U46-G10MOBILE PHONE-GSM PORTION

FCC ID: U46-G10 MODEL: G10 USER MANNUAL 1. SAFETY AND CAUTIONS z Switch off the phone in the vicinity of chemical plants, gas stations and other locations containing explosive objects. z Keep the phone away from children. z Please switch off your phone as instructed where notices are present. z Switch off the phone before boarding on plane and don’t switch on the phone during flight. z Please strictly conform to your local legal regulations during a drive. When hands free function is available, please use the hands free calling device to ensure safety. Please park the car at the roadside for communication only if in emergency. z Take special care when using the mobile phone in the vicinity of such devices as pacemakers, hearing aids and electro-medical equipments, which may be interfered by the mobile phone. When the phone is switched on, a minimum distance of 6 inches (15cm) shall be kept between the phone and pacemaker. When using other medical equipments, please consult the vendors of these equipments or doctors for relevant information. z No guarantee for the accessories and fitments not produced by the original factory. z Never attempt to disassemble the phone by unauthorized persons. Contact the authorized service center in your region in case of any trouble with your mobile phone. z Recharging the phone without battery being installed is prohibited. z Charge the phone in well-ventilated environment, and keep it away from inflammable and high explosive objects. z To avoid demagnetization, keep the handset away from magnetic substances such as magnetic discs or credit cards. z Ensure to keep the handset away from liquid. Take the battery off and contact the authorized service center if the handset gets soaked or erosion can happen. z Avoid using the phone in too high or too low temperature environments. Never expose the phone directly under sunlight or in high humidity or dusty environment. z Do not use liquids or damp cloth with strong detergents to clean the handset. z Avoid dropping, crashing or excessively squeezing the phone, or it may be subject to damages of different degrees. z The original factory will not take any responsibility in the case of noncompliance with the above advices or improper use of the phone. z Please send used li-ion batteries to specified locations or return them to our company. Do not dispose the batteries into dustbins. CONTENT 1. SAFETY AND CAUTIONS.............................................................................................................. 2 2. PHONE LAYOUT.............................................................................................................................. 8 3. SPECIFICATIONS LIST................................................................................................................. 10 4. ESSENTIAL TOPICS..................................................................................................................... 12 5. GETTING STARTED...................................................................................................................... 15 6. BASIC OPERATIONS.................................................................................................................... 18 7. USING THE MENU......................................................................................................................... 22 ENTER THE MENU................................................................................................................................22 MENU.................................................................................................................................................. 23 OPTION LIST........................................................................................................................................ 23 SMS .................................................................................................................................................. 23 Contact 29 CALL HISTORY..................................................................................................................................... 31 PROFILES 33 F ILE MANAGER.................................................................................................................................... 34 M ULTIMEDIA....................................................................................................................................... 35 S ETTINGS............................................................................................................................................ 35 TOOL ................................................................................................................................................. 43 EXTRA................................................................................................................................................. 47 8. OPERATIONS OF INPUT METHODS......................................................................................... 50 APPENDIX I COMMON FAULT DIAGNOSES............................................................................... 50 APPENDIX II ABBREVIATIONS AND EXPLANATIONS.......................................................... 50 2. Phone layout Appearance 3. Specifications list Phone Type Specification G10 Dimensions 107×46×13.6mm Weight 75g Screen display resolution 2.0” QCIF 176*220 pixel Card type SIM Applicable system GSM+WCDMA Contact capacity 1000 sets in the phone SMS capacity 100 pieces for inbox and 200 pieces for outbox in mobile phone(Not including the SIM card) Preset short message 12 preset short messages Call records 20 each for missed, answered and dialed calls Receiving call vibration Support Preset ringing tone type 10 ringing tones Preset SMS tone type 10 tones Language English/Spanish Call time Support Date and time display Support Alarm/Calculator Support MP3 Support MP4 Support Double Camera Support Bluetooth Support FM Radio Supp…

Text truncated - open the document above for the full version.

