TTHDNMA92AMDNMA92AM data radio module

1761 International Parkway, Suite 113 Richardson, TX 75081 O: 972-231-2122; F: 972-231-2406; www.agilemesh.com Agilemesh RF Module Implementation Guide Purpose: This guide is intended as an internal Agilemesh guidance document to ensure that the radio module identified is installed in Agilemesh equipment in an appropriate manner so as to comply with the conditions of the original FCC grant and IC certificate. Applicability: RF module FCC ID.: TTHDNMA92AM, IC:10127A-DNMA92AM Antennas: The module was certified with the following antennas. These antennas or antennas of the same design but lower gain may be used in the final installation. Band (GHz) Gain dBi Manufacturer’s P/N Manufacturer 2.4 7.4 SF-245SPR NCG 4.9 5.3 SF-D49NSR NCG 5.X 5.5 SF-D53NSR NCG Antenna connection: The final assembly must have non-standard antenna connection such as a reverse gender connector. Final assembly labeling: The final assembly must contain a label notifying the user that the device contains a certified rf module that is identified by the following product approval numbers: FCC ID.: TTHDNMA92AM IC: 10127A-DNMA92AM An example of such a label is shown below. 1761 International Parkway, Suite 113 Richardson, TX 75081 O: 972-231-2122; F: 972-231-2406; www.agilemesh.com Human exposure to Radio Frequency (RF) energy: The module referenced in this document was evaluated to determine compliance with ANSI C.95 (USA) and Safety Code 6 (Canada). This module can only be used in final assemblies that are used in a mobile environment where the radiating element is located a minimum of 20 cm. from the user or nearby persons. This module must not be used in a final product that is used in an environment where the radiated element may be expected to be closer than 20 cm. from the user or nearby persons. Unintentional emission requirements: The final product must be tested for unintentional emissions in accordance with the following regulations. USA – CFR 47, Part 15, Subpart B Canada – ICES-003, Issue 4 Modification: The rf module referenced in this document must not be modified in an manner. RF Power and channel assignment: The rf module is programmed to operate only in the following channels and with the specified rf power output. AgileMesh Channel Band/Modulation Center Freq. (GHz) TX Power (dBm) 0 2.4 GHz OFDM 2.4120 16 1 2.4 GHz OFDM 2.4170 20 2 2.4 GHz OFDM 2.4220 20 3 2.4 GHz OFDM 2.4270 20 4 2.4 GHz OFDM 2.4320 20 5 2.4 GHz OFDM 2.4370 20 6 2.4 GHz OFDM 2.4420 20 7 2.4 GHz OFDM 2.4470 20 8 2.4 GHz OFDM 2.4520 20 9 2.4 GHz OFDM 2.4570 20 10 2.4 GHz OFDM 2.4620 16 22 5.X GHz OFDM 5.1800 19 23 5.X GHz OFDM 5.2000 20 24 5.X GHz OFDM 5.2200 20 25 5.X GHz OFDM 5.2400 20 30 5.X GHz OFDM 5.7450 21 31 5.X GHz OFDM 5.7650 21 32 5.X GHz OFDM 5.7850 21 33 5.X GHz OFDM 5.8050 21 34 5.X GHz OFDM 5.8250 21 50 4.9 GHz OFDM 4.9600 21 51 4.9 GHz OFDM 4.9800 21 1761 International Parkway, Suite 113 Richardson, TX 75081 O: 972-231-2122; F: 972-231-2406; www.agilemesh.com Final Product User Guide Statements: The user guide for the final product must have the following statements to inform the user of proper operation and implementation of the product. FCC specific statements:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation.
RF Exposure warning: This device must be operated with a minimum separation distance of 20 cm between the radiating elements and the user or nearby persons. Industry Canada specific statements (in both English and French):
The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems 1761 International Parkway, Suite 113 Richardson, TX 75081 O: 972-231-2122; F: 972-231-2406; www.agilemesh.com
This device has been designed to operate with the antennas listed below, and having a maximum gain of 7.4dBi. Antennas not included in this list or having a gain greater than 7.4dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. Band (GHz) Gain dBi Manufacturer’s P/N Manufacturer 2.4 7.4 SF-245SPR NCG 5.X 5.5 SF-D53NSR NCG
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accep…

Text truncated - open the document above for the full version.

1761 International Parkway, Suite 113 Richardson, TX 75081 O: 972-231-2122; F: 972-231-2406; www.agilemesh.com AgileMesh FCC & IC Label Location Exhibit AgileMesh P/N 100528, radio module Model: DNMA92AM FCC ID: TTHDNMA92AM IC: 10127A-DNMA92AM AgileMesh P/N 700207, Label

APPENDIX A. Photographs of EUT

LEV Pos Ite m Descri p tion M/B GP Per Q t y Producer Name 1 10 60DNMA13.G60 DNMA-92,PCBA ASSY M Y 1 (60DNMA13.G60) 0.2 10 34DNMA92.011 SHIELDING,COVER, MB92,DNMA-92,298-05839-100 B Y 1 HUN PAI (298-05839-100) 0.2 30 55DNMA06.MG1 DNMA-92,PCBA SMT VER:0GA M Y 1 (55DNMA06.MG1) ..3 10 21.90004.003 COAXIAL CONN,SMT,3 PIN,AM4_1000_000_3 B Y 2 SUPER LINK (AM4_1000_000_3) ..3 20 34DNMA92.001 SHIELDING,FRAME, MB92,DNMA-92,298-05839-000 B Y 1 HUN PAI (298-05839-000) ..3 40 45DRUC13.008 LABEL,WHITE,MAC,35X6,DRUC-I2 B Y 0.5 XIONGFENG (45DRUC13.008) ..3 50 48DNMA06.0GA DNMA-92,PCB,6L 48DNMA06.0GA B Y 1 CPC (48DNMA06.0GA) ..3 60 56.21DNM.031 FRONT END MODULE,11AG POWER 22DBM NF 2 6DB SE2593A20 R B Y 2 SKYWORKS (SE2593A20-R) ..3 70 63.18034.1D1 *CHIP RES 18 J 1/16W 0402 RM04JTN180 B Y 2 TA-I (RM04JTN180) ..3 80 63.51134.L02AX CHIP RES 510 J0402 1/16W RM04JTN511 B Y 2 TA-I (RM04JTN511) ..3 90 63.R0004.151 *!R6 CHIP RES 0 J 1/10W 0603 B Y 3 TA-I (RM06JTN0) ..3 100 63.R0034.1D1 CHIP RES 0 J 1/16W 0402 RM04JTN0 B Y 15 TA-I (RM04JTN0) ..3 110 64.10025.6D1 CHIP RES 10K F 1/16W 0402 RM04FTN1002 B Y 10 TA-I (RM04FTN1002) ..3 120 64.10R05.L06 CERAMIC THICK FILM RESISTOR,SMT,10 OHM F 0402 1/16W RM04FTN10R0 B Y 1 TA-I (RM04FTN10R0) ..3 130 64.22R05.6D1 CHIP RES 22OHM F0402 1/16W RM04FTN22R0 B Y 8 TA-I (RM04FTN22R0) ..3 140 64.61915.L03 !CHIP RES 6.19K F 1/16W 0402(TA-I) B Y 1 TA-I (RM04FTN6191) ..3 150 68.1R0AN.1R1 *!CHIP IND 1NH B 0402 LQP15MN1N0B02D B Y 2 MURATA (LQP15MN1N0B02D) ..3 160 68.1R5AN.1R1 *CHIP INDUCTOR 1.5NH B 0402 LQP15MN1N5B02D B Y 4 MURATA (LQP15MN1N5B02D) ..3 170 68.1R86N.1RC *!CHIP INDUCTOR 1.8NH +/-0.3NH 0402 LQG15HN1N8S02D B Y 2 MURATA (LQG15HN1N8S02D) ..3 180 68.2R210.121 FIXED COIL,SMT,2.2UH,1210,LQH32CN2R2M53K B Y 1 MURATA (LQH32CN2R2M53K) ..3 190 68.2R70N.2R1 !CHIP COIL 2.7NH +-0.1NH 0402 LQP15MN2N7B02D B Y 2 MURATA (LQP15MN2N7B02D) ..3 200 68.3R3AN.1R1 *!CHIP IND 3.3NH B 0402 LQP15MN3N3B02D B Y 2 MURATA (LQP15MN3N3B02D) ..3 210 69.10067.081 *!CHIP FILTER BPF LFB215G37SG8A185 B Y 2 MURATA (LFB215G37SG8A185) ..3 220 69.F1608.001 BALUN,2.45GHZ 50-100OHM THIN FILM,SMT,TBL-1608- 245 L2 B Y 2 CYNTEC (TBL-1608-245-L2) ..3 240 72.24C32.A0F !IC EEPROM M24C32-WMN6TP SOIC 8P B Y 1 ST (M24C32-WMN6TP) ..3 260 74.08805.F38 VOLTAGE REGULATOR IC,SMT,SOT-89,3 PIN AME88052EFTZ B Y 1 AME (AME88052EFTZ) ..3 270 78.0R2B4.L01 CERAMIC CAPACITORS NPO 50V SMT 0 2PF B 0402 C1005NP0208BGT B Y 2 DARFON (C1005NP0208BGT) ..3 280 78.0R574.L01AX *!CHIP CAP 0.5PF 50V C 0402 NPO(MURATA) GRM1555C1HR50C B Y 13 MURATA (GRM1555C1HR50CZ01D) ..3 290 78.0R574.L04 !CHIP CAP 0.5PF 50V B0402 C1005NPO508BGT B Y 2 DARFON (C1005NPO508BGT) ..3 300 78.10034.L07 *!CHIP CAP 10PF 50V J0402 NPO GRM1555C1H100JZ01D B Y 3 MURATA (GRM1555C1H100JZ01D) ..3 310 78.10134.1J1 CERAMIC CAPACITORS C0G 50V SMT 100PF J 0201 GRM0335C1H101JD01D B Y 6 MURATA (GRM0335C1H101JD01D) ..3 320 78.10134.L05AX *!CHIP CAP 100PF 50V J 0402 NPO GRM1555C1H101JZ01D B Y 14 MURATA (GRM1555C1H101JZ01D) ..3 330 78.10322.L02 CHIP CAP C 0.01U 25V K0402 X7R GRM155R71E103KA01D B Y 1 MURATA (GRM155R71E103KA01D) ..3 340 78.10323.5F1 *!CHIP CAP C0.1U 10V K0402 X5R GRM155R61A104KA01D B Y 17 MURATA (GRM155R61A104KA01D) ..3 350 78.15224.2F1 *CHIP CAP C 1500P 50V K0402 XR RM UMK105BJ152KV-F B Y 1 TAIYO (RM UMK105BJ152KV-F) ..3 360 78.1R574.L05 CHIP CAPACITOR NPO 1.5PF 50V C 0402 C1005NP0159CGT B Y 2 DARFON (C1005NP0159CGT) ..3 370 78.22420.L01AX *CHIP CAP 220NF 6.3V K 0402 X5R B Y 17 MURATA (GRM155R60J224KE01D) ..3 380 78.22521.L03 CHIP CAP 2.2UF DC16V K0805 X5R C2012X5R1C225KT B Y 1 TDK (C2012X5R1C225KT) ..3 390 78.22523.L03 CHIP CAP 2.2UF DC10V K0805 X7R C2012X7R1A225KT B Y 1 TDK (C2012X7R1A225KT) ..3 400 78.22620.5I1 CHIP CAP 22UF X5R K 6.3V 1206 GRM31CR60J226K B Y 4 MURATA (GRM31CR60J226K) ..3 410 78.2R274.L04 CHIP CAPACITOR CERAMIC 2.2PF 50V C0402 NPO C1005NPO229CGT(DARFON) B Y 2 DARFON (C1005NPO229CGT) ..3 420 78.33034.1F1 *CHIP CAP NPO 33PF 50V J 0402 C1005NPO330JGT B Y 2 DARFON (C1005NPO330JGT) ..3 430 78.3R974.L02 *G6 CHIP CAPACITOR CERAMIC 3.9PF 50V C0402 NPO (DARFO) B Y 4 DARFON (C1005NPO399CGT) ..3 440 78.47034.L04AX CHIP CAP 47PF 50V J 0402 NPO GRM1555C1H470JZ01D B Y 8 MURATA (GRM1555C1H470JZ01D) ..3 450 78.47523.L04 CHIP CERAMIC CAPACITORS X5R 10V SMT 4 7UF K 0603 C1608X5R475KDT B Y 2 DARFON (C1608X5R475KDT) ..3 460 78.47610.5E1 CHIP CAP 47UF 1206 X5R 6.3V JMK316BJ476ML-T B Y 2 TAIYO (JMK316BJ476ML-T) ..3 470 78.8R274.1FA G6 CHIP CAP 8.2PF 50V C1005NPO829CGT B Y 2 DARFON (C1005NPO829CGT) ..3 480 78.R75B4.1F1 *!CHIP CAP B 0.75PF 50V 0402NPO B Y 4 MURATA (GJM1555C1HR75BB01D) ..3 490 82.20041.111 OSCILLATOR,SMT,4 PIN,1.8V,7C40000281 B Y 1 TXC (7C40000281) ..3 500 71.92201.A0U PERIPHERAL IC,SMT,BGA,337 PIN,AR9220-AC1A B Y 1 ATHEROS (AR9220-AC1A) ..3 510 38.02MA3.031 SOLDER PASTE,S3X58-M406,MA3 B Y 0.0004 KOKI (S3X58-M406) ..3 520 45DKSP01.001YS2 LABEL,WHITE,7*7MM,DKSP-S1 B Y 1 YESHENG (45DKSP01.001YS2) ..3 530 74.08010.B40 VOLTAGE REGULATOR,SMT,WDFN,6 PIN,RT8010-GQW B Y 1 RICHTEK (RT8010-GQW) 0.2 40 4L-RRAA103-001KX2 LABEL,32*13 BARCODE,RRAA-P1 B Y 1 XIONGFENG (4L-RRAA103-001KX2) 0.2 50 53DNMA06.010 FIRMWARE,DNMA-92,V1.0,GENERIC M Y 0 (53DNMA06.010) 1 20 DPDNMA13.G60 DNMA-92,DUMMY PACKING M Y 1 (DPDNMA13.G60) 0.2 30 44.WSC13.001ST2 BOX,!PACKAGE BOX 390*210*80,CM9 B Y 0.01 SHANGDA (44.WSC13.001ST2) 0.2 70 42.CM913.001JH2 PE BAG,ANTI-STATIC, L150XW60XT0.08,CM9 B Y 1 JINGHONG (42.CM913.001JH2) 0.2 80 44.CM913.001QQ2 CARTON,B 428*400*225,CM9 B Y 0.002 SHENGQUAN (44.CM913.001QQ2) 0.2 90 45.AU211.002YS2 LABEL,OOB LABEL 60*40MM PAPER MATERIAL,AU2 B Y 0.014 YESHENG (45.AU211.002YS2) 0.2 100 4L-CM90103-010 LABEL,DO NOT BREAK SECURITY SEAL LABEL,CM9 B Y 0.004 XIONGFENG (4L-CM90103-010) 0.2 110 60DCMA13.G62ST2 ASSEMBLY,,PARTITION,DCMA-86 B Y 0.01 SHANGTA (60DCMA13.G62ST2) ..3 10 4T-DCMA113-001ST2 PARTITION,B, 358X76MM,DCMA-86 B Y 1 SHANGDA (4T-DCMA113-001ST2) ..3 20 4T-DCMA113-002ST2 PARTITION,B, 201X76MM,DCMA-86 B Y 1 SHANGDA (4T-DCMA113-002ST2)

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:21.30(dBm)* Maximum peak output power at antenna input terminal:134.8962883(mW) Antenna gain(maximum):7.4(dBi)* Maximum antenna gain:5.495408739(numeric) Time Averaging:100(%)* Prediction distance:20(cm)* Prediction frequency:2437(MHz)* MPE limit for uncontrolled exposure at prediction frequency:1.000(mW/cm^2) Power density at prediction frequency:0.147479 (mW/cm^2) This equates to:1.474789866 W/m^2 2 4R PG S   Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:15.00(dBm)* Maximum peak output power at antenna input terminal:31.6227766(mW) Antenna gain(maximum):5.5(dBi)* Maximum antenna gain:3.548133892(numeric) Time Averaging:100(%)* Prediction distance:20(cm)* Prediction frequency:5200(MHz)* MPE limit for uncontrolled exposure at prediction frequency:1.000(mW/cm^2) Power density at prediction frequency:0.022322 (mW/cm^2) This equates to:0.223218479 W/m^2 2 4R PG S   Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:21.90(dBm)* Maximum peak output power at antenna input terminal:154.8816619(mW) Antenna gain(maximum):5.5(dBi)* Maximum antenna gain:3.548133892(numeric) Time Averaging:100(%)* Prediction distance:20(cm)* Prediction frequency:5785(MHz)* MPE limit for uncontrolled exposure at prediction frequency:1.000(mW/cm^2) Power density at prediction frequency:0.109328 (mW/cm^2) This equates to:1.093276831 W/m^2 2 4R PG S  

Nemko Test Report: 10217451RUS3 Applicant: AgileMesh, Inc. 1761 International ParkwaySuite 113 Richardson TX 75081 USA Equipment Under Test: DNMA92AM (E.U.T.) FCC ID.: TTHDNMA92AM IC: 10127A-DNMA92AM In Accordance With: CFR 47 Part 90, Subpart I and Subpart Y Regulations Governing Licensing and Use of Frequencies in the 4940–4990 MHz Band RSS 111, Issue 4 Broadband Public Safety Equipment Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 17 January 2012 David Light, Senior Wireless Engineer APPROVED BY: DATE: 17-Jan-2012 Michael Cantwell, GM Total Number of Pages: 36 Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 2 of 36 Table of Contents SECTION 1. SUMMARY OF TEST RESULTS 3 SECTION 2. GENERAL EQUIPMENT SPECIFICATION 5 SECTION 3. RF POWER OUTPUT 6 SECTION 4. PEAK POWER SPECTRAL DENSITY 9 SECTION 5. SPURIOUS EMISSIONS AT ANTENNA TERMINALS 12 SECTION 6. FIELD STRENGTH OF SPURIOUS 21 SECTION 7. FREQUENCY STABILITY 22 SECTION 8. OCCUPIED BANDWIDTH 24 SECTION 9. TEST EQUIPMENT LIST 27 ANNEX A - TEST METHODOLOGIES 28 ANNEX B - TEST DIAGRAMS 33 Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 3 of 36 Section 1. Summary of Test Results Manufacturer: AgileMesh, Inc. Model No.: DNMA92AM Serial No.: None General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with RSS 111,Issue 4 and CFR 47, Part 90,Subparts I and Y. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 4 of 36 Summary Of Test Data NAME OF TEST CFR PARA. NO. RSS PARA. NO. RESULT RF Power Output 90.1215(a)(1) 5.3 Complies Peak Power Spectral Density 90.1215(a)(2) 5.3 Complies Audio Frequency Response TIA EIA-603.3.2.6 - NA 1 Audio Low-Pass Filter Response TIA EIA-603.3.2.6 - NA 1 Modulation Limiting TIA EIA-603.3.2.6 - NA 1 Occupied Bandwidth 90.210 5.4 Complies Spurious Emissions at Antenna Terminals 90.210 5.4 Complies Field Strength of Spurious Emissions 90.210 - Complies Frequency Stability 90.213 5.2 Complies Transient Frequency Behavior 90.214 - NA 2 Receiver Spurious Emissions - 5.5 Complies Footnotes: 1) The radio has no audio components 2) The radio does not operate in the necessary bands for this test. Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 5 of 36 Section 2. General Equipment Specification Frequency Range: 4940 to 4990 MHz Tunable Bands: 4960 to 4980 Necessary Bandwidth: 20 MHz Emission Designator: 17M1W7D Output Impedance: 50 ohms RF Power Output (rated): 21 dBm Number of Channels: 2 Channel Spacing: 20 MHz Operator Selection of Frequency: Software Controlled Power Output Adjustment Capability: Software Controlled System Description Wireless data radio module Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 6 of 36 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 90.1215(a)(1) TESTED BY: David Light DATE: 11 January 2012 Test Results: Complies. Measurement Data: Frequency (MHz) Output Power (dBm) Output Power (W) 4960 22.75 0.188 4980 21.61 0.145 Spectrum analyzer settings: RBW: 100 kHz VBW: 100 kHz Detector: RMS Sweep: Auto RSS 111, Issue 4 Frequency (MHz) Output Power (dBm) Output Power (W) 4960 22.54 0.179 4980 22.36 0.172 Spectrum analyzer settings: RBW: 100 kHz VBW: 100 kHz Detector: Peak Sweep: Auto Equipment Used: 1036-1082-1472 Measurement Uncertainty: 1.7 dB Temperature: 23 C Relative Humidity: 48 % Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 7 of 36 Peak Power – RSS 111 Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 8 of 36 Peak Power – RSS 111 Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 9 of 36 Section 4. Peak Power Spectral Density NAME OF TEST: Peak Power Spectral Density PARA. NO.: 90.1215(a)(2) TESTED BY: David Light DATE: 16 January 2012 Test Results: Complies. Test Data: See attached plots. Equipment Used: 1036-1082-1472 Measurement Uncertainty: 1x10 -7 ppm Temperature: 23 C Relative Humidity: 48 % Detector: Max. Peak Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 10 of 36 Test Data – Peak Power Spectral Density Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 11 of 36 Test Data – Peak Power Spectral Density Nemko USA, Inc. CFR 47, Part 90, Subparts I and Y RSS 111, Issue 4 EQUIPMENT: DNMA92AM PROJECT NO.: 10217451 Page 12 of 36 Section 5. Spurious Emissions at Antenna Terminals NAME OF TEST: Spurious Emissions @ Antenna Terminals PARA. N…
