TQ8-FOB-4F61M43FOB Smart Key

Manual for vehicle manufacturer Model name: FOB-4 F61M43 OUTLINE1. How to use FOB-4F61M43 ‐ FOB-4F61M43 is a part of Remote Keyless System. ‐ This unit controls door lock/door unlock/ trunk open/panic/remote engine start-stop /forward/backward wirelessly. 2. Introduction of Transmitter ( FOB-4F61M43 ) - Th ese unit s use the battery ‐ Frequency is 433.92MHz GENERAL DESCRIPTION PRIMARY FUNCTION ‐ Remote door lock/door unlock/ trunk open/panic/remote engine start-stop /forward/backward ‐ Operating voltage: 3V DC ‐ Center freq.: 433.92MHz MANUAL1. LOCK Button If the LOCK button is pressed, then TRANSMITTER sends the LOCK data. 2. UNLOCK Button If the UNLOCK button is pressed, then TRANSMITTER sends the UNLOCK data. 3. TRUNK Button If the TRUNK button is pressed, then TRANSMITTER sends TRUNK open data. 4 . PANIC Button If the PANIC button is pressed, then TRANSMITTER sends PANIC data. 5 . Remote Engine Start-Stop Button If the Remote Engine Start-Stop Button is pressed, then TRANSMITTER sends the Remote Engine Start-Stop data. 6 . Forward Button If the Forward button is pressed, then TRANSMITTER sends Forward data. 7 . Backward Button If the Backward Button is pressed, then TRANSMITTER sends the Backward data. FCC/ISED NOTICE [FCC]This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Any changes or modifications to this device not explicitly approved by manuf acture r could avoid your authority to operate this equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC [ISED]This device contains licence ‐ ex empt transmit t er(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence ‐ exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le pr ésent appare il es t conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with ISED rad i ation exposure limits set forth for an uncontrolled environment. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the ISED Cet appareil est conforme aux limites d'exposition aux rayonnements de l’ISDE pour un environnement non con tr ô lé. L'émetteur ne doit pas être colocalisé ni fonctionner conjointement avec à autre antenne ou autre émetteur, à moins d'y être autorise par I'ISDE.

Hyundai MOBIS Co., Ltd. 203, Teheran‐ro, Gangnam‐gu, Seoul, 06141, Korea Tel. 82‐31‐260‐0092 June 16, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Letter of Authorization We, Hyundai MOBIS Co., Ltd. hereby authorize SGS Korea Co., Ltd. (Joohee Park, Brant Jang) to act on our behalf in all matters of certification. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). Any and all acts carried out by SGS Korea on our behalf shall have the same effect as acts of our own. This authorization is valid until further written notice. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd.

Applicant Declaration Applicant Declaration Rev:0. 0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Hyundai MOBIS Co., Ltd. Address 203, Teheran-ro, Gangnam-gu, Seoul, 135-977, Korea Grantee Code TQ8 FCC ID -FOB-4F61M43 Authorized Contact Name Seung Hoon Choe Contact Email [email protected] Contact Phone +82-31-260-0098 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2022-06-16 Print Name: Seung Hoon Choe Title: Senior Researcher *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. 82-3 1-2 60-0 092 June 16, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID: TQ8-FOB-4F61M43 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Hyundai MOBIS Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04- 1705. This provision will give Hyundai MOBIS Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short-Term 4 External Photos 5 Internal Photos 6 Test -Setup Photos 7 User ’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, __________________________ Seung Hoon Choe Senior Researcher Hyundai MOBIS Co., Ltd.

Hyundai MOBIS Co., Ltd. 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Tel. +82-31-260-2707, Fax. +82-31-899-1788 Letter of Declaration Product Equality June 27, 2022 We, Hyundai MOBIS Co., Ltd., as a manufacturer of following project, hereby declare that our product has variant model name as listed below. Variant model is identical with basic model but only has different number of buttons. Model Name Description Button Basic FOB-4F61M43 Basic model 7 Variant FOB-4F62M33 Same as basic model, but the difference in the number of external buttons of the product 6 FOB-4F62M42 6 FOB-4F63M41 5 FOB-4F64M31 4 FOB-4F64M40 4 FOB-4F65M21 3 FOB-4F65M30 3 FOB-4F66M20 2 FOB-4F64M301 4 Sincerely, Seung-Hoon Choe Senior Researcher Hyundai MOIBS Co., Ltd.

