TQ8-RKE-3F04Remote Keyless Entry

1. PRIMARY FUNCTION - Remote door lock/unlock/panic/tail gate - Operating distance : 30 m over - Id input(setting mode) 2. ELECTRICAL CHARACTERISTICS ETCFM modulation Operating frequency Power75 dBuV/m under -20 ~ +60 °C Consumption currentMax 15 mA Sensitivity- 315 ㎒ Operating temperature Description of Transmitter Operating voltage3 VDC TRANSMITTER model nameRKE-3F04 3. OPERATING DIAGRAM 1) TRANSMITTER A) DATA FRAME B) DATA FORMAT C) TRANSMISSION SPECIFICATION - BAUD RATE : 1kbps - CODING METHOD : MANCHESTER - TRANSMISSION BIT COUNT : 380Bit - TRANSMISSION TIME : 380ms±15% LOGIC "1"LOGIC "0" 9-17 APPENDIX M & SOFT AMERICA MAP CENTERTEL : 888-757-0010 WEBSITE : www.mapnsoft.com MAP DATABASE HOTLINE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equ ipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tu rning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ˍ Reorient or relocate the receiving antenna. ˍ Increase the separation between the equipment and receiver. ˍ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ˍ Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operat e this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may n ot cause harmful interference, and (2) this device must accept any interference received, including interference that may cause un desired operation. I              !   "# $     %&    $'(    $'    $    $   )*   $+,   "       ),    *      %&,    "  '(,  ,  "   * - " '. "      ",$    -     /       $ $   -  "      (0"  "     "   #         1 " /

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 HYUNDAI MOBIS CO.,LTD. March 22, 2012 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, HYUNDAI MOBIS CO.,LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Remote Keyless Entry , RKE-3F04 We affirm that between SIEMIC and HYUNDAI MOBIS CO.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Jong Tae Kim/ Senior Research Engineer HYUNDAI MOBIS CO.,LTD. 80-9, Mabook-Dong, Giheung-Gu Yongin-shi, Gyunggi-Do South Korea 446-912 FCC ID : TQ8-RKE-3F04

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 HYUNDAI MOBIS CO.,LTD. March 22,2012 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: TQ8-RKE-3F04 We hereby request confidential treatment of information accompanying this application as outlined below: COMNFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Schematics CONFIDENTIAL 3 Operational Description 4 External Photos 5 Internal Photos 6 Test-Setup Photos SHORT-TERM CONFIDENTIAL 7 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Jong Tae Kim / Senior Research Engineer HYUNDAI MOBIS CO., LTD. 80-9, Mabook-Dong, Giheung-Gu Yongin-shi, Gyunggi-Do South Korea 446-912

FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 6 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 6 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 6 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 4 / 6 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 5 / 6 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 6 / 6

FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 2 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 1.1 PRODUCT LABEL Model Name : RKE-3F04 FCC ID : TQ8-RKE-3F04 IC Model Name : RKE-3F04 IC: 5074A-RKE3F04 S/N: HYUNDAI MOBIS CO., LTD. MADE IN KOREA FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 2 1.2 Label Location Photos The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Figure 1.2 LABEL LOCATION LABEL

FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 1 / 3 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 2 / 3 FCC ID: TQ8-RKE-3F04/ IC: 5074A-RKE3F04 HCT CO., LTD. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA TEL:+82 31 645 6300 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1005FR15 3 / 3

