J3EUJ03 (영어 | 미국) 표준5 J3MS7-BD000 DIGITAL CAR AVN SYSTEM | User's Manual 1 [The functions and services described in this guide are subject to change without prior notice for performance improvement. If the system software is updated, the screenshots in this guide may appear different than the actual images on the system. [The functions and services described in this guide may differ from those provided in your vehicle. For precise information related to your vehicle, refer to the owner's manual or catalog of your vehicle. [The design and specification of the system may change without prior notice for performance improvement. [This multimedia system contains open source software, including without limitation, software distributed and/or modified under the GNU General Public license, Version 2, June 1991, and the GNU lesser General Public License, Version 2.1, February 1999. For additional information and to obtain related materials including without limitation, the previous referred to licenses and software, please contact us at [email protected] All Map Database cannot be copied without permission. Important Notice: This is protected by U.S. copyright laws. All rights not expressly granted are reserved. You may not otherwise reproduce, modify and distribute the content without HYUNDAI MnSoft, Inc’s prior written consent. 2 Available information for users Car Multimedia System User's Manual This guide introduces your system's functions and explains how to use them. To use your system correctly and safely, read this guide before using the system. Car Multimedia System Quick Reference Guide This guide combines key information into a quick reference. Use this guide to refer to descriptions and instructions more quickly and easily. Quick GuideThis guide is the help built into the system. You can access basic information on how to control the system and a brief description of major functions directly on the system screen. •How to access the guide: On the Home screen, touch All Menus > Quick Guide. For safety, this quick guide will not be displayed while the vehicle is moving. Park your vehicle in a safe location before accessing the quick guide. 3 Symbols used in this guide Warning Indicates important information related to user safety. Failure to follow warnings may result in death or serious personal injury. Caution Indicates important information related to user safety. Failure to follow cautions may result in personal injury, or damage or malfunction your vehicle. Note Indicates helpful information for convenient use. *if equipped Indicates descriptions for optional features. This guide covers all specifications, including all trim models and optional specifications. It may include descriptions for features that are not equipped in your vehicle. 4 For safety, follow the instructions below. Failure to do so may increase the risk of a traffic accident, which may result in death or personal injury. ÜAbout driving Do not operate the system while driving. •Driving while distracted may result in a loss of vehicle control, potentially leading to an accident, severe personal injury, or death. The driver’s primary responsibility is the safe and legal operation of a vehicle, and any handheld devices, equipment, or vehicle systems which divert the driver’s attention from this responsibility should never be used during operation of the vehicle. Follow traffic regulations while driving. •Driving only with the guidance of the navigation system may cause violation of traffic regulations, which may lead to a traffic accident. Depend on your vehicle's speedometer when checking your driving speed. •The speed displayed in the navigation screen may differ from your actual speed. Avoid watching the screen while driving. •Driving while distracted may lead to a traffic accident. •Stop your vehicle in a safe location before using functions that require multiple operations. Stop your vehicle first before using your mobile phone. •Using a mobile phone while driving may lead to a traffic accident. •If necessary, use the Bluetooth Handsfree feature to make calls and keep the call as short as possible. Keep the volume low enough to hear external sounds. •Driving without the ability to hear external sounds may lead to a traffic accident. •Listening to a loud volume for a long time may cause hearing damage. When looking for emergency services, such as hospitals or fire stations, do not depend solely on the navigation system. •Some emergency services may not be included in the navigation map. Locate nearby emergency services in advance so you can take the proper action quickly in an emergency situation. Safety warnings 5 ÜAbout handling the system Do not disassemble or modify the system. •Doing so may result in an accident, fire, or electric shock. Do not allow liquids or foreign substances to enter the system. •Liquids or foreign substances may cause noxious fumes, a fire, or a system malfunction. Stop using the system if it malfunctions, such as no audio output or display. •If you continue using the system when it is malfunctioning, it may lead to a fire, electric shock, or system failure. ÛNote If you experience any problems with the system, contact your place of purchase or dealer. 6 Safety cautions For safety, follow the instructions below. Failure to do so may result in personal injury or damage to the system. ÝAbout operating the system Use the system with the engine running. •Using the system for a long time when the engine is stopped may discharge the battery. Do not install unapproved products. •Using unapproved products may cause an error while using the system. •System errors caused by installing unapproved products are not covered under the warranty. ÝAbout handling the system Do not apply excessive force to the system. •Excessive pressure on the screen may damage the LCD panel or the touch panel. When cleaning the screen or button panel, make sure to stop the engine and use a soft, dry cloth. •Wi…

Text truncated - open the document above for the full version.

