U9O-SM520

Synapse Wireless Inc.

SNAP OS-enabled 2.4GHz modular radio

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 23, 2022
Application Purpose: Original Equipment
Date of Application: Mar 22, 2022
Equipment Note: SNAP OS-enabled 2.4GHz modular radio
Frequency Range: 2405.00000000 - 2480.00000000
Company: Synapse Wireless Inc.
Country: United States

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission
1	15C	2.40 GHz - 2.48 GHz	83.00 mW	2M27F1D

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Output power listed is Conducted. The antennas shown in this filing must be installed to provide a separation distance of at least 20cm from all persons. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product guidelines. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter.
