UEF92443417171275PLAY-IT online controller Model: 888

Play-It, Incorporated Website: www.Play-it.com User Guide Congratulations on your purchase of the PLAY-iT online controller model # 888. Please read this User Guide carefully for using our products properly. Keep this User Guide for your reference when necessary. For avoiding any damage or danger, please follow the instruction of this guide. To install your PLAY-iT online controller, plug the smaller unit into any open USB port on your computer and install three size AA batteries in the battery box on the back of the controller. We recommend alkaline batteries for best results. Do not mix old and new batteries or mismatched batteries. Your PLAY-iT online controller has four big buttons, RED, YELLOW, GREEN and BLUE on the front. The four big buttons are used to respond to options offered on-screen during PLAY-iT interactive programs. The two smaller RED buttons at the Top-Left and Top-Right are Application Specific; they control different functions depending on the program you're watching. Press any button to wake up the PLAY-iT online controller. Your online controller wakes up with the sound effects ON but you can turn them OFF or back ON by pressing and holding the RED and BLUE buttons at the same time for 8 seconds. The Console has no POWER switch because it shuts itself down if no buttons are pushed for several seconds. It wakes up again when any button is pressed. With your computer turned on and connected to the Internet go to the www. play-it.com web-site and follow the on-screen directions to register and become a part of the PLAY-iT family. Warranty 1. Play-It, Inc. warrants its products to be free of any defects in materials or workmanship for one year from the date of purchase. 2. The following situations would be charged even under the Period of warranty: • Improper Operation or repairing or other reasons after purchasing. • Damage caused by using incorrect voltage or connection. • User cannot provide prove of the warranty period. FCC Rules and Regulations NOTICE: To comply with FCC and Industry Canada (IC) rules, adjustments or modifications of this receiver and/or transmitter are prohibited except for the changing of batteries. Any unauthorized modification may void users authority to operate this device. THERE ARE NO OTHER USER SERVICABLE PARTS. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a RESIDENTIAL OR OFFICE installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ⎯ Reorient or relocate the receiving antenna. ⎯ Increase the separation between the equipment and receiver. ⎯ Connect the device into an outlet on a circuit different from that to which the receiver is connected. ⎯ Consult the dealer or an experienced radio/TV technician for help. Play-It, Inc., 162 Rhode Island Avenue, Newport, RI 02840, USA. PLAY-iT is a registered trademark of Play-It, Inc.

PCB ANTENNA 315MHz OSCILLATOR Q1 , SAW U1 ENCODER AND MCU DATA RF POWER ON/OFF Q2,Q6 SPEAKER Q11 DC POWER SUPPLY 4.5V CONTROL KEYS S1,S2,S3,S4,S5,S6 A (RED LIGHT) B (YELLOW LIGHT) C (GREEN LIGHT) D (BLUE LIGHT) E/F (RED LED) Y1 3.58MHz PLAY-IT INCORPORATED 888 PLAY-IT ONLINE CONTROLLER 315MHz TX BLOCK DIAGRAM LIGHT INDICATION Q3,Q4,Q7,Q8,Q9,Q10 D1,D2,D3,D4,D5,D6