TeleEpoch Limited FCC ID: U46-G10 POWER OF ATTORNEY March 24, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen Super Test Service Technology Co., Ltd. (Terry YANG/General Manager) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen Super Test Service Technology Co., Ltd. (Terry YANG/General Manager) on our behalf shall have the same effect as acts of our own. This authorization expires on May 31, 2010. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, TeleEpoch Limited are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Name: Joyce Chou Title: Project Assistant Date: March 24, 2010

FCC ID: U46-G10 Report No.: STS100304F2 FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE FCC ID: U46-G10 Report No.: STS100304F2 LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FCC ID: U46-G10 Report No.: STS100304F2 TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE FCC ID: U46-G10 Report No.: STS100304F2 PHOTO OF POWER SUPPLY PHOTO OF USB CABLE FCC ID: U46-G10 Report No.: STS100304F2 PHOTO OF EARPHONE PHOTO OF BATTERY FCC ID: U46-G10 Report No.: STS100304F2 PHOTO OF THE ENTIRE SAMPLE

FCC ID: U46-G10 Report No.: STS100304F2 INTERNAL PHOTO OF SAMPLE – 1 INTERNAL PHOTO OF SAMPLE –2 FCC ID: U46-G10 Report No.: STS100304F2 INTERNAL PHOTO OF SAMPLE – 3 INTERNAL PHOTO OF POWER SUPPLY-1 FCC ID: U46-G10 Report No.: STS100304F2 INTERNAL PHOTO OF POWER SUPPLY-2

1/2 Operation Description OPERATIONAL DESCRIPTION APPLICANT: TeleEpoch Limited Manufacturer: TeleEpoch Limited FCC ID: U46-G10 Instruction Book: Users Manual Frequency Range GSM Transmit Frequency Band: 824.2-848.8 MHz Receive Frequency Band: 849.2-893.8 MHz Specific Operating Power Range: Power Class 1; Power Control Level 0 +30dBm +2.0dB/-2.0dB Power Control Level 1 +28dBm +3.0dB/-3.0dB Power Control Level 2 +26dBm +3.0dB/-3.0dB Power Control Level 3 +24dBm +3.0dB/-3.0dB Power Control Level 4 +22dBm +3.0dB/-3.0dB Power Control Level 5 +20dBm +3.0dB/-3.0dB Power Control Level 6 +18dBm +3.0dB/-3.0dB Power Control Level 7 +16dBm +3.0dB/-3.0dB Power Control Level 8 +14dBm +3.0dB/-3.0dB Power Control Level 9 +12dBm +4.0dB/-4.0dB Power Control Level 10 +10dBm +4.0dB/-4.0dB Power Control Level 11 +8dBm +4.0dB/-4.0dB Power Control Level 12 +6dBm +4.0dB/-4.0dB Power Control Level 13 +4dBm +4.0dB/-4.0dB Power Control Level 14 +2dBm +5.0dB/-5.0dB Power Control Level 15 +0dBm +5.0dB/-5.0dB Note; Effective radiation efficiency is –3.7dB DC Voltage and Current into the Final Amplifier Module: Supply Voltage = 3.6Vdc Supply Current = ~0.8Amp. Tune-up Procedure: Tune-up Procedure Equipment Identification: Equipment's Identification label and its intended Location are as shown in EXHIBIT Type “ID Label / Location Information” (FCC ID Nameplate), and in EXHIBIT Type “Internal Photo”(Photograph of inside) Photographs: A complete set of the Photographs showing External and Internal Views of Circuit Details and Construction are provided by from EXHIBIT Type “External Photos” and “Internal Photos”. Accessories: 2/2 Operation Description Figure 1.2: Terminal Components (Accessories) Technical Descriptions TX synthesizer uses an Offset-PLL circuit. The Offset-PLL circuit consists of PLL-IC and TX_VCO and loop filter. Reference frequency of the above synthesizers is 26MHz and generated by VCTCXO. Control signal is sent from Baseband section and keeps frequency stability. TX IQ signal is applied to the quadrature up-converter, and the up-converter LO signal is generated from the transceiver VCO . This up-converter translates the GMSK-modulated signal to an intermediate frequency (IF) that forms one input to a frequency/phase detector circuit. This IF signal is the reference input to an Offset-PLL circuit. The feedback path of this Offset-PLL circuit includes a down-conversion from the RF output frequency range to the IF