People Tracker Basic, People Tracker Plus , and People Tracker Plus Encoder Users Guide ™ ™ ™ People Tracker ™ Users Guide Covers: People Tracker Basic, People Tracker Plus , and People Tracker Plus Encoder ™™™ http://www.silvercomdistribution.com/ Part No. PTPUG-2.0 Revision B Published December 2004 Silvercom Distribution Inc. 3164 Pepper Mill Court Unit #7 Mississauga, Ontario L5L 4X4 Copyright © 2003, Silvercom Distribution Inc.. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from Silvercom Distribution Inc.. Silvercom Distribution reserves the right to revise this documentation and make changes in content from time to time without obligation on the part of Silvercom Distribution to provide notification of such revision or change. Silvercom Distribution provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. Silvercom may make improvements or changes in the product(s) and or program(s) described in this document at any time. Silvercom and the Silvercom logo are registered trademarks of Silvercom Distribution Inc. People Tracker, People Tracker Plus, and the People Tracker logo are registered trademarks of Silvercom Distribution Inc. All other company and product names may be trademarks of the respective companies which they are associated. Contents About This Guide Conventions5 Overview Chapter Summary7 Top View Detail8 Rear View Detail9 Bottom View Detail10 Display Detail10 Features11 Installation Chapter Summary13 Choosing The Right Location14 System Assembly14 Table Top Installation15 Wall Mount Installation15 Configuration Chapter Summary17 Powering On For The First Time18 Basic System Configuration18 Configuring The Encoder And Radio19 Pocsag Options19 Two-Tone Options19 Transmit Options19 Radio Options19 Adding Pagers To The System20 Adding Pager Groups21 Configuring The Serial Ports22 Configuring The Telephone Port22 Configuring The Alarm Inputs23 Setting The Time23 Adding A Setup Password24 Performing A Range Test24 1 2 3 Operation Chapter Summary25 General Operating Information26 Sending A Tone Page26 Sending A Numeric Page26 Sending An Alphanumeric Page27 Sending A Voice Page27 Sending A Page From A Telephone28 Care and Maintenance Chapter Summary29 Cleaning Precautions30 LCD Care30 Replacing The Clock Battery30 Compliance and Safety Reserved33 Connector Pin-Outs Power Connector35 Keyboard Connector35 Serial Ports 1 And 236 9 To 25 Pin Mapping36 Straight Through CableConnection (DTE-DCE)36 Null Modem Cable Connection (DTE-DTE)37 Encoder Output Port37 Alarm Input Connector38 Alarm Connection Detail38 Code Plan and Tone Codes Code Plans39 Code Plan Table39 Tone Groups40 Tone Codes41 Technical Specifications General53 Encoder54 Radio54 Physical54 Wall Mounting Template Template55 4 5 A B C D E About This Guide This guide provides all the information you need to setup, install, and use a People Tracker or People Tracker Plus with a basic configuration. This guide is intended to be used by the installers and system administrators who are responsible for installing, configuring and maintaining this local area paging unit; consequently, it assumes a basic working knowledge of paging equipment and radio transmitters. ConventionsTable 1 and Table 2 list several conventions used throughout this guide. Table 1 Table 2 Icon Convention Notice TypeDescription Description Information that describes a important features or instructions. Also used to point out helpful shortcuts. This typeface represents information as it appears on the display of the unit. Information that alerts you to potential loss of data or potential