Model name: FOB-4F61M43 External photos of EUT Model name: FOB-4F61M43 Top view of EUT Bottom view of EUT Model name: FOB-4F61M43 Side view of EUT Model name: FOB-4F61M43

Label Information FOB-4F61M43 LABEL MODEL: FOB-4F61M43 FCC ID: TQ8- FOB- 4 F61M43 I SED : 5074A- FOB 4F61M43 Inside battery compartment Label Label PositionLabel will be put on the inside battery compartment. End user can see the label when replacing the battery. Hyundai MOBIS Co., Ltd. Label Information FOB-4F62M33 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB- 4F62M33 FCC ID: TQ8- FOB- 4 F61M43 I SED : 5074A- FOB 4F61M43 Label PositionLabel will be put on the inside battery compartment.End user can see the label when replacing the battery. Label Information FOB-4F62M42 LABEL MODEL: FOB-4F62M 42 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Inside battery compartment Label Hyundai MOBIS Co., Ltd. Label PositionLabel will be put on the inside battery compartment. End user can see the label when replacing the battery. Label Information FOB-4F63M41 LABEL MODEL: FOB-4F63M41 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Inside battery compartment Label Hyundai MOBIS Co., Ltd. Label PositionLabel will be put on the inside battery compartment. End user can see the label when replacing the battery. Label Information FOB-4F64M31 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB-4F64M31 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Label PositionLabel will be put on the inside battery compartment.End user can see the label when replacing the battery. Label Information FOB-4F64M40 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB-4F64M40 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Label PositionLabel will be put on the inside battery compartment.End user can see the label when replacing the battery. Label Information FOB-4F65M21 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB-4F65M21 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Label PositionLabel will be put on the inside battery compartment.End user can see the label when replacing the battery. Label Information FOB-4F65M30 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB-4F65M30 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Label PositionLabel will be put on the inside battery compartment. End user can see the label when replacing the battery. Label Information FOB-4F66M20 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB-4F66M20 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Label PositionLabel will be put on the inside battery compartment.End user can see the label when replacing the battery. Label Information FOB-4F64M301 LABEL Inside battery compartment Label Hyundai MOBIS Co., Ltd. MODEL: FOB-4F64M301 FCC ID: TQ8-FOB-4F61M43 ISED: 5074A-FOB4F61M43 Label PositionLabel will be put on the inside battery compartment.End user can see the label when replacing the battery.

Model name: FOB-4F61M43 Internal photos of EUT Model name: FOB-4F61M43 Internal view of EUT Model name: FOB-4F61M43 Top view of Main PCB Bottom view of Main PCB Model name: FOB-4F61M43 View of Antenna PCB Pattern Antenna