DOC-FCC009 4/14/2005 Page 1 of 2 FEDERAL COMMUNICATIONS COMMISSION - FCC FORM 731 APPLICATION FOR EQUIPMENT AUTHORIZATION Approved by OMB 3060 - 0934 Expires 02/28/2005 Item 1. Applicant's complete, legal business name: Play-It Incorporated Item 2. Applicant's mailing address Line 1: 162 Rhode Island Avenue, Line 2: P.O.Box: City: Newport State: Country (if foreign address): United States Zip/Postal Code: RI 02840 Item 3. FCC ID: Grantee code: UEF Equipment Product Code (14 characters maximum): 92443417171275 Item 4. Person at the applicant's address to receive grant or for contact: First Name: KC Mail Stop: Last Name: Lee Telephone: 852 26661807 Ext: Title: Manager E-mail: [email protected] Fax No: Item 5. Instead of Applicant, the original Grant is authorized to be mailed to: The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Tai Po Industrial Estate, N.T., Hong Kong. Contact: KC Lee E-mail: [email protected] Item 6. Technical Contact: Firm Name: The Hong Kong Standards and Testing Centre Ltd. Telephone: 852 26661807 Ext: Fax No: 852 2665 0848 First Name: KC Middle Initial: Last Name: Lee Address Line 1: 10 Dai Wang Street, P.O.Box: Address Line 2: Tai Po Industrial Estate City: Country (if foreign address):Hong Kong Zip/Postal Code: E-mail: [email protected] Item 7. Non-Technical Contact: Firm Name: The Hong Kong Standards and Testing Centre Ltd. Telephone: 852 26661807 Ext: Fax No: 852 2665 0848 First Name: KC Middle Initial: Last Name: Lee Address Line 1: 10 Dai Wang Street, P.O.Box: Address Line 2: Tai Po Industrial Estate City: Country (if foreign address):Hong Kong Zip/Postal Code: E-mail: [email protected] Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules? If "Yes" see instructions. (please mark as appropriate) x No Item 9. Does the applicant request that the Commission defer grant of this application pursuant 47 CFR § 0.457(d)(1)(ii)? (See instructions) If so, specify date when grant may be issued (MM/DD/YYYY format): Item 10. * Equipment Class: DSC * Description of Product as it is Marketed: Part 15 Security / Remote Control Transmitter (NOTE: PLAY-IT online controller) Item 11. * Application is for: (please mark as appropriate) x Original Equipment (See instructions) Ο Change in identification of presently authorized equipment: Original FCC ID: Grant Date (MM/DD/YYYY format): Ο Class II permissive change or modification of presently authorized equipment (See instructions) Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered "Yes" complete section 12(c). Ο Yes x No Ο Yes x No DOC-FCC009 4/14/2005 Page 2 of 2 (c) The related application: Ο has been granted under the FCC ID listed to the right Ο is in the process of being filed under the FCC ID listed to the right Ο is pending with the FCC under the FCC ID listed to the right FCC ID Item 13. Name of test firm and contact person on file with the FCC, if different from applicant or contact person: Firm Name: The Hong Kong Standards & Testing Centre Ltd. Last Name: KC Telephone 26661852 Ext Fax No. 26650848 E-mail: [email protected] Item 14. Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization. Read each certification carefully before answering and signing this application Equipment Specifications: Rule Part Frequency Range (MHz) Power (W) Frequency Tolerance and Units Emission Designator Note Codes 15 315 WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTITUTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503). Item 15. *SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? x Yes Ο No Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. IN accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. * Sig…

Text truncated - open the document above for the full version.