HYUNDAI MOBIS CO., LTD. 203 Teheran-ro, Gangnam-gu, Seoul, Korea, 135-977 Date: Oct 13, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: TQ8-VT240GKAN including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from HYUNDAI MOBIS CO., LTD. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seung Hoon Choe Manager

HYUNDAI MOBIS CO., LTD. 203 Teheran-ro, Gangnam-gu, Seoul, Korea, 135-977 Date: Oct 13, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: TQ8-VT240GKAN To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, HYUNDAI MOBIS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give HYUNDAI MOBIS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Seung Hoon Choe Manager

Supplier’s Declaration of Conformity 47 CFR, Part2.1077 Compliance Information Product: DIGITAL CAR AVN SYSTEM Model: VT240GKAN This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This document is the proof that above product, system, and also relates OEM models are complying with FCC requirement. Company: Address: Tel: E-mail: Responsible Party – U.S. Contact Information HYUNDAI MOBIS Co., Ltd. 46501 Commerce Center Drive Plymouth, Michigan MI 48170 1-248-426-5577 [email protected] Signature: Name: Position: Date: Seung-Kun Chon Manager October 26, 2020

FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 <Port> <Antenna>

FCC ID: TQ8-VT240GKAN SAMPLE LABEL & LOCATION MODEL: VT240GKAN 14.4 V 4 Ω10 A AM 531 ~ 1602 kHz MADE IN KOREA This device complies with part 15 of the FCC Rules. O peration is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. UNDER LICENSE OF STAAR S.A. , BRUXELLS BELGIUM: DOLBY NOISE REDUCTION MANUFACTURED UNDER LICENSE FROM DOLBY LABORATORIES LICENSING CORPORATION. "DOLBY" AND THE DOUBLE-D SYMBOL ARE TRADEMARKS OF DOLBY LABORATORIES LICENSING CORPORATION MANUFACTURED : HYUNDAI MOBIS CO., LTD. Copyright Ⓒ 2020, DT&C Co., Ltd. FM 87.5 ~ 108 MHz FCC ID: TQ8-VT240GKAN Contains FCC ID: YZP-VL3000

FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 5 <Module> <Module> FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 6 <Module>

FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 7 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 8 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 9 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 10

FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 11 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 12 FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. View 13 <Antenna> <Antenna>

