31EYAN (1) DFS Device: Client without Radar detection capability (2) Active / Passive Scanning, adhoc mode access point capability Frequency Band (MHz) Active Scanning Passive Scanning Ad Hoc Mode or WIFI Direct capability Access point capability DFS 2412 – 2462 No Yes No No No 5180 – 5240 No Yes No No No 5260 – 5320 No Yes No No Yes 5500 – 5720 No Yes No No Yes 5745 – 5825 No Yes No No No (3) Country code Selection ability: No (4) Meet 15.202 requirement: Yes pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can’t be modified by end user or an installer. : No Apply, (If apply, pls help to provide explanation on it was implement, and how software was controlled) Sincerely, Company Name : HYUNDAI MOBIS CO., LTD. Company Address : 203, Teheran-ro Gangnam-gu, Seoul, South Korea 135-977 Contact Person Name/Title (in print) : Seung Hoon / Representative

HYUNDAI MOBIS CO.,LTD. DATE : Mar 12, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: Subject : Declaration for no non-US channel operation for FCC ID : TQ8-ATC42S2AN We, HYUNDAI MOBIS CO., LTD., declare that the device, FCC ID: TQ8- ATB31EYAN, does not support operation on WLAN channels 12&13 in any operation mode in USA. US 2.4 GHz channel 12&13 and country code selection are disabled through proprietary software and not user changeable. If you have any question or comment regarding this declaration, please contact us. Thank you. Sincerely, Signed by: Company Name : HYUNDAI MOBIS CO., LTD. Company Address : 203, Teheran-ro Gangnam- gu, Seoul, South Korea 135-977 Contact Person Name/Title (in print) : Seung Hoon / Representative

Product Declaration March 12, 2020 Applicant: HYUNDAI MOBIS CO.,LTD. Product Type: Car Audio System FCC ID: TQ8-ATC42S2AN Basic Model: ATC42S2AN Additional Model: ATC41S2AN, ATC40SCAN, ATC41SCAN, ATC42SCAN, ATC43SCAN We, HYUNDAI MOBIS CO.,LTD., provide the product information. 1. RF specification 1)Basic Model: ATC42S2AN – BT / Wifi 2.4 GHz and 5 GHz 2) Additional Model: ATC41S2AN, ATC40SCAN, ATC41SCAN, ATC42SCAN, ATC43SCAN 2. Difference the function and H/W 1)SVM(Surround View Monitoring System): ATC42S2AN, ATC41SCAN, ATC43SCAN 2)RVM(Rear View Monitoring System): ATC41S2AN, ATC40SCAN, ATC42SCAN SVM(Surround View Monitoring System) RVM(Rear View Monitoring System) 1.Image input connector is inserted 2.Insert LVDS processing IC 1.Image input connector is deleted 2. Delete LVDS processing IC ============================= Company name : HYUNDAI MOBIS CO.,LTD. Title and name : Representative / SeungHoon, Choe Tel : 82-31-260-0098 Place : South Korea – BT/ Wifi 2.4 GHz and 5 GHz / LTE / CDMA BC0 and BC1

Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Agent Authorization Letter Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 2.3 Fixed Typo “Agent” 11/09/2017 QM HYUNDAI MOBIS CO., Ltd HACS-F004 FCC Agent Authorization Letter Rev : 2.3 DATE : March 12, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: Subject : FCC Agent Authorization Letter for FCC ID : TQ8-ATC42S2AN We, the undersigned, hereby authorize HCT CO.,LTD to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by HCT CO.,LTD on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Signed by: Seung Hoon Choe / Representative HYUNDAI MOBIS CO., LTD 203, Teheran-ro Gangnam-gu, Seoul, South Korea

Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Confidentiality Request Letter Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 3.0 Updated LTC and STC Confidentiality table 11/09/2017 QM HYUNDAI MOBIS CO., Ltd HACS-F003 FCC Confidentiality Request Letter Rev : 3.0 DATE : March 12, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD SUBJECT : Request for Confidentiality for FCC ID : TQ8-ATC42S2AN We hereby request confidential treatment of the information accompanying this application as outlined below: LONG-TERM AND SHORT-TERM CONFIDENTIAL LIST LONG-TERM CONFIDENTIAL Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics SHORT-TERM CONFIDENTIAL (180 DAYS) 5 External Photos 6Internal Photos 7Test-Setup Photos 8User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signed by: Seung Hoon Choe / Representative HYUNDAI MOBIS CO., LTD 203, Teheran-ro Gangnam-gu, Seoul, South Korea 4 Part List

FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO FCC ID : TQ8-ATC42S2AN / IC : 5074A-ATC42S2KN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO

Label Location ATC42S2AN FCC ID: TQ8-ATC42S2AN ATC41S2AN FCC ID: TQ8-ATC42S2AN Contains FCC ID : YZP-VL3000 Supporting Band: BT, WLAN Supporting Band: BT, WLAN, LTE ATC41SCAN FCC ID: TQ8-ATC42S2AN Contains FCC ID : YZP-VL3000 Supporting Band: BT, WLAN, LTE ATC40SCAN FCC ID: TQ8-ATC42S2AN Contains FCC ID : YZP-VL3000 Supporting Band: BT, WLAN, LTE ATC43SCAN FCC ID: TQ8-ATC42S2AN Contains FCC ID : YZP-VL3000 Supporting Band: BT, WLAN, LTE ATC42SCAN FCC ID: TQ8-ATC42S2AN Contains FCC ID : YZP-VL3000 Supporting Band: BT, WLAN, LTE

FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 15 INTERNAL PHOTOGRAPHS FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １１ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １２ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １３ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １４ of 15 ■ INTERNAL PHOTO FCC ID : TQ8-ATC42S2AN HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １５ of 15 ■ INTERNAL PHOTO

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 On your side FCC MPE Test for ATC42S2AN Certification APPLICANT HYUNDAI MOBIS CO., LTD. REPORT NO. HCT-RF-2003-FI005 DATE OF ISSUE March 18, 2020 Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 3 of 13 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 March 18, 2020 Initial Release The measurements shown in this report were made in accordance with the procedures specified in §2.947. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. HCT CO., LTD. Certifies that no party to this application has subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1998,21 U.S. C.853(a) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 4 of 13 RF Exposure Statement 1. Limit According to §1.1310, §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34 1.34 - 30 30 - 300 300 - 1500 1500 - 100.000 614 824/f 27.5 ... ... 1.63 2.19/f 0.073 ... ... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. Maximum Permissible Exposure Prediction Prediction of MPE limit at a given distance ଶ S = Power density P = Power input to antenna G = Power gain to the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 5 of 13 3. RESULTS 3-1. Bluetooth Average output Power at antenna input terminal 4.000 dBm Average output Power at antenna input terminal 2.512 mW Prediction distance 20.00 cm Prediction frequency 2402 ˊ 2480 MHz Antenna Gain(typical) 3.040 dBi Antenna Gain(numeric) 2.014 - Power density at prediction frequency( S) 0.0010 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.000 mW/cm 2 2.1091 EIRP 7.04 (dBm) ERP 4.89 (dBm) ERP 0.003 (W) ERP Limit 3.00 (W) MARGIN 29.88 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 6 of 13 3-2. DTS Average output Power at antenna input terminal 10.00 dBm Average output Power at antenna input terminal 10.000 mW Prediction distance 20.00 cm Prediction frequency 2412 ˊ 2462 MHz Antenna Gain(typical) -0.70 dBi Antenna Gain(numeric) 0.851 - Power density at prediction frequency( S) 0.0017 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.000 mW/cm 2 2.1091 EIRP 9.30 (dBm) ERP 7.15 (dBm) ERP 0.005 (W) ERP Limit 3.00 (W) MARGIN 27.62 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 7 of 13 3-3. UNII Average output Power at antenna input terminal 10.00 dBm Average output Power at antenna input terminal 10.000 mW Prediction distance 20.00 cm Prediction frequency 5180 - 5825 MHz Antenna Gain(typical) 3.510 dBi Antenna Gain(numeric) 2.244 - Power density at prediction frequency( S) 0.0045 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.000 mW/cm 2 2.1091 EIRP 13.51 (dBm) ERP 11.36 (dBm) ERP 0.014 (W) ERP Limit 3.00 (W) MARGIN 23.41 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 8 of 13 3-4. CDMA BC0 Average output Power at antenna input terminal 25.00 dBm Average output Power at antenna input terminal 316.23 mW Prediction distance 20.000 cm Prediction frequency 824-849 MHz Cable Loss -1.71 dB Antenna Gain(typical) 1.290 dBi Antenna Gain(numeric) 1.346 - Power density at prediction frequency( S) 0.08467 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.549 mW/cm 2 2.1091 EIRP 26.29 (dBm) ERP 24.14 (dBm) ERP 0.26 (W) ERP Limit 1.50 (W) MARGIN 7.62 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 9 of 13 3-5. CDMA BC1 Average output Power at antenna input terminal 25.00 dBm Average output Power at antenna input terminal 316.23 mW Prediction distance 20.000 cm Prediction frequency 1850-1910 MHz Cable Loss -3.300 dB Antenna Gain(typical) -0.780 dBi Antenna Gain(numeric) 0.836 - Power density at prediction frequency( S) 0.05257 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.000 mW/cm 2 2.1091 EIRP 24.22 (dBm) ERP 22.07 (dBm) ERP 0.161 (W) ERP Limit 3.00 (W) MARGIN 12.70 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 10 of 13 3-6. LTE B4 Average output Power at antenna input terminal 24.00 dBm Average output Power at antenna input terminal 251.19 mW Prediction distance 20.000 cm Prediction frequency 1710-1755 MHz Cable Loss -3.300 dB Antenna Gain(typical) -0.990 dBi Antenna Gain(numeric) 0.796 - Power density at prediction frequency( S) 0.03979 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 1.000 mW/cm 2 2.1091 EIRP 23.01 (dBm) ERP 20.86 (dBm) ERP 0.122 (W) ERP Limit 3.00 (W) MARGIN 13.91 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 11 of 13 3-7. LTE B13 Average output Power at antenna input terminal 24.00 dBm Average output Power at antenna input terminal 251.19 mW Prediction distance 20.000 cm Prediction frequency 777-787 MHz Cable Loss -1.710 dB Antenna Gain(typical) 1.590 dBi Antenna Gain(numeric) 1.442 - Power density at prediction frequency( S) 0.07207 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.518 mW/cm 2 2.1091 EIRP 25.59 (dBm) ERP 23.44 (dBm) ERP 0.22 (W) ERP Limit 1.50 (W) MARGIN 8.32 (dB) Report No. HCT-RF-2003-FI005 F-TP22-03 (Rev. 02) Page 12 of 13 3-8. LTE B5 Average output Power at antenna input terminal 24.00 dBm Average output Power at antenna input terminal 251.19 mW Prediction distance 20.000 cm Prediction frequency 824-849 MHz Cable Loss -1.71 dB Antenna Gain(typic…

