TX4-RD49Remote Controller

INSTITUTION: 2021.04.30 SPECIFICATION (Recharging Station ) MODEL NO: RD49A00 REFORM : DECISION : REMOTE SOLUTION CO.,LTD. REMOTE SOLUTION CO., LTD. 40 5 2-3 ELECTRICAL CHARACTERISTICS 2-3-1 OPERATING & LEAKAGE CURRENT * IR CURRENT (AVERAGE) - 20mA ±3 [VBAT : 3.0V] * RF CURRENT (AVERAGE) - 6 mA ±2[VBAT 3.0V] * VOICE TRANS CURRENT (AVERAGE) - 7 mA ±2 [VBAT 3.0V] * LEAKAGE CURRENT (AVERAGE) - IR MODE : 2.1uA ±1 [VBAT 3.0V] - RF MODE : 100uA ±20[VBAT .30V] (MEASURE THE CURRENT, AFTER LEAVING FOR 1 MINUTE) 2-3-2 OPERATING VOLTAGE : MORE THAN DC 2.2V ~ 3.2V, BATTERY 2-3-3 FUNCTION OF LOW VOLTAGE DETECT : 2.4V±0.1V 2-3-4 OPERATING DISTANCE AND POINTING ANGLE Vb: D.C 3.0V (ALKALINE BATTERY ‘AAA’ * 2 EA) 2-3-4-1 IR RANGE * STRAIGHT (0 °) : MAX. 15m * Angle 20°Left / Right : Mn10 (m) * Angle 30°Up : Min 10 (m) * Angle 10°Down : Min 10 (m) 2-3-4-2 RF RANGE * STRAIGHT (0 °) : MIN. 30m * sight at all directions with anelevationangle +/- 20° INSTITUTION: 2021.04.30 SPECIFICATION (Recharging Station ) MODEL NO: RD49A00 REFORM : DECISION : REMOTE SOLUTION CO.,LTD. REMOTE SOLUTION CO., LTD. 40 3. ENVIRONMENT CHARACTERISTICS 3-1 Fundamental performance A. Operating Current B. Stand-by Current C. Operating Voltage D. Performance E. Exterior 3-2 Dry Heat Test A. Temperature : 60 ±3°C B. Humidity : 5 ~ 10% B. Time : 96 Hrs. 3-3 Damp Heat Test A. Temperature : 65 ±3°C B. Humidity : 90 ~ 95% B. Time : 96 Hrs. 3-4 Temperature Cycling A. Temperature : 65°C~ -10°C/ 3Cycles B. Time : 3Hrs 3-5 Cold Test A. Temperature : -10 ±3°C B. Time : 96 Hrs. 3-6 Stressing Chip-On-Board One cycle of -40°Cuncontrolled relative humidity (rh) for 8 hours; 70C°at 10% rh for 8 hours; 70 C°at 90% rh for 8 hours and room ambient until stable. Temperature ramp rate is 2 C°per minute. 3-7 Vibration Test A. Vibration width : 1.5mm B. Sweep Frequency : 10~55 Hz C. Test Period : 6 Hrs / each direction (X Y Z) 3-8 ESD Test A. ±8㎸,1㎐,10 Times Contact discharge B. ±16㎸,1㎐,10 Times Air contact discharge 3-9 Life Time A. Once Per second for 500,000 cycles 3-10 Drop (with batteries installed) A. Height: 80 cm (31.5 in.) B. Floor: hard vinyl tiles over concrete foundation C. Impact: Six impact locations on the remote control 6 INSTITUTION: 2021.04.30 SPECIFICATION (Recharging Station ) MODEL NO: RD49A00 REFORM : DECISION : REMOTE SOLUTION CO.,LTD. REMOTE SOLUTION CO., LTD. 40 3-11 Resistance to Oil and Liquids A.Apply the following liquids individually and the confirm appearance after keeping them in a normal ambient B.Condition for 96 hours : cooking oil, butter, margarine, hair spray, soy sauce, artificial sweat lanolin 4-12 Liquid Test A.50 cc of coffee including 2cc sugar in solution, poured over the top of the remote. After a drying time of 48hours, the Remote shall operate normally. 5-13 Distance Test A.IR Range - Straight line from a Receiver module : Min 15 (m) - Angle 25° Left / Right : Min 10 (m) - Angle 30° Up : Min 10 (m) - Angle 15° Down : Min 10 (m) B.RF Range - The range shall be greater than 30 meters line of sight at all directions with anelevation angle +/- 20° 6-14 Alcohol Test A.Using a cloth soaked in isoporpy l alcohol, rub key legend 100 times with 500gF 7 FCC Information This device complies with part 15 of the FCC Results. Operation is subject to the following two conditions : (1) This Device may not cause harmful interface, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for CLASS B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: 1.1. Reorient or relocate the receiving antenna. 1.2. Increase the separation between the equipment and receiver. 1.3. Connect the equipment into an outlet on a circuit different from that to which receiver is connected. 1.4. Consult the dealer or experienced radio/TV technician for help. WARNING Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. “CAUTION : Exposure to Radio Frequency Radiation. Antenna shall be mounted in such a manner to minimize the potential for human contact during normal operation. The antenna should not be contacted during operation to avoid the possibility of exceeding the FCC radio frequency exposure limit.