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003231 Page: 2 of 24 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) INDEX Table of Contents Page 1. General Information ----------------------------------------------------------------------- 3 2. Field Strength of Fundamental and Spurious Emission--------------------------- 7 3. Bandwidth of Operation Frequency---------------------------------------------------- 16 4. Occupied Bandwidth----------------------------------------------------------------------- 18 5. Transmission Time-------------------------------------------------------------------------- 20 6. Duty Cycle Correction Factor------------------------------------------------------------ 22 7. Antenna Requirement---------------------------------------------------------------------- 24 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003231 Page: 3 of 24 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil. Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone : +82 31 688 0901 FAX : +82 31 688 0921 1.2. Details of Applicant Applicant : Hyundai Mobis Co., Ltd. Address : 203, Teheran-ro, Gangnam-gu, Seoul, South Korea, 135-977 Contact Person : Seung-hoon, Choe Phone No. : +82 31 260 0098 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product FOB Smart Key Model Name FOB-4F61M43 Variant Model Names FOB-4F62M33, FOB-4F62M42, FOB-4F63M41, FOB-4F64M31, FOB-4F64M40, FOB-4F65M21, FOB-4F65M30, FOB-4F66M20, FOB-4F64M301 Serial Number Conducted: 001, Radiated: 002 Power Supply DC 3.0 V Frequency Range Tx: 433.92 ㎒, Rx: 125.00 ㎑ Modulation Type FSK Number of Channel 1 Antenna Type PCB Pattern Antenna Antenna Gain ※ -11.48 ㏈i H/W Version 1.00 S/W Version 1.00 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003231 Page: 4 of 24 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Signal Generator R&S SMBV100A 255834 May 25, 2022 Annual May 25, 2023 Spectrum Analyzer R&S FSV30 103210 Dec. 08, 2021 Annual Dec. 08, 2022 Spectrum Analyzer Agilent N9020A MY53421758 Aug. 27, 2021 Annual Aug. 27, 2022 DC Power Supply Agilent U8002A MY50020026 Dec. 01, 2021 Annual Dec. 01, 2022 Preamplifier H.P. 8447F 2944A03909 Aug. 06, 2021 Annual Aug. 06, 2022 Signal Conditioning Unit R&S SCU-18 10117 Jun. 09, 2021 Annual Jun. 09, 2022 High Pass Filter Wainwright Instrument GmbH WHKX10-900-1000- 18000-40SS 7 Mar. 04, 2022 Annual Mar. 04, 2023 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 23, 2021 Biennial Aug. 23, 2023 Bilog Antenna Schwarzbeck Mess-Elektronik VULB 9163 01126 Feb. 07, 2022 Annual Feb. 07, 2023 Horn Antenna R&S HF906 100326 Feb. 18, 2022 Annual Feb. 18, 2023 EMI Test Receiver R&S ESU26 100109 Jan. 18, 2022 Annual Jan. 18, 2023 Turn Table Innco systems GmbH DS 1200 S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/38 330516/L N.C.R. N/A N.C.R. Antenna Mast Innco systems GmbH MA4640-XP-ET MA4640/536/38 330516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE MWX221-NMSNMS (4 m) J1023142 Apr. 04, 2022 Semi- Annual Oct. 04, 2022 Coaxial Cable micro-coax UTiflex 142A SERIES 502839-8 (10 m) 90000034 Apr. 04, 2022 Semi- Annual Oct. 04, 2022 Coaxial Cable RFONE PL360P-292M292M-1.5 M-A 20200324002 Feb. 18, 2022 Semi- Annual Aug. 18, 2022 Note; - Operating software of EUT has integrated test interface. No additional software was used. - For equipment listed above that has a calibration date or calibration due date that falls within the test date range, care was taken to ensure that this equipment was used after the calibration date and before the calibraition due date. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003231 Page: 5 of 24 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 1.6. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15 Subpart C, IC RSS-210 Issue 10 and RSS-Gen Issue 5 Section in FCC Section in IC Test Item(s) Result 15.209(a) 15.231(b) RSS-210 Issue 10 A.1, Table A1 RSS-Gen Issue 5 8.9 Radiated emission, Spurious Emission and Field Strength of Fundamental Complied 15.231(c) - Bandwidth of Operation Frequency Complied - RSS-210 Issue 10 A.1.3 RSS-Gen Issue 5 6.7 Occupied Bandwidth Complied 15.231(a) RSS-210 Issue 10 A.1.1 Transmission Time Complied 15.207 RSS-Gen Issue 5 8.8 AC Power Line Conducted Emission N/A 1) Note; 1) The AC power line test was not performed because the EUT use battery power for operation and which do not operate from the AC power lines. 1.7. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the apparatus: Parameter Uncertainty Occupied Bandwidth 3.90 ㎑ Radiated Emission, 9 ㎑ to 30 ㎒ H 3.30 ㏈ V 3.30 ㏈ Radiated Emission, below 1 ㎓ H 4.80 ㏈ V 5.20 ㏈ Radiated Emission, above 1 ㎓ H 3.90 ㏈ V 4.00 ㏈ All measurement uncertainty values are shown with a coverage factor of k=2 to indicate a 95 % level of confidenc…

Text truncated - open the document above for the full version.

Model name: FOB-4F61M43 Test setup photos of EUT Model name: FOB-4F61M43 1. Orthogonal plane of EUT - The testing was set in the three orthogonal planes and measured for each position (X, Y, Z). X-axis Y-axis Model name: FOB-4F61M43 Z-axis Model name: FOB-4F61M43 2. Photos of Radiated Spurious Emission Test (Below 1㎓) Model name: FOB-4F61M43 3. Photo of Radiated Spurious Emission Test (Above 1㎓) Model name: FOB-4F61M43 4. Photo of Conducted Test
