TVN-MARS-1MARS-1 DESKTOP READER

Magellan Reader Manager Guide Document Number : 40-01-006-DOC Last Changed : 14 September 2006 Version: 2.01 Copyright    Magellan Technology 2005 Commercial in Confidence Reference Documents Document Number Description Date Version 40-01-000-DOC Applications Programmer’s Guide For Version 3 Reader Server 27 June 2006 45-00-001-SPC BT and ST Chip Logical Specification 30 June 2003 Ver 2 Document History Date Version Change Description Author 14 Dec 2005 1 Jeff Gray original document Jeff Gray 6 Sep. 06 2.00 Changed formatting, updated to show new tools. Daryl Dusheiko 14 Sep. 06 2.01 Added more instructions to the axis test section. Daryl Dusheiko Table of Contents 1 INTRODUCTION ................................................................................................................................................... 1 2 FREQUENTLY ASKED QUESTIONS ................................................................................................................ 2 2.1 HOW DO I INSTALL OR UPGRADE READERMANAGER? ...................................................................................... 2 2.2 HOW TO CONNECT READERMANAGER TO A READER? ...................................................................................... 2 2.3 I HAVE A NEW READER, WHAT DO I DO NOW? ................................................................................................... 2 2.4 HOW DO I CHANGE THE NETWORK SETTINGS ON A READER?............................................................................. 2 2.5 HOW DO I SET A TAG TO NORMAL POWERED MODE? ........................................................................................ 2 2.6 HOW DO I RESTORE THE READER TO ITS DEFAULT SETTINGS? ........................................................................... 3 2.7 HOW DO I GET THE READERSERVER VERSION OF MY NETWORK BASED READER? ............................................ 3 3 INSTALLATION .................................................................................................................................................... 4 3.1 NEW INSTALLATION......................................................................................................................................... 4 3.2 UPGRADING READERMANAGER SOFTWARE......................................................................................................4 3.3 STARTING READERMANAGER.......................................................................................................................... 5 3.4 GETTING SOFTWARE UPGRADES....................................................................................................................... 5 4 THE READERMANAGER DESKTOP................................................................................................................ 7 4.1 READERMANAGER MENU BAR........................................................................................................................ 7 4.2 READER MANAGER STATUS BAR................................................................................................................... 10 5 MANAGING CONNECTIONS ........................................................................................................................... 12 5.1 DEFINING A STATIC CONNECTION................................................................................................................... 12 5.2 CLOSING A CONNECTION................................................................................................................................ 14 6 TOOLS ................................................................................................................................................................... 15 6.1 CONFIGURATION SYSTEM............................................................................................................................... 16 6.2 CONSOLE........................................................................................................................................................ 18 6.3 GRID OF TAG SIGHT COUNTS.......................................................................................................................... 20 6.4 IMMEDIATE COMMAND.................................................................................................................................. 21 6.5 INTERROGATE COMMAND.............................................................................................................................. 23 6.6 MEMORY MAP................................................................................................................................................ 24 6.7 READER SETTINGS.......................................................................................................................................... 26 6.8 READER SETUP............................................................................................................................................... 32 6.9 SIMPLE TAG TEST........................................................................................................................................... 45 6.10 TABLE OF TAG MESSAGES.............................................................................................................................. 46 6.11 TAG TEST....................................................................................................................................................... 47 7 READER CONFIGURATIONS .......................................................................................................................... 49 7.1 EDIT CONFIGURATIONS DIALOG..................................................................................................................... 49 7.2 READER CONFIGURATION DIALOG.................................................................................................................. 49 8 UPGRADING READER SOFTWARE .…

Text truncated - open the document above for the full version.