range. The two inputs to this down-conversion mixer are formed the TX_VCO output and the LO generation circuits. The mixer output is the offset feedback signal that forms the variable input to a frequency/phase detector circuit. The detector compares its variable input to its reference input and generates an error signal that is low-pass filtered by the loop filter and applied to TX_VCO to force the RF frequency in the direction that minimizes errors. The TX_VCO output passes PA, Antenna SW, Coaxial connector with switch and emitted from embedded antenna. Digital Modulation: Analog speech produced by a microphone is encoded to digital PCM samples using a CODEC. The PCM samples are passed to a Vocoder for AMR (Advanced Multi Rate) encoding, to compress the speech samples. The encoding rate is determined by the Vocoder which formats the speech samples as data packets. A new data packet with data rate information is read by the microprocessor every 20 ms. The speech CODEC becomes AMR, FR(Full Rate), EFR(Enhanced FR) and HR(Half Rate). The microprocessor then sends the data packet to the transmit subsystem, and passed DAC to covert analog signal. I/Q base band signal is filtered and is inputted into RTR6250 containing quadrature phase modulator. The Data Required (EXHIBIT “Test Report”): (2.1046) RF power output (2.1047) Modulation characteristics (2.1049) Occupied bandwidth (2.1051) Spurious emission at antenna terminals (2.1053) Field strength of spurious radiation (2.1055) Frequency stability (2.1057) Frequency spectrum to be investigated Battery AC Charger Accessories

1 WA01-1_Main board,V1.1,8Layers PCS 1 PCB WA01-1 V1.1 SHENGYI 2 Solid Tantalum Chip,100uF,±20%,6.3V,S case(3.2*1.6*H1.0),NICHICON PCS 3 F950J107MSAAQ2 NICHICON C1 C86 C189 3 Chip Ceramic Capacitor,0.5pF,±0.1pF,50V,COG,0402 PCS 1 GRM1555C1HR50BZ01D Murata C187 4 Chip Ceramic Capacitor,100pF,±5%,50V,COG,0402 PCS 22 GRM1555C1H101JA01 Murata C3 C6 C43 C64 C66-67 C70 C87 C116 C121-123 C133C136 C156 C158 C190-192 C201-202 C214 5 Chip Ceramic Capacitor,1.5pF,±0.1pF,50V,COG,0402 PCS 3 GRM1555C1H1R5CZ01D Murata C112 C124 C153 6 Chip Ceramic Capacitor,18pF,±5%,50V,COG,0402 PCS 1 GRM1555C1H180JZ01D Murata L29 7 Chip Ceramic Capacitor,22pF,±5%,50V,COG,0402 PCS 2 GRM1555C1H220JZ01D Murata C91-92 8 Chip Ceramic Capacitor,220pF,±5%,50V,COG,0402 PCS 2 GRM1555C1H221JA01 Murata C108 C110 9 Chip Ceramic Capacitor,27pF,±5%,50V,COG,0402 PCS 1 GRM1555C1H270JZ01D Murata C157 10 Chip Ceramic Capacitor,33pF,±5%,50V,COG,0402 PCS 21 GRM1555C1H330JZ01D Murata C12 C61-62 C71-72 C100 C103 C105 C127 C131 C138C146 C148-149 C170-171 C193 C203 C206 C211 C215 11 Chip Ceramic Capacitor,2.2pF,±0.25pF,50V,COG,0402 PCS 2 GRM1555C1H2R2CA01 Murata L39 L40 12 Chip Ceramic Capacitor,3.9pF,±0.25pF,50V,COG,0402 PCS 1 GRM1555C1H3R9CZ01D Murata L20 13 Chip Ceramic Capacitor,68pF,±5%,50V,COG,0402 PCS 1 GRM1555C1H680JZ01D Murata C150 14 Chip Ceramic Capacitor,6pF,±0.1pF,50V,COG,0402 PCS 3 GRM1555C1H6R0BZ01D Murata C132 C135 C151 15 Chip Ceramic Capacitor,6.8pF,±0.1pF,50V,COG,0402 PCS 1 GRM1555C1H6R8BZ01D Murata C98 16 Chip Ceramic Capacitor,8.2pF,±0.5pF,50V,COG,0402 PCS 2 GRM1555C1H8R2DA01 Murata C93-94 17 Chip Ceramic Capacitor,1uF,±10%,6.3V,X5R,0402 PCS 10 GRM155R61A105KE15D Murata C5 C27 C41-42 C83-85 C95-97 18 Chip Ceramic Capacitor,100nF,±10%,10V,X5R,0402 PCS 48 GRM155R61A104KA01 Murata C4 C8 C20 C28-29 C33 C38-39 C44 C45 C46 C48-54C56-57 C59-60 C63 C65 C68-69 C74-75 C82 C101-102C106 C113-114 C117 C119-120 C137 C155 C173 C175-176 C213 C220 C222-223 R1 C89 19 Chip Ceramic Capacitor,10nF,±10%,16V,X7R,0402 PCS 1 GRM155R71C103KA01 Murata C11 20 Chip Ceramic Capacitor,1nF,±10%,50V,X7R,0402 PCS 12 GRM155R71H102KA01D Murata C7 C13-14 C76-81 C90 C109 C221 21 Chip Ceramic Capacitor,3.3nF,±10%,50V,X7R,0402 PCS 2 GRM155R71H332KA01D Murata C145 C147 