TQ8-BCM-E50BODY CONTROL UNIT

1.GENERAL DISCRIPTION The SMART KEY ECU is a part of START-STOP BUTTON SYSTEM. It is possible to output the LF(125kHz) signal by pushing the button of door handle and SSB. 2. ELECTRICAL CHARACTERISTICS Dark current5mA Max. ModulationFSK Operating temperature -40°C ~ +85°C Operating frequency125KHz Manual of BCM ECU Operating voltage9V ~ 16V BCM-E50model name This device is designed to vehicle Burglar alarm by the burglar alarm signal. The IBU(-SMK) is controlled door actuator by the Transmitter. The IBU(-SMK) is reset burglar alarm then receive transmitter signal and to key holder have car key during 30secend over Product: BODY CONTROL UNIT Model Name: BCM-E50 *This device was evaluated for RF exposure at 10cm distance in accordance with SPR-002 regulation. FCC / ISED Notice Caution: Any changes or modifications to this device not explicitly approved by manufacturer could avoid your authority to operate this equipment. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. Cet appareil est conforme aux limites d'exposition aux rayonnements de l’ISDE pour un environnement non contrôlé.

Hyundai MOBIS Co., Ltd. 203, Teheran‐ro, Gangnam‐gu, Seoul, 06141, Korea Tel. 82‐31‐260‐0092 April 01, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Letter of Authorization We, Hyundai MOBIS Co., Ltd. hereby authorize SGS Korea Co., Ltd. (Joohee Park, Jungmin Yang) to act on our behalf in all matters of certification. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Ant i‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). Any and all acts carried out by SGS Korea on our behalf shall have the same effect as acts of our own. This authorization is valid until further written notice. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd.

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. 82-3 1-2 60-0 092 April 01, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID: TQ8-BCM-50 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Hyundai MOBIS Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04- 1705. This provision will give Hyundai MOBIS Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short-Term 4 External Photos 5 Internal Photos 6 Test -Setup Photos 7 User ’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd.

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

Label Information BCM-E50 LABEL Label TOP OF EUT Label Position Hyundai MOBIS Co., Ltd. MODEL: BCM-E50 FCC ID: TQ8-BCM-E50 IC: 5074A-BCME50 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal photos of EUT View of Test Zig and EUT Internal view of EUT Antenna Zig Board EUT Top view of Main PCB Bottom view of Main PCB X400 X500 X501

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000487 Page:2of20 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) INDEX Table of Contents 1. General Information ----------------------------------------------------------------------- 3 2. Field Strength of Fundamental and Spurious Emission--------------------------- 6 3. 20㏈Bandwidth -------------------------------------------------------------------------- 17 4. Occupied Bandwidth----------------------------------------------------------------------- 19 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000487 Page:3of20 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.: +82 31 688 0901 Fax No.: +82 31 688 0921 1.2. Details of Applicant Applicant:Hyundai Mobis Co., Ltd. Address:203, Teheran-ro, Gangnam-gu, Seoul, South Korea, 135-977 Contact Person:Choe, Seung-hoon Phone No.:+82 31 260 0098 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product Body Control Module Model Name BCM-E50 Power Supply DC 12.0 V Frequency Range Tx: 125.00㎑, Rx: 433.92㎒ Antenna Type Tx Coil antenna Rx Chip antenna SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000487 Page:4of20 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.5. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due Spectrum Analyzer R&SFSV30103102 Jun. 05, 2019 Annual Jun. 05, 2020 Signal GeneratorR&SSMBV100A259067 Jun. 10, 2019 Annual Jun. 10, 2020 DC Power SupplyAgilent U8002AMY50060028Mar. 03, 2020AnnualMar. 03, 2021 Test ReceiverR&SESU26100109Feb. 18, 2020 Annual Feb. 18, 2021 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 15191519-039Aug. 22, 2019 BiennialAug. 22, 2021 Bilog Antenna Schwarzbeck Mess-Elektronik VULB 9163396Mar. 21, 2019BiennialMar. 21, 2021 Turn Table Innco systems GmbH DS 1200 SN/AN.C.R.N/AN.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/3 8330516/L N.C.R.N/AN.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. Coaxial CableSUCOFLEX 104 (3 m) MY3258414 Jan. 28, 2020 Semi- annual Jul. 28, 2020 Coaxial CableSUCOFLEX 104 (10 m) MY3145814 Jan. 28, 2020 Semi- annual Jul. 28, 2020 1.6. Test Procedure(s) The measurement procedures described in the American National Standard of Procedure for Compliance Testing of unlicensed Wireless Devices (ANSI C63.10-2013). 1.7.Sample Calculation Where relevant, the following sample calculation is provided: Field strength level (㏈㎶/m) = Measured level (㏈㎶) + Antenna factor (㏈) + Cable loss (㏈) SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000487 Page:5of20 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.8. Summary of Test Results The EUT has been tested according to the following specifications: Applied Standard: FCC Part15 subpart C, IC RSS-210 Issue 10 and RSS-Gen Issue 5 Section in FCCSection in ICTest Item(s)Result 15.209 RSS-210 Issue 10, 7.3, RSS-Gen Issue 5, 8.9 Radiated emission, Spurious Emission and Field Strength of Fundamental Complied 2.1049- 20㏈Bandwidth Complied - RSS-Gen Issue 5, 6.7 Occupied BandwidthComplied 1.9. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the apparatus: ParameterUncertainty Occupied Bandwidth ±9.66㎑ Radiated Emission, 9㎑to 30㎒ ± 3.59㏈ Radiated Emission, below 1㎓ ± 5.88㏈ Uncertainty figures are valid to a confidence level of 95 %. 1.10. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0004872020.03.30Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000487 Page:6of20 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2. Field Strength of Fundamental and Spurious Emission 2.1. Test Setup The diagram below shows the test setup that is utilized to make the measurements for emission from 9㎑ to 30㎒emissions. The diagram below shows the test setup that is utilized to make the measurements for emission from 30㎒ to 1㎓emissions. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL000487 Page:7of20 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2.2. Limit 2.2.1. FCC According to §15.209(a), except as provided elsewhere in this subpart, the emissions from an intentional radiator shall not exceed the field strength levels specified in the following table: Frequency (㎒) Field Strength (microvolts/meter) Measurement Distance (meter) 0.009-0.4902 400/F(㎑)300 0.490-1.70524 000/F(㎑)30 1.705-30.03030 30-88100**3 88-216150**3 216-960200**3 Above 9605003 ** Except as provided in paragraph (g), fundamental emissions from intentional radiators operating under this section shall not be located in the frequency bands 54-72㎒, 76-88㎒, 174-216㎒or 470-806㎒. However, operation within these frequency bands is permitted under other sections of this part, e.g., §§15.231 and 15.241. According to §15.209(d), The emission limits shown in the abov…

Text truncated - open the document above for the full version.

Test setup photos of EUT 1. Orthogonal plane of EUT - The testing was set in the below orthogonal plane and measured. X-axis 2. Photo of Radiated Spurious Emission Test (Below 1㎓)
