31 Knowing your vehicle D300800AHM How vehicle audio works AM and FM radio signals are broadcast from transmitter towers located around your city. They are intercepted by the radio antenna on your vehicle. This signal is then received by the radio and sent to your vehicle speakers. When a strong radio signal has reached your vehicle, the precise engineering of your audio system ensures the best pos- sible quality reproduction. However, in some cases the signal coming to your vehicle may not be strong and clear. This can be due to factors such as the dis- tance from the radio station, closeness of other strong radio stations or the pres- ence of buildings, bridges or other large obstructions in the area. AM broadcasts can be received at greater distances than FM broadcasts. This is because AM radio waves are transmitted at low frequencies. These long, low frequency radio waves can fol- low the curvature of the earth rather than travelling straight out into the atmos- phere. In addition, they curve around obstructions so that they can provide bet- ter signal coverage. ¢¢¢¢¢¢ JBM002 AM reception ¢¢¢ JBM001 FM reception Knowing your vehicle 23 FM broadcasts are transmitted at high frequencies and do not bend to follow the earth's surface. Because of this, FM broadcasts generally begin to fade at short distances from the station. Also, FM signals are easily affected by buildings, mountains, or other obstruc- tions. These can result in certain listening conditions which might lead you to believe a problem exists with your radio. The following conditions are normal and do not indicate radio trouble: • Fading - As your vehicle moves away from the radio station, the signal will weaken and sound will begin to fade. When this occurs, we suggest that you select another stronger station. • Flutter/Static - Weak FM signals or large obstructions between the trans- mitter and your radio can disturb the signal causing static or fluttering nois- es to occur. Reducing the treble level may lessen this effect until the distur- bance clears. • Station Swapping - As a FM signal weakens, another more powerful sig- nal near the same frequency may begin to play. This is because your radio is designed to lock onto the clear- est signal. If this occurs, select another station with a stronger signal. • Multi-Path Cancellation - Radio signals being received from several directions can cause distortion or fluttering. This can be caused by a direct and reflect- ed signal from the same station, or by signals from two stations with close frequencies. If this occurs, select another station until the condition has passed. JBM005 ¢¢¢ JBM004JBM003 FM radio station 33 Knowing your vehicle Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equipment. This does not mean that something is wrong with the audio equipment. In such a case, use the cellu- lar phone at a place as far as possible from the audio equipment. Care of discs • If the temperature inside the vehicle is too high, open the vehicle windows for ventilation before using your vehicle audio. • It is illegal to copy and use MP3/WMA files without permission. Use CDs that are created only by lawful means. • Do not apply volatile agents such as benzene and thinner, normal cleaners and magnetic sprays made for ana- logue disc onto CDs. • To prevent the disc surface from get- ting damaged. Hold and carry CDs by the edges or the edges of the center hole only. • Clean the disc surface with a piece of soft cloth before playback (wipe it from the center to the outside edge). • Do not damage the disc surface or attach pieces of sticky tape or paper onto it. • Make sure objects other than CDs are not inserted into the CD player (Do not insert more than one CD at a time). • Keep CDs in their cases after use to protect them from scratches or dirt. • Depending on the type of CD-R/CD- RW CDs, certain CDs may not operate normally according to manufacturing companies or making and recording methods. In such circumstances, if you still continue to use those CDs, they may cause the malfunction of your vehicle audio system. ✽✽ NOTICE- Playing an Incompatible Copy Protected Audio CD Some copy protected CDs, which do not comply with the international audio CD standards (Red Book), may not play on your vehicle audio. Please note that if you try to play copy pr otected CDs and the CD player does not perform correct- ly the CDs maybe defective, not the CD player. WARNING Do not use a cellular phone while driving. Stop at a safe location to use a cellular phone. Knowing your vehicle 43 1. AM Button 2. FM Button 3. SEEK Button 4. Power ON/OFF Button 5. Preset Buttons 6. AST(AUTO STORE) Button 7. SETUP Button 8. TUNE Button 9. OK Button 10. MUTE Button 11. VOLUME Knob Using RADIO, SETUP, VOLUME and AUDIO CONTROL(CDP: PA710VG, CDC: PA760VG) VG_PA710VG_RADIO / VG_760VG_RADIO Using RADIO, SETUP, VOLUME and AUDIO CONTROL 1. AM Button Pressing the [AM] button selects the AM band. AM Mode is displayed on the LCD. 2. FM Button Turns to FM mode and toggles FM1and FM2 when the button is pressed each time. 3. SEEK Button • When the [SEEK] button is pressed, it increases the band frequency to auto- matically select channel. Stops at the previous frequency if no channel is found. • When the [TRACK] button is press- ed, it reduces the band frequency to automatically select channel. Stops at the previous frequency if no channel is found. 4. Power ON/OFF Button • Turns on/off the set when the IGNI- TION SWITCH is on ACC or ON. 5. Preset Buttons Push [1]~[6] buttons less than 0.8 sec- ond to play the channel saved in each button. Push Preset button for 0.8 sec- ond or longer to save current channel to the respective button with a beep. 6. AST(AUTO STORE Button) When the button is pressed, it automati- cally selects and saves channels with high reception rate to PRESET buttons [1]~[6] and plays the channel saved in PRESET1. If no chann…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 HYUNDAI MOBIS CO.,LTD. Nov 17, 2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, HYUNDAI MOBIS CO.,LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): CAR AUDIO, PA710VGXMB_MY We affirm that between SIEMIC and HYUNDAI MOBIS CO.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Seung-Kun Chon/ Assistant Manager HYUNDAI MOBIS CO.,LTD. 80-9, MABOOK-RI, GUSEONG-EUP, YONGIN-SHI, GYUNGGI-DO, 449-912 SOUTH KOREA FCC ID : TQ8-PA710VGXMB-MY