22 Chip Ceramic Capacitor,2.2uF,±10%,6.3V,X5R,0603 PCS 15 GRM188R60J225KE19 Murata C2 C17-19 C21-26 C36 C55 C154 C177 C212 23 Chip Ceramic Capacitor,4.7uF,±10%,6.3V,X5R,0603 PCS 12 GRM188R60J475KE19 Murata C34-35 C37 C40 C104 C107 C111 C115 C118 C178-179 C224 24 Chip Ceramic Capacitor,10uF,±10%,6.3V,X5R,0805 PCS 7 GRM219R60J106KE19D Murata C9 C15-16 C30-32 C99 25 24pin B TO B Stocket connector,0.4mmPitch,Hight 1.2mm PCS 1 BAF04-24153-0502 LCN CON5 26 Battery Connector,3pin,Height=5.8mm,3.0mm pitch,BATSV-00315-TPL1,Saber PCS 1 BATSV-00315-TPL1 LINKTEK CON4 27 UIM Socket,6pin,pitch=2.54,15.25×16.20×1.9,CAF99-06193-1504,linkconn PCS 1 CAF99-06193-1504 LCN CON1 28 T-Flash socket,Height 1.93mm PCS 1 CAH11-08193-SF00 LCN CON6 29 USB Stocket,10 pin , UAF04-10374-1507 PCS 1 UAF04-10374-1507 LCN CON7 30 Microwave coaxial connector,3x3x1.9mm PCS 1 MM8430-2610RB3 Murata CON2 31 Directional coupler,836.50±12.50MHz,20dB coupling,MURATA,0402 PCS 1 LDC15836M20Q-360 Murata CP1 32 Directional coupler,1950.00±30.00MHz,20.5dB coupling,MURATA,0402 PCS 1 LDC151G9519Q-391 Murata CP2 33 Ultra bright InGaN White Chip LED,Vf:2.7V,Ir:<100uA@Vr=5V,0603 PCS 6 LTW-C193TS5 LITE-ON D1-4 D9-10 34 Schottky barrier diode,30V,1A,TUMD2 PCS 1 RB161VA-20 ROHM D8 TCH-WA01-1_V1.0_BOM No description unit dosage model supplier location 35 Chip Ferrite Beads,for EMI,220 Ω ,±25%,100MHz,20 °C ,0402 PCS 3 BLM15AG221SN1 Murata FB2 FB4-5 36 Chip Ferrite Beads,for RF break ,1000 Ω ,±25%,100MHz,20 °C ,0402 PCS 4 BLM15HD102SN1 Murata FB1 FB6-8 37 Chip Ferrite Beads,for power supplies,120 Ω ,±25%,100MHz,20 °C ,0603 PCS 1 BLM18KG121TN1 Murata FB3 38 UMTS BC1 Tx SAW FILTER,1.35x1.05x0.6mm PCS 1 SAFEB1G95KA0F00 Murata FL3 39 GSM1800 Rx SAW FILTER,1.35x1.05x0.5mm PCS 1 SAFEB1G84FC0F00 Murata FL1 40 Multilayer Chip Band-Pass Filters for Bluetooth PCS 1 LFB182G45SG9B740 Murata FL4 41 Chip multilayer inductor,1.5nH,±0.3nH,0402 PCS 1 LQG15HN1N5S02D Murata L7 42 Chip multilayer inductor,2.2nH,±0.3nH,0402 PCS 1 LQG15HS2N2S02D Murata L15 43 Chip multilayer inductor,2.7nH,±0.3nH,0402 PCS 1 LQG15HS2N7S02D Murata C125 44 Chip multilayer inductor,39nH,±5%,0402 PCS 1 LQG15HN39NJ02D Murata L27 45 Chip multilayer inductor,3.3nH,300mA,0.1ohm,±0.3nH,Q>8,0402 PCS 1 LQG15HS3N3S02D Murata L22 46 Chip multilayer inductor,3.9nH,±0.3nH,0402 PCS 4 LQG15HN3N9S02D Murata L19 L47-48 C196 47 Chip multilayer inductor,4.7nH,±0.3nH,0402 PCS 2 LQG15HN4N7S02D Murata L37 C134 48 Chip multilayer inductor,15nH,±5%,0402 PCS 3 LQG15HS15NJ02D Murata L14 L25 L49 49 Chip multilayer inductor,18nH,±5%,0402 PCS 2 LQG15HS18NJ02D Murata L9 C144 50 Chip multilayer inductor,7.5nH,±5%,0402 PCS 2 LQG15HS7N5J02D Murata L50 C47 51 Chip Monolithic Inductor,4.7uH,±30%,1100mA,0.14 OHm,0806 PCS 3 LQM2MPN4R7NG0 Murata L2-4 52 Power MOSFET ,20 Volts P-Channel,SOT-23-3L,WPM2341,WILL PCS 1 WPM2341 WILL Q1 53 TRANSISTOR WITH BUILT IN BIAS RESISTORS,SOT-416 PCS 1 DTC114EET ROHM Q2 54 Chip Resitor,6.04K Ω ,±1%,1/16W,0402 PCS 1 RC0402FR-076K04 YAGEO R5 55 Chip Resitor,0 Ω ,±5%,1/16W,0402 PCS 6 RC0402JR-070RL YAGEO R31 R33 R36 R38 L24 R52 56 Chip Resitor,100 Ω ,±5%,1/16W,0402 PCS 9 RC0402JR-07100R YAGEO R4 R39 R41 R47-48 R103-106 57 Chip Resitor,10K Ω ,±5%,1/16W,0402 PCS 11 RC0402JR-0710KL YAGEO R12-18 R30 R32 R45 R53 58 Chip Resitor,1 Ω ,±5%,1/16W,0402 PCS 1 RC0402JR-071R YAGEO R37 59 Chip Resitor,20K Ω ,±5%,1/16W,0402 PCS 1 RC0402JR-0720K YAGEO R20 60 Chip Resitor,2K Ω ,±5%,1/16W,0402 PCS 1 RC0402JR-072K YAGEO R3 61 Chip Resitor,2.2K Ω ,±5%,1/16W,0402 PCS 2 RC0402JR-072K2L YAGEO R11 R27 62 Chip Resitor,300 Ω ,±5%,1/16W,0402 PCS 5 RC0402JR-07300R YAGEO R21 R23-25 R54 63 Chip Resitor,47K Ω ,±5%,1/16W,0402 PCS 1 RC0402JR-0747KL YAGEO R2 64 Chip Resitor,5.1K Ω ,±5%,1/16W,0402 PCS 2 RC0402JR-075K1 YAGEO R19 R46 65 Ch…

Text truncated - open the document above for the full version.