damage to the device. This typeface represents the key names of the keys on the keyboard. Information that alerts you to potential personal injury. Italics are used to: Emphasize a point Denote a new term at the place where it is defined in the text. Identify menu names and menu commands. + + + Informative Note Screen Text Caution KeyboardKeys Warning Words initalics Notice Icons Text Conventions 5 (Page Intentionally Left Blank) 6 Overview of the People Tracker 1 This section contains introductory information about the People Tracker and some of it’s features. It covers the following topics: People Tracker Display Detail People Tracker Feature Overview + + + + + People Tracker/Plus Top View Detail People Tracker Rear View Detail People Tracker Plus Rear View Detail People Tracker Plus Encoder Rear View Detail People Tracker/Plus Bottom View Detail + + 7 Top View Detail A B C D E F G HII K J L ALCD Screen BLCD Backlight On/Off Button CNumeric Keypad DLCD Contrast Controls EMicrophone (Plus/Encodr Models Only) FCancel Button GSend Button HQWERTY Keyboard (Plus/Encoder Models Only) ICursor Keys (Plus/Encoder Models Only) JAlternate Character Key KTalk Button (Plus/Encoder Models Only) LSoft Function Keys (Plus/Encoder Models Only) Figure 1 People Tracker/Plus Top View 8 Rear View Details APower Switch BPower Connector CKeyboard Connector (Plus Models Only)) DRS-232 Serial Ports EEncoder Output (Encoder Model Only)) FTelephone Line Jack GAntenna Connector (Non-Encoder Models Only) HAlarm Inputs SERIAL 1SERIAL 2 ALARM INPUTS TELEPHONE LINE POWER ANTENNA I O ABDF GH SERIAL 1SERIAL 2 ALARM INPUTS TELEPHONE LINE KEYBOARD POWER ANTENNA I O ABCDF GH SERIAL 1SERIAL 2 ALARM INPUTS ENCODER OUT TELEPHONE LINE KEYBOARD POWER I O ABCDEF H Figure 2 Figure 3 Figure 4 People Tracker Rear Plate People Tracker Plus Rear Plate People Tracker Plus Encoder Rear Plate 9 Display Detail Bottom Detail A B C A Figure 6 Figure 5 Display Detail Bottom Detail - All units AStatus Bar - Displays Date and Time, as well as occasional status i…

Text truncated - open the document above for the full version.

November 20, 2006 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Subject: Equipment Authorization under FCC 47 CFR, Parts 2, 22 and 90 (Subpart I) - Non-Broadcast Radio Transceivers Operating in the Frequency Band 450-470 MHz (25 kHz and 12.5 kHz Channel Spacings). Applicant: SilverCom Distribution Inc Product: People Tracker Model: PTSPLUS-05 and PTSBASIC-05 FCC ID: UBEPTSPLUS Dear Sir/Madam, As appointed agent for SilverCom Distribution Inc, we would like to submit the application to Federal Communications Commission for certification of the above product. Please review all files uploaded to Timco electronic filing site. The People Tracker incorporated a certified radio (FCC ID: PT9SDU-2000), the construction and electrical characteristics of the integrated device is identical to the certified radio. For this filing, a test report for the People Tracker is submitted to address the RF power output, RF exposure requirement and field strength of spurious emissions. For other required tests see original test report, submitted with this filing. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.: 1-877-747-6381 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering UltraTech Group of Labs Ultratech’s Accreditations: 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

