Meraki MR72 Hardware Installation Guide Trademarks Cisco, Cisco Meraki, Meraki, Meraki MR72, and Meraki Cloud Controller are trademarks of Cisco Systems, Inc. Other brand and product names are registered trademarks or trademarks of their respective holders. Warranty Cisco Systems, Inc. provides a one year warranty on this product. Warranty details may be found at www.meraki.cisco.com/support. Table of Contents . 1 Scope of Document and Related Publications . 2 MR72 Overview . 3 Pre-Install Preparation . 4 Installation Instructions . 5 Troubleshooting . 6 Regulatory 1 Scope of Document and Related Publications The MR72 Hardware Installation Guide describes the installation procedure for the MR72 access point. Additional reference documents are available online at meraki.cisco.com/support 2 MR72 Overview The Meraki MR72 is an enterprise-class, 802.11abgn/ac outdoor access point designed for rugged environments. When connected to the Meraki Cloud Controller, the MR72 enables the creation of high- speed and reliable networks that cover large outdoor and industrial areas quickly, easily, and cost-effectively. The Meraki MR72 has an operating temperature of -40 o to 60 o C. 2.1 Package Contents The MR72 package contains the following: - MR72 access point - Wall screws & anchors - Mounting plate - Cable gland - Mounting straps 2.2 Antennas and Ports The Meraki MR72 has two radios. Each radio has two external antenna connectors; both connectors for a particular radio should be attached to the same type of antenna. The 5 GHz radio is used for mesh or client communication. The 2.4 GHz radio is primarily used for client communication. However, it can also communicate with Meraki 2.4 GHz access points. Meraki offers a number of different antennas for use with the MR72: MA-ANT-20, MA-ANT-21, MA-ANT-23, and MA-ANT-25. The Meraki MA-ANT-20 omni-directional antennas must be installed vertically. The Meraki MA-ANT-25 patch antenna must be installed facing downward, at least 30 degrees from the horizon line. 2.3 Power Source Options The MR72 access point can be powered using either an 802.3at capable PoE switch or the Meraki 802.3at PoE injector (sold separately). 2.4 LED Indicators and Run Dark Mode Your MR72 uses a single LED to inform the user of the device’s status. Function LED Status Meaning Power Up/ Boot Solid Orange Power is applied Connecting Rainbow Device in process of connecting to the Meraki Dashboard Connected Solid White Fully operational Upgrading Flashing White During boot or no WAN link The MR72 may be operated in “Run Dark” mode for additional security and to reduce the visibility of the access point. In this mode, the LED will not be illuminated. This mode may be enabled through Meraki Dashboard. 3 Pre-Install Preparation You should complete the following steps before going on-site to perform an installation. 3.1 Configure Your Network in Dashboard Meraki recommends that you add your MR72 to a network in Dashboard before mounting it in the field. The following is a brief overview only of the steps required to add an MR72 to your network. For detailed instructions about creating, configuring and managing Meraki wireless networks, refer to the Meraki Cloud Controller Manual (cisco.meraki.com/support/#documentation). 1. Login to http://dashboard.meraki.com. If this is your first time, create a new account. 2. Find the network to which you plan to add your nodes or create a new network. 3. Add your nodes to your network. You will need your Meraki order number (found on your invoice if you ordered directly from Meraki) or the serial number of each node, which looks like Qxxx-xxxx-xxxx, and is found on the bottom of the unit. 4. Finally, go to the map / floor plan view and place each node on the map by clicking and dragging it to the location where you plan to mount it. You can always modify the location later. 3.2 Check and Upgrade Firmware To ensure your MR72 performs optimally immediately following installation, Meraki recommends that you facilitate a firmware upgrade prior to mounting your MR72. 1. Attach your MR72 to power and a wired Internet connection. 2. The MR72 will turn on and the LED will glow solid orange. If the unit does not require a firmware upgrade, the LED will turn solid white within 30 seconds. * If the unit requires an upgrade, the LED will cycle rainbow until the upgrade is complete, at which point the Power LED will turn solid white. You should allow about an hour for the firmware upgrade to complete, depending on the speed of your internet connection. 3.3 Check and Configure Firewall Settings If your network will be located behind a firewall, it must allow outgoing connections on particular ports to particular IP addresses in order for the MR72 to be able to seamlessly communicate with the Cloud Controller. The most current list of outbound ports and IP addresses can be found here: http://bit.ly/oZpMQ7 3.4 Assigning IP Addresses to MR72s All gateway MR72s (MR72s with Ethernet connections to the LAN) must be assigned routable IP addresses. These IP addresses can be dynamically assigned via DHCP or statically assigned. 3.4.1 Dynamic Assignment When using DHCP, the DHCP server should be configured to assign a static IP address for each MAC address belonging to a Meraki AP. Other features of the wireless network, such as 802.1X authentication, may rely on theproperty that the APs have static IP addresses. 3.4.2 Static Assignment Static IPs are assigned using the local web server on each AP. The following procedure describes how to set the static IP: 1. Using a client machine (e.g., a laptop), connect to the AP either wirelessly (by associating to any SSID broadcast by the AP) or over a wired connection. If using a wired connection, connect the client machine to the MR72 either through a PoE switch or a Meraki PoE Injector. If using a PoE switch, plug an Ethernet cable into the MR72’s Ethernet jack, and the other end into a PoE switch. Then connect the client machine ov…

