22198 Page 1 Wissenschaftlich-Technische Werkst‰tten GmbH MANUAL 22198 Radio Transceiver Module 22198 Page 2 Wissenschaftlich-Technische Werkst‰tten GmbH Dr.-Karl-Slevogt-Strafle 1 D-82362 Weilheim Telephone +49 (0881) 1 83-244 Telefax +49 (0881) 1 83-313 Internet: http://www.wtw.de Copyright © 2006 by WTW GmbH. All rights reserved. All information in the following document is protected by copyright law. No part of this document may be reproduced without the written consent of WTW GmbH. WTW GmbH reserves the right to make any changes of specification and other information in this document without further notice. Please note During the compilation of this technical documentation, great care has been taken to ensure the accuracy of the information contained in it. However, despite our constant effort to ensure the highest degree of accuracy and comprehensiveness possible, the information provided cannot be guaranteed to be absolutely error- free. Trademarks This documentation may contain representations of registered product or service trademarks owned by WTW GmbH or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions. In any case the intellectual property rights remain exclusively with their respective owners. 22198 Page 3 FCC 15.21: IMPORTANT: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment The final product should contain labelling according to FCC requirements. For example: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device contains FCC ID UAC-M022198. This label will be placed on the final product, clearly visible to all persons exposed to the transmitter. CANDADA: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device 22198 Page 4 General 22198 is a Radio Transceiver Module (RFID module) which is designed for installation in WTW devices by WTW GmbH only. The module is not to be sold as an individual product. 22198 must be connected to the appropriate devices by means of the plug-in connector provided for this purpose. 22198 Page 5 22198 / front view 22198 / front view

Federal Communications Commission 445 12 th Street SW Washington, DC 20554 USA Request for Confidentiality in accordance with CFR 0.457 and 0.459 08 June 2006 EMCCert DR. RAäEK - Certification Institute - Boelwiese 5 D-91320 Ebermannstadt RE: Certification Application FCC ID: UAC-M022198 Please be advised that the following information is to be held confidential on behalf of WTW GmbH: • Schematics • Parts List • Block Diagram • Technical Description The application contains technical information which WTW GmbH deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

EMV-Pr ̧fzentrum EMI/EMC-Testcenter Coordinates: ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing Telefon (0 94 21) 55 22-0 Telefax (0 94 21) 55 22-99 [email protected] ! http://www.senton.de Senton GmbH ! ƒussere Fr ̧hlingstrasse 45 ! D-94315 Straubing EMCC DR. Raöek Boelwiese 5 D-91320 Ebermannstadt 14 June 2006 In reference to FCC ID UAC-M022198 Justification for Part 15 Limited Modular Transmitter Approval according to DA 00-1407 1. Own RF Shielding Not complied, but subject to limited modular approval. The Grantee can demonstrate that it will retain control over the final installation of the device, such that compliance of the end product is assured. In such a case, an operating condition on the grant of equipment authorization for the module would state that the module is only approved for use when installed in devices produced by a specific manufacturer, typically the Grantee. 2. Buffered Modulation inputs Complied, no direct modulation input. Modulated signals will be buffered by microcontroller IC1 3. Own power supply regulation Complied, voltage regulated power supply on board, see schematic diagram 4. Antenna requirements Complied, integrated antenna 5. Test in stand-alone configuration Complied, see test report for details. Cable lengths typical to actual use 6. Own FCC ID Complied, the exterior label will be "Contains FCC ID UAC-M022198" Subject to limited modular approval 7. The Modular Transmitter must comply with any specific rule and the manufacturer must provide adequate instructions The EUT is compliant with all applicable FCC rules. Detail instructions are given in the User guide 8. RF Exposure requirements Not applicable since the unit operates under section 15.209 of the FCC rules. The reference guide contains general installation and operation instructions. MPE evaluation not required Johann Roidt Senton GmbH

