U93GUITARWireless Guitar operating on 2.4 GHz

Warranty This product comes with three (3) month limited warranty from the date of purchase against manufacturing defect. Notice: Wireless Guitar Setup Instructions: Install 4 AA batteries into wireless guitar. Plug wireless receiver into game console. Turn on your wireless guitar, and wait until the guitar and the receiver are synchronized. The light on the guitar (behind the strum bar) & the receiver will be lit. Now your wireless guitar is ready to go, ROCK ON! 1 2 3 4 MEMOR Y CARD MEMORY CA RD 1 2 PS2 MEMOR Y CARD MEMORY CARD 1 2 PS2 TAC TAC + - + - + - BATTERIES + - SIZE AA 1.5vx4 OFF/ON OFF/ON Guitar Controls: *The actual style of the guitar controller may be dierent from the example shown above. a b c d e f g h j i Plug wired guitar into game console. Now your wired guitar is ready to go, ROCK ON! 1 2 MEMORY CARD MEMORY CARD 1 2 MEMORY CARD MEMORY CARD 1 2 PS2 PS2 Wired Guitar Setup Instructions: • This product is made for indoor use only. • Keep the product at room temperature. • Product contains electrical components; keep it away from moisture • Modifying or disassembling the controller in any way will void the warranty • The controller must be used with care to avoid injury. • TAC will not be liable for injury resulting from the improper use of the controller • Small parts may be a choking hazard for children under 3 For more information or to activate the warranty register the product at: http://www.theantcommandos.com/warranty For technical support, email us at: [email protected] For Frequently Asked Questions visit us at: http://www.theantcommandos.com/FAQDisplay.aspx (To setup a second wireless guitar, repeat step 2 & 3 after the rst wireless guitar is setup). START button: SELECT button: GREEN button: RED button: YELLOW button: BLUE button: ORANGE button: STRUM BAR: WHAMMY BAR: TILT SENSOR: a: b: c: d: e: f: g: h: i: j: Pause Activate STAR POWER Activate the GREEN note/Conrm Activate the RED note/Cancel Activate the YELLOW note Activate the BLUE note Activate the ORANGE note Move the STRUM BAR up and down to activate the color buttons and to navigate the menu Press WHAMMY BAR down to alter the sound of the song Activate the STAR POWER. To activate, tilt the guitar up or down changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

WIRLESS GUITAR BLOCK DIAGRAM DO CS CLK ACK DI PS console RF RECEIVE MODUL RF transmit module MCU oscillate Keyboard control circuit AU AD AR AL BU BD BL BR R2 L2 RP4 OSCI OSCO 12MHz Power LDO LED MCU LDO LED indicate PSII INTERFACE Wireless data transmit 24000kHz~ 2483.5MHz 24000kHz~ 2483.5MHz

FCC ID: U93GUITAR This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Proposed Label Location on EUT FCC ID Label Location

WIRLESS GUITAR BLOCK DIAGRAM DO CS CLK ACK DI PS console RF MODUL 24000kHz~ 2483.5MHz Wireless data transmit PSII I N TERF A CE LED indicate LDO MCU RF module LED LDO Power MCU OSCI OSCO 12MHz Keyboard control circuit oscillate 24000kHz~ 2483.5MHz AU AD AR AL BU BD BL BR R2 L2 RP4 Operational Description of equipment 1. Plug the receiver to your PS2 game console first, and power on your console. The LED light will be shining and blinking now, and the receiver starts to search a suited wireless guitar controller. 2. Properly put the batteries into the battery box that is on the back of the guitar controller. 3. The switch of the guitar controller should be pushed to “ON” now. 4. The LED light near the switch will be blinking, and begins to look for a suited receiver. 5. When a pair of receiver and controller is matched, the LED light on the receiver will be always shining, and the LED light on the guitar controller will be shining for only 5 seconds and go out. The wireless guitar controller is ready to use. 6. The guitar controller will go into its sleep mode if without any action for 2 minutes. But you can press any button to make it work again. 7. wireless guitar all button by keyboard control scan circuit and encode. And send to receiver part through RF transmit module. If the guitar better is low level, the LDO circuit control LED glitter, by 8Hz . 8. receiver circuit part. Thought the RF receiver module receiver the Control data and decode the button by MCU, then send to PSII console

