TQ8-BDC-4E01SMART KEY ECU

Model: BDC-4E01 The SMART KEY ECU is a part of START-STOP BUTTON SYSTEM. It is possible to output the LF(125kHz) signal by pushing the button of door handle and SSB. External antenna Internal antenna Manual for Vehicle Manufacturer #용진 정 / [email protected] / 본 문서는 현대모비스의 대외비 정보자산이므로 무단 전재 및 복제할 수 없으며, 위반 시 당사 사규 및 관련 법규에 의해 제재될 수 있습니다. FCC / ISED Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could avoid your authority to operate this equipment. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. Cet appareil est conforme aux limites d'exposition aux rayonnements de l’ISDE pour un environnement non contrôlé. ANTENNA INFORMATION This device has 7 Tx antennas as below: SSB antenna (93502-N1000) 6 LF antennas (95460-L2000, 95460-L2100, 95460-L2200, 95460-L2300, 95460-L2400, 95460-L2500) 6 LF antennasare identical but have 4 different part numbers as follow depending on the installation location in vehicle: 95460-L2000 95460-L2100 95460-L2200 95460-L2300 95460-L2400 95460-L2500 Each antenna is individually transmitted at each location. All antenna can transmit at the same time but physical location and distance between antenna are very far, at least 1 meter. Because of this, only one LF antenna was used for MPE testing. Rx antenna is PCB pattern antenna on the basic model and external antenna on the variant model. External LF antenna: ANTENNA PHOTOS Internal Receive antenna: External Receive antenna: External SSB antenna: EUT POSITION This device will be installed inside the vehicle. This distance between driver's seat and the EUT is 1.4m, and the distance between passenger's seat and the EUT is 1.04m. Please refer to the below drawing.

Hyundai MOBIS Co., Ltd. 203, Teheran‐ro, Gangnam‐gu, Seoul, 06141, Korea Tel. 82‐31‐260‐0092 June 24, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Letter of Authorization We, Hyundai MOBIS Co., Ltd. hereby authorize SGS Korea Co., Ltd. (Joohee Park, Jinhyoung Cho) to act on our behalf in all matters of certification. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, t hat includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). Any and all acts carried out by SGS Korea on our behalf shall have the same effect as acts of our own. This authorization is valid until further written notice. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Hyundai MOBIS Co., Ltd. Address 203, Teheran-ro, Gangnam-gu, Seoul, 135-977, Korea Grantee Code TQ8 FCC ID TQ8-BDC-4E01 Authorized Contact Name Seung Hoon Choe Contact Email [email protected] Contact Phone +82-31-260-0098 I, the under signed, certify that I am an authorized signatory for the Applicant and therefore declare; a)in ac cordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and beli ef. b)in ac cepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made i n th is application, the Applicant is responsible for: (1 ) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)i f the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensur e that pr oduction units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordanc e with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsibl e par ty and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in ac cordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements . (1 ) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CF R 1.2002(b) for the definition of a “party” for these purposes. g)t he Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions . Li nk to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2022-07-21 Print Name: Seung Hoon Choe Title: Senior Researcher *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 21 Ju ly 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID: TQ8-BDC-4E01 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Hyundai MOBIS Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04- 1705. This provision will give Hyundai MOBIS Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short-Term 4 External Photos 5 Internal Photos 6 Te s t-Setup Photos 7 User’s Manual Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Seung-Hoon Choe Senior Researcher Hyundai MOIBS Co., Ltd.

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 Letter of Declaration Product Equality J uly 21, 2022 We, Hyundai MOBIS Co., Ltd., as a manufacturer of following project, hereby declare that our product has variant model name as listed below. Variant model is identical with basic model but only has different received antenna. M odel Name Description Description Basic BDC-4E01 Representative production model Built-in received antenna Variant BDC-4E02 Variant production model External type received antenna S incerely, S eung-Hoon Choe Senior Researcher Hyundai MOIBS Co., Ltd. Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 ANNEX I: Please refer to the below tables for differences of basic model and variant model. a) The enclosure and general appearance in this family certification are identical and there is no difference on the external casing BDC-4E01 BDC-4E02 b) BDC-4E01 (Basic model) and BDC-4E02 (Variant model) use identical printed circuit board (PCB) design. only received antenna type is different. BDC-4E01 uses internal received antenna on the PCB BDC-4E02 uses external received antenna

Model name: BDC-4E01 External photos of EUT Model name: BDC-4E01 View of Test Zig and EUT View of External Receive Antenna Zig Board EUT SSBAntenna LFAntenna Model name: BDC-4E01 View of LF Antenna Model name: BDC-4E01 Model name: BDC-4E01 Model name: BDC-4E01 View of SSB Antenna Model name: BDC-4E01 - Basic model Top view of EUT Bottom view of EUT Model name: BDC-4E01 Side view of EUT Model name: BDC-4E01 Model name: BDC-4E01 - Variant model Top view of EUT Bottom view of EUT Model name: BDC-4E01 Side view of EUT Model name: BDC-4E01

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 Label information BDC-4E01 MODEL: BDC-4E01 FCC ID: TQ8- BDC-4E01 IC: 5074A- BDC4E01 Label draft Top of EUT LABEL Label Position Label will be put on the top of the EUT Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 Label information BDC-4E02 MODEL: BDC-4E02 FCC ID: TQ8- BDC-4E01 IC: 5074A- BDC4E01 Label draft Top of EUT LABEL Label Position Label will be put on the top of the EUT