FCC ID: RF function(Mode) Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) Bluetooth(1Mbps) 2402.00 ~ 2480.00 1.00 -0.38 0.62 1.154 0.0003 1.0000 Bluetooth(2,3Mbps) 2402.00 ~ 2480.00 -4.00 -0.38 -4.38 0.365 0.0001 1.0000 ~~~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : MPE Calculation : Bluetooth Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below.Note: Please refer to the operation description for Max tune-up power. TQ8-VT240GKAN ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 1.154 S= Maximum power density(mW/cm 2 ) 0.0003 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the antenna(20cm) FCC ID: Mode(Worst case) Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum power density (mW/cm 2 ) Requriment (mW/cm 2 ) 802.11g 2412.00 ~ 2462.00 8.50 -1.19 7.31 5.383 0.0011 1.0000 802.11a 5180.00 ~ 5240.00 8.50 0.59 9.09 8.110 0.0017 1.0000 802.11a 5260.00 ~ 5320.00 8.50 2.00 10.50 11.221 0.0023 1.0000 802.11a 5500.00 ~ 5720.00 7.00 4.58 11.58 14.388 0.0029 1.0000 802.11a 5745.00 ~ 5825.00 7.00 4.19 11.19 13.153 0.0027 1.0000 ~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : R= Distance to the center of the radiation of the antenna(20cm) ▪ Limits for Maximum Perm issible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 5.383 S= Maximum power density(mW/cm 2 ) 0.0011 EIRP= Equivalent Isotropic Radiated Power(mW) MPE Calculation : WLAN Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below.Note: Please refer to the operation description for Max tune-up power. TQ8-VT240GKAN FCC ID: TQ8-VT240GKAN RF function or Mode Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum power density (mW/cm 2 ) Requriment (mW/cm 2 ) LTE(Band 13) 777.00 ~ 787.00 26.20 4.14 30.34 1081.434 0.2152 0.5180 LTE(Band 5) 824.70 ~ 848.30 26.20 4.76 30.96 1247.384 0.2482 0.5490 LTE(Band 4) 1710.70 ~ 1754.30 26.20 0.62 26.82 480.840 0.0957 1.0000 LTE(Band 2) 1850.70 ~ 1909.30 26.20 4.70 30.90 1230.269 0.2448 1.0000 CDMA(Band 850) 824.70 ~ 848.31 26.20 4.76 30.96 1247.384 0.2482 0.5490 CDMA(Band 1900) 1851.25 ~ 1908.75 26.20 4.70 30.90 1230.269 0.2448 1.0000 ~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : R= Distance to the center of the radiation of the antenna(20cm) 0.2152 EIRP= Equivalent Isotropic Radiated Power(mW) MPE Calculation : LTE, CDMA Frequency range (MHz) Note: Please refer to the operation description for Max tune-up power. ▪ Limits for Maximum Perm issible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below. EIRP / ( 4 R 2 π ) 1081.434 S= Maximum power density(mW/cm 2 ) ▪▪ - TQ8-VT240GKAN FCC ID: RF Exposure Compliance for simultaneous operations - The exposure condition of this device is compliant with FCC rul es. Conclusion : Σ of MPE ratios ≤ 1 ▪ Requirment = - 0.4553 0.0029 Worst case for simultaneous operations Requirement (mW/cm 2 ) - 1.0000 - - Worst case(MPE ratio) 0.4521 - 0.00030.0003 MPE ratio (Power Density/Requirement) -- Σ of MPE ratios - 2.4GHz 0.0003 5GHz 0.45210.5490 0.0029 - Band 5 0.2482 RF function or mode(Worst case) BT + W-LAN(5GHz) + LTE (Band 5) 1.0000 WLAN BT Power Density (mW/cm2) 0.0029 LTE Band(Worst case)