FCC PT.15.231 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1203FR19-1 Date of Issue: March 23, 2012 EUT Type: Remote Keyless Entry FCC ID: TQ8-RKE-3F04 IC: 5074A-RKE3F04 Page ２ of 22 Version TEST REPORT NO. DATE DESCRIPTION HCTR1203FR19 March 20, 2012 - First Approval Report HCTR1203FR19-1 March 23, 2012 - Revised section 3.2 and 3.4 - Insert OBW result(Page. 8) FCC PT.15.231 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1203FR19-1 Date of Issue: March 23, 2012 EUT Type: Remote Keyless Entry FCC ID: TQ8-RKE-3F04 IC: 5074A-RKE3F04 Page ３ of 22 Table of Contents 1. GENERAL INFORMATION .........................................................................................................................４ 2. EUT DESCRIPTION .....................................................................................................................................４ 3. TEST METHODOLOGY ...............................................................................................................................５ 3.1 EUT CONFIGURATION.......................................................................................................................５ 3.2 EUT EXERCISE ...................................................................................................................................５ 3.3 GENERAL TEST PROCEDURES .......................................................................................................５ 3.4 DESCRIPTION OF TEST MODES ......................................................................................................５ 4. INSTRUMENT CALIBRATION.....................................................................................................................６ 5. FACILITIES AND ACCREDITATIONS .........................................................................................................６ 5.1 FACILITIES..........................................................................................................................................６ 5.2 EQUIPMENT ........................................................................................................................................６ 6. ANTENNA REQUIREMENTS ......................................................................................................................６ 7. LIMITS AND TEST RESULT ........................................................................................................................７ 7.1 20dB BANDWIDTH .............................................................................................................................８ 7.2 MAXIMUM MODULATION PERCENTAGE (M%) ..........................................................................１０ 7.3 LESS THAN 5 SECOND PLOT.......................................................................................................１３ 7.4 RADIATED EMISSIONS..................................................................................................................１５ 7.4.1 TRANSMITTER RADIATED SPURIOUS EMISSIONS........................................................１５ 7.4.2 TEST RESULTS ...................................................................................................................１８ 7.4.3 TEST RESULTS ...................................................................................................................１９ 7.4.4 FIELD STRENGTH CALCULATION .................................................................................... ２１ 8. LIST OF TEST EQUIPMENT ...................................................................................................................２２ FCC PT.15.231 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1203FR19-1 Date of Issue: March 23, 2012 EUT Type: Remote Keyless Entry FCC ID: TQ8-RKE-3F04 IC: 5074A-RKE3F04 Page ４ of 22 1. GENERAL INFORMATION Applicant: HYUNDAI MOBIS CO., LTD. Address: 80-9, Mabook-Dong, Giheung-Gu Yongin-shi Gyunggi-Do, 446-912 South Korea FCC ID: TQ8-RKE-3F04 IC : 5074A-RKE3F04 EUT: Remote Keyless Entry FCC Model(s): RKE-3F04 IC Model(s): RKE-3F04 Date of Test: February 09 , 2012 ~ March 17, 2012 Contact Person: Name: Keun Seop Park Phone #: +82-31-288-5194 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION Type Remote Keyless Entry Model Name RKE-3F04 Power Supply DC 3 V (Lithium Battery) Tx Frequency 315.00 MHz (Tx) Type of Modulation FSK Antenna Antenna type : PCB Pattern Antenna FCC PT.15.231 TEST REPORT FCC & IC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1203FR19-1 Date of Issue: March 23, 2012 EUT Type: Remote Keyless Entry FCC ID: TQ8-RKE-3F04 IC: 5074A-RKE3F04 Page ５ of 22 3. TEST METHODOLOGY The measurement procedure described in the American National Standard for Testing Unlicensed Wireless Devices(ANSI C63.10-2009) and FCC Public Notice DA 00-705 dated March 30, 2000 entitled “Filing and Measurement Guidelines for Transmitter for Remote Keyless Entry System” were used in the measurement of the HYUNDAI MOBIS CO., LTD. Remote Keyless Entry FCC ID: TQ8-RKE-3F04 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the Tx frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.231 under the FCC Rules Part 15 Subpart C. 3.3 GENERAL TEST PROCEDURES Conducted Emissions The EUT is placed on the turntable, which is 0.8 m above ground plane. According to the requirements in Section 6.2 of ANSI C63.10. (Version :2009) Conducted emissions from the EUT measured in the f…