Tune Up Description Transmit Frequency EGSM : 880 - 915MHz GSM850: 824MHz - 849MHz DCS1800: 1710 - 1785MHz WCDMA BAND I : 2110 -2170 MHz WCDMA BANS V: 869-894 MHz Receive Frequency EGSM : 925 - 960MHz GSM850 : 869 -894MHz DCS1800: 1805 -1880MHz WCDMA BAND I: 1920 - 1980 MHz WCDMA BANS V: 824 - 849 MHz Modulation GSM/GPRS : GMSK EGPRS : MCS1-4 GMSK EGPRS: MCS5-9 8PSK WCDMA: QPSK Hardware Version V1.1 Software Version EmissionDesignator GSM : 200KHz GPRS : 200KHz EGPRS :200KHz WCDMA :5MHz Freq.stability GSM: 0.1ppm GPRS: 0.1ppm EGPRS: 0.1ppm WCDMA: 0.1ppm Dimension We i g h t Data Transmission Voltage 3.6~4.2V Current Idel <5mA Traffic< 1.5A Transmitter Power GSM850: Power class 4 EGSM: Power class 4 GSM1800: Power class 1 EGPRS- 8psk : Power class E2 WCDMA : Power class 3 Specific Operating Power Range: Power class 4: Tolerance(dB) for conditions Power control level Nomina Ouput Power(dBm) normal Extreme 5 33 ±3 ±4 6 31 ±3 ±4 7 29 ±3 ±4 8 27 ±3 ±4 9 25 ±3 ±4 10 23 ±3 ±4 11 21 ±3 ±4 12 19 ±3 ±4 13 17 ±3 ±4 14 15 ±3 ±4 15 13 ±3 ±4 16 11 ±5 ±6 17 9 ±5 ±6 18 7 ±5 ±6 19-31 5 ±5 ±6 Power class 1 Tolerance(dB) for conditions Power control level Nomina Ouput Power(dBm) normal Extreme 0 30 ±3 ±4 1 28 ±3 ±4 2 26 ±3 ±4 3 24 ±3 ±4 4 22 ±3 ±4 5 20 ±3 ±4 6 18 ±3 ±4 7 16 ±3 ±4 8 14 ±3 ±4 9 12 ±4 ±5 10 10 ±4 ±5 11 8 ±4 ±5 12 6 ±4 ±5 13 4 ±4 ±5 14 2 ±5 ±6 15-28 0 ±5 ±6 Power class E2 GSM900&GSM850 Tolerance(dB) for conditions DCS Tolerance(dB) for conditions Power class GSM900&GS M850 Nominal Maximum output Power normal Extreme DCS Nominal Maximum output Power normal Extreme E2 27dBm ±3 ±4 26dBm -4/+3 -4.5/+4 Power class 3 Operating Band Power class 3 Power （dBm）Tol（dB） Band I +24 +1/-3 Band V +24 +1/-3 Adjustment of Outpout power (1) The test qquioment setup as shown in figure 1. (2) Operation of PC adjusts equipment (3) Run the Calibration Script. (4) Reset the handset RF Connectors Handset PC USB RF Tester GPIB

Submit 1 System Validation Plots Project name: KS100315B01 Page 1 System Validation Plots Project name : KS100315B01 EUT DESCRIPTION Product name: Mobile phone Model No.: G10 Trade name: Zonda FCC ID:U46-G10 Tested date: March 16, 2010 Applicant: TeleEpoch Limited. 2/F, R2-A North Gate, Shenzhen High-Tech Industria Nanshan District, Shenzhen,Guang Dong, China. Air Temperature: 21 °C Liqued Temperature: 20 °C Crest Factor: CW:___1__ GSM:__8___ WCDMA: __1___ GPRS CLASS 12: __2___ EDGE CLASS 12: __2___ Area Scan: 7 x 7 x 1 dx=15mm dy=15mm Zoom Scan: 5 x 5 x 7 dx=5mm dy=5mm dz=5mm Z Axis Scan: 1 x 1 x 21 dx=20mm dy=20mm dz=5mm Probe：Antennessa (SN:SN_1109_EP_100) Compliance Certification Services (Kunshan) Inc. No.10, Weiye Rd., Innovation Park, Eco & Tec. Development Part, Kunshan City, Jiangsu Province, PRC. TEL: 86-512-57355888 FAX: 86-512-57370818 http://www.ccsrf.com Project name: KS100315B01 Page 2 850 HEAD VALIDATION I. RESULTS TYPE PAR AM E TE RS Noise -- Validation Measurement 1: Validation Plane with Dipole device position on Middle Channel in CW mode GSM850 Phone -- Project name: KS100315B01 Page 3 MEASUREMENT 1 Type: Validation measurement (Complete) Date of measurement: 03/16/2010 Measurement duration: 6 minutes 41 seconds Mobile Phone IMEI number: -- A. Experimental conditions. Phantom File surf_sam_plan.txt, Adaptative 2 max Phantom Validation plane Device Position Dipole Band GSM850 Channels Middle Signal CW Project name: KS100315B01 Page 4 B. Instrumentations. PC HP (Pentium(R) V 3.06GHz, SN:375052-AA1) Network Emulator R&S (CMU200, SN:B23-03291) Vo l t m e t e r Keithley (2000, SN:1015843) Synthetizer Agilent (E8257C, SN:MY43321570) Amplifier Mini-Circuits (ZHL-42, SN:110405) Power Meter Agilent (E4416A, SN:QB41292714) Probe Antennessa (SN:SN_1109_EP_100) Phantom Antennessa (SN:SN41_05_SAM29) Liquid Antennessa Project name: KS100315B01 Page 5 C. SAR Measurement Results Frequency (MHz) 835.000024 Relative permitivity (real part) 41.047180 Relative permitivity (imaginary part) 19.591301 Conductivity (S/m) 0.900756 