Model name: BDC-4E01 In ternal photos of EUT Model name: BDC-4E01 - Basic model Internal view of EUT Model name: BDC-4E01 Top view of Main PCB Bottom view of Main PCB Model name: BDC-4E01 View of Internal Antenna Receive Antenna Model name: BDC-4E01 - Variant model Internal view of EUT Receive Antenna Model name: BDC-4E01 Top view of Main PCB Bottom view of Main PCB

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003303 Page: 2 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents Page 1. General Information ----------------------------------------------------------------------- 3 2. Field Strength of Fundamental and Spurious Emission--------------------------- 6 3. 20 ㏈ Bandwidth -------------------------------------------------------------------------- 27 4. Occupied Bandwidth----------------------------------------------------------------------- 31 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003303 Page: 3 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant Applicant : Hyundai Mobis Co., Ltd. Address : 203, Teheran-ro, Gangnam-gu, Seoul, South Korea, 135-977 Contact Person : Seung-hoon, Choe Phone No. : +82 31 260 0098 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product SMART KEY ECU Model Name BDC-4E01 Variant Model BDC-4E02 Serial Number 001 Power Supply DC 12.0 V Frequency Range Tx: 125.00 ㎑, Rx: 433.92 ㎒ Antenna Type Tx Coil Antenna Rx PCB Pattern Antenna Antenna Part Number SSB Antenna: 93502-N1000 LF Antenna: 95460-L2000, 95460-L2100, 95460-L2200, 95460-L2300, 95460-L2400, 95460-L2500 H/W Version B.02 S/W Version B.2 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003303 Page: 4 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Declarations by the manufacturer - The EUT has 7 transmit antenna and 1 receive antenna. - The transmit antennas can not operate at the same time. 1.6. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Spectrum Analyzer R&S FSV30 103210 Dec. 08, 2021 Annual Dec. 08, 2022 Signal Generator R&S SMBV100A 255834 May 25, 2022 Annual May 25, 2023 DC Power Supply Agilent U8002A MY49030063 Jan. 25, 2022 Annual Jan. 25, 2023 Preamplifier H.P. 8447F 2944A03909 Aug. 06, 2021 Annual Aug. 06, 2022 Test Receiver R&S ESU26 100109 Feb. 18, 2022 Annual Feb. 18, 2023 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 23, 2021 Biennial Aug. 23, 2023 Bilog Antenna Schwarzbeck Mess-Elektronik VULB 9163 01126 Feb. 07, 2022 Biennial Feb. 07, 2023 Turn Table Innco systems GmbH DS 1200 S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/3 8330516/L N.C.R. N/A N.C.R. Antenna Mast Innco systems GmbH MA4640-XP-ET MA4640/536/3 8330516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE MWX221-NMSNMS (4 m) J1023142 Apr. 04, 2022 Semi- annual Oct. 04, 2022 Coaxial Cable Micro-coax UTiflex 142A SERIES 50283-8 (10 m) 90000034 Apr. 04, 2022 Semi- annual Oct. 04, 2022 1.7. Sample Calculation Where relevant, the following sample calculation is provided: Field strength level (㏈㎶/m) = Measured level (㏈㎶) + Antenna factor (㏈) + Cable loss (㏈) SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003303 Page: 5 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.8. Summary of Test Results The EUT has been tested according to the following specifications: Applied standard: FCC Part 15 Subpart C, IC RSS-210 Issue 10, RSS-Gen Issue 5 Section in FCC Section in IC Test Item(s) Result 15.209 RSS-210 Issue 10, 7.3, RSS-Gen Issue 5, 8.9 Radiated emission, Spurious Emission and Field Strength of Fundamental Complied 2.1049 - 20 ㏈ Bandwidth Complied - RSS-Gen Issue 5 6.7 Occupied Bandwidth Complied 15.207 RSS-Gen Issue 5 8.8 AC Power Line Conducted Emission N/A 1) Note; 1) The AC power line test was not performed because the EUT use battery power for operation and which do not operate from the AC power lines. 1.9. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the apparatus: Parameter Uncertainty 20 ㏈ Bandwidth 3.90 ㎑ Radiated Emission, 9 ㎑ to 30 ㎒ H 3.30 ㏈ V 3.30 ㏈ Radiated Emission, below 1 ㎓ H 4.80 ㏈ V 5.20 ㏈ All measurement uncertainty values are shown with a coverage factor of k=2 to indicate a 95 % level of confidence. 1.10. Test Report Revision Revision Report Number Date of Issue Description 0 F690501-RF-RTL003303 2022.07.20 Initial 1.11. Description of Variant Model Model name Description Basic Model BDC-4E01 - Representative production model - Built-in received antenna Variant Model BDC-4E02 - Variant production model - External type received antenna SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003303 Page: 6 of 34 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 2. Field Strength of Fundamental and Spurious Emission 2.1. Test Setup The diagram below shows the test setup that is utilized to make the measurements for emission below 30 ㎒. The diagram below shows the test setup that is utilized to make the measurements for emission from 30 ㎒ to 1 ㎓. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea,…

Text truncated - open the document above for the full version.

Model name: BDC-4E01 Test setup photo of EUT Model name: BDC-4E01 1. Photo of Radiated Spurious Emission Test (9 ㎑ ~ 30 ㎒) 2. Photo of Radiated Spurious Emission Test (30 ㎒ ~ 1 000 ㎒)