HF RFID System User Manual MARS-1-2-4-6 Multiple Antenna Reader-Writer Systems Document Number : 64-70-017-DOC Last Changed : 04 October 2006 Copyright  Magellan Technology 2006 Commercial in Confidence Content 1. INTRODUCTION ------------------------------------------------------------------------------------------------------------------- 3 1.1 REGULATION AND STANDARDS .......................................................................................................................................... 3 1.2 WARRANTY ................................................................................................................................................................... 4 1.3 LIMITATION OF LIABILITY ................................................................................................................................................. 4 1.4 CHANGES IN PRODUCT FAMILY, SPECIFICATIONS AND USER MANUALS/GUIDES ....................................................................... 4 1.5 COPYRIGHTS AND COPY PERMISSION .................................................................................................................................. 4 1.6 MEANING OF ALERT SYMBOLS AND SIGNAL WORDS ........................................................................................................... 5 1.7 GLOSSARY OF TERMS AND ABBREVIATIONS ........................................................................................................................ 6 2. PRODUCT OVERVIEW ---------------------------------------------------------------------------------------------------------- 8 2.1 MARS-1 ...................................................................................................................................................................... 8 2.2 MARS-2 ...................................................................................................................................................................... 8 2.3 MARS-4 ...................................................................................................................................................................... 9 2.4 MARS-6 ...................................................................................................................................................................... 9 3. BEFORE YOU BEGIN ----------------------------------------------------------------------------------------------------------- 10 3.1 UNPACKING AND INSPECTION .......................................................................................................................................... 10 3.2 INSTALLATION ENVIRONMENT ......................................................................................................................................... 12 3.3 RECOMMENDED SYSTEM REQUIREMENTS .......................................................................................................................... 12 3.4 INSTALLATION REQUIREMENTS ........................................................................................................................................ 13 3.5 ANTENNA MAINTENANCE (TUNING) ................................................................................................................................ 16 3.6 WORKING WITH TAGS .................................................................................................................................................... 18 3.7 TAG-TO-ANTENNA ORIENTATION .................................................................................................................................... 20 4. INSTALLATION ------------------------------------------------------------------------------------------------------------------ 21 4.1 HARDWARE INSTALLATION ............................................................................................................................................. 22 4.1.1 Connecting to a power supply ........................................................................................................................... 23 4.1.2 Connecting a Reader to a Computer using USB ............................................................................................... 24 4.1.3 Connecting a Reader to a Computer using Ethernet ........................................................................................ 24 4.1.4 Connecting Multiple Readers to a local network .............................................................................................. 25 4.1.5 Connecting External Antennas .......................................................................................................................... 25 4.1.6 Antenna Matching, Tuning and Testing ............................................................................................................ 26 4.2 READERMANAGER SOFTWARE INSTALLATION .................................................................................................................... 27 4.2.1 Installation and Functionality Test ................................................................................................................... 27 4.3 CONNECTING TO A READER USING READERMANAGER ........................................................................................................ 28 4.3.1 Connecting to a Reader via USB for the first time ............................................................................................ 32 4.3.2 Upgrading software ........................................................................................................................................... 34 4.4 COMMUNICATION TEST .................................................................................................................................................. 35 5. REPORTING A PROBLEM ---------------------------------------------------------------------------------------------------- 36 5.1 TROUBLESH…

Text truncated - open the document above for the full version.

Dear Sir REFERENCE: Timco Engineering email dated 11 November 2006 (Job 2984AU6) In response to the above email, please find details addressing the 2 enquiries as follow: (a) EUT marketing methods ƒ The equipment is never sold at retail or to the general public. We manufacture and sell our products only to licensed users. ƒ The equipment is sold through only exclusive and formal license arrangements. ƒ Only PGIC (a system integrator company) is licensed by Magellan to install this equipment in the USA. ƒ PGIC technicians are professionally trained in installation methods and procedures by Magellan and by PGIC. ƒ PGIC already has trained professional installers to ensure that equipment is professionally installed and supervised. (b) Professional installation ƒ The following statement has being included in the user manual, important information section, installation sub-section (at page 2): ƒ Magellan’s RFID reader-writers are to be professionally installed by authorized, qualified and service-trained installation personnel only. ƒ Section 4.1.5 and 4.1.6 of the user manual describe the hardware and software installation of the antenna respectively. ƒ The antenna software set-up at section 4.1.6 refers to Reader Manager Guide (40-10-006-DOC) for detailed instructions using the Wizard tool in Reader Setup (Section 6.8) to properly set-up the antenna. A copy of the new User Manual and Reader Manager Guide (40-10-006-DOC) are attached for your reference. Sincerely Yours, Tai Wai Pong Senior Test Engineer 65 Johnston Street Annandale NSW 2038 Phone: +61 2 9562-9800 Fax: +61 2 9518-7620 Web: http://www.magtech.com.au E-mail:[email protected]

