TQ8-AV230TBANDIGITAL CAR AVN SYSTEM

2TEND08 CAR MULTIMEDIA SYSTEM l USER'S MANUAL CAR MULTIMEDIA SYSTEM USER'S MANUAL 2TEND08 Thank you for purchasing this multimedia system . This user's manual explains how to usethe KIA Motor multimedia system . Before using the product, read the con-tents of this user's manual carefully and use this product safely. • The screens shown in this manual may differ with the actual screens of the product. • The design and specification of this product may change without prior notifi-cation for product improvement. • When transferring the vehicle to another individual, include this user's manual so that the next driver can continue its use. Precaution for safe usage • Driving while distracted can result in a loss of vehicle control, that may lead to an accident, severe personal injury, and death. The driver’s primary responsibil-ity is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle. • Do not operate the multimedia system while driving. • Do not disassemble, assemble, or modify the multimedia system . • Do not watch the screen for prolonged periods of time while driving. • Set the volume to a level which allows the driver to be aware of external conditions. • Do not operate the multimedia system for prolonged periods of time with the vehicle ignition in ACC. Such operations may lead to battery discharge. • Be cautious not to spill water or introduce foreign objects into the device. • Do not cause severe shock to the device. Direct pressure onto the front side of the monitor may cause damage to the LCD or touch panel. • In case of product malfunction, please contact your place of purchase or service center. • When cleaning the touch screen, make sure to turn off the device and use a dry and smooth cloth. Never use tough mate-rials, chemical cloths, or solvents (alcohol, ammonia, benzene, thinners, etc.) as such materials may damage the device panel or cause color and quality deterioration. All Map Database cannot be copied without permission.Important Notice: This is protected by U.S. copyright laws. All rights not expressly granted are reserved. You may not otherwise reproduce, modify, and distribute the content without M&Soft, Inc's prior written consent. • SiriusXM service requires a subscription, sold separately, after 3-month trial included with vehicle purchase. If you decide to continue your SiriusXM service at the end of your trial subscrip-tion, the plan you choose will automatically renew and bill at then-current rates until you call Sirius XM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm.com. Programming subject to change. Sirius satellite service is available only to those at least 18 and older in the 48 contiguous USA, D.C., and PR (with coverage limi-tations). Traffic information not available in all markets. See siriusxm.com/traffic for details. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. WARNING • Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe personal injury, and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permis-sible by law should never be used during operation of the vehicle. • Infinity is a trademark of Harman International Industries, Inc. • At launch, the Apple iPhone ® will be the only UVO eServices compatible device. iPhone ® is a registered trademark of Apple Inc. Apple iOS6 compatibility expected early 2013. Additional compatible devices expected late 2013. • App Store is a service mark of Apple Inc. No charge for the UVO eServices app. App runs on your smartphone cellular data service. Normal data rates will apply. • HD Radio and the HD Radio logo are proprietary trademarks of iBiquity Digital Corporation. • 24-hour Roadside Assistance is a service plan provided by Kia Motors America, Inc. Certain limitations apply. Coverage details are available in the Kia Warranty and Consumer Information Manual. For access to Enhanced Roadside Assistance, a con-nected mobile phone via Bluetooth within the cellular service coverage area is required. • Vehicle Diagnostics do not take the place of regularly sched-uled maintenance. Feature checks powertrain, chassis, and airbag systems only. For factory-recommended maintenance schedule, see the Maintenance Feature of UVO eServices or the Owner’s Manual. • 911 Connect activates after an airbag deployment. Feature requires a connected mobile phone via Bluetooth. Dependant on cellular service coverage. • The rear-camera display is not a substitute for proper and safe backing-up procedures. The rear-camera display may not display every object behind the vehicle. Always drive safely and use cau-tion when backing up. 5HDGWKHIROORZLQJVDIHW\FDXWLRQVIRU\RXUVDIHW\Before using the product, read the contents of this user's manual carefully and use this product safely . The design and specification of this product may change without prior notification for product improvement. 1RWDWLRQVXVHGZLWKLQWKLV8VHU V0DQXDO WARNING Failure to observe the instructions within this category could result in damage to the vehicle. CAUTION Information on matters that could potentially lead to injury or vehi-cle damage/malfunction Information that could lead to higher user safety i Information Information and tips that provide additional user convenience in using the product NOTICE Information on specific features that facilitate proper product use and functional understanding Information on terminology used within this manual 2:DUQLQJVDQG&DXWLRQVSafe…

Text truncated - open the document above for the full version.

Hyundai Mobis Co., Ltd. 80-9, Mabook-dong, Giheung-gu, Yongin-shi, Gyunggi-do, Korea Tel. 82-31-260-0092 / Fax. 82-31-899-1788 Date: September 11, 2013 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Hyundai Mobis Co., Ltd., hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project : - Product : DIGITAL CAR AVN SYSTEM - Model name : AV230TBAN - FCC ID : TQ8- AV230TBAN We affirm that between SIEMIC and Hyundai Mobis Co., Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, ______________________________________ Jong-Tae Kim /Manager /Hyundai Mobis Co., Ltd.

Hyundai Mobis Co., Ltd. 80-9, Mabook-dong, Giheung-gu, Yongin-shi, Gyunggi-do, Korea Tel. 82-31-260-0092 / Fax. 82-31-899-1788 FCC Confidentiality Request Letter Date: September 11, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 Subject: Permanent Confidentiality Request for FCC ID: TQ8- AV230TBAN We hereby request confidential treatment of information accompanying this application as outlined below: Block diagram Schematics Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, ______________________________________ Jong-Tae Kim /Manager /Hyundai Mobis Co., Ltd.

