LABEL LOCATION mCar Security Terminal Brand: KENJI Model: KJ-8501 FCC ID: UH8-KENJI

Tune up procedure I Test condition： 1，Test tool：Spectrum (up to 1GHz), Static-free desk 2，Transmitter technical requirement：315MHz ±75KHz / Power 10dBm±1dBm； 3，Test condition：Normal temperature; Distance 30CM。 II Test method： 1，Connect the EUT with the spectrum on the desk and setup the testing environment/distance. 2，Measure the control unit (engineering unit) at FREQ. 315MHz (tolerance: ±75KHz) and POWER 10dBm(tolerance: ±1dBm), HOLD the trace on the spectrum and marked as trace A. 3 Replace the control unit (engineering unit) by the mass product unit, measure and mark the trace as trace B. 4，Compare trace A & trace B, if trace B is under trance A, then PASS 5，Otherwise, if trace B over trace A, then NG

This device is used with a PCB Antenna, gain is 0dBi

Compliance Certification Services (Shenzhen) Inc. Report No: SZ060707B01-RP FCC ID: UH8-KENJI Date of Issue: August 30, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 23 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For mCar Security Terminal Model: KJ-8501 / 850X / 860X / 830X Trade Name: KENJI Prepared for TECH-LINK T&E LTD. ROOM 1905-07, TOWER III, ENTERPRISE SQUARE, PHASE 19 SHEUNG YUET ROAD, KOWLOON BAY, KOWLOON, HONGKONG Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO. 5, JINAO INDUSTRIAL PARK, NO. 35 JUKENG ROAD, DASHUIKENG VILLAGE, GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL: 86-755-28055000 FAX: 86-755-28055221 LAB CODE:200577-0 Compliance Certification Services (Shenzhen) Inc. Report No: SZ060707B01-RP FCC ID: UH8-KENJI Date of Issue: August 30, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.............................................................................................................. 5 3.2 EUT EXERCISE......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES.................................................................................................. 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 6 3.5 DESCRIPTION OF TEST MODES................................................................................................. 6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES.............................................................................................................................. 8 5.2 EQUIPMENT............................................................................................................................. 8 5.3 LABORATORY ACCREDITATIONS AND LISTING....................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT.............................................................................................. 9 6.2 SUPPORT EQUIPMENT.............................................................................................................. 9 7. FCC PART 15.231 REQUIREMENTS...................................................................................... 10 7.1 20 DB BANDWIDTH .......................................................................................................... 10 7.2 LIMIT OF TRANSMISSION TIME.............................................................................................. 12 7.3 DUTY CYCLE ..................................................................................................................... 14 7.4 RADIATED EMISSIONS........................................................................................................... 17 7.5 POWERLINE CONDUCTED EMISSIONS.................................................................................... 22 Compliance Certification Services (Shenzhen) Inc. Report No: SZ060707B01-RP FCC ID: UH8-KENJI Date of Issue: August 30, 2006 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: TECH-LINK T&E LTD. ROOM 1905-07, TOWER III, ENTERPRISE SQUARE, PHASE 19 SHEUNG YUET ROAD, KOWLOON BAY, KOWLOON, HONGKONG Equipment Under Test: mCar Security Terminal Tr a d e N a m e : KENJI Model: KJ-8501 / 850X / 860X / 830X Date of Test: July 07-August 11, 2006 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and Part 15.231. The test results of this report relate only to the tested sample identified in this report. Approved by: Tested By: Henry Ding Reviewed By: Harris Lai / General Manager Eric Wong / Assistant manager COMPLIANCE CERTIFICATION COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. SERVICES (SHENZHEN) INC. Compliance Certification Services (Shenzhen) Inc. Report No: SZ060707B01-RP FCC ID: UH8-KENJI Date of Issue: August 30, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product mCar Security Terminal Trade Name KENJI Model Number KJ-8501 / 850X / 860X / 830X Model Difference All the model are identical in electronic level, different model designation applies due to marketing purpose Power Supply Powered by lithium battery Frequency Range 315 MHz Antenna Designation PCB Antenna Remark: This submittal(s) (test report) is intended for FCC ID: UH8-KENJI filing to comply with Section 15.207, 15.209 and 15.231 of the FCC Part 15, Subpart C Rules. Compliance Certification Services (Shenzhen) Inc. Report No: SZ060707B01-RP FCC ID: UH8-KENJI Date of Issue: August 30, 2006 Page 5 Rev. 00 3. TEST METHODOLOGY The t…