Dear Sir REFERENCE: Timco Engineering email dated 4 November 2006 (Job 2984AU6) In response to the above email, prior to submitting the device for FCC Certification we consulted Timco Engineering regarding the FCC requirement for a unique connector. A response from Rita Choi was received (attached – Annex A). In the email it stated that we must demonstrate that the antenna will be professionally installed in three aspects. The device, in our opinion, meets these aspects in that: Point 1. Marketing. Page 2 of the user manual states that the product must be installed and maintained by professional service trained personnel only. Point 2. Nature of the Application. The devices are intended solely for the use by casinos in the gaming industry. On installation the antennas are embedded in the casino tables to which only professional people will have access. The general public do not have any knowledge about the installation of the devices and therefore do not have general access. Point 3. Installation. Section 3 of the user manual contains a dedicated section relating to antenna installation. Section 15.203 of the FCC Rules and Regulations states that the requirement of a unique connector is not required if the intentional radiator is professionally installed. We feel that we satisfy the requirements of a professional installation. A copy of the User manual is attached for reference. Sincerely Yours, Chief Engineer 65 Johnston Street Annandale NSW 2038 Phone: +61 2 9562-9800 Fax: +61 2 9518-7620 Web: http://www.magtech.com.au E-mail:[email protected] ANNEX A – EMAIL FROM RITA CHOI From: Rita Choi To: 'Ken McAnulty' Sent: Friday, September 22, 2006 8:01 AM Subject: RE: Antenna Connection Hi Ken, Thanks! That is what I need. I discussed with engineers. To challenge FCC requirement for a unique connector, you shall demonstrate your antenna will be professionally installed in three aspects 1. Marketing. In user's manual, you shall spell out clearly the requirement and the intention of professional installation 2. The nature of the application. You shall convince FCC the general population will not easily have access to your device. For example, your device is installed in a remote area only oil company employees can have access or installed on the roof and few people will climb there to modify it. 3. details about how to install the antenna professionally. If the RFID you put under the gambling table at casino meets the above three considerations, you are okay. Please contact me if you have further questions. Rita

TIMCO ENGINEERING INC. 849 NW State Rd 45 Newberry, Florida 32669 Ph: 888 472 2424 Fax: 352 472 2030 Subject: Request for Confidentiality for FCC Certification Application Company: Magellan Technology Pty Limited Pursuant to Rule 47 CFR, Chapter 1, Section 0.457(d)(1)(ii), Magellan Technology Pty Limited, requests that prior to the equipment authorization grant for the test sample, the entire application be classified and deemed confidential by the Federal Communications Commission (FCC) and as such be withheld from public inspection. As per 47 CFR, Chapter 1, Section 0.457, the exhibits tendered for the purpose of this grant, contain details of trade secrets and technical data that are not made available to competitors and the general public. This information is treated in a confidential manner by Magellan Technology Pty Limited and guarded from disclosure to our competitors. The exhibits outlined below are not routinely made available to Magellan Technology Pty Limited, with such access granted only to those specifically involved with this particular project. They contain information detailing the unique technology and circuitry of the product that would be of significant benefit to our competitors. All employees treat this technical data in a confidential manner. The manufacture of this product has taken place after an extensive research and development process that has seen the company invest a considerable amount of time and money. The time and effort taken has enabled the product to meet the specific demands of the competitive market for which it is intended and it would be therefore detrimental to allow competitors easy access to design and development details. Apart from a limited number of employees, the information has previously only been disclosed to the Test House responsible for conducting testing and authorized to act as our agent during the certification process. Pursuant to 47CFR Chapter 1, Section 0.459, Magellan Technology Pty Limited requests post-grant confidentiality for the following items, ensuring that this material continue to be withheld from public inspection following the grant. Exhibits: Appendix Description File Name E Block Diagram APPENDIX E_Block Diagram.pdf F Test Sample Schematic APPENDIX F_Test Sample Schematics.pdf G Test Sample PCB Layouts APPENDIX G_Test Sample PCB Layouts.pdf Sincerely Yours, ______________________ TITLE : CHIEF ENGINEER 65 Johnston Street Annandale NSW 2038 Phone: +61 2 9562-9800 Fax: +61 2 9518-7620 Web: http://www.magtech.com.au E-mail:[email protected]