ANNEX 2 – EXTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A2 - 1 ANNEX 2 – EXTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A2 - 2 ANNEX 2 – EXTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A2 - 3 ANNEX 2 – EXTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A2 - 4 ANNEX 2 – EXTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A2 - 5 ANNEX 2 – EXTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A2 - 6

ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 1 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 2 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 3 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 4 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 5 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 6 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 7 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 8 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 9 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 10 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 11 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 12 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 13 ANNEX 3 – INTERNAL PHOTOGRAPHS SilverCom Distribution Inc People Tracker, Model(s) PTSPLUS-05 / PTSBASIC-05 FCC ID: UBEPTSPLUS A3 - 14

PART LIST _ SDU_2000_2W DataRadio KaceTelecom 대외비 I J JANG 12 /8/2006 11:56 AM PART-NO NAME & DESCRIPTION AS REFERENCE NO 5302001MA MAIN BODY ASS'Y J101 42360809 A D-SUB CONNECTOR 107-09SKKB(FEMALE ) CA J102 44110940B BNC ANT JACK UG-1094/U-W CA J101 6D2006800 MAIN BODY ZN DIE CASTING CA 6D3033500 COVER ZN DIE CASTING CA UPPER,BOTTOM 7I3033600 GASKET RING SILICONE RUBBER BLAC K CA 7I4017800 GASKET CONNECTOR RUBBER SPONG E CA 7K3034300 A NT TERMINA L CA 8C4017300 NAME LABEL PE T=0.1 CA 9AP02040 W MACHINE SCREW (+)2.0X4.0 PH ZN-WPLATING CA 5302002MA MAIN P.C.B ASS'Y (SMD) A 02000016 A CHIP RESISTOR 0 -J-1/16W (1608) SMD L503,507 02010016 A CHIP RESISTOR 10 -J-1/16W (1608) SMD R105,512 02010116 A CHIP RESISTOR 100 -J-1/16W (1608) SMD R102,112,128,136,402, 403,416,503,520 02010216 A CHIP RESISTOR 1K -J-1/16W (1608) SMD R113,135,220,524,528, 529,531 02010316 A CHIP RESISTOR 10K -J-1/16W (1608) SMD R114,120,125,410,411, 414,415,417,517,521,525,530,532,533 02010416 A CHIP RESISTOR 100K -J-1/16W (1608) SMD R204,211,409 02010516 A CHIP RESISTOR 1M -J-1/16W (1608) SMD R205 02012216 A CHIP RESISTOR 1K2 -J-1/16W (1608) SMD R511 02015216 A CHIP RESISTOR 1K5 -J-1/16W (1608) SMD R508,514 02015316 A CHIP RESISTOR 15K -J-1/16W (1608) SMD R201 02015416 A CHIP RESISTOR 150K -J-1/16W (1608) SMD R109,401 02018316 A CHIP RESISTOR 18K -J-1/16W (1608) SMD R103,127 CHIP RESISTOR 2R2 -J-1/16W (1608) SMD R516 02022016 A CHIP RESISTOR 22 -J-1/16W (1608) SMD R513 02022116 A CHIP RESISTOR 220 -J-1/16W (1608) SMD R106,107,111,518,519, 534,609 02022216 A CHIP RESISTOR 2K2 -J-1/16W (1608) SMD R207,505,603,607,608 02022316 A CHIP RESISTOR 22K -J-1/16W (1608) SMD R116,117,118,119,404, 419,523,527,601,602 02022416 A CHIP RESISTOR 220K -J-1/16W (1608) SMD R210 02027116 A CHIP RESISTOR 270 -J-1/16W (1608) SMD R522 02027216 A CHIP RESISTOR 2K7 -J-1/16W (1608) SMD R206,502,515 02033116 A CHIP RESISTOR 330 -J-1/16W (1608) SMD R507 02033216 A CHIP RESISTOR 3K3 -J-1/16W (1608) SMD R110,526 02033316 A CHIP RESISTOR 33K -1-1/16W (1608) SMD R208,209,408 02033416 A CHIP RESISTOR 330K -J-1/16W (1608) SMD R202 02039216 A CHIP RESISTOR 3K9 -J-1/16W (1608) SMD R203 SDU-2000 Parts List PART LIST _ SDU_2000_2W KaceTelecom 대외비 1 OF 4 PART LIST _ SDU_2000_2W DataRadio KaceTelecom 대외비 I J JANG 12 /8/2006 11:56 AM PART-NO NAME & DESCRIPTION AS REFERENCE NO CHIP RESISTOR 39K -J-1/16W (1608) SMD R122 02047016 A CHIP RESISTOR 47 -J-1/16W (1608) SMD R407,504 02047116 A CHIP RESISTOR 470 -J-1/16W (1608) SMD R406,413,418 02047216 A CHIP RESISTOR 4K7 -J-1/16W (1608) SMD R104,412,509,510,606, 610 02047316 A CHIP RESISTOR 47K -J-1/16W (1608) SMD R101,115,124,405,605 02047416 A CHIP RESISTOR 470K -J-1/16W (1608) SMD R126,604 02068016 A CHIP RESISTOR 68 -J-1/16W (1608) SMD R506 02068216 A CHIP RESISTOR 6K8 -J-1/16W (1608) SMD R123,501 02068316 A CHIP RESISTOR 68K -J-1/16W (1608) SMD R212 02082216 A CHIP RESISTOR 8K2 -J-1/16W (1608) SMD R129 02082316 A CHIP RESISTOR 82K -J-1/16W (1608) SMD R121 06010311 A RESISTOR SEMI EVM3YSX50B14 (10KB) SMD RV101,201,202,501 06022411 A RESISTOR SEMI EVM3YSX50BE5 (220KB) SMD RV401 11102001M CERAMIC GRM39 COG 020 C50 SMD C127 11103001M CERAMIC GRM39 COG 030 C50 SMD C610 11104001M CERAMIC GRM39 COG 040 C50 SMD C115,503,510,512,612 11105001M CERAMIC GRM39 COG 050 C50 SMD C106,527,531 11106001M CERAMIC GRM39 COG 060 D50 SMD C113,513,519,606,608 11107001M CERAMIC GRM39 COG 070 D50 SMD C120,518,528 11109001M CERAMIC GRM39 COG 090 D50 SMD C533 11110001M CERAMIC GRM39 COG 100 D50 SMD C534,609 11110101 A CERAMIC UMK107CH101J- T SMD C412,413,414,506,507,601 11110202A CERAMIC UMK107 B102K-T SMD C143,204,301,304,307,402,404,411,418,538540 , 541 , 614 , 617 , 618 , 11110302A CERAMIC UMK107 B103K-T SMD C123,125,126,130,131,145,152,153,406415 , 416 , 419 , 509 , 544 , 602 , 11110402A CERAMIC TMK107 F104Z-T SMD C136,137,138,139,140,141,142,144,147,148149 , 207 , 516 , 522 11111001M CERAMIC GRM39 COG 110 J50 SMD C511 11112001M CERAMIC GRM39 COG 120 J50 SMD C133,504,521 11113001M CERAMIC GRM39 COG 130 J50 SMD C129,525 11115001M CERAMIC GRM39 COG 150 J50 SMD C517 11116001M CERAMIC GRM39 COG 160 J50 SMD C118,124 1111R801M CERAMIC GRM39 COG 1R8 C50 SMD C101,111 11122001M CERAMIC GRM39 COG 220 J50 SMD C107,114,132,134,409 11122101 A CERAMIC UMK107CH221J- T SMD C1,2,119,122,603 11122202 A CERAMIC UMK107 B222K- T SMD C408 11124001M CERAMIC GRM39 COG 240 J50 SMD C104 11127101 A CERAMIC UMK107CH271J- T SMD C208 1112R201M CERAMIC GRM39 COG 2R2 C50 SMD C117 PART LIST _ SDU_2000_2W KaceTelecom 대외비 2 OF 4 PART LIST _ SDU_2000_2W DataRadio KaceTelecom 대외비 I J JANG 12 /8/2006 11:56 AM PART-NO NAME & DESCRIPTION AS REFERENCE NO 1112R701M CERAMIC GRM39 COG 2R7 C50 SMD C604,607 11139001M CERAMIC GRM39 COG 390 J50 SMD C105,530 11139202 A CERAMIC UMK107 B392K- T SMD C205 1113R301M CERAMIC GRM39 COG 3R3 C50 SMD C103 11147001M CERAMIC GRM39 COG 470 J50 SMD C202,417,526 11147101A CERAMIC UMK107CH471K-T SMD C108,09,10,403,05,20,21,22,501,02,05,08415 , 20 , 23 , 29 , 32 , 36 , 37 , 42 , 43 , 605 , 11 , 13 11147302 A CERAMIC TMK107 F473Z-T SMD C407,539 11147402 A CERAMIC EMK107 F474Z- T SMD C201 11168101 A CERAMIC UMK107CH681J- T SMD C206 13110010 A TANTAL 10UF 10V SIZE A SMD C514 13110020 C TANTAL 10UF 16V SIZE C SMD C302 13110520 A TANTAL 1UF 16V SIZE A SMD C211,305 13122020 C TANTAL 22UF 16V SIZE C SMD C303 Not Used 13122220 A TANTAL 2.2UF 16V SIZE A SMD C524 13147210 A TANTAL 4.7UF 10V SIZE A SMD C135,146,209,210,306,308,310,401, 410,615,616 18003011 A TRIMMER RCTKN003A61X (3PF) SMD TC601 18010011 A TRIMMER ECRKN010E01X (10PF) SMD TC101,102,103,104,105 20101000 A DIODE RECTIFIER S1A SMD D301 20116000B DIODE KDS 160 SMD D104,401,402,404,505 20118400B DIODE KDS 184 SMD D102,103 20122600B DIODE KDS 226 SMD D101 20122900D DIODE 1SV 229 (TPH3) SMD D601 20128100 A DIODE MMBD101LT1 SMD D504 20134010 C DIODE MMBV3401 LT1 SMD D502,503 20186200 A DIODE KDS114 SMD D500,501,602 23010014 A TRANSISTOR KTA 1001 (SOT89) SMD Q511 23013505 C TRANSISTOR BFG 135 (SOT223) SMD Q50…

Text truncated - open the document above for the full version.