Report No.: DRTFCC2010-0307 FCC ID: TQ8-VT240GKAN TRF-RF-228(04)170516 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 15 Test Report Version Test Report No. Date Description Tested by Reviewed by DRTFCC2010-0307 Oct. 14, 2020 Initial issue JungWoo Kim JaeJin Lee Report No.: DRTFCC2010-0307 FCC ID: TQ8-VT240GKAN TRF-RF-228(04)170516 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 15 Table of Contents 1. GENERAL INFORMATIONEUT DESCRIPTION ........................ 4 1.1. EUT Description .................................................................... 4 1.2. Auxiliary equipment ............................................................... 4 1.3. Testing environment .............................................................. 4 2. DYNAMIC FREQUENCY SELECTION TEST DESCRIPTION ... 5 2.1. Applicability of DFS requirements prior to use of a channel ... 5 2.2. Applicability of DFS requirements during normal operation ... 5 2.3. Requirements of client devices .............................................. 6 2.4. DFS response requirement values ........................................ 7 2.5. DFS detection thresholds ...................................................... 7 2.6. Radar test waveforms ........................................................... 8 3. Test procedure .......................................................................... 9 3.1. Setup for Client with injection at the Master ........................... 9 3.2. Spectrum analyzer setting parameter .................................... 9 3.3. Conducted test procedure ..................................................... 9 4. SUMMARY OF TESTS ............................................................. 10 5. LIST OF EQUIPMENTS ............................................................11 6. TEST RESULTS ....................................................................... 12 6.1. Move time and aggregate time ............................................ 12 6.1.1. U-NII-2A: 5 310 MHz ........................................................................ 12 6.1.2. U-NII-2C: 5 510 MHz ........................................................................ 12 6.2. Non-occupancy period ........................................................ 13 6.2.1. U-NII-2A: 5 310 MHz ........................................................................ 13 6.2.2. U-NII-2C: 5 510 MHz ........................................................................ 13 APPENDIX I ................................................................................. 14 Report No.: DRTFCC2010-0307 FCC ID: TQ8-VT240GKAN TRF-RF-228(04)170516 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 15 1. GENERAL INFORMATIONEUT DESCRIPTION 1.1. EUT Description Equipment class Unlicensed National Information Infrastructure (UNII) Product DIGITAL CAR AVN SYSTEM Model Name VT240GKAN Add Model Name VT240I3AN Serial Number Conducted sample: 0646385692 EUT capabilities DFS Power supply DC 14.4 V Test condition Conducted Radiated Channel bandwidth 802.11a/n/ac: 20 MHz 802.11n/ac: 40 MHz 802.11ac: 80 MHz Frequency Range U-NII 2A(5 250 ~ 5 350 MHz) U-NII 2C(5 470 ~ 5 725 MHz) ▪ 802.11a/n(HT20)/ac(VHT20): 5 260 ~ 5 320 MHz ▪ 802.11n(HT40)/ac(VHT40): 5 270 ~ 5 310 MHz ▪ 802.11ac(VHT80) 5 290 MHz ▪ 802.11a/n(HT20)/ac(VHT20): 5 500 ~ 5 580, 5 660 ~ 5 720 MHz ▪ 802.11n(HT40)/ac(VHT40): 5 510 ~ 5 550, 5 670~5 710 MHz ▪ 802.11ac(VHT80): 5 530, 5 690 MHz Modulation type OFDM Operational mode Master mode Client mode without radar detection Client mode with radar detection Antenna specification Antenna type: PCB Pattern Antenna Antenna gain U-NII-2A 2.00 dBi U-NII-2C 4.58 dBi Note1: The above EUT information was declared by the manufacturer. Note2: Refer to UNII report. 1.2. Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note Access Point (Master) DIR-868L R3X81E6000093 D-Link FCC ID: KA2IR868LA1 Contains FCC ID: RRK2012060056-1 1.3. Testing environment Ambient Condition ▪ Temperature 21 o C ~ 23 o C ▪ Relative Humidity 40 % ~ 43 % Report No.: DRTFCC2010-0307 FCC ID: TQ8-VT240GKAN TRF-RF-228(04)170516 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 15 2. DYNAMIC FREQUENCY SELECTION TEST DESCRIPTION 2.1. Applicability of DFS requirements prior to use of a channel Requirement Operational mode Master Client without radar detection Client with radar detection Non-Occupancy Period Yes Not required Yes DFS Detection Threshold Yes Not required Yes Channel Availability Check time Yes Not required Not required U-NII Detection Bandwidth Yes Not required Yes 2.2. Applicability of DFS requirements during normal operation Requirement Operational mode Master or client with radar detection Client without radar detection DFS Detection Threshold Yes Not required Channel Closing Transmission Time Yes Yes Channel Move time Yes Yes U-NII Detection Bandwidth Yes Not required Report No.: DRTFCC2010-0307 FCC ID: TQ8-VT240GKAN TRF-RF-228(04)170516 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 6 / 15 Additional requirements for devices with multiple bandwidth modes Operational mode Master or client with radar detection Client without radar detection U-NII Detection Bandwidth and Statistical Performance Check All BW modes must be tested Not required Channel Move Time and Channel Closing Transmission Time Test using widest BW mode available Test using the widest BW mode available for the link All other tests Any single BW mode Not required Note: Frequencies selected for statistical performance check (Section 7.8.4) should include several frequencies within the radar detection bandwidth and frequencies near the edge of the radar detection bandwidth. For 802.11 devices it is suggested to select frequencies in each of the bonded 20 MHz channels and the channel center frequency. The EUT was tested according to the foll…

Text truncated - open the document above for the full version.

Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 56 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT20 & Ch.149 Maximum Power Spectral Density Test Mode: 802.11n HT20 & Ch.157 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 57 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT20 & Ch.165 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 58 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.38 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.46 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 59 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.54 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.62 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 60 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.102 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.110 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 61 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.142 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 62 / 110 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.151 Maximum Power Spectral Density Test Mode: 802.11n HT40 & Ch.159 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 63 / 110 Maximum Power Spectral Density Test Mode: 802.11ac VHT80 & Ch.42 Maximum Power Spectral Density Test Mode: 802.11ac VHT80 & Ch.58 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 64 / 110 Maximum Power Spectral Density Test Mode: 802.11ac VHT80 & Ch.106 Maximum Power Spectral Density Test Mode: 802.11ac VHT80 & Ch.138 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 65 / 110 Maximum Power Spectral Density Test Mode: 802.11ac VHT80 & Ch.155 Report No.: DRTFCC2010-0312 FCC ID: TQ8-VT240GKAN TRF-RF-234(05)180806 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 66 / 110 8.5 Radiated Spurious Emission Measurements ▣ Test Requirements ▪ FCC Part 15.209(a) and (b) Frequency (MHz) Limit (uV/m) Measurement Distance (meter) 0.009 – 0.490 2400/F(KHz) 300 0.490 – 1.705 24000/F(KHz) 30 1.705 – 30.0 30 30 30 ~ 88 100 ** 3 88 ~ 216 150 ** 3 216 ~ 960 200 ** 3 Above 960 500 3 ** Except as provided in 15.209(g), fundamental emissions from intentional radiators operating under this Section shall not be located in the frequency bands 54-72 MHz, 76-88 MHz, 174-216 MHz or 470-806 MHz. However, operation within these frequency bands is permitted under other sections of this Part, e.g. 15.231 and 15.241. ▪ FCC Part 15.205 (a): Only spurious emissions are permitted in any of the frequency bands listed below: MHz MHz MHz MHz GHz GHz 0.009 ~ 0.110 0.495 ~ 0.505 2.1735 ~ 2.1905 4.125 ~ 4.128 4.17725 ~ 4.17775 4.20725 ~ 4.20775 6.215 ~ 6.218 6.26775 ~ 6.26825 6.31175 ~ 6.31225 8.291 ~ 8.294 8.362 ~ 8.366 8.37625 ~ 8.38675 8.41425 ~ 8.41475 12.29 ~ 12.293 12.51975 ~ 12.52025 12.57675 ~ 12.57725 13.36 ~ 13.41 16.42 ~ 16.423 16.69475 ~ 16.69525 16.80425 ~ 16.80475 25.5 ~ 25.67 37.5 ~ 38.25 73 ~ 74.6 74.8 ~ 75.2 108 ~ 121.94 123 ~ 138 149.9 ~ 150.05 160.52475 ~ 160.52525 160.7 ~ 160.9 162.0125 ~ 167.17 167.72 ~ 173.2 240 ~ 285 322 ~ 335.4 399.90 ~ 410 608 ~ 614 960 ~ 1240 1300 ~ 1427 1435 ~ 1626.5 1645.5 ~ 1646.5 1660 ~ 1710 1718.8 ~ 1722.2 2200 ~ 2300 2310 ~ 2390 2483.5 ~ 2500 2655 ~ 2900 3260 ~ 3267 3332 ~ 3339 3345.8 ~ 3358 3600 ~ 4000 4.5 ~ 5.15 5.35 ~ 5.46 7.25 ~ 7.75 8.025 ~ 8.5 9.0 ~ 9.2 9.3 ~ 9.5 10.6 ~ 12.7 13.25 ~ 13.4 14.47 ~ 14.5 15.35 ~ 16.2 17.7 ~ 21.4 22.01 ~ 23.12 23.6 ~ 24.0 31.2 ~ 31.8 36.43 ~ 36.5 Above 38.6 ▪ FCC Part 15.205(b): The field strength of emissions appearing within these frequency bands shall not exceed the limits shown in §15.209. At frequencies equal to or less than 1000 MHz, compliance with the limits in §15.209 shall be demonstrated using measurement instrumentation employing a CISPR quasi-peak detector. Above 1000 MHz, compliance with the emission limits in §15.209 shall be demonstrated based on the average value of the measured emissions. The provisions in §15.35 apply to these measurements. ▪ FCC Part 15.407 (b): Undesirable emission limits. Except as shown in paragraph (b)(7) of this section, the maximum emissions outside of the frequency bands of operation shall be attenuated in accordance with the following limits: (1) For transmitters operating in the 5.15-5.25 GHz band: all emissions outside of the 5.15-5.35 GHz band shall not exceed an EIRP of -27 dBm/MHz. (2) For transmitters operating in the 5.25-5.35 GHz band: all emissions outside of the 5.15-5.35 GHz band shall not exceed an EIRP of -27 dBm/MHz. (3) For transmitters operating in the 5.47-5.725 GHz band: all emissions outside of the 5.47-5.725 GHz band shall not exceed an EIRP of -27 dBm/MHz. (4) For transmitters operating in the 5.725-5.85 GHz band: All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the band edge, and from 25 MHz above or below the band edge increasing linear…

Text truncated - open the document above for the full version.

FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement EUT Position: X-axis FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz)) FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz) FCC ID : TQ8-VT240GKAN Copyright Ⓒ 2020, DT&C Co., Ltd. Test Setup Photo for DFS