Page 1 of 8 EMC Technologies Pty Ltd ABN 82 057 105 549 Unit 3/87 Station Road Seven Hills NSW 2147 Australia Telephone +61 2 9624 2777 Facsimile +61 2 9838 4050 Email [email protected] www.emctech.com.au Melbourne 57 Assembly Drive Tullamarine Vic 3043 Tel: +61 3 9335 3333 Fax: +61 3 9338 9260 Sydney Unit 3/87 Station Road Seven Hills NSW 2147 Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 Brisbane 1/15 Success Street Acacia Ridge Qld 4110 Tel: +61 7 3875 2455 Fax: +61 7 3875 2466 Auckland (NZ) 47 MacKelvie Street Grey Lynn Auckland Tel: +64 9 360 0862 Fax: +64 9 360 0861 APPENDIX C OF TEST REPORT T60919_F PHOTOGRAPHS OF TEST SAMPLE (EXTERIOR) FCC ID: TVN-MARS-1 Manufacturer: Magellan Technologies Pty Ltd Test Sample: RFID Read Write Device Model: Mars-1-2-4-6 Serial Number: Production Prototype Date: 12 th October 2006 FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 2 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C1 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) Overview of 64-10-002 Overview of 63-10-004 FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 3 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C2 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) 64-10-002 Top Side of PCB 64-10-002 Bottom Side of PCB FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 4 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C3 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) 64-10-002 Label 64-10-002 PCB Detail FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 5 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C4 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) 64-10-002 PCB Detail (Cont’d) 63-10-004 Top Side of PCB FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 6 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C5 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) 63-10-004 Bottom Side of PCB 63-10-004 Label FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 7 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C6 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) 63-10-004 PCB Detail FCC ID:TVN-MARS-1 Report No. T60919_F Appendix C Page 8 of 8 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX C7 PHOTOGRAPHS TEST SAMPLE (EXTERIOR) Power Supply