Date: May 07, 2021 RE: New Family Listing Declaration Please review the attached exhibits supporting our request for applying New Family Listing to the FCC ID: TX4-RD49 for Company Name: Remote Solution Co., Ltd. Product Description: Remote Controller Base model: RD49B00 Additional model(s): RD49A00 The only difference between the base model RD49B00 and the additional model(s) RD49A00 is as follows: Model Name Differences RD49B00 Basic Model. - RF: 4.2 / Profile : HOGP - Carbon Keypad - Dual IR LEDs, Indicate LEDs - Voice Transmission - Backlight Leds with Accelerometer, Ambient Light Sensor - Buzzer - IR Learning Circuit RD49A00 This model and the basic model have different components. - RF: 4.2 / Profile : HOGP - Carbon Keypad - Dual IR LEDs, Indicate LEDs - Voice Transmission Should you have any questions, please contact us. Sincerely, Name: Byung-Cheol, Kim Date: May 07, 2021 Title: Manager Signature of applicant:

Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 07, 2021 Subject; Request for Confidentiality FCC ID: TX4-RD49 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Byung-Cheol, Kim Title: Manager

Letter of Authorization Company : Remote Solution Co., Ltd. Address : 92, Chogokri, Nammyun, Kimchon City, Kyungbuk, 740-871, South Korea Product Name : Remote Controller Model Number : RD49B00, RD49A00 FCC Identifier : TX4-RD49 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Byung-Cheol, Kim Date: May 07, 2021 Title: Manager Signature of applicant:

Page 1 of 6 Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 Page 6 of 6

Page 1 of 4 Page 2 of 4 Page 3 of 4 Page 4 of 4 PCB Antenna

Page 1 of 4 Page 2 of 4 Page 3 of 4 Page 4 of 4 PCB Antenna

Page 1 of 8 Report No.: OT-215-RWD-003 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) ELECTROMAGNETIC EMISSION C OMPLIANCE REPORT FOR LOW-POWER, NON-LICENSED TRANSMITTER Test Report No. : OT-215-RWD-003 Reception No. : 2104001519 Applicant : Remote Solution Co., Ltd. Address : 92, Chogokri, Nammyun, Kimchon City, Kyungbuk, 740-871, South Korea Manufacturer : Remote Solution Co., Ltd. Address : 71, Gunpocheomdansaneop 2-roGunpo-si, Gyeonggi-do, 15880, Korea Type of Equipment : Remote Controller FCC ID. : TX4-RD49 Model Name : RD49B00 Multiple Model Name : RD49A00 Serial number : N/A Total page of Report : 8 pages (including this page) Date of Incoming : April 26, 2021 Date of issue : May 07, 2021 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Tested by Hyung-Kwon, Oh / Manager ONETECH Corp. Reviewed by Tae-Ho, Kim / Senior Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 8 Report No.: OT-215-RWD-003 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 4 2. GENERAL INFORMATION ............................................................................................................................................ 5 2.1 PRODUCT DESCRIPTION ................................................................................................................................................. 5 2.2 ALTERNATIVE TYPE(S)/MODEL(S); ALSO COVERED BY THIS TEST REPORT. ................................................................ 5 3. EUT MODIFICATIONS .................................................................................................................................................... 6 4. MAXIMUM PERMISSIBLE EXPOSURE ...................................................................................................................... 7 4.1 RF EXPOSURE CALCULATION ....................................................................................................................................... 7 4.2 EUT DESCRIPTION ......................................................................................................................................................... 7 4.3 CALCULATED MPE SAFE DISTANCE............................................................................................................................. 8 Page 3 of 8 Report No.: OT-215-RWD-003 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision History Rev. No. Issue Report No. Issued Date Revisions Section Affected 0 OT-215-RWD-003 May 07, 2021 Initial Release All Page 4 of 8 Report No.: OT-215-RWD-003 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. VERIFICATION OF COMPLIANCE Applicant : Remote Solution Co., Ltd. Address : 92, Chogokri, Nammyun, Kimchon City, Kyungbuk, 740-871, South Korea Contact Person : Byung-Cheol, Kim / Manager Telephone No. : +82-54-420-4517 FCC ID : TX4-RD49 Model Name : RD49B00 Brand Name : Tivo Brook Serial Number : N/A Date : May 07, 2021 EQUIPMENT CLASS DTS – DIGITAL TRNSMISSION SYSTEM E.U.T. DESCRIPTION Remote Controller THIS REPORT CONCERNS Original Grant MEASUREMENT PROCEDURES ANSI C63.10: 2020 TYPE OF EQUIPMENT TESTED Pre-Production KIND OF EQUIPMENT AUTHORIZATION REQUESTED Certification EQUIPMENT WILL BE OPERATED UNDER FCC RULES PART(S) FCC PART 15 SUBPART C Section 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 Modifications on the Equipment to Achieve Compliance None Final Test was Conducted On 3 m, Semi Anechoic Chamber -. The above equipment was tested by ONETECH Corp. for compliance with the requirement set forth in the FCC Rules and Regulations. This said equipment in the configuration described in this report, shows the maximum emission levels emanating from equipment are within the compliance requirements. Page 5 of 8 Report No.: OT-215-RWD-003 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 2. GENERAL INFORMATION 2.1 Product Description The Remote Solution Co., Ltd., Model RD49B00 (referred to as the EUT in this report) is a Remote Controller. The product specification described herein was obtained from product data sheet or user’s manual. DEVICE TYPE Remote Controller TEMPERATURE RANGE 0 °C ~ 40 °C OPERATING FREQUENCY 2 402 MHz ~ 2 480 MHz MODULATION TYPE GFSK (Bluetooth LE) NUMBER OF CHANNEL 40 Channel RF OUTPUT POWER 0.36 dBm ANTENNA TYPE PCB Antenna ANTENNA GAIN 0.39 dBi List of each Osc. or crystal Freq.(Freq. >= 1 MHz) 24 MHz 2.2 Alternative type(s)/model(s); also covered by this test report. -. The following lists consist of the added model and their differences. Model Name Differences Tested RD49B00 Basic Model. - RF: 4.2 / Profile : HOGP - Carbon Keypad - Dual IR LEDs, Indic…

Text truncated - open the document above for the full version.

Page 1 of 33 Report No.: OT-215-RWD-002 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) ELECTROMAGNETIC EMISSION C OMPLIANCE REPORT FOR LOW-POWER, NON-LICENSED TRANSMITTER Test Report No. : OT-215-RWD-002 Reception No. : 2104001519 Applicant : Remote Solution Co., Ltd. Address : 92, Chogokri, Nammyun, Kimchon City, Kyungbuk, 740-871, South Korea Manufacturer : Remote Solution Co., Ltd. Address : 71, Gunpocheomdansaneop 2-roGunpo-si, Gyeonggi-do, 15880, Korea Type of Equipment : Remote Controller FCC ID. : TX4-RD49 Model Name : RD49B00 Multiple Model Name : RD49A00 Serial number : N/A Total page of Report : 33 pages (including this page) Date of Incoming : April 26, 2021 Date of issue : May 07, 2021 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Tested by Hyung-Kwon, Oh / Manager ONETECH Corp. Reviewed by Tae-Ho, Kim / Senior Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 33 Report No.: OT-215-RWD-002 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 5 2. TEST SUMMARY .............................................................................................................................................................. 6 2.1 TEST ITEMS AND RESULTS ............................................................................................................................................. 6 2.2 ADDITIONS, DEVIATIONS, EXCLUSIONS FROM STANDARDS ........................................................................................... 6 2.3 RELATED SUBMITTAL(S) / GRANT(S) ............................................................................................................................ 6 2.4 PURPOSE OF THE TEST ................................................................................................................................................... 6 2.5 TEST METHODOLOGY .................................................................................................................................................... 6 2.6 TEST FACILITY ............................................................................................................................................................... 6 3. GENERAL INFORMATION ............................................................................................................................................ 7 3.1 PRODUCT DESCRIPTION ................................................................................................................................................. 7 3.2 ALTERNATIVE TYPE(S)/MODEL(S); ALSO COVERED BY THIS TEST REPORT. ................................................................ 7 4. EUT MODIFICATIONS .................................................................................................................................................... 8 5. SYSTEM TEST CONFIGURATION ............................................................................................................................... 9 5.1 JUSTIFICATION ............................................................................................................................................................... 9 5.2 PERIPHERAL EQUIPMENT .............................................................................................................................................. 9 5.3 MODE OF OPERATION DURING THE TEST ...................................................................................................................... 9 5.4 CONFIGURATION OF TEST SYSTEM ............................................................................................................................. 11 6. PRELIMINARY TEST .................................................................................................................................................... 11 6.1 AC POWER LINE CONDUCTED EMISSIONS TESTS ....................................................................................................... 11 6.2 GENERAL RADIATED EMISSIONS TESTS ..................................................................................................................... 11 7. MINIMUM 6 DB BANDWIDTH .................................................................................................................................... 12 7.1 OPERATING ENVIRONMENT ......................................................................................................................................... 12 7.2 TEST SET-UP ................................................................................................................................................................. 12 7.3 TEST DATE ................................................................................................................................................................... 12 7.4 TEST DATA FOR 1 MBPS ............................................................................................................................................... 13 8. MAXIMUM PEAK OUTPUT POWER ......................................................................................................................... 15 8.1 OPERATING ENVIRONMENT ..........…

Text truncated - open the document above for the full version.

Page 1 of 2 - RADIATED EMISSION TEST Page 2 of 2