Text truncated - open the document above for the full version.

!!!!!!Cisco Systems, Inc. 170 West Tasman Drive, San Jose, CA 95134 USA !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! Date: 27 December 2014 Letter of Attestation for Power Conformity Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 We, Cisco Systems, Inc., declare that this equipment (FCC ID: UDX-60033010) has channel selection/operation algorithms to comply with FCC rules when radio 1 and radio 3 transmit simultaneously in 2.4GHz mode, and when radio 2 and radio 3 transmit simultaneously in 5GHz mode. The Meraki MR72 (MR72-HW) wireless access point firmware will take the following actions to ensure RF compliance within FCC regulations: (a) Rely on an algorithm coded in our firmware to avoid concurrent same-channel transmission of radio 1 and radio 3, and radio 2 and radio 3. (b) Rely on an algorithm coded in our firmware to eliminate servicing 802.11 clients on the radio 3. Thus there will be no broadcasting of SSID or timer-based beacon frames. This will preclude the need for action (a) described above in all known operational cases. (c) Power reduction settings are not customer adjustable. Tools exist for customer configuration via Meraki Dashboard to reduce the power beyond the required reduction. Please see other attestation/filing documents related to SDR and radio configuration control/country setting for more information. Radio 3’s primary function is as a scanning radio. It has rare to occasional transmissions. Meraki Access Point firmware is optimized by design to eliminate simultaneous same-band transmission, as it would be detrimental to radio 2 function. Sincerely, Benjamin Calderon Vice President, Operations and Hardware Cisco Systems, Inc. Tel: +1 415-432-1000 Fax: +1 415 632-5899 [email protected]

!!!!!!Cisco Systems, Inc. 170 West Tasman Drive, San Jose, CA 95134 USA !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! Date: 27 December 2014 Letter of Attestation Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: UDX-60033010 We, Cisco Systems, Inc., declare the Meraki MR72 (MR72-HW) wireless access point complies within the following FCC regulations: 1) Part 15.15 2) Part 15.27 3) Part 15.203 and Part 15.204 for the antennas Sincerely, Benjamin Calderon Vice President, Operations and Hardware Cisco Systems, Inc. Tel: +1 415-432-1000 Fax: +1 415 632-5899 [email protected]

!!!!!!Cisco Systems, Inc. 170 West Tasman Drive, San Jose, CA 95134 USA !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! Date: 27 December 2014 Request For Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: UDX-60033010 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation SDR File Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 45 days. !!!!!!Cisco Systems, Inc. 170 West Tasman Drive, San Jose, CA 95134 USA !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Benjamin Calderon Vice President, Operations and Hardware Cisco Systems, Inc. Tel: +1 415-432-1000 Fax: +1 415 632-5899 [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT EUT with Dipole antenna Page 2 EUT with Patch antenna Page 3 EUT with sector antenna Page 4

Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Dipole Antenna Page 14 Patch Antenna Page 15 Sector Antenna

Gluhwein Build-in Antenna Test Report By GTT RF Design Center @ 2014-09-04 1. Antenna Definition and Scanning Orientation P.2 2. Antenna Performance Summary BT Antenna P.3 Efficiency, Average Gain, Peak GainVSWRRadiation Pattern P.4 3. Antenna Performance Summary DB Scanning Antenna P.5 Efficiency, Average Gain, Peak Gain VSWR Radiation Pattern P.6 4. Isolation between antenna P.7 All rights reserved by GTT under NDA agreements 1 2014/9/04 Antenna Definition and Scanning Orientation All rights reserved by GTT under NDA agreements 2 2014/9/04 BT Antenna DB Antenna Antenna Performance Summary-BT Antenna All rights reserved by GTT under NDA agreements 3 2014/9/04 Cisco P/N: 460-33070 Frequency (MHz) 3D Efficiency Avg. Gain Peak Gain 2400 61% -2.1 3.4 2450 71% -1.5 4.1 2500 68% -1.7 4.2 All rights reserved by GTT under NDA agreements 4 Radiation Pattern XY-plane YZ-plane ZX-plane 2014/9/04 Antenna Performance Summary-DB Scanning Antenna All rights reserved by GTT under NDA agreements 5 2014/9/04 Cisco P/N: 460-33060 Frequency (MHz) 3D Efficiency Avg. Gain Peak Gain 2400 75% -1.3 5.4 2450 73% -1.4 5.7 2500 69% -1.6 4.7 4900 70% -1.5 6.0 5150 69% -1.6 6.1 5350 69% -1.6 5.7 5475 73% -1.4 6.2 5725 67% -1.7 5.8 5875 64% -1.9 6.5 All rights reserved by GTT under NDA agreements 6 Radiation Pattern XY-plane YZ-plane ZX-plane 2014/9/04 2013/9/4 All rights reserved by GTT under NDA agreements 7 Isolation Specification: Isolation >20dB  Pass

Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / 2.4GHz 11dBi Outdoor Directional Antenna P/N: ANT-23 RF Specification • Frequency Range: 2.4~2.5GHz • Polarization: Linear, Vertical / Horizontal • HPBW / Horizontal: 70 ∘ • HPBW / Vertical: 30 ∘ • Peak Gain: 11dBi • VSWR:2.0max:1 • Isolation:>15 dB • Power Handing: 2W(cw) • Impedance: 50 Ohms • Cable Length:40cm • Connector:N-Plug Environmental & Mechanical Characteristics • Temperature: -40 °C to +70 °C • Humidity: 95% @55 °C • Radome Material: PC, UV Resistance • Dimensions: 233mm(L) x 140mm(W) x 40mm(T) • Weight: 672g Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Performance Summary RADIATION PATTERN PORT#1 RADIATION PATTERN PORT#2 -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 V-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz V-plane Cross-polar. Pattern -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 V-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Cross-polar. Pattern Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz V-plane Cross-polar. Pattern -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Cross-polar. Pattern Magnitude (dB) Angle (degree) 2400 MHz 2450 MHz 2500 MHz

Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / 5GHz 13dBi Outdoor Directional Antenna P/N: ANT-21 RF Specification • Frequency Range: 5.15~5.875GHz • Polarization: Linear, Vertical / Horizontal • HPBW / Horizontal: 80 ∘ • HPBW / Vertical: 17 ∘ • Peak Gain: 13 dBi • VSWR:2.0max:1 • Isolation:>20 dB • Power Handing: 2W(cw) • Impedance: 50 Ohms • Cable Length:40cm • Connector:N-Plug Environmental & Mechanical Characteristics • Temperature: -40 °C to +70 °C • Humidity: 95% @55 °C • Radome Material: PC, UV Resistance • Dimensions: 233mm(L) x 140mm(W) x 40mm(T) • Weight: 672g Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Performance Summary RADIATION PATTERN PORT#1 RADIATION PATTERN PORT#2 -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 V-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz V-plane Cross-polar. Pattern -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz V-plane Cross-polar. Pattern -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 V-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Cross-polar. Pattern Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Co-polar. Pattern Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz -180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180 -20 -15 -10 -5 0 5 10 15 20 H-plane Cross-polar. Pattern Magnitude (dB) Angle (degree) 4900 MHz 5150 MHz 5350 MHz 5600 MHz 5725 MHz 5875 MHz

Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / 2.4GHz/5GHz Dual Band Outdoor Omni Antenna P/N: ANT-20 RF Specification • Frequency Range: 2.4~2.5GHz / 5.15~5.875GHz • Polarization: Linear, Vertical • HPBW / Horizontal: 360 • HPBW / Vertical: 45 ∘ • Peak Gain: 4dBi @2.4GHz / 7dBi @5GHz • VSWR: 2.0max:1 • Power Handing: 2W(cw) • Impedance: 50 Ohms • Connector:N-Plug Environmental & Mechanical Characteristics • Temperature: -40 °C to +70 °C • Humidity: 95% @55 °C • Radome Material: PC, UV Resistance • Dimensions: 25mm(D) x 180mm(L) • Weight: 79g Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Performance Summary 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 24002500515054755875 EFFICIENCY(%) EFFICIENCY ‐5.0 ‐4.0 ‐3.0 ‐2.0 ‐1.0 0.0 1.0 24002500515054755875 AVERAGE GAIN(dBi) AVERAGE GAIN RADIATION PAT TERN 2.4GHz XY‐planeYZ‐planeZX‐plane RADIATION PAT TERN 5GHz

Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / 2.4GHz /5GH Outdoor Dual Band Antenna P/N: ANT-25 RF Specification • Frequency Range: 2.4~2.5GHz / 5.15~5.875GHz • Polarization: Linear, Vertical / Horizontal • HPBW / Horizontal: 60 ∘ / 75 ∘ • HPBW / Vertical: 70 ∘ / 84 ∘ • Peak Gain: 8dBi / 6.5dBi • VSWR:2.0max:1 • Isolation:>15 dB • Power Handing: 2W(cw) • Impedance: 50 Ohms • Cable Length:40cm • Connector:N-Plug Environmental & Mechanical Characteristics • Temperature: -40 °C to +70 °C • Humidity: 95% @55 °C • Radome Material: PC, UV Resistance • Dimensions: 180mm(L) x 180mm(W) x 47mm(T) • Weight: 630g Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Performance Summary V‐Polarization Performance Summary Frequency (MHz) 3D HPBW Efficiency Avg. Gain Peak Gain H-planeV-plane 240077%-1.18.15569 245075%-1.27.95771 250071%-1.57.65771 515071%-1.56.27982 535070%-1.66.57584 547569%-1.66.67286 572564%-1.96.37287 587563%-2.07.15676 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 24002500515054755875 EFFICIENCY(%) V‐Pol ‐5.0 ‐4.0 ‐3.0 ‐2.0 ‐1.0 0.0 1.0 24002500515054755875 AVERAGE GAIN(dBi) V‐Pol 0.0 2.0 4.0 6.0 8.0 10.0 24002500515054755875 PEAK GAIN(dBi) V‐Pol EFFICIENCYAVERAGE GAIN PEAK GAIN Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Radiation Pattern V‐Pol H‐PlaneV‐Plane Co‐Polar Pattern X‐Polar Pattern Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Performance Summary H‐Polarization Performance Summary EFFICIENCY AVERAGE GAIN PEAK GAIN Frequency (MHz) 3D HPBW Efficiency Avg. Gain Peak GainH-planeV-plane 240077%-1.28.16068 245071%-1.57.96068 250061%-2.27.35968 515072%-1.45.810168 535068%-1.75.99665 547570%-1.56.69159 572568%-1.66.19460 587562%-2.06.09656 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 2400 2500 5150 5475 5875 EFFICIENCY(%) H‐Pol ‐5.0 ‐4.0 ‐3.0 ‐2.0 ‐1.0 0.0 1.0 24002500515054755875 AVERAGE GAIN(dBi) H‐Pol 0.0 2.0 4.0 6.0 8.0 10.0 2400 2500 5150 5475 5875 PEAK GAIN(dBi) H‐Pol Tel : +886-2-29177353 / http://www.grand-tek.com/ [email protected] / Radiation Pattern H‐Pol H‐PlaneV‐Plane Co‐Polar Pattern X‐Polar Pattern