Page 1 of 3 EMC Technologie s ABN 82 057 105 549 Unit 3/87 Station Road Seven Hills NSW 2147 A u Telephone +61 2 962 4 Facsimile +61 2 9838 Email syd@emctech www.emctech.com.au Melbourne 57 Assembly Drive Tullamarine Vic 3043 Tel: +61 3 9335 3333 Fax: +61 3 9338 9260 Sydney Unit 3/87 Station Road Seven Hills NSW 2147 Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 Brisbane 1/15 Success Street Acacia Ridge Qld 4110 Tel: +61 7 3875 2455 Fax: +61 7 3875 2466 Auckland (NZ) 47 MacKelvie Street Grey Lynn Auckland Tel: +64 9 360 0862 Fax: +64 9 360 0861 APPENDIX I OF TEST REPORT T 60919_F LABELLING - LOCATION FCC ID: TVN-MARS-1 Manufacturer: Magellan Technologies Pty Ltd Test Sample: RFID Read Write Device Model: Mars-1-2-4-6 Serial Number: Production Prototype Date: 12 th October 2006 w eiV p o T m otto B w eiV la c e D M E O 0 9 4 5.3 0 2 9 7.0 7.5 4 0 8.1 a n n etn A rotc e n n o C O /I re s U la n oitp O 6 4 1 8.1 s'D E L te nre htE A B S U B B S U C D V 2 1 e s u F h ctiw S re w o P 3 1 2 9 3.8 0 0 3 1 8.1 1 # N C E A / N A / N S N O ISIV E R .V E R N O ITPIR C S E D ET A D D E V O R P P A 2 1 re V / 2 0 C L M e s a ele R n oit c u d orP 6 0 0 2 / 5 0 / 0 1 Z H 3 n oit p O O /I re s U d d A n oit alu g e R yt ef a S t a e m o t diL e g n a h C 6 0 0 2 / 9 0 / 2 1 Z H F 8 EDCBAGHJKLM 7 6 5 4 3 2 1 9 0 1 1 1 2 1 3 1 4 1 5 1 6 1 9 1 2 3 4 5 6 7 8 0 1 1 1 2 1 KGABCDEFHJ 3 :n oisre V )s(re b m u N tra P d etale R n alle g a M re g nillo Z H 1 F O 1 T E E H S . O N G W D :E L TIT G NI W A R D E L A C S T O N O D E T A D E R U T A N G IS E M A N D'V P P A D'K H C N W A R D G F M ) M O B ( laireta M fo lliB ) Y S A ( ylb m e ss A ) P D 3( le d o M tra P D 3 ) W A H ( tra P era w dra H )s(re ht O Y S A -0 0 0-0 7-4 6 A D 3-0 0 0-0 7-4 6 M O B -0 0 0-0 7-4 6 6 0 5 0 0 1 Y G O L O N H C E T N A L L E G A M 1:1 : E L A C S L AIT N E DIF N O C D N A Y R A T EI R P O R P SI H T NI D E NIA T N O C N O IT A M R O F NI E H T F O Y T R E P O R P E L O S E H T SI G NI W A R D . D E TI M IL Y T P Y G O L O N H C E T N A L L E G A M A S A R O T R A P NI N O IT C U D O R P E R Y N A N O IS SI M R E P N E T TI R W E H T T U O H TI W E L O H W . D E TI BI H O R P SI Y G O L O N H C E T N A L L E G A M F O Y S A 6-4-2-1-sra M A D 3-0 0 0-0 7-4 6 1 A 90 90 R3 Model: RFID Reader Mars-1-2-4-6 64-70-030 Type: P/N: D/C: Rating: 12VDC/2.5Amp S/N: MLC 02 03 01 04 05 06 07 08 09 10 Made in Australia EMC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation This Class A digital apparatus complies with ICES-003. Cet appariel numerique de la classe A est conforme a la norme NMB-003 du Canada IC: 6596A-MARS1 FCC ID: TVN-MARS-1 www.magtech.com.au +V GND Magellan Logo BLACK TEXT (White BACKGROUND) Serial Number Start at: XXXXXXX (XXXXXX to be adviced by Megallan) OEM Label Mars-1 Material: 0.5mm Polycarbonate Parts digitally printed at high resolution and laminated with Polycarbonate to the face and 3M 467 adhesive to the rear. Black Background - White Text Note: D/C Field (Date Code) to be entered when reader is manufactured White Field 3 REVISIONS ECN#REV.DESCRIPTIONDATEAPPROVED N/A1Production Release 23/10/2006HZ N/A2Change FCC Id to all upercase10/25/2006HZ N/A3Change IC:6596A-Mars-1 to IC:6596A-Mars110/26/2006HZ D E F C 1234 B A 3215 C D 4678 A B MAGELLAN TECHNOLOGY 060906 Entech heinzz A3 SHEET 1 OF 1SCALE: 1:1 DWG NO. TITLE: Version: DO NOT SCALE DRAWING DATE SIGNATURE NAME MFG APPV'D CHK'D DRAWN 64-70-036-3DD OEM Decal Cashier Cage Reader 3 Magellan Related Part Number(s) Bill of Material (BOM) Assembly (ASY) 3D Part Model (3DP) Hardware Part (HAW) Other(s) 64-70-030-BOM 64-70-030-ASY N/A 64-70-036-DCL 64-70-036-SPC PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MAGELLAN TECHNOLOGY PTY LIMITED. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF MAGELLAN TECHNOLOGY IS PROHIBITED.