FCC ID UAC-M022198 FCC ID UAC-M022198 FCC ID UAC-M022198

FCC ID UAC-M022198 FCC ID UAC-M022198 FCC ID UAC-M022198

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 52501-60214 (Edition 1) Page 1 of 32 Pages Straubing, 11 May 2006 T E S T - R E P O R T No. 52501-60214 (Edition 1) for 22198 (RFID-Module 125 kHz) RFID Reader Applicant: WTW Wissenschaftlich-Technische Werkst‰tten GmbH Test Specifications: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207 and 15.209 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 52501-60214 (Edition 1) Page 2 of 32 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ........................................................ 3 2 Administrative Data..................................................................................................... 4 3 Identification of the Test Laboratory ........................................................................... 5 4 Summary .................................................................................................................... 6 5 Operation Mode and Configuration of EUT................................................................. 7 6 Measurement Procedures........................................................................................... 8 6.1 Bandwidth Measurements .................................................................................... 8 6.2 Radiated Emission Measurement 9 kHz to 30 MHz ............................................. 9 6.3 Radiated Emission in Fully or Semi Anechoic Room.......................................... 11 6.4 Radiated Emission at Open Field Test Site........................................................ 13 7 Photographs Taken During Testing .......................................................................... 14 8 Test Results .............................................................................................................. 20 8.1 Occupied Bandwidth........................................................................................... 21 8.2 Bandwidth of the Emission ................................................................................. 24 8.3 Designation of Emissions ................................................................................... 26 8.4 Restricted Bands of Operation ........................................................................... 27 8.5 Radiated Emission Measurement 9 kHz to 30 MHz .......................................... 28 8.6 Radiated Emission Measurement 30 MHz to 1 GHz ......................................... 29 9 Referenced Regulations ........................................................................................... 31 10 Charts taken during testing ....................................................................................... 32 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 52501-60214 (Edition 1) Page 3 of 32 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : 22198 (RFID-Module 125 kHz) Parts 2 : Serial number(s): #1 Manufacturer: WTW Wissenschaftlich-Technische Werkst‰tten GmbH Type of equipment: RFID Reader Version: As received FCC ID: Additional parts/accessories: Technical data of EUT Application frequency range: 119 - 135 kHz Frequency range: 119 - 135 kHz Operating frequency: 125 kHz Type of modulation: ASK Pulse train: --- Pulse width: --- Number of RF-channels: 1 Channel spacing: --- Designation of emissions 3 : 10K0A1D Type of antenna: Inductive loop Size/length of antenna: ∅ 10 cm Connection of antenna: detachable not detachable Type of power supply: DC supply Specifications for power supply: nominal voltage: 3.3 V minimum voltage: 2.97 V maximum voltage: 3.3 V nominal frequency: 0 Hz 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 52501-60214 (Edition 1) Page 4 of 32 Pages 2 Administrative Data Application details Applicant (full address): WTW Wissenschaftlich-Technische Werkst‰tten GmbH Dr.-Karl-Slevogt-Strafle 1 D-82362 Weilheim Contact person: Wilhelm Kl ̧pfel Contract identification: Order no. EB45526 Receipt of EUT: 20 April 2006 Date(s) of test: 20 April due 10 May 2006 Note(s): --- Report details Report number: 52501-60214 Edition: 1 Issue date: 11 May 2006 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 52501-60214 (Edition 1) Page 5 of 32 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: Senton GmbH EMI/EMC Test Center Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-P-171/94-02 FCC test site registration number 90926 Industry Canada test site registration: IC 3050 Contact person: Mr. Johann Roidt Phone: (+49) (0)9421 5522-0 Fax: (+49) (0)9421 5522-99 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 52501-60214 (Edition 1) Page 6 of 32 Pages 4 Summary Summary of test results The tested sample complies with the requirements set forth in the Code of Federal Regulations CFR 47, Part 15, Sections 15.205 and 15.209 of the Federal Communication Commission (FCC). Personnel involved in this report Laboratory Manager: Mr. Johann Roidt Responsible for testing: Mr. Thomas Eberl Responsible for test report: Mr. Thomas Eberl Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 52501-60214 (Edition 1) Page 7 of 32 Pages 5 Operation Mode and Configuration of EUT Operation Mode(s) Transmit mode continuously Configuration(s) of EUT EUT was tested as a stand alone device mounted in a test cabinet. EUT is equipped with…