External photos of EUT Front view of EUT Rear view of EUT Top view of EUT

FCC ID LABEL 1.FCC ID label drawing 2. FCC ID label location

Internal photos of EUT Internal view of EUT Top view of Main board Bottom view of Main board Top view of Key button boards Bottom view of Key button boards Top view of NAVI board Bottom view of NAVI board Top view of LCD board Bottom view of LCD board Top view of Bluetooth module BT Chip Antenna BT Module * BT Module and antenna are soldered on the PCB as above.

http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 55 of 58 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. 5.9 RF Exposure 5.9.1 Regulation According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. Limits for Maximum Permissive Exposure: RF exposure is calculated. Frequency Range Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [mW/cm 2 ] Averaging Time [minute] Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *(100) 30 1.34 ~ 30 824 /f 2.19/f *(180/f 2 ) 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1500 / / f/1500 30 1500 ~ 15000 / / 1.0 30 f=frequency in MHz, *= plane-wave equivalent power density MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01  SPGRRPGS4 4 2  S=power density [mW/cm 2 ] P=Power input to antenna [mW] G=Power gain of the antenna in the direction of interest relative to an isotropic radiator R= distance to the center of radiation of the antenna [cm] EUT: Maximum peak output power = 2.239 [mW](= 3.53 dBm) Antenna gain=2.239(= 3.5 [dBi]) 100 mW, at 20 cm from an antenna 6[dBi] S = PG/4πR² = 100 × 3.98 / (4 × π × 400) = 0.0792 [mW/cm 2 ] < 1.0 [mW/cm 2 ] 2.239 mW, at 20 cm from an antenna 3.5 [dBi] S = PG/4πR²= 0.001 00 [mW/cm 2 ] < 1.0 [mW/cm 2 ] 2.239 mW, at 2.5 cm from an antenna 3.5 [dBi] S = PG/4πR²= 0.063 83 [mW/cm 2 ] < 1.0 [mW/cm 2 ] 5.9.2 RF Exposure Compliance Issue The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements.

http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 1 of 61 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. FCC/IC TEST REPORT Test report No.: EMC- FCC- R0122 FCC ID: TQ8-AV230TBAN IC: 5074A-AV2A1TBKN Type of equipment: DIGITAL CAR AVN SYSTEM Basic Model Name: AV230TBAN Variant Model name: AV2A1TBKN Applicant: Hyundai Mobis Co., Ltd. Max.RF Output Power: 3.53 dBm FCC Rule Part(s): FCC Part 15 Subpart C 15.247 IC Rule: RSS-210, RSS-GEN Frequency Range: 2 402 MHz ~ 2 480 MHz Test result: Complied The above equipment was tested by EMC compliance Testing Laboratory for compliance with the requirements of FCC Rules and Regulations. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of test: September 2, 2013 ~ September 5, 2013 Issued date: September 5, 2013 Tested by: Approved by: . SON, MIN GI YU, SANG HOON http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 2 of 61 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. [ Contents ] 1. Client information .................................................................................................. 3 2. Laboratory information ........................................................................................... 4 3. Description of E.U.T. ............................................................................................... 5 3.1 Basic description ................................................................................................ 5 3.2 General description ............................................................................................. 5 3.3 Test frequency ................................................................................................... 6 3.4 Test Voltage ..................................................................................................... 6 4. Summary of test results ............................................................................................ 7 4.1 Standards & results ............................................................................................. 7 4.2 Uncertainty ...................................................................................................... 7 5. Test results .......................................................................................................... 8 5.1 Antenna Requirement ........................................................................................... 8 5.2 Maximum Peak Output Power ................................................................................. 9 5.3 Carrier Frequency Separation ................................................................................. 14 5.4 20 dB Channel Bandwidth .................................................................................... 19 5.5 Number of Hopping Channels ................................................................................ 24 5.6 Time of Occupancy(Dwell Time) ............................................................................. 26 5.7 Spurious Emission, Band edge, and Restricted bands ....................................................... 31 5.8 Receiver Spurious Emissions ................................................................................. 51 5.9 RF Exposure ................................................................................................... 58 6. Test equipment used for test .................................................................................... 59 Appendix 1 Test setup photos Appendix 2 External photos of EUT Appendix 3 Internal photos of EUT Appendix 4 Block diagram Appendix 5 Schematics Appendix 6 User manual Appendix 7 Part list Appendix 8 Layout diagram Appendix 9 Antenna Specification http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 3 of 61 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. 1. Client information Applicant: Hyundai Mobis Co., Ltd. Address: 80-9, Mabook-dong, Giheung-gu, Yongin-shi, Gyunggi-do, Korea (446-912) Telephone number: +82-31-260-0092 Facsimile number +82-31-899-1788 Contact person: Jong Tae Kim / [email protected] Manufacturer: Hyundai Mobis Co., Ltd. Address : 80-9, Mabook-dong, Giheung-gu, Yongin-shi, Gyunggi-do, Korea (446-912) http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 4 of 61 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. 2. Laboratory information Address EMC Compliance Ltd. 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea Telephone Number: 82 31 336 9919 Facsimile Number: 82 31 336 4767 Certificate CBTL Testing Laboratory, KOLAS NO.: 231 FCC Filing No.: 508785 VCCI Registration No.: C-1713, R-1606, T-258 IC Recognition No.:8035A-2 SITE MAP SUWON-CITY EMC Compliance Ltd. http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 5 of 61 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. 3. Description of E.U.T. 3.1 Basic description Applicant : Hyundai Mobis Co., Ltd. Address of Applican…

Text truncated - open the document above for the full version.

http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 57 of 58 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. Appendix 1. Test Setup Photos Below 30MHz Above 30MHz http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0122 EMC compliance Ltd. Page: 58 of 58 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval. Above 1GHz