MET TCB SERVICE AGREEMENT DOCJ-TCB002 11/24/04 Page 1 of 3 THIS AGREEMENT is made at Baltimore, Maryland this day of , 20 , by and between MET LABORATORIES, INC. (hereinafter referred to as MET) and the following: Applicant: Play-It Incorporated (Hereinafter referred to as the "Responsible Party") Address: 162 Rhode Island Avenue, Newport, RI 02840, USA Manufacturer: Herald Metal & Plastic Works Ltd. (required for Part 68 only - (Hereinafter referred to as the "Manufacturer") Address: 1/F Pat Tat Ind. Bldg., 1, pat Tat St., Sanpokong, Kln., Hong Kong. Only the product(s) designed and engineered by the Applicant/Responsible Party and manufactured by the Manufacturer at the Manufacturer's facility at the above address, which have been certified by MET are covered by this service Agreement. NOW, THEREFORE, in consideration of the premises set forth in this agreement, the above mentioned parties agree that; Upon successful evaluation, MET will issue the Applicant/Responsible Party a Grant of Equipment Authorization Certificate, granting the Applicant/Responsible Party permission to market the certified product(s). At a minimum the product's identification plate or label will include the FCC ID Number or the Registration/Certification Number as well as any other information as might be required bystatute. The FCC requires that MET perform random post-certification surveillance. Surveillance for continued certification compliance can be accomplished by the Applicant/Responsible Party providing production models of the product to MET at MET’s request or to other locations as approved by MET for the purpose of compliance testing. The Manufacturer agrees to allow free and unrestricted access to the Manufacturer's facility during normal working hours for the purpose of permitting supervision. The Applicant/Responsible Party or Manufacturer agrees to provide and deliver to MET or locations approved by MET models of the certified product at MET’s request. All costs associated with testing of the device will be borne by the Applicant/Responsible Party or the Manufacturer and paid within 30 days of notice. If required the Applicant/Responsible Party agrees to provide to MET for MET review certain identified technical documents or quality documents that provide for a review of product update and compliance. Acceptable Markings are found in 47 CFR 2.925, 2.926, 15.19, and part 68.300. Only products visually bearing the appropriate FCC identification label and identified as to model and type will be acknowledged as being an authorized product. The Applicant/Responsible Party is responsible for applying the label to the product in accordance with current FCC requirements. An Applicant/Responsible Party is required to submit to MET a sample of the label or plate showing the FCC ID Number or the Registration/Certification Number for approval prior to applying to the product. The Applicant/Responsible Party is required to submit to MET a label location drawing or photograph showing the location of the mark on the product. Any reference to MET certification shall not be permitted on any non-eligible product(s), packaging, or literature. If the Applicant/Responsible Party or the Manufacturer applies the FCC identification label to unauthorized products, then the Applicant/Responsible Party and the Manufacturer shall save, indemnify, and hold harmless MET LABORATORIES, INC. from any and all claims which may arise out of said unauthorized action. The label and/or references to MET are permitted on promotional, advertising, and packaging of Certified Product(s) provided that misrepresentation of results of the marking process and/or this agreement do not occur. Final judgment in the suitability of use of the label or the MET Laboratories name is reserved by MET. (continued, next page) MET TCB SERVICE AGREEMENT DOCJ-TCB002 11/24/04 Page 2 of 3 The Applicant/Responsible Party shall maintain or require the manufacturer to maintain a record of all complaints made known to them relating to the product's compliance with the requirements of the relevant standard and agrees to make these records available to MET when requested. The Aplicant/Responsible Party agrees to take appropriate action, or have the manufacturer take appropriate action with respect of such complaints and/or any deficiencies found in products or services that affect compliance with the requirements for certification. Compliance with all requirements and stipulations of the Certification Program and this agreement between MET and the Applicant/Responsible Party is required for program compliance. Non-compliance with all or part of this agreement may result in termination of the agreement and the notification to the FCC to withdraw certification of the product. The Applicant/Responsible Party assumes responsibility for complying with the requirements of the product's certification and this agreement regarding the application of the FCC identification label. The Applicant/Responsible Party understands that any violation of the requirements of this agreement can immediately, at MET's discretion, terminate this agreement. Upon notification by MET, the Applicant/Responsible Party shall immediately take action to correct non-conformance that may have been found during surveillance or during modification to the product by the Applicant/Responsible Party. The Applicant/Responsible Party understands that corrective actions must be immediate. The Applicant/Responsible Party also understands that MET is required to report to the FCC any noted non-compliance. MET will also report corrective actions taken and the status of corrective action. The FCC will determine if any certificate or grants will be withdrawn. Upon termination of this agreement, the Applicant/Responsible Party agrees to remove any references to MET Laboratories from all literature, stationary, packaging, or other promotional media as may have been used by the Applicant/Responsible Party. Addition…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

label: 47mm x 14.5mm

label: 47mm x 14.5mm

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

Technical Description The transmitter is used for the remote control of a smaller unit plugged into the USB port, which is operated at 315MHz. The transmitter is powered by 3 x 1.5V battery. The four big buttons on the transmitter are used to respond to options offered on-screen during PLAY-iT interactive programs. The two smaller RED buttons at the Top-Left and Top-Right are Application Specific; they control different functions depending on the program you're watching. The brief circuit description is listed as below: - SAW resonator, Q1 and the associated circuit act as 315MHz Oscillator - U1 acts as Encoder and MCU - Q2, Q6 and the associated circuit act as RF ON/OFF Circuit - Q3, Q4, Q7, Q8, Q9, Q10 and the associated circuit act as Light Indication - Q11 and the associated circuit act as Audio Amplifier - S1, S2, S3, S4, S5 and S6 act as Control Keys