Variation (%) 0.600000 SURFACE SAR VOLUME SAR Project name: KS100315B01 Page 6 Maximum location: X=0.00, Y=-5.00 SAR 1g (W/Kg) 9.201164 Project name: KS100315B01 Page 7 Z Axis Scan Project name: KS100315B01 Page 8 850 BODY VALIDATION I. RESULTS TYPE PAR AM E TE RS Noise -- Validation Measurement 1: Validation Plane with Dipole device position on Middle Channel in CW mode GSM850 Phone -- Project name: KS100315B01 Page 9 MEASUREMENT 1 Type: Validation measurement (Complete) Date of measurement: 03/16/2010 Measurement duration: 6 minutes 51 seconds Mobile Phone IMEI number: -- A. Experimental conditions. Phantom File surf_sam_plan.txt, Adaptative 2 max Phantom Validation plane Device Position Dipole Band GSM850 Channels Middle Signal CW Project name: KS100315B01 Page 10 B. Instrumentations. PC HP (Pentium(R) V 3.06GHz, SN:375052-AA1) Network Emulator R&S (CMU200, SN:B23-03291) Vo l t m e t e r Keithley (2000, SN:1015843) Synthetizer Agilent (E8257C, SN:MY43321570) Amplifier Mini-Circuits (ZHL-42, SN:110405) Power Meter Agilent (E4416A, SN:QB41292714) Probe Antennessa (SN:SN_1109_EP_100) Phantom Antennessa (SN:SN41_05_SAM29) Liquid Antennessa Project name: KS100315B01 Page 11 C. SAR Measurement Results Frequency (MHz) 835.000024 Relative permitivity (real part) 54.020525 Relative permitivity (imaginary part) 22.120529 Conductivity (S/m) 0.938128 Variation (%) 0.240000 SURFACE SAR VOLUME SAR Project name: KS100315B01 Page 12 Maximum location: X=1.00, Y=-2.00 SAR 1g (W/Kg) 9.7453247 Project name: KS100315B01 Page 13 Z Axis Scan Submit 2 SAR Test Plots Project name: KS100315B01 Page 1 SAR Test Plots Project name : KS100315B01 EUT DESCRIPTION Product name: Mobile phone Model No.: G10 Trade name: Zonda FCC ID: U46-G10 Tested date: March 16, 2010 Applicant: TeleEpoch Limited. 2/F, R2-A North Gate, Shenzhen High-Tech Industria Nanshan District, Shenzhen,Guang Dong, China. Air Temperature: 21 °C Liqued Temperature: 20 °C Crest Factor: CW:___1__ GSM:__8___ WCDMA: __1___ GPRS CLASS 12: __2___ EDGE CLASS 12: __2___ Area Scan: 7 x 7 x 1 dx=15mm dy=15mm Zoom Scan: 5 x 5 x 7 dx=5mm dy=5mm dz=5mm Z Axis Scan: 1 x 1 x 21 dx=20mm dy=20mm dz=5mm Probe：Antennessa (SN:SN_1109_EP_100) Compliance Certification Services (Kunshan) Inc. No.10, Weiye Rd., Innovation Park, Eco & Tec. Development Part, Kunshan City, Jiangsu Province, PRC. TEL: 86-512-57355888 FAX: 86-512-57370818 http://www.ccsrf.com Project name: KS100315B01 Page 2 GSM850 I. RESULTS TYPE BAND PAR AM E TE RS Noise -- -- Validation -- -- Phone GSM850 Measurement 1: Right Head with Cheek device position on Low Channel in GSM mode Measurement 2: Right Head with Cheek device position on Middle Channel in GSM mode Measurement 3: Right Head with Cheek device position on High Channel in GSM mode Measurement 4: Right Head with Tilt device position on Low Channel in GSM mode Measurement 5: Right Head with Tilt device position on Middle Channel in GSM mode Measurement 6: Right Head with Tilt device position on High Channel in GSM mode Measurement 7: Left Head with Cheek device position on Low Channel in GSM mode Measurement 8: Left Head with Cheek device position on Middle Channel in GSM mode Measurement 9: Left Head with Cheek device position on High Channel in GSM mode Measurement 10: Left Head with Tilt device position on Low Channel in GSM mode Measurement 11: Left Head with Tilt device position on Middle Channel in GSM mode Measurement 12: Left Head with Tilt device position on High Channel in GSM mode Measurement 13: Validation Plane with Body device position on Low Channel in GSM mode Measurement 14: Validation Plane with Body device position on Middle Channel in GSM mode Measurement 15: Validation Plane with Body device position on High Channel in GSM mode Project name: KS100315B01 Page 3 MEASUREMENT 1 Type: Phone measurement (Complete) Date of measurement: 03/16/2010 Measurement duration: 19 minutes 56 seconds Mobile Phone IMEI num…

Text truncated - open the document above for the full version.