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 HYUNDAI MOBIS CO.,LTD. Nov 17 ,2010 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TQ8-PA710VGXMB-MY We hereby request confidential treatment of information accompanying this application as outlined below: COMNFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Schematics CONFIDENTIAL 3 Operational Description 4 External Photos 5 Internal Photos 6 Test-Setup Photos SHORT-TERM CONFIDENTIAL 7 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Seung-Kun Chon / Assistant Manager HYUNDAI MOBIS CO., LTD. 80-9, MABOOK-RI, GUSEONG-EUP, YONGIN-SHI, GYUNGGI-DO, 449-912 SOUTH KOREA

FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 1 / 6 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 2 / 6 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 3 / 6 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 4 / 6 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 5 / 6 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 6 / 6

FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 1 / 4 ATTACHMENT A. - ID LABEL INFORMATION AND LOCATION PHOTOS - FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 2 / 4 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 1.1 PRODUCT LABEL FCC Model No FCC ID EUT Type Serial No : PA710VGXMB_MY : TQ8-PA710VGXMB-MY : CAR AUDIO This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. 80-9, MABOOK-RI, GUSEONG-EUP, YONGIN-SHI, GYUNGGI-DO, 449-912 SOUTH KOREA MADE IN KOREA FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 3 / 4 FCC Model No FCC ID EUT Type Serial No : PA710VGMB_MY : TQ8-PA710VGXMB-MY : CAR AUDIO This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. 80-9, MABOOK-RI, GUSEONG-EUP, YONGIN-SHI, GYUNGGI-DO, 449-912 SOUTH KOREA MADE IN KOREA FCC Model No FCC ID EUT Type Serial No : PA710VGGB_MY : TQ8-PA710VGXMB-MY : CAR AUDIO This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. HYUNDAI MOBIS CO., LTD. 80-9, MABOOK-RI, GUSEONG-EUP, YONGIN-SHI, GYUNGGI-DO, 449-912 SOUTH KOREA MADE IN KOREA FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 4 / 4 1.2 Label Location Drawing The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Figure 1.2 LABEL LOCATION LABEL

FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 1 / 17 ATTACHMENT - INTERNAL PHOTOS - FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 2 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 3 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 4 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 5 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 6 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 7 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 8 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 9 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 10 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 11 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 12 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 13 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 14 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 15 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 16 / 17 FCC ID: TQ8-PA710VGXMB-MY HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1005FR15 17 / 17