1 2 3 4 5 6 7 8 ABCD 8 7 6 5 4 3 2 1 D CBA Scale Sheet Size FCSM No. DWG No. Rev 1 of 1 A3 Play-It Incorporated INC. PLAY-iT online controller 6 #888T TITLE. Date: 2006 Jul 6 L210UH BT14.5V + C124.7UF D9 POWER_LED Q5 MMBT3906 R171k Q7 MMBT8550 Q8 MMBT8550 Q9 MMBT8550 Q10 MMBT8550 Q3 MMBT3906 Q4 MMBT3906 R51.8 R111k R121k R131k R141k R151k R161k R64.7 R76.8 R85.6 R91K R101K IP04 9 IP05 10 IP06 11 IP07 12 BP00 14 BP01 15 BP02 16 BP03 17 BP04 18 BP05 19 BP06 20 BP07 21 BP10 22 BP11 23 BP12 24 BP13 25 BP14 26 BP15 27 BP16 28 BP17 29 VDD 13 VDD0SC 4 DAC 7 OSCI 2 OSCO 3 /RESET 5 TEST 6 VSS 8 VSSOSC 1 2W567B010 S6-1S5-2S5-1S4-2S4-1S3-2 R2510 R2322K R27390 R1847 R330K R2100k R422K R1100 Q1 MMBT-H10 Q6MMBT3904 Q11MMBT8050 Q2 MMBT3906 Y13.58MHZ SPEAKER C80.1u C70.1uF C22P C13P C34P C4390P C5560P R213.3K R226.8K C90.1u VCC VCC 0 1 2 3 4 5 6 123456789100 10 9 vcc VCC TP1 TP2 TP3 TP4 TP5 TP6 TP7 POWER_LED POWER_LED RF_EN RF_EN DATA+ LED6 LED5 LED1 LED2 LED3 LED4 LED1LED2LED3LED4LED5LED6 TEST_PIN_IK DATA-DATA+ for testing only COB board R24470 mounted on test fixture TP8 TP9 S3-1S6-2 S2S1 1 2 3 315MHz SAW BLUEGREEN YELLOW RED FE C D A B D C B A E F PCB LOOP TP10 TP0 D8IN4001 D1 BLUE D2GREEN D3YELLOW D4RED D5RED LED D6RED LED C61UF L11UH PTC only use in EU market D73.9V R2610 R19 N.C R20 N.C C11 N.C C10 N.C address 0key delay time select use only in EU market 888315MHz TX schematic Note: NC=No Connection 315MHz U1

STC Test Report Date : 2006-07-18 Page 1 of 19 No. : HM156864 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant: Play-It Incorporated 162 Rhode Island Avenue, Newport, RI 02840, USA Description of Samples: Model name: PLAY-IT online controller Model no.: 888 Brand name: PLAY-IT FCC ID: UEF92443417171275 Date Samples Received: 2006-06-17 Date Tested: 2006-26 to 2006-07-15 Investigation Requested: FCC Part 15 Subpart C Conclusions: The submitted product was deemed to have COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- TSANG Chi Ho, Steven, EMD For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2006-07-18 Page 2 of 19 No. : HM156864 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 19 Content Page 2-3 of 19 1.0 General Details 1.1 Test Laboratory Page 4 of 19 1.2 Applicant Details Page 4 of 19 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 19 Description of EUT operation 1.4 Date of Order Page 5 of 19 1.5 Submitted Samples Page 5 of 19 1.6 Test Duration Page 5 of 19 1.7 Country of Origin Page 5 of 19 2.0 Technical Details 2.1 Investigations Requested Page 6 of 19 2.2 Test Standards and Results Summary Page 6 of 19 3.0 Test Results 3.1 Emission Page 7-11 of 19 3.2 Bandwidth Measurement Page 12-13 of 19 STC Test Report Date : 2006-07-18 Page 3 of 19 No. : HM156864 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage Appendix A List of Measurement Equipment Page 14 of 19 Appendix B Duty Cycle Correction During 100 msec Page 15-16 of 19 Appendix C Periodic Operation Page 17 of 19 Appendix D Photographs Page 18-19 of 19 STC Test Report Date : 2006-07-18 Page 4 of 19 No. : HM156864 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant Play-It Incorporated 162 Rhode Island Avenue, Newport, RI 02840, USA HKSTC Code Number for Applicant Manufacturer Herald Metal & Plastic Works Ltd. 1/F Pat Tat Ind. Bldg., 1, Pat Tat St., Sanpokong, Kln., H.K. STC Test Report Date : 2006-07-18 Page 5 of 19 No. : HM156864 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.3 Equipment Under Test [EUT] Description of Sample Product: PLAY-IT online controller Manufacturer: Herald Metal & Plastic Works Ltd. Brand Name: PLAY-IT Model Number: 888 Rating: 4.5Vd.c. (“AA” size battery x 3) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a Play-It Incorporated, PLAY-IT online controller. The transmitter is a 4 button transmitter. The EUT continues to transmit while button is being pressed, Modulation by Data Code type is pulse modulation. 1.4 Date of Order 2006-06-17 1.5 Submitted Sample(s): 1 Sample 1.6 Test Duration 2006-26 to 2006-07-15 1.7 Country of Origin China STC Test Report Date : 2006-07-18 Page 6 of 19 No. : HM156864 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 2005 and ANSI C63.4:2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.231a ANSI C63.4:2003 N/A Radiated Emissions, 30MHz to 1GHz FCC 47CFR 15.209 ANSI C63.…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