Page 1 of 5 EMC Technologies Pty Ltd ABN 82 057 105 549 Unit 3/87 Station Road Seven Hills NSW 2147 Australia Telephone +61 2 9624 2777 Facsimile +61 2 9838 4050 Email [email protected] www.emctech.com.au Melbourne 57 Assembly Drive Tullamarine Vic 3043 Tel: +61 3 9335 3333 Fax: +61 3 9338 9260 Sydney Unit 3/87 Station Road Seven Hills NSW 2147 Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 Brisbane 1/15 Success Street Acacia Ridge Qld 4110 Tel: +61 7 3875 2455 Fax: +61 7 3875 2466 Auckland (NZ) 47 MacKelvie Street Grey Lynn Auckland Tel: +64 9 360 0862 Fax: +64 9 360 0861 APPENDIX D OF TEST REPORT T60919_F PHOTOGRAPHS OF TEST SAMPLE (INTERIOR) FCC ID: TVN-MARS-1 Manufacturer: Magellan Technologies Pty Ltd Test Sample: RFID Read Write Device Model: Mars-1-2-4-6 Serial Number: Production Prototype Date: 12 th October 2006 FCC ID:TVN-MARS-1 Report No. T60919_F Appendix D Page 2 of 5 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX D1 PHOTOGRAPHS TEST SAMPLE (INTERIOR) Exploded View 1 Exploded View 2 FCC ID:TVN-MARS-1 Report No. T60919_F Appendix D Page 3 of 5 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX D2 PHOTOGRAPHS TEST SAMPLE (INTERIOR) Mains Board, Bottom View FCC ID:TVN-MARS-1 Report No. T60919_F Appendix D Page 4 of 5 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX D3 PHOTOGRAPHS TEST SAMPLE (INTERIOR) Main Board With Shielding Cans FCC ID:TVN-MARS-1 Report No. T60919_F Appendix D Page 5 of 5 EMC Technologies Pty Ltd Unit 3, 87 Station Road Seven Hills NSW 2147 Australia Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 APPENDIX D4 PHOTOGRAPHS TEST SAMPLE (INTERIOR) Exploded View 3 Main Board No Shielding Cans

MARS-1 Multiple Antenna Reader System-1 Overview The Multiple Antenna Reader System (MARS-1) is an RFID reader-writer designed to operate a single external antenna and to meet the requirements to verify, inventory, monitor and control a large number of valuable items located in one position or moving on a conveyor at high speed. The MARS-1 is a high performance system for PJM StackTag® and PJM ItemTag® RFID tags. It provides fast and reliable operations with different external antenna types. Product Description The MARS-1 operates with a single antenna and is particularly well suited to gaming, jewelry, document management, pharmaceutical and retail applications. The MARS-1 features: • The ability to identify, read and write reliably to over 100 tags in 1-3 second • Reliable identification of tightly stacked and overlapping or touching tags • Fast operation with 2 reply channels • Operates PJM StackTag® and PJM ItemTag® simultaneously • A powerful processing platform allowing for stand-alone reader operation • Very good connectivity offering both Ethernet and USB interfaces • Complies with ISO/IEC 18000-3 Mode 2 Specification Read and write operations No user-serviceable parts ISO/IEC Compliance 18000-3 Mode 2 Operating Frequency 13.56 MHz Number of Reply Channels 2 Command Data Rate 424 kbit/s Reply Data Rate 106 kbit/s per channel Number of External Antennas 1 Single axis antennas with dimensions: External Antennas Round 60 mm diam. and 124 mm diam. (custom design is available on request) Rectangular 60 x 420 mm, 120 x 240 mm and 202 x 352 mm Antenna Connection Cable 1.5 m External Dimensions (L x W x H) 270 x 196 x 46 cm with fixed mounting brackets Net Weight 1.5 kg (without external antennas) Low Voltage Input 12 VDC @ 1.5 A Operation environment Indoor use Temperature range +10 o C to +45 o C Humidity 10% to 80% (non-condensing) Recommended Minimum Host Computer Requirement Windows XP SP2/ 500 MHz CPU/ 128MB RAM Host Interface USB and Ethernet MAGELLAN Technology Pty Ltd, 65 Johnston Street, Annandale NSW 2038, AUSTRALIA Phone: +61 2 9562 9800, Fax: +61 2 9518 7620 www.magtech.com.au, [email protected]

Page 1 of 2 EMC Technologies Pty Ltd ABN 82 057 105 549 Unit 3/87 Station Road Seven Hills NSW 2147 Australia Telephone +61 2 9624 2777 Facsimile +61 2 9838 4050 Email [email protected] www.emctech.com.au Melbourne 57 Assembly Drive Tullamarine Vic 3043 Tel: +61 3 9335 3333 Fax: +61 3 9338 9260 Sydney Unit 3/87 Station Road Seven Hills NSW 2147 Tel: +61 2 9624 2777 Fax: +61 2 9838 4050 Brisbane…

Text truncated - open the document above for the full version.