MPE CALCULATION For HYUNDAI MOBIS CO., LTD – ; Model: PA710VGXMB_MY FCC ID: TQ8-PA710VGXMB-MY RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 / 47 CFR §2.1091 EUT Frequency Band: 2402 – 2480 MHz Limits for General Population/Uncontrolled Exposure in the band of: 1500 – 100,000 MHz Power Density Limit: 1.0mW/ cm 2 ; Equation: S = PG / 4πR 2 or R = √PG / 4πS Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ Low Channel (2402 MHz): Power = 2.97 d Bm, Antenna Gain = -0.27 dBi, Prediction distance 20cm S = 0.00037 mW/cm 2 Result The Above Result had shown that Device complied with 1.0 mW/cm 2 Power density requirement for distance of 20cm. Completed By : Jong Suk LEE Date : NOV 17, 2010

FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1011FR16 Date of Issue: November 16, 2010 EUT Type: CAR AUDIO FCC ID : TQ8-PA710VGXMB-MY Page 2 of 44 Version TEST REPORT NO. DATE DESCRIPTION HCTR1011FR16 November 16, 2010First Approval Report FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1011FR16 Date of Issue: November 16, 2010 EUT Type: CAR AUDIO FCC ID : TQ8-PA710VGXMB-MY Page 3 of 44 Table of Contents 1. GENERAL INFORMATION ....................................................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................................. 4 3. TEST METHODOLOGY ............................................................................................................................ 5 3.1 EUT CONFIGURATION ............................................................................................................. 5 3.2 EUT EXERCISE ......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ............................................................................................. 5 3.4 DESCRIPTION OF TEST MODES ............................................................................................ 5 4. INSTRUMENT CALIBRATION .................................................................................................................. 6 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1 FACILITIES ................................................................................................................................ 6 5.2 EQUIPMENT .............................................................................................................................. 6 6. ANTENNA REQUIREMENTS.................................................................................................................... 6 7. SUMMARY OF TEST RESULTS............................................................................................................... 7 8. FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1 PEAK POWER ........................................................................................................................... 8 8.2 BAND EDGES MEASUREMENT ............................................................................................ 12 8.3 FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 15 8.4 NUMBER OF HOPPING FREQUENCY .................................................................................. 20 8.5 TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 23 8.6 SPURIOUS EMISSIONS.......................................................................................................... 27 8.6.1 CONDUCTED SPURIOUS MEASUREMENT.................................................................. 27 8.6.2 RADIATED SPURIOUS EMISSIONS .............................................................................. 34 8.6.3 RADIATED RESTRICTED BAND EDGE MEASUREMENTS......................................... 42 8.7 POWERLINE CONDUCTED EMISSIONS............................................................................... 43 9. LIST OF TEST EQUIPMENT................................................................................................................... 44 FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1011FR16 Date of Issue: November 16, 2010 EUT Type: CAR AUDIO FCC ID : TQ8-PA710VGXMB-MY Page 4 of 44 1. GENERAL INFORMATION Applicant Name: HYUNDAI MOBIS CO., LTD. Address: 80-9, MABOOK-RI, GUSEONG-EUP, YONGIN-SHI,GYUNGGI-DO,449-912 SOUTH KOREA FCC ID: TQ8-PA710VGXMB-MY EUT: CAR AUDIO Model name(s): PA710VGXMB_MY Additional Model name(s): PA710VGMB_MY, PA710VGGB_MY Date(s) of Tests: October 26, 2010 ~ November 04, 2010 Contact Person: Name: Seung Keun, Jeon Phone #: +82-31-288-5232 Fax #: +82-31-899-1788 Place of Tests: HCT Co., Ltd. Icheon-si, Kyunggi-Do, Korea(Lab) (IC Recognition No. : 5944A-2) 2. EUT DESCRIPTION Product CAR AUDIO FCC Model Name PA710VGXMB_MY Additional Model(s) PA710VGMB_MY, PA710VGGB_MY Power Supply DC 12 V Frequency Range 2402 - 2480 MHz (Bluetooth) Transmit Power 2.97 dBm(1.98 mW) Modulation Type GFSK(Normal), PSK(EDR) Modulation Technique FHSS Number of Channels 79Channels Antenna Specification Manufacturer: AUTO INDUSTRIAL Co., Ltd. Antenna type: Chip Antenna Peak Gain : -0.27 dBi 15.247 Requirements for Bluetooth transmitter※ ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudorandomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1011FR16 Date of Issue: November 16, 2010 EUT Type: CAR AUDIO FCC ID : TQ8-PA710VGXMB-MY Page 5 of 44 3. TEST METHODOLOGY The measurement proced…
