TSNMOXLROutdoor Sound Module/Transmitter

Minaska Outdoors
Outdoor Sound Module/Transmitter - FCC ID TSNMOXLR - Minaska Outdoors
Click to zoom

Application Details

Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Date of Grant
Dec 01, 2005
Application Purpose
Original Equipment
Date of Application
Dec 01, 2005
Equipment Note
Outdoor Sound Module/Transmitter
Frequency Range
418.00000000 - 418.00000000
Company
Minaska Outdoors
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Minaska Outdoors 6517 Platte Avenue Lincoln, Nebraska 68507 Phone: 1-877-646-2752 www.minaskaoutdoors.com User Manual Call Base Receiver Unit: • Load sounds on Compact Flash Card (See: Loading Sounds On Card) • Turn unit on by rotating volume switch clockwise to desired volume level • Raise base antenna to vertical NOTE: Although The Bandit can operate on the ground with respectable range. To obtain maximum range place unit a few feet off of ground on a stable surface. Suspending from a tree by the handle with a sturdy strap also will improve operation range. Call Remote Transmitter: • Turn power switch on top of unit to “ON” • “BANK” Button: Select sound file by first selecting the sound bank by pressing “Bank” button and within a few seconds pressing the respective number button “0-9”. If you desire bank 0 the unit needs no bank selection after power up. • “0 – 9” Buttons: A bank of ten sounds is now ready for selection, select you sound by again pressing the respective number button “0-9”. • Once the remote is in a bank it will stay in that bank until a different bank is selected with the “Bank” button or the remote is powered off. The remote always powers up to default “Bank 0”. TIP: Organize up to 100 sounds in the given banks by category. REMEMBER: When you select a bank you can switch between the sounds of that bank with a single button push without reselecting the bank again. • “P” Button: To PAUSE the sound press the “P” button once. To resume the sound press the “P” again, or select a sound file. • “Aux: Button: To operate the auxiliary relay output for decoy operation press the “Aux” button once to close the relay, press it once again to open the relay contacts. Contacts are rated: < 50V AC/DC and < 100mA • “ + ” & “ - “ Buttons: Push and hold increase or decrease the volume of playback Page 1 Loading Sounds On Card: • Remove compact flash card from call and insert in a card reader on you computer • Open Windows Explorer, the card will show up as a drive on your computer • Drag .mp3 sounds on to the card • Rename the file names in proper the call recognizable format below • Sounds must have a 3 digit prefix in the file name for the call to recognize a given sound. Ex: 001 is Bank 0 file 1 - 099 is Bank 9 file 9 So a typical file name should look as follows: 076 CoonPuppies.mp3 This file will be stored in bank 7 file 6, only one file with a given numbered prefix may be on the compact flash card. In other words don’t double up the prefixs, the call doesn’t care about anything but the first three characters of a file name. TIP: Organize up to 100 sounds in the given banks by category. REMEMBER: When you select a bank you can switch between the sounds of that bank with a single button push without reselecting the bank again. • After card has been changed to desired format, reinsert into call with care using light pressure it only goes in one way, with label facing out. FCC STATEMENT The user is cautioned that changes or modifications to this equipment not expressly approved by Minaska Outdoors could void your authority to operate this equipment. This equipment has been tested and found to comply with limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: *Reorient or relocate the receiving antenna. *Increase separation between the equipment and the receiver. *Consult the dealer or an experienced radio / TV technician for help. FCC ID: TSNMOXLR Page 2

Cover Letter(s)

Mr. Fujimoto: In order for processing of this application (FCC ID: TSNMOXLR) to continue, the following issue(s) will have to be addressed: 1) The FCC ID in the test report and the one stated in the 731 form are different. Please clarify the correct FCC ID that is to be used and submit any corrections. 2) The block diagram submitted does not appear to match the schematics submitted. Please submit the appropriate block diagram or schematic. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is TSNMOXLR-1. Best Regards, Mike Christensen Evaluator Compatible Electronics TCB Phone: 714-579-0500 Fax: 714-579-1850 www.celectronics.com

Cover Letter(s)

Correspondence by Project Project Number: -201779991 Correspondence Number Memo TSNMOXLR-1 1. The Test Report has been revised to show the Correct FCC-ID. 2. The wrong block diagram was uploaded. The Correct one has been Uploaded.

Test Report

Report Number: B51031D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Outdoor Sound Module/Transmitter Model: The Bandit 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for OUTDOOR SOUND MODULE/TRANSMITTER MODEL: THE BANDIT Prepared for MINASKA OUTDOORS 6517 PLATTE AVENUE LINCOLN, NEBRASKA 68507 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: NOVEMBER 8, 2005 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 12 17 51 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B51031D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Outdoor Sound Module/Transmitter Model: The Bandit 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Radiated Emissions (Spurious and Harmonics) Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test (continued) 14 7.3 Bandwidth of the Fundamental 15 8. CONCLUSIONS 16 Report Number: B51031D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Outdoor Sound Module/Transmitter Model: The Bandit 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Test Site Report Number: B51031D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Outdoor Sound Module/Transmitter Model: The Bandit 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Outdoor Sound Module/Transmitter Model: The Bandit S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Manufacturer: Minaska Outdoors 6517 Platte Avenue Lincoln, Nebraska 68507 Test Dates: October 28 and 31, 2005 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209, and 15.231 Test Procedure: ANSI C63.4: 2003 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT operates on batteries only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions, 9 kHz - 4400 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. 3 -20 dB Bandwidth of the Fundamental Complies with the limits of Subpart C, sections 15.231 [c]. Report Number: B51031D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Outdoor Sound Module/Transmitter Model: The Bandit 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Outdoor Sound Module/Transmitter Model: The Bandit. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 2003. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B51031D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Outdoor Sound Module/Transmitter Model: The Bandit 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 16 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3 Cognizant Personnel Minaska Outdoors Steve Borland Owner Compatible Electronics, Inc. Kyle Fujimoto Test Engineer James Ross Test Engineer 2.4 Date Test Sample was Received The…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Steve Borland(Owner)
[email protected](402) 570-1680Fax: N/A

Technical Contact

Compatible Electronics, Inc.Kyle Fujimoto
[email protected]714-579-0500

114 Olinda Drive · Brea, California · United States

Test Firm

Compatible Electronics, Inc.Michael Christensen
[email protected]714-579-0500Fax: 714-579-1850

Technical Specifications

#Rule PartsFrequency RangePower Output
115.231418 MHz - 418 MHz-
Confidentiality
Long Term