FCC Parts 2, 22 & 90 Page 9 People Tracker, Models PTSPLUS-05 and PTSBASIC-05 FCC ID: UBEPTSPLUS ULTRATECH GROUP OF LABS File #: SDI-005F2290 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 20, 2006 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.6. RF EXPOSURE REQUIREMENTS [§§ 1.1310 & 2.1091] 6.6.1. Limits FCC 1.1310:- The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). 6.6.2. Method of Measurements Refer to FCC @ 1.1310 and 2.1091 • In order to demonstrate compliance with MPE requirements (see Section 2.1091), the following information is typically needed: (1) Calculation that estimates the minimum separation distance (20 cm or more) between an antenna and persons required to satisfy power density limits defined for free space. (2) Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement. (3) Any caution statements and/or warning labels that are necessary in order to comply with the exposure limits. (4) Any other RF exposure related issues that may affect MPE compliance. FCC Parts 2, 22 & 90 Page 10 People Tracker, Models PTSPLUS-05 and PTSBASIC-05 FCC ID: UBEPTSPLUS ULTRATECH GROUP OF LABS File #: SDI-005F2290 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 20, 2006 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Calculation Method of RF Safety Distance : S = PG/4Πr 2 =EIRP/4Πr 2 Where: P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm r = PG/4ΠS • For portable transmitters (see Section 2.1093), or devices designed to operate next to a person’s body, compliance is determined with respect to the SAR limit (define in the body tissues) for near-field exposure conditions. If the maximum average output power, operating condition configurations and exposure conditions are comparable to those of existing cellular and PCS phones, SAR evaluation may be required in order to determine if such a device complies with SAR limit. When SAR evaluation data is not available, and the additional supporting information cannot assure compliance, the Commission may request that an SAR evaluation be performed, as provided for in Section 1.1307(d). 6.6.3. Test Data Evaluation of RF Exposure Compliance Requirements RF Exposure Requirements Compliance with FCC Rules Minimum calculated separation distance between antenna and persons required: 33 cm Manufacturer’ instruction for separation distance between antenna and persons required: 33 cm Antenna installation and device operating instructions for installers (professional/unskilled users), and the parties responsible for ensuring compliance with the RF exposure requirement Please refer to User’s Manual for details. Caution statements and/or warning labels that are necessary in order to comply with the exposure limits Refer to User’s Manual for RF Exposure Information. Any other RF exposure related issues that may affect MPE compliance None. Remarks: (1) The calculation is based on the lowest frequency (450 MHz) and the highest conducted power (36.94 dBm) for the worst case. (2) The minimum separation distance between the antenna and bodies of users are calculated using the following equation: RF EXPOSURE DISTANCE LIMITS: r = (PG/4ΠS) 1/2 = (EIRP/4ΠS) 1/2 EIRP = 39.09 dBm = 10 (39.09/10) mW = 8110 mw = 4055 mW (at 50% duty cycle) S = f/1500 = 450/1500 mW/cm 2 (General Population/ Uncontrolled Exposure) r = (EIRP/4ПS) 1/2 = 4055 / (4П(450/1500)) 1/2 = 33 cm

People Tracker Model No.: PTSPLUS-05 and PTSBASIC-05 FCC ID: UBEPTSPLUS Applicant: SilverCom Distribution Inc 3164 Pepper Mill Court Unit #7 Mississauga, Ontario Canada L7L 4X4 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR Parts 2, 22 and 90 UltraTech's File No.: SDI-005F2290 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: November 20, 2006 Report Prepared by: Mr. Dan Huynh Issued Date: November 20, 2006 Tested by: Mr. Hung Trinh Test Dates: May 24, 2006 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R FCC Parts 2, 22 & 90 Contents i People Tracker, Model PTSPLUS-05 AND PTSBASIC-05 FCC ID: UBEPTSPLUS ULTRATECH GROUP OF LABS File #: SDI-005F2290 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 November 20, 2006 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST ..........................................................................................................................................1 EXHIBIT 2. INTRODUCTION ............................................................................................................................................................2 2.1. SCOPE ............................................................................................................................................................................................2 2.2. RELATED SUBMITTAL(S)/GRANT(S).......................................................................................................................................2 2.3. NORMATIVE REFERENCES .......................................................................................................................................................2 EXHIBIT 3. PERFORMANCE ASSESSMENT .................................................................................................................................3 3.1. CLIENT INFORMATION ..............................................................................................................................................................3 3.2. EQUIPMENT UNDER TEST (EUT) INFORMATION.................................................................................................................3 3.3. EUT’S TECHNICAL SPECIFICATIONS......................................................................................................................................4 3.4. LIST OF EUT’S PORTS.................................................................................................................................................................4 EXHIBIT 4. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS...................................................5 4.1. CLIMATE TEST CONDITIONS ...................................................................................................................................................5 4.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS.................................................................5 EXHIBIT 5. SUMMARY OF TEST RESULTS..................................................................................................................................6 5.1. LOCATION OF TESTS..................................................................................................................................................................6 5.2. APPLICABILITY & SUMMARY OF EMISSION TEST RESULTS............................................................................................6 5.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES............................................................6 5.4. DEVIATION OF STANDARD TEST PROCEDURES .................................................................................................................6 EXHIBIT 6. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ..................................................7 6.1. TEST PROCEDURES ....................................................................................................................................................................7 6.2. MEASUREMENT UNCERTAINTIES ..........................................................................................................................................7 6.3. MEASUREMENT EQUIPMENT USED .......................................................................................................................................7 6.4. ESSENTIAL/PRIMARY FUNCTIONS AS DECLARED BY THE MANUFACTURER ............................................................7 6.5. RF POWER OUTPUT [§§ 2.1046 & 90.205] ...................................................................................... ...........................................8 6.6. RF EXPOSURE REQUIREMENTS [§§ 1.1310 & 2.1091]............................................................................................................9 6.7. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§ 90.210] .................................................................... 11 EXHIBIT 7. MEASUREMENT UNCERTAINTY............................................................................................................................ 14 7.1. RADIATED EMISSION MEASUREMENT UNCERTAINTY.......…

Text truncated - open the document above for the full version.

