CAR AVN SYSTEM • Warnings and Cautions • Key Product Features • Component Names and Functions • Starting the System for the First Time Basic 1 1-2 Safety Warnings Even when receiving route guidance from the Navigation system, please abide by actual traffic and road regulations. Following only the Navigation route guidance may lead to violations of actual traffic and road regulations and lead to traffic accidents. Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents. Do not operate the Navigation system while driving, such as entering POIs or conducting route searches. Such acts could lead to accidents, fire, or electric shock. Park the vehicle before operating the device. Do not disassemble, assemble, or modify the Navigation system. Such acts could result in accidents, fire, or electric shock. Heed caution not to spill water or introduce foreign objects into the device. Such acts could lead to smoke, fire, or product malfunction. Please refrain from use if the screen is blank or no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (fires, electric shock) or product malfunctions. Do not touch the antenna during thunder or lightening as such acts may lead to lightning induced electric shock. Do not stop or park in parking-restricted areas to operate the prod- uct. Such acts could lead to traffic accidents. For most Audio and multimedia modes, the display will not operate when the vehicle is in motion. For your safety, first park the vehicle to watch or view the screen. (The screen will operate when the park- ing brake is set to ON for manual transmission vehicles and when set to P or Parking Brake On state for auto transmission vehicles.) Warnings and Cautions Warnings and Cautions Basic l 1-3 Safety Cautions Pay attention to traffic conditions while driving. In some instances, the navigation may provide guidance through re- stricted areas. Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. In addition, the touch screen may not work for some functions when the vehicle is in motion. The touch screen fea- ture will be supported once the vehicle has stopped. Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to accidents. Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.) If you want to change the position of device installation, please in- quire with your place of purchase or service maintenance center. Technical expertise is required to install or disassemble the device. Turn on the car ignition before using this device. Do not operate the Navigation system for long periods of time with the ignition turned off as such operations may lead to battery discharge. Upon using the Navigation system for more than 10 minutes with the car engine turned off, the following warning will be displayed. After 10 minutes, the warning will be displayed for 5 seconds every 1 minute. Do not subject the device to severe shock or impact. Direct pres- sure onto the front side of the monitor may cause damage to the LCD or touch screen. When cleaning the device, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents(alcohol, benzene, thinners, etc.) as such materials may damage the de- vice panel or cause color/quality deterioration. When experiencing product malfunctions, inquire with your place of purchase or service maintenance center. 1-4 This device is an Audio Navigation system equipped with a multifunctional disc player that supports Radio (FM1, FM2, AM), HD Radio, Audio CD, MP3, USB, iPod, and Audio, Aux, and My Music features. The WIDE VGA LCD provides a high quality resolution while the powerful and rich sound system adds to the driving enjoyment. Display Wide TFT-LCD Display • Provides high quality sound and video through a Wide TFT-LCD Display using an LED Back Light • Touch screen for maximum user convenience Radio Digital Tuner Feature • Digital Tuner using PPL method that supports memory of 6 broadcast stations for each AM, FM1, and FM2 modes Integrated Antenna (RADIO+NAVI) • Outstanding reception via integrated antenna with high sensitivity Radio broadcast station name • Displays broadcast station names for key locations HD Radio/Satellite Radio feature • Supports HD Radio and Satellite Radio (XM) Multimedia Player Support for various Media Formats • Support for various media formats, including Radio, audio MP3 CD, USB, iPod and AUX • Supports USB, iPod, and Bluetooth ® Audio Streaming modes My Music • Supports copying of music stored within USB or iPod devices into My Music (internal memory) mode USB Image • Copy to view and save images saved in USB devices Key Product Features Key Product Features Basic l 1-5 Navigation Voice Guidance • Voice route guidance to safely and conveniently reach set destinations • Various map scales that enables drivers to accurately view map and surrounding areas Automatic Correction for Current Location • Automatically corrects current position using map matching and GPS information Blue Link ® Sync with Blue Link ® Center • Synchronization with the Blue Link ® Center to provide various types of information Vehicle Diagnostics/Maintenance • Supports Vehicle Theft Protection, Parts Diagnostics and Recall Information Eco Driving and Fuel Economy Management • Supports Economic driving practices by providing driver/community fuel economy information and Eco Rewards Miscellaneous Bluetooth ® Wireless Technology • Convenient use of Bluetooth ® Handsfree by using button…