Text truncated - open the document above for the full version.

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 On your side FCC/IC DFS Test for ATC42S2AN&ATC42S2KN Certification APPLICANT HYUNDAI MOBIS CO., LTD. REPORT NO. HCT-RF-2003-FI004 DATE OF ISSUE March 18, 2020 Report No. HCT-RF-2003-FI004 F-TP22-03 (Rev. 02) Page 3 of 22 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 March 18, 2020 Initial Release The result shown in this test report refer only to the sample(s) tested unless otherwise stated. Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC / IC Rules under normal use and maintenance. Report No. HCT-RF-2003-FI004 F-TP22-03 (Rev. 02) Page 4 of 22 CONTENTS 1. EUT DESCRIPTION EUT DESCRIPTION 5 2. SCOPE 7 3. INSTRUMENT CALIBRATION 7 4. FACILITIES AND ACCREDITATIONS 8 FACILITIES 8 EQUIPMENT 8 5. SUMMARY OF TEST RESULTS 9 6. DESCRIPTION OF DYNAMIC FREQUENCY SELECTION TEST 10 6.1 Requirements 10 6.2 Limit 11 6.3 DFS detection threshold values 12 6.4 DFS test signals 13 6.5 Test and measurement system 14 6.6 TEST RESULT 17 7. LIST OF TEST EQUIPMENT 21 8. ANNEX A_ TEST SETUP PHOTO 22 Report No. HCT-RF-2003-FI004 F-TP22-03 (Rev. 02) Page 5 of 22 1. EUT DESCRIPTION EUT DESCRIPTION FCC Model ATC42S2AN IC Model ATC42S2KN FCC Additional Model ATC41S2AN,ATC40SCAN,ATC41SCAN,ATC42SCAN,ATC43SCAN IC Additional Model ATC41S2KN,ATC40SCKN,ATC41SCKN,ATC42SCKN,ATC43SCKN EUT Type Car Audio System Power Supply DC 14.4 V Modulation Type OFDM Operating mode Slave Device without radar detection Frequency Range 5250 ˊ 5350 MHz (UNII-2A Band) 5470 ˊ 5725 MHz (UNII-2C Band) Test Procedure FCC KDB 905462 D02 v02 Architecture 802.11a/n/ac Channel Bandwidth 20, 40, 80MHz Antenna Specification Antenna type: Wi-Fi Dual Band Antenna Peak Gain : 3.12 dBi Date(s) of Tests February 05, 2020 ~ March 02, 2020 PMN (Product Marketing Number) ATC42S2KN, ATC41S2KN, ATC40SCKN, ATC41SCKN, ATC42SCKN, ATC43SCKN HVIN (Hardware Version Identification Number) ATC42S2KN, ATC41S2KN, ATC40SCKN, ATC41SCKN, ATC42SCKN, ATC43SCKN FVIN (Firmware Version Identification Number) N/A HMN (Host Marketing Name) N/A Report No. HCT-RF-2003-FI004 F-TP22-03 (Rev. 02) Page 6 of 22 Note: 1. TPC is not required since the maximum EIRP is less than 500mW(27dBm). 2. WLAN traffic that meets or exceeds the minimum required loading was generated by transferring a data stream from the controller/server PC to the EUT using Streaming Video. Report No. HCT-RF-2003-FI004 F-TP22-03 (Rev. 02) Page 7 of 22 Max. RF Output Power: 2. SCOPE This report has been prepared to demonstrate compliance with the requirements for Dynamic Frequency Selection(DFS) as stated in KDB 905462 D02 v02. Testing was performed in accordance with the measurement procedure described in FCC KDB 905462 D02 v02. 3. INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipmentˏs, which is traceable to rec…

Text truncated - open the document above for the full version.