V1.1 V1.1 WA01-1 1 11 TELEEPOCH LIMITED OF PCB VERSION SCHEMATIC VERSION: SHEET TITLE: MODEL: FILE No: 差分 , 等长 , 平行 480MHz 3.3v 弱信号 , 差分 , 平行 , 地防护 平均电流 500mA 峰值电流 1.2A, 平均电流 400mA 峰值电流 1.2A, 平均电流 400mA VCOINUSB_VBUSVCHGVCHGVPH_PWRVPH_PWRBAT_FET_NVBAT U1-K C86 S D G Q1 123 CON5 12345678910 CON6 C1 C3 C4 FB1 VR7 VR8 VR9 VR1 VR3 VR4 VR5 VR6 C2 R2 R11 C68 C69 C70 C71 C72 MODE_3MODE_2MODE_1MODE_0 DNC TDI TMS TCK TRST_N UART1_RXD UART1_TXD TDO RTCK USB_DMUSB_DPUSB_IDREF_EXTRESOUT_N U1-A R32 R5 R6 C100 C101 C102 C103 R14 R15 R16 R17 R18 R20 1 DAT2 2 DAT3/CD 3 CMD 4 VDD 5 CLK 6 VSS2 7 DAT0 8 DAT1 CON7 C201 C202 1 I/O 2 VPP 3 GND 4 VCC 5 RST 6 CLK CON1 T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 VR20 VR21 VR22 VR23 VR24 VR25 VR26 VR27 VR28 FB6 FB7 FB8 T15 T16 T19 T20 C88 A1 ZT1 ZTP A1 ZT2 ZTP A1 ZT3 ZTP A1 ZT4 ZTP MARK1MARK2MARK3MARK4 1 MARK_BAD1 MARK_BAD 1 MARK_BAD2 MARK_BAD 1 MARK_BAD3 MARK_BAD 1 MARK_BAD4 MARK_BAD 1 MARK_BAD5 MARK_BAD [1] USB_D_M [1] USB_D_P [2] HPH_L_P [2] HPH_R_M [11] FM_ANT [3] HEADSET_DET_N [1] USB_VBUS [1] USB_VBUS [2] HSED_BIAS [2] MIC2_P [2] MIC2_M [3,4,6,7,10] VPH_PWR VCOIN [1,4,6,9,11] VREG_MSMP [1] JTAG_TDI [1] JTAG_TMS [1] JTAG_TCK [1] JTAG_TRST_N [11] UART1_RX_DATA [1] USB_D_P [1] USB_D_M [1] JTAG_TDO [1] JTAG_RTCK [11] UART1_TX_DATA [1] JTAG_TRST_N [1] JTAG_TDI [1] JTAG_TMS [1] JTAG_TCK [1] JTAG_TDO [1,4,6,9,11] VREG_MSMP [2] PON_RESET_N [1,2] D2D_PS_HOLD [1,4,5,6,11] VREG_MSME [1,4,5,6,11] VREG_MSME USB_PREFEXT [1] JTAG_RTCK VBAT [4] VREG_USIM [3] USIM_RESET [3] USIM_CLK [3] USIM_DATA [3] SDCC1_DATA(2) [3] SDCC1_DATA(3) [3] SDCC1_CMD [3] SDCC1_CLK [3] SDCC1_DATA(0) [3] SDCC1_DATA(1) [4,11] VREG_GP2 [6] RESOUT_N [1,2] D2D_PS_HOLD [2,3] KPDPWR_N [9] VBAT [2]BATT_TEMP V1.1 V1.1 WA01-1 2 FILE No: MODEL: TITLE: SHEET SCHEMATIC VERSION: PCB VERSION OF TELEEPOCH LIMITED 11 弱信号 , 差分 , 平行 , 地保护 差分 , 平行 差分 , 平行 , 强信号 , 低频干扰源 , 峰值 300mA DNCG_PA_ON_0G_PA_ON_1U_PA_ON_0U_PA_ON_1U_PA_ON_2XO_EN_GP1XO_OUT_GP1XO_OUT_GP2XTAL_32K_INXTAL_32K_OUTPS_HOLDSLEEP_CLKKPD_PWR_NREF_BYPMPP4GND_NCP XO_ADC_REF XO_ADC_IN GND_XO_ADC VREF_THERM HKAIN0 XTAL_19M_IN XTAL_19M_OUT D2D_XO PON_RESET_N LCD_DRV_N KPD_DRV_N VIB_DRV_N MPP2 HSED_BIAS SPKR_OUT_P