UHW10030006Part 18 Consumer Device

IMPORTANT SAFETY INSTRUCTIONS. READ ALL INSTRUCTIONS BEFORE USING. IMPORTANT SAFETY INSTRUCTIONS. Use this appliance only for its intended purpose as described in this Owner’s Manual. When using electrical appliances basic safety precautions should be followed, including the following: n Read and follow the specific precautions in the PRECAuTiONS TO AvOid POSSiBLE ExPOSuRE TO ExCESSivE MiCROWAvE ENERGY section above . n This appliance must be grounded . Connect only to a properly grounded outlet . See the GROuNdiNG iNSTRuCTiONS section on page 5 . n install or locate this appliance only in accordance with the provided installation instructions . n Be certain to place the front surface of the door 3" or more back from the countertop edge to avoid accidental tipping of the appliance in normal usage . n This microwave oven is not approved or tested for marine use . n do not mount this appliance over a sink . n do not mount the microwave oven over or near any portion of a heating or cooking appliance . n do not store anything directly on top of the microwave oven surface when the microwave oven is in operation . n do not operate this appliance if it has a damaged power cord or plug, if it is not working properly, or if it has been damaged or dropped . n do not cover or block any openings on the appliance . n use this appliance only for its intended use as described in this manual . do not use corrosive chemicals or vapors in this appliance . This microwave oven is specifically designed to heat, dry or cook food, and is not intended for laboratory or industrial use . n do not store this appliance outdoors . do not use this product near water—for example, in a wet basement, near a swimming pool, near a sink or in similar locations . n Keep power cord away from heated surfaces . n do not immerse power cord or plug in water . n do not let power cord hang over edge of table or counter . n To reduce the risk of fire in the oven cavity: — do not overcook food . Carefully attend appliance when paper, plastic or other combustible materials are placed inside the oven while cooking . — Remove wire twist-ties and metal handles from paper or plastic containers before placing them in the oven . — do not use the oven for storage purposes . do not leave paper products, cooking utensils or food in the oven when not in use . — if materials inside the oven ignite, keep the oven door closed, turn the oven off and disconnect the power cord, or shut off power at the fuse or circuit breaker panel . if the door is opened, the fire may spread . n See door surface cleaning instructions in the Care and cleaning of the microwave oven section of this manual . n GE does not support any servicing of this microwave oven, except as described by the Consumer Support sections of this manual . do not attempt to service the microwave oven yourself . if service is desired, the this appliance should be serviced only by qualified service personnel . Contact the nearest authorized service facility for examination, repair or adjustment . n This appliance must only be serviced by qualified service personnel . Contact the nearest authorized service facility for examination, repair or adjustment . n As with any appliance, close supervision is necessary when used by children . WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 2 (a) Do Not Attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy . it is important not to defeat or tamper with the safety interlocks . (b) Do Not Place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces . (c) Do Not Operate the oven if it is damaged . it is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces . (d) The Oven Should Not be adjusted or repaired by anyone except properly qualified service personnel . SAVE THESE INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS. READ ALL INSTRUCTIONS BEFORE USING. GEAppliances.com ARCING If you see arcing, press the CLEAR/OFF pad and correct the problem. Arcing is the microwave term for sparks in the oven . Arcing is caused by: n Metal or foil touching the side of the oven . n Foil not molded to food (upturned edges act like antennas) . n Metal, such as twist-ties, poultry pins or gold- rimmed dishes, in the microwave . n Recycled paper towels containing small metal pieces being used in the microwave . FOODS n do not pop popcorn in your microwave oven unless in a special microwave popcorn accessory or unless you use popcorn labeled for use in microwave ovens . n Some products such as whole eggs and sealed containers—for example, closed jars—are able to explode and should not be heated in this microwave oven . Such use of the microwave oven could result in injury . n do not boil eggs in a microwave oven . Pressure will build up inside egg yolk and will cause it to burst, possibly resulting in injury . n Operating the microwave with no food inside for more than a minute or two may cause damage to the oven and could start a fire . it increases the heat around the magnetron and can shorten the life of the oven . n Foods with unbroken outer “skin” such as potatoes, hot dogs, sausages, tomatoes, apples, chicken livers and other giblets and egg yolks should be pierced to allow steam to escape during cooking . n Avoid heating baby food in glass jars, even with the lid off . Make sure all infant food is thoroughly cooked . Stir food to distribute the heat evenly . Be careful to prevent scalding when warming formula . The container may feel cooler than the formula really is . Always test the formula…

Text truncated - open the document above for the full version.

Guangdong Galanz Enterprises Co., Ltd 25 South Ronggui Rd., Shunde, Foshan, Guangdong, China DATE 2012-03-19 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: UHW10030006 Product Name: Microwave Oven Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Part list • Operational description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this / Day of 19/03/2012 / By: Valley.Wang Signature Printed Title: Vice director/CTSC On behalf of : Guangdong galanz Enterprises Co.,Ltd Telephone: 86-757-23612785

External Photos of EUT Sample 1. Front and Top View of EUT 2. Rear View of EUT 3. Door Open View of EUT

Label of D100N30AP-D2 FCC ID: UHW10030006 D100N30AP-D2VAC: 120 Hz: 60 PHASE: 1 WIRE: 3 WATTS: 1450 AMPS: 12.5 OPERATION FREQUENCY:2450MHz HOUSEHOLD MICROWAVE OVENSERIAL: MANUFACTURED: MADE IN CHINA Label Location for D100N30AP-D2 Back board Rating label

Internal Photos of EUT Sample 1. Uncovered View from Right Side of EUT 2. Uncovered View from Top Side of EUT 3. Front View of Main Board 4. Back View of Main Board 5. Front View of AC Power Filter Board 6. Back View of AC Power Filter Board 7. View of Magnetron

FCC CFR47 PART 18 SUBPART C ISM EQUIPMENT TEST REPORT FOR MICROWAVE OVEN Model: P100N30(X)-(Y) (Testing case: P100N30AP-D2) Magnetron Model: Galanz, M24FC-610A Brand Name: Galanz Test Report No.: 12CA03191-01 FCC ID: UHW10030006 Prepared for GUANGDONG GALANZ ENTERPRISE (GROUP)CO.,LTD. 25 RONGGUI NAN ROAD, RONGGUI SHUNDE, GUANGDONG P.R.C.528305 ACCORDING TO FCC PART 18 INDUSTRIAL, SCIENTIFIC AND MEDICAL EQUIPMENT & FCC/0ST MP-5(1986) FCC METHODS OF MEASUREMENTS OF RADIO NOISE EMISSION FROM INDUSTRIAL, SCIENTIFIC AND MEDICAL EQUIPMENT Prepared By: Daomen Guan Reviewed By: Yanhan Lu QC Manager: Valley.Wang Test Report Released By _____________________ _19/03/2012_________________ Name Date Page 1 of 36 List Attached Files Exhibit Type File Description File Name Te s t re p o r t Te s t re p o r t UHW10030006 -Test report .pdf Operation Description Operational Description UHW10030006 -Operational description .pdf External Photos External Photos UHW10030006 -External photos .pdf Internal Photos Internal Photos UHW10030006 -Internal photos .pdf Block Diagram Block Diagram UHW10030006 -Block diagram .pdf Schematics Diagram Schematics Diagram UHW10030006 -Schematics .pdf ID Label/ Location ID Label/ Location UHW10030006 -label & location .pdf User Manual User Manual UHW10030006 -User manual .pdf Test setup Photos Test setup Photos UHW10030006 -Test setup photos .pdf Part List Part List UHW10030006 - Part list .pdf Page 2 of 36 Test Location Tests performed at Galanz in a certified Ansi Semi-Anechoic Chamber and Shielded Room. Test Site Location EMC Laboratory Guangdong Galanz Enterprises Co., Ltd 25 South Ronggui Rd., Shunde, Foshan, Guangdong, China. Tel: 86-757-23612785 Fax: 86-757-23612537 In compliance with the site registration requirements of section 2.948 of the FCC rules to perform EMI measurements for the general public. FCC Registration Number: 580210 Page 3 of 36 Table of Contents GOVERNMENT DISCLAIMER NOTICE-----------------------------------------------4 REPRODUCTION CAUSE------------------------------------------------------------------4 OPINIONS AND INTERPRETATIONS---------------------------------------------------4 STATEMENT OF MEASUREMENT UNCERTAINTY--------------------------------4 ADMINISTRATIVE DATA- -----------------------------------------------------------------5 EUT DESCRIPTION--------------------------------------------------------------------------5 TYPE OF DERIVER------------------------------------------------------------------------6 TEST SUMMARY------------------------------------------------------------------------------7 LORD FOR MWO-----------------------------------------------------------------------------8 EQUIPMENT MODIFICATION-----------------------------------------------------------8 EUT SAMPLE PHOTOS FOR MODEL--------------------------------------------------9 TEST SYSTEM DETAILS------------------------------------------------------------------14 CONFIGURATION OF TESTED SYSTEM--------------------------------------------15 ATTACHMENT 1- RADIATION HAZARD TEST------------------------------------16 ATTACHMENT 2-INPUT POWER MEASUREMENT------------------------------19 ATTACHMENT 3-RF OUTPUT POWER MEASUREMENT----------------------22 ATTACHMENT 4- OPERATING FREQUENCY MEASUREMENT-------------25 ATTACHMENT 5-CONDUCTED EMISSION TEST RESULTS------------------28 ATTACHMENT 6-RADIATED EMISSION TEST RESULTS----------------------33 Page 4 of 36 GOVERNMENT DISCLAIMER NOTICE When government drawing, specification or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States government thereby incurs no responsibility nor any obligation whatsoever, and the fact that the Government might have formulated, furnished or in any way supplied the said drawing, specification or other data, is not to be regarded implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights to permission to manufacture, use or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of the document must be done in full. No single part of the document may be reproduced without permission from EMC Laboratory of Guangdong Galanz Enterprises Co., Ltd Opinions and Interpretations This test report relates to the above mentioned equipment under test (EUT). Without permission of EMC Laboratory of Guangdong Galanz Enterprises Co., Ltd, this report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. Page 5 of 36 Administrative Data Test Sample Microwave oven Model Numbers P100N30(X)-(Y) Model Tested P100N30AP-D2 Brand Name Galanz Date Tested February 28, 2012 Applicant Guangdong Galanz Enterprises Co., Ltd. 25 ronggui nan Rd., Shunde, Foshan, Guangdong , China Telephone 86-757-23612785 Fax 86-757-23612537 Manufacturer Guangdong Galanz Enterprises Co., Ltd. 25 ronggui nan Rd., Shunde, Foshan, Guangdong , China EUT DESCRIPTION Guