U5L-WBM220

Wise & Blue Co., Ltd.

BLUETOOTH HEADSET

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Jul 31, 2007
Application Purpose: Original Equipment
Date of Application: Jul 30, 2007
Equipment Note: BLUETOOTH HEADSET
Frequency Range: 2402.00000000 - 2480.00000000
Company: Wise & Blue Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Operational Description

Test Report

Test Setup Photos

Document Text Content (5 documents)

Cover Letter(s)

Catalyst AirCom UWB Analyzer Model: SWAE10 Theory of Operation The Catalyst AirCom Ultra Wideband (UWB) Analyzer is capable of capturing and analyzing UWB traffic. The analyzer supports the following: • Capture and trigger of UWB events such as transactions and packets • Pre and post trigger pattern capture • Real time protocol error detection • Integrated frame generator to send user defined UWB frames over the air • Comprehensive statistical report. Before initiating the capture session, the user must address the following items. • Place the AirCom analyzer close to host/device and ensure the distance between the AirCom unit and host/device is less than 10 meters. • Define WiMedia channel and band group on AirCom analyzer. • Configure the AirCom analyzer software to capture the needed data. The AirCom UWB Analyzer incorporates WisAir 532 chipset and technology based on the WiMedia MB-OFDM standard. In WiMedia MB-OFDM there are 14 band groups and 30 channels. The AirCom implements only the lower three bands and seven channels of the standard with the center frequencies at 3432MHz, 3960MHz and 4488MHz. Each band is 528 MHz in bandwidth and composed of 128 OFDM tones. Each OFDM tone is 4.125 MHz in bandwidth and is QPSK modulated. The data rate is limited to 100Mbps total for uplink and downlink. The Catalyst AirCom analyzer is designed to meet the appropriate FCC part 15 rules and regulations. The AirCom analyzer configures PHY to work on a user-defined channel and capture each valid frame transmitted on this channel. The AirCom analyzer tracks Host/Device traffic and when host changes the channel, it changes capturing channel like a real device. Then AirCom extracts and shows the captured WiMedia and WUSB frames in a graphical view. The user can then search for specific pattern, filter undesired traffic or get statistical report. In ciphering connection, the AirCom could capture and decode WUSB traffic. Each device has a CDID and each Host has a CHID and each secur...

External Photos

All services undertaken are subject to the following general policy. Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of TDK RF Systems Inc. This report must not be used to claim product endorsement by A2LA, NVLAP nor any other agency of the US Government. Compliance report of Catalyst AirCom UWB Analyzer Model: SWAE10-X Customer: LeCroy Corporation Date: March 12, 2007 TDK Report: TTS-TR-T111-110 Test performed by: TDK R&D Corporation 1101 Cypress Creek Rd Cedar Park, TX 78613 Technician Checked by Radiated 30 MHz to 40 GHz A. Medina K. Yata Conducted 150 KHz to 30 MHz A. Medina K. Yata Report A. Medina P. Carson This document contains confidential information and cannot be disclosed outside of LeCroy or any affiliated company in whole or in part without the express written permission of TDK RF Systems Inc. TTS-TR-T111-110 2 1. Executive Summary An EMC evaluation to determine compliance of the Catalyst AirCom UWB Analyzer Model: SWAE10-X with requirements of FCC 47 CFR Part 15, Subpart F Section 15.517 was conducted. All references are to the most current version of the Code of Federal Regulations 47 that is currently in effect. In accordance with §2.1033, the following data is presented in support of the Certification of the WUSB HUB. The client should retain a copy of this document on file for at least 5 years after the manufacturing of the product has been discontinued. Test Description FCC 47 CFR Section Compliance Operational Limitations 15.517(a) The client has been notified of these limitations. In normal operating mode the transmitter will only send data when associated with a receiver. See section 5 for detail UWB Bandwidth 15.517(b) Yes Radiated Emissions 15.517(c), 15.209 Yes Radiated Em...

Contact Information

Applicant

IL-HEUNG SON(Director)

[email protected]+82-2-2028-7400Fax: +82 2 2028 7422

Test Firm

Dt&C Co., Ltd.Lee Sang-Wook

[email protected]82-31-321-2664Fax: 82-31-321-1664

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.04 mW

Confidentiality

Long Term

Grant Notes

This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with specific operating instructions for satisfying RF exposure compliance.

Other Applications from Wise & Blue Co., Ltd.

U5L-WMA300

BLUETOOTH MONO HEADSET

DSS - Part 15 Spread Spectrum TransmitterSep 12, 2007

ID Label/Location Info

March 2007 P/N 400-0103-001 User’s Manual Version 1.22 Catalyst Enterprises Inc.Copyright ii Trademarks and Servicemarks AirCom is a trademark of LeCroy Corporation. Universal Serial Bus and On-The-Go are registered trademarks of USB-IF. Microsoft and Windows are registered trademarks of Microsoft Corporation. Intel and Pentium are registered trademarks of Intel Corporation. AMD Duron and AMD Athlon are trademarks of Advanced Micro Devices, Inc. All other trademarks and registered trademarks are property of their respective owners. Disclaimer THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL INFORMATION, EXAMPLES AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE REPRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS ARE FULLY RESPONSIBLE FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN INFORMATION THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT LECROY CORPORATION FOR A COPY. Copyright Copyright © 2003-2007, LeCroy Corporation; All rights reserved. This document may be printed and reproduced without additional permission, but all copies should contain this copyright notice. WEEE Program This electronic product is subject to disposal and recycling regulations that var y b y country and region. Man y countries prohibit the disposal of waste electronic equipment in standard waste receptacles. For more information about proper disposal and recycling of your Catalyst product, please visit www.getcatalyst.com/recycle. CopyrightCatalyst Enterprises, Inc. iii FCC Conformance Statement Compliance with 47 CFR 15.519 (a)(1) This device complied with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device ...