SPKR_OUT_M VOUT_PA_CTL U1-J XT1 C5 C6 C7 C8 C10 C11 C12 R3 R4 VCON GND OUTVCC XT3 C13 C14 J2 HKAIN1MIC1PMIC1NMIC2PMIC2NLIN_IN_L_PLIN_IN_R_NCCOMP HPH_OUT_R_N HPH_OUT_L_P LINE_OUT_L_P LINE_OUT_R_N EARON EAROP U1-E C59 C60 C61 C62 C63 C64 R9 R10 C65 C66 C67 +- J5 12 J4 VR14 VR15 VR16 VR17 VR18 VR19 L1 L6 C58 C73 R53 R54 C89 [3] TRK_LO_ADJ [4] VREG_TCXO [9] GSM_PA_EN [9] GSM_PA_BAND [10] WCDMA_PA_ON1 [10] WCDMA_PA_ON2 [11] BT_CLK_EN [1] D2D_PS_HOLD [11] D2D_SLEEP_CLK [1,3] KPDPWR_N [1] PON_RESET_N [3] KPD_DRV_N [3] VIB_DRV_N [1,2] HSED_BIAS [1,2] HSED_BIAS [1] MIC2_P [1] MIC2_M [11] LINE_L_P [11] LINE_R_M [1] HPH_L_P [1] HPH_R_M MIC1_MSM_P MIC1_MSM_M EAR_P EAR_M [6] LCD_DRV [1] BATT_TEMP V1.1 V1.1 WA01-1 3 FILE No: MODEL: TITLE: SHEET SCHEMATIC VERSION: PCB VERSION OF TELEEPOCH LIMITED 11 PWR/END SEND CLEAR SELECT 1 23 UP LEFT 4 56 RIGHT DOWN 7 8 9 * 0 # OK 脉冲干扰源 , 大电流 20mA 大电流 ,60mA GPIO_38GPIO_37GPIO_36GPIO_35GPIO_34GPIO_33GPIO_32GPIO_31GPIO_30GPIO_29GPIO_28GPIO_27GPIO_26GPIO_25GPIO_24GPIO_23GPIO_22GPIO_21GPIO_20GPIO_19GPIO_18GPIO_17GPIO_16GPIO_15GPIO_14GPIO_13GPIO_12GPIO_11GPIO_10GPIO_9GPIO_8GPIO_7GPIO_6GPIO_5GPIO_4GPIO_3GPIO_2GPIO_1GPIO_0 GPIO_39 GPIO_40GPIO_41GPIO_42GPIO_43GPIO_44GPIO_45GPIO_46GPIO_47GPIO_48GPIO_49GPIO_50GPIO_51GPIO_52GPIO_53GPIO_54GPIO_55GPIO_56GPIO_57GPIO_58GPIO_59GPIO_60GPIO_61GPIO_62GPIO_63GPIO_64GPIO_65GPIO_66GPIO_67GPIO_68GPIO_69GPIO_70GPIO_71GPIO_72GPIO_73GPIO_74GPIO_75GPIO_76GPIO_77 U1-D GND_DIGGND_DIGGND_A_RF(GND_ANA)GND_A_RF(GND_RX_CDC2)GND_A_RF(GND_RX_PLL)GND_A_RFGND_A_RFGND_A_RFGND_DIGGND_DIGGND_A_RF(GND_RX_OSC)GND_A_RFGND_A_RFGND_DIGGND_DIGGND_A_RF(GND_ANA)GND_A_RF(GND_ANA)GND_A_RFGND_DIGGND_DIGGND_DIGGND_DIGGND_DIGGND_A_RFGND_A_RFGND_DIGGND_DIGGND_A_RF(GND_ANA)GND_A_RF(GND_ANA)GND_A_RF(GND_ANA)GND_A_RF(GND_ANA)GND_A_RFGND_A_RFGND_A_RFGND_A_RFGND_A_RFGND_A_RF(GND_TX_ANA)GND_A_RF(GND_TX_ANA)GND_A_RFGND_A_RF(GND_TX_PLL)GND_A_RFGND_A_RFGND_A_RF(GND_TX_PA,PA2)GND_A_RF(GND_TX_OSC)REF_GNDGND_5V GND_DIG GND_A_RF GND_DIGGND_DIGGND_DIG GND_A_RF GND_DIGGND_DIGGND_DIGGND_DIG GND_A_RF GND_DIGGND_DIGGND_DIGGND_DIGGND_DIGGND_DIGGND_DIGGND_DIG GND_A_RFGND_A_RFGND_A_RF GND_…

Text truncated - open the document above for the full version.
