TXEADL100ID Caller

User’s Manual This product is able to send caller id information to the computer when an incoming call is received. The purpose of the product is to display a customer or caller's information when an incoming call is received. Businesses that use the telephone on a constant basis, such as a pizza shop, will be able to utilize the product, which will aid in business efficiency. By using the software, the name, telephone number, previous call record and memo, can be stored to insure efficient and effective customer service and increase customer satisfaction. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interface, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.. Caller ID for 1 Line Connect to PC Caller ID HUB Hub connection

ADELINFO Co.,Ltd. 202, Gwanggaeto-praza 9B-1L, Dang-dong Gunpo City, Gyeonggi-do, Korea February 1, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize KTL, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by KTL on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KTL as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Myong-Gi, Hong, Signature Printed Title : President ADELINFO Co.,Ltd.

ADELINFO Co.,Ltd. 202, Gwanggaeto-praza 9B-1L, Dang-dong Gunpo City, Gyeonggi-do, Korea Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material ADELINFO Co.,Ltd. would like the following documents regarding this submission for FCC ID : TXEADL100 to be kept confidential. 1. Block Diagram 2. Schematic Diagram The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Date 1 th of February, 2006 Myong-Gi, Hong, Signature Printed Title : President ADELINFO Co.,Ltd.

1 Helen Zhao Subject:FW: Adel Information Co.,Ltd., FCC ID: TXEADL100, Assessment NO.: AN06T5485, Notice#1 FCC Labeling-ADL100.pdf block diagram-ADL100.pdf FCC Labeling-ADL300.pdf block diagram-ADL300.pdf From: ??? Sent: Friday, February 03, 2006 1:03 AM To: Helen Zhao Subject: Re: Adel Information Co.,Ltd., FCC ID: TXEADL100, Assessment NO.: AN06T5485, Notice#1 Dear Helen, we revised the FCC ID label format and block diagram. please see the attatched files. best regards bum jong KIM > -----Original Message----- > From: Compliance Certification Services [mailto:[email protected]] > Sent: Thursday, February 02, 2006 5:35 PM > Subject: Adel Information Co.,Ltd., FCC ID: TXEADL100, Assessment NO.: > AN06T5485, Notice#1 > > > Question #1: The proposed FCC ID label format does not contain labeling requirement specified in FCC15.19. Based on FCC rule, only those devices smaller than palm size (8 x 10 cm) is allowed to put labelling statement into the manual instead. Please revise the FCC ID label format. > > Question #2: Based upon FCC2.1033(b)(5), "A block diagram showing the frequenc of all oscillators in the device". Please revise the block diagram to show the frequencies of local oscillator/crystal. By the way, the schematics in the filing is not clear enough to read the crystal values. > > Best Regards, > Helen Zhao > > > The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 2 > > > >

Photographs (Outside) <Outside – Front> <Outside – side> <Outside – side>

FCC Labeling

Photographs (In-side) <In-side >

KTL Korea Testing Laboratory Page 1 of 13 TEST REPORT This test report only responds to the tested sample and shall not be reproduced except in full without written approval of the Korea Testing Laboratory. Tested and reported by Reviewed by Bum-Jong Kim, Engineer Won-Seo Cho , Telecommunication Team Manager KOREA TESTING LABORATORY FG101-01-02-00 222-13, Guro-Dong Guro-Gu Seoul Korea 152-053 http://www.ktl.re.kr Ref. Report No. 06-341-003 Name and address of the applicant Adel Information Co., Ltd. 202, Gwanggaeto-praza, 9B-1L, Dang-dong, Gunpo City, Gyeonggi-do, Korea Standard / Test regulation FCC Part 15, Subpart B Test result Pass Incoming date : January 11, 2006 Test item(s) ; Class B Computing Device Peripheral (ID call) Model/type ref. ; CID300 Manufacturer ; Adel Information Co., Ltd. 202, Gwanggaeto-praza, 9B-1L, Dang-dong, Gunpo City, Gyeonggi-do, Korea Additional information ; -Required Authorization : Certification -FCC ID. : TXEADL100 Test date : January 27, 2006 ~ February 01, 2006 Issue date : February 02, 2005 Ref. Report No. 06 - 341 – 003 Page 2 of 13 Korea Testing Laboratory Telecommunication Team 222-13, Guro3-dong, Guro-gu, Seoul Korea 152-848 TABLE OF CONTENTS I. GENERAL INFORMATION 3 1. Applicant’s Name and Mailing Address 2. Manufacturer's Name and Mailing Address 3. Equipment Descriptions 4. Rules and Regulations 5. Measuring Procedure 6. Date of Measurement II. GENERAL REQUIREMENTS OF THE EUT 4 1. Labeling Requirement (Section 15.19) 2. Information to User (Sections 15.21and 15.105) 3. Special Accessories (Section 15.27) III. CONDUCTED EMISSION MEASUREMENT (Section 15.107) 6 1. Test Procedure 2. Photograph for the test configuration 3. Sample Calculation 4. Measurement Data IV. RADIATED EMISSION MEASUREMENT (Section 15.109) 10 1. Test Procedure 2. Photograph for the test configuration 3. Sample Calculation 4. Measurement Data V . TEST EQUIPMENTS USED FOR MEASUREMENT 13 Ref. Report No. 06 - 341 – 003 Page 3 of 13 Korea Testing Laboratory Telecommunication Team 222-13, Guro3-dong, Guro-gu, Seoul Korea 152-848 I. GENERAL INFORMATION 1. Applicant’s Name and : Adel Information Co., Ltd. Mailing Address 202, Gwanggaeto-praza, 9B-1L, Dang-dong, ` Gunpo City, Gyeonggi-do, Korea 2. Manufacturer's Name and : Adel Information Co., Ltd. Mailing Address 202, Gwanggaeto-praza, 9B-1L, Dang-dong, Gunpo City, Gyeonggi-do, Korea 3. Equipment Descriptions 3.1 Test Item : ID caller 3.2 I/O port : Serial com port (MAX232) 3.3 Power Supply : DC 8~12 V, 100mA 3.4 Model name : CID300 3.5 Crystal used : 3.579 MHz 4. Devices of Test System Device Model name Serial Number Manufacturer Personal Computer DPEP P500 7951/CJN20009 Compaq Monitor DP15L/S DP15HICN102768 Compaq Mouse M-S34 166861-001 Compaq Keyboard PR235BTWKO B13BBOT39I7045 Compaq Printer 2225C+ 3145S02416 Hewlett Packard ID caller CID100 - Adel Information 5. Rules and Regulations : FCC Part 15, Subpart B 6. Measuring Procedure : ANSI C63.10-2004 7. Date of Measurement 7.1 Conducted Emission : Jan 27, 2006 7.2 Radiated Emission : Feb 01, 2006 Ref. Report No. 06 - 341 – 003 Page 4 of 13 Korea Testing Laboratory Telecommunication Team 222-13, Guro3-dong, Guro-gu, Seoul Korea 152-848 II . GENERAL REQUIREMENTS OF THE EUT 1. Labeling Requirement (Section 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 1.1 Location of Label : User’s guide manual 1.2 How Applied : Printed 2. Information to User (Section 15.21 and 15.105) The following or similar statements were provided in the manual for user instruction. Please refer page 1 of the attached manual for details. CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Ref. Report No. 06 - 341 – 003 Page 5 of 13 Korea Testing Laboratory Telecommunication Team 222-13, Guro3-dong, Guro-gu, Seoul Korea 152-848 3. Special Accessories (Section 15.27) 3.1 Were the special Accessories provided? [ ] yes, [ x ] no 3.2 If yes, details for the special accessories are as follows : 3.3 If yes, were the appropriate instructions provided on the first page of the text concerned with the device? [ ] yes, [ ] no 3.4 Are these accessories provided of the type which can be readily obtained from multiple retail outlets ? [ ] yes, [ ] no And therefore does the manual specify what additional components or accessories are required to used in order to comply with the Rules? [ ] yes, [ ] no Ref. Report No. 06 - 341 – 003 Page 6 of 13 Korea Testing Laboratory Telecommunication Team 222-13, Guro3-dong, Guro-gu, Seoul Korea 152-848 III . CONDUCTED EMISSION MEASUREMENT (Section 15.107) …

Text truncated - open the document above for the full version.

TEST Photographs < Radiated emission – Front > < Radiated emission – Rear > <Conducted emission – Front > < Conducted emission – Rear >