123456 A B C D 6 54321 D C B A Title NumberRevisionSize B Date:30-Apr-2007Sheet of File:E:\product design\TAC Commpany\pcb\MR-pcb.DdbDrawn By: 1 SCLK 1 2 SO(GDO1) 2 3 GDO2 3 4 DVDD 4 5 DCOUPL 5 6 G D O 0 6 7 C S n 7 8 X O S C - Q 1 8 9 A V D D 9 1 0 X O S C - Q 2 1 0 11 AVDD 11 12 RF-P 12 13 RF-N 13 14 AVDD 14 15 AVDD 15 1 6 G N D 1 6 1 7 R B I A S 1 7 1 8 D G U A R D 1 8 1 9 G N D 1 9 2 0 S I 2 0 U? CON EISA62 SCLK SO GDO2 1.8V -3.6V POWER SUPPLY L131 C132 C51 C131 C121 GDO0 CSn SI C81C101 Y1 L121 L122 C123C124 R171 ANTENNA (50 Ohm) C122 CC2500

1234 A B C D 4 321 D C B A C1 104 E1 100uF Vbat C2 104 E2 47uF BT1 6V G N D 1 VI 2 VO 3 U2HT7533 VCC C4 103 VR VCC X1 12M C5 20P C6 20P VCC R2 10K VCC C7 104 VCC G N D 1 G N D 7 V C C 2 C S 9 G D O 0 8 G D O 2 6 S O 5 S C L K 4 S I 3 U3 RF MODEL K9 Green K8 Red K4Up K2Select K1Start K3Down K5 Orange K10 FC Link PE0 1 PE1 2 PE2/SDI 3 PE3/SDO 4 PE4/SCK 5 PE5/SCS 6 PA0 7 PA1 8 PA2 9 PA3 10 PA4 11 P A 5 1 2 P A 6 1 3 P A 7 1 4 P D 0 1 5 P D 1 1 6 R S T B 1 7 P D 2 1 8 P D 3 1 9 P D 4 2 0 P D 5 2 1 P D 6 2 2 PD7 23 PB0 24 PB1 25 PB2 26 PB3 27 PB4 28 PB5 29 PB6 30 PB7 31 PC2 32 PC1 33 P C 0 3 4 P C 3 3 5 P E 6 3 6 P E 7 3 7 V D D 3 8 O S C I 3 9 O S C O 4 0 V S S 4 1 I N T 4 2 D A T A 4 3 C L K 4 4 U1 D4 Link R1 1K VCC K7 Yellow K6 Blue R7*10 可省略 R7 涤纶电容 Q2 8050 R3 4.7K R4 2.7K* R5 20K Vbat Q1 8050 R6 100K D1 IN4148 K12 MODE K11 L2

ISO/IEC17025 Accredited Lab. Report No: FCC0704092 File reference No: 2007-04-28 Applicant: The Ant Commandos，Inc Product: Wireless Shredder Guitar Model No: SHRD-WL-SBBL Brand Name: TAC Test Standards: FCC Part 15 Subpart C, Paragraph 15.249 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 Subpart C, Paragraph 15.249 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: April 28, 2007 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO LTD East 5/Block 4, Anhua Industrial Zone, No.8,Tairan Rd. CheGongMiao, FuTian District, Shenzhen, CHINA. Tel (755) 83448688 Fax (755) 83442996 Report No: 0704092 Page 2 of 44 Date: 2007-04-28 TEST REPORT The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAL-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAL/AC01:2002 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:1999 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC- Registration No.: IC5205 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205. Report No: 0704092 Page 3 of 44 Date: 2007-04-28 TEST REPORT The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 5 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operating Condition....................................…