Report No.: SA141029C03 1 of 8 Report Format Version 5.0.1 RF EXPOSURE REPORT REPORT NO.: SA141029C03 MODEL NO.: MR72-HW FCC ID: UDX-60033010 RECEIVED: Oct. 07, 2014 TESTED: Oct. 07 ~ Dec. 10, 2014 ISSUED: Dec. 22, 2014 APPLICANT: Cisco Systems, Inc. ADDRESS: 170 West Tasman Drive, San Jose, CA 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-com pliance to the specification. Report No.: SA141029C03 2 of 8 Report Format Version 5.0.1 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE ....................................................................................................... 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ................................. 5 2.2 MPE CALCULATION FORMULA ............................................................................. 5 2.3 CLASSIFICATION .................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .......................... 6 Report No.: SA141029C03 3 of 8 Report Format Version 5.0.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA141029C03 Original release Dec. 22, 2014 Report No.: SA141029C03 4 of 8 Report Format Version 5.0.1 1. CERTIFICATION PRODUCT: 802.11 abgn/ac device MODEL NO.: MR72-HW BRAND: Cisco APPLICANT: Cisco Systems, Inc. TESTED: Oct. 07 ~ Dec. 10, 2014 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment (model: MR72-HW) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Dec. 22, 2014 Pettie Chen / Senior Specialist APPROVED BY : , DATE :Dec. 22, 2014 Ken Liu / Senior Manager Report No.: SA141029C03 5 of 8 Report Format Version 5.0.1 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 22cm away or farther depends on the antenna type used as evaluated in following section. So, this device is classified as Mobile Device. Report No.: SA141029C03 6 of 8 Report Format Version 5.0.1 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For Dipole antenna (Radio 1 & 2) + PIFA antenna (Radio 3 & 4): RADIO ANTENNA FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 1 Dipole 2412-2462 27.97 7.01 22 0.518 1 2 Dipole 5180-5240 21.59 10.01 22 0.238 1 5745-5825 22.31 10.01 22 0.281 1 3 PIFA 2412-2462 19.64 5.7 22 0.056 1 5180-5240 13.98 6.5 22 0.018 1 5745-5825 21.62 6.5 22 0.107 1 4 PIFA 2402-2480 2.54 4.2 22 0.0008 1 NOTE: 1. Radio 1: Dipole antenna: Directional gain = 4dBi + 10log(2) = 7.01dBi 2. Radio 2: Dipole antenna: Directional gain = 7dBi + 10log(2) = 10.01dBi *Antenna gains were calculated for coherent signals per KDB 662911 D01 FREQUENCY BAND MAX POWER (dBm) TOTAL POWER (dBm) POWER LIMIT (dBm) RADIO 1 RADIO 2 RADIO 3 RADIO 4 2.4GHz 27.97 - 19.64 2.54 28.58 30 5180-5240MHz - 21.59 13.98 - 22.28 30 5745-5825MHz - 22.31 21.62 - 24.99 30 CONCLUSION: The formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Radio 1 + Radio 2 + Radio 3 (2.4G) + Radio 3 (5GHz) + Radio 4 = 0.518 + 0.281 + 0.056 + 0.107 + 0.0008 = 0.962 Therefore the maximum calculations of above situations are less than the “1” limit. Report No.: SA141029C03 7 of 8 Report Format Version 5.0.1 For Patch antenna (Radio 1 & 2) + PIFA antenn…
