XPDA‐S PCI Operational Description Product: PANDORA Model Name: XPDA‐S PCI XPDA‐S PCI is a secure all‐in‐one mobile computer that satisfies PCI PED security standard and EMV. Based on Windows CE.net 5.0, XPDA‐S PCI has integrated printer, barcode scanner, and secure PIN‐PAD with smart card reader and magnetic stripe reader. Comple x business a pplications that need to collect data and perform real‐ time communication is easy and fast with XPDA‐S PCI. In addition, PCI PED certified PIN PAD will allow you process credit card securely and effortlessly. As, printer, barcode scanner, GSM and PIN PADs are all integrated in to a single devic e, there is no ne ed to purchase additional accessories or device to handle printing or payment. Wireless LAN 1. XPDA‐S PCI use DDCBW‐NMx1A WLAN + Bluetooth Combo module by Device Design that is a the compact size and low power system‐in‐Package (SiP) complying with the IEEE 802.11b/g/n standard compliant. It uses Broadcom 4329 chipset and supports standard interfaces SDIO v1.2 (50 Mhz, 4 bit and 1 bit), SPI (4 8 Mhz) and high‐ speed UART. 2. DDCBW‐NMx1A supports various security setups in the followings. ‐ WPA and WPA2 ‐ AES and TKIP for faster data encryption and 802.11i compatibility ‐ WLAN subsystem provides WPS (WiFi Protected Setup) 3. DDCBW‐NMx1A is designed to be connected to CPUs ba sed on ARM11. 4. Elec tronic Information ‐ Operating voltage is 3.3V and regulated 1.8V ‐ Operating Frequency Range: 2412 ~ 24 62 MHz (11 channels) ‐ Mod ulation mode: DSSS for 802.1 1b, CFDM for 802.11g, OFDM for 802.11n(20) Bluetooth 1. XPDA‐S PCI use DDCBW‐NMx1A WLAN + Bluetooth Combo module by Device Design that is a the compact size and low power system‐in‐Package (SiP) complying with the Bluetooth 2.1 + EDR specifications. 2. DDCBW‐NMx1A is designed to be connected to the CPU based on ARM11. 3. Ele ctronic Information ‐ Operating voltage is 3.3V. ‐ Operating Frequency Range: 2402 MHz ~ 2480 MHz ‐ Modulation mode: TDD Modem 1. XPDA‐S PCI use MU509 HSDPA Module which supports both GSM and WCDMA . 2. MU 509 is designed to be connected to the mobile products which have CPUs based on ARM11. 3. Electronic Information ‐ Operating voltage range is 3.3 to 4.2V (3.8 is recommended) ‐ Frequency: WCD MA Dual band 850/1900 Mh z, GSM/GPRS/EDGE 850/900/1800/1900 Mhz