APPLICANT: TECNET GLOBAL CORPORATION FCC ID: PT9SDU-2000 REPORT #: T:\T\TECNET\665ZAU1\665ZAU1TestReport.doc TABLE OF CONTENTS TABLE OF CONTENTS LIST FOR PART 90 VHF DEVICE APPLICANT: TECNET GLOBAL CORPORATION FCC ID: PT9SDU-2000 TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......MPE CALCULATION AND TECHNICAL DESCRIPTION PAGE 3......RF POWER OUTPUT, MOD CHARACTERISTICS PAGE 4......AUDIO FREQUENCY RESPONSE PLOT PAGE 5......MODULATION LIMITING – 300 Hz PAGE 6......MODULATION LIMITING – 12.5kHz – 1000 Hz PAGE 7......MODULATION LIMITING – 12.5kHz – 3000 Hz PAGE 8......OCCUPIED BANDWIDTH PAGE 9......OCCUPIED BANDWIDTH CONTINUED PAGE 10.....OCCUPIED BANDWIDTH PLOT – CW – 12.5 kHz – CHANNEL B PAGE 11.....OCCUPIED BANDWIDTH PLOT – CW – 25 kHz – CHANNEL A PAGE 12.....OCCUPIED BANDWIDTH PLOT – 9600 BAUD/825Hz – CH B PAGE 13.....OCCUPIED BANDWIDTH PLOT – 9600 BAUD/825Hz – 25kHz – CH A PAGE 14.....SPURIOUS EMISSIONS AT ANTENNA TERMINALS PAGE 15.....FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 16.....METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 17.....FREQUENCY STABILITY PAGE 18-19..TRANSIENT FREQUENCY STABILITY PAGE 20.....TRANSIENT FREQUENCY RESPONSE – 12.5kHz DEVIATION-1 PAGE 21.....TRANSIENT FREQUENCY RESPONSE – 12.5kHz DEVIATION-2 PAGE 22.....TRANSIENT FREQUENCY RESPONSE – 25kHz DEVIATION-1 PAGE 23.....TRANSIENT FREQUENCY RESPONSE – 25kHz DEVIATION-2 PAGE 24.....LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1A........FCC ID LABEL SAMPLE EXHIBIT 1B........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 2A........EXTERNAL PHOTO – FRONT VIEW EXHIBIT 2B........EXTERNAL PHOTO – REAR VIEW EXHIBIT 2C........EXTERNAL PHOTO – SIDE VIEW EXHIBIT 2D........EXTERNAL PHOTO – TOP VIEW EXHIBIT 2E........INTERNAL PHOTO – COMPONENT VIEW EXHIBIT 2F........INTERNAL PHOTO – COPPER VIEW EXHIBIT 3.........USER’S MANUAL EXHIBIT 4.........THEORY OF OPERATION EXHIBIT 5.........TUNING PROCEDURES AND PROGRAMMING EXHIBIT 6.........BLOCK DIAGRAM EXHIBIT 7.........SCHEMATIC EXHIBIT 8.........TEST SET UP PHOTO APPLICANT: TECNET GLOBAL CORPORATION FCC ID: PT9SDU-2000 REPORT #: T:\T\TECNET\665ZAU1\665ZAU1TestReport.doc Page 1 of 24 GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033 TECNET GLOBAL CORPORATION will sell the (c)(1)(2) FCC ID: PT9SDU-2000 UHF transceiver in quantity, for use under FCC RULES PART 22 & 90. 2.1033 (c) TECHNICAL DESCRIPTION 2.1033 (3) User Manual See Exhibit 3 MODELS SDU-2000 AND TNET-44 SHARE THE SAME USERS MANUAL 2.1033 (4) Type of Emission: 20K0F2D For 25 kHz 10K0F2D For 12.5 kHz For 25 kHz Bn = 2M + 2DK M = 19,200Bits per second D = 0.4 kHz (Peak Deviation) K = 1 Bn = 2(19,200/2) + 2(10.4k)(1) = 19.2k + 0.8k = 20.0K ALLOWED AUTHORIZED BANDWIDTH = 20.00 kHz. For 12.5 kHz Bn = 2M +2DK M = 9600Bits per second D = 0.825 kHz (Peak Deviation) K = 1 Bn = 2(9.6/2) K + 2(0.825k)(1) = 9.6k = 1.65k = 11.25 k ALLOWED AUTHORIZED BANDWIDTH = 11.25 kHz. 90.209(b)(5) 2.1033 (5) Frequency Range: 450-470 MHz (6) Power Range and Controls:There are NO user Power controls. (7) Maximum Output Power Rating: 4.5 Watts , into a 50 ohm resistive load. (8) DC Voltages and Current into Final Amplifier: POWER INPUT FINAL AMPLIFIER ONLY Vce = 13.6 Volts IC = 1.2A Pin = 16.3 Watts Efficiency = 27.6% APPLICANT: TECNET GLOBAL CORPORATION FCC ID: PT9SDU-2000 REPORT #: T:\T\TECNET\665ZAU1\665ZAU1TestReport.doc Page 2 of 24 2.1093 RF exposure is intended to be handled during licensing by the responsible FCC bureau(s).The transmitter is intended to operate with a 10% duty cycle. An example MPE calculation is based on continuou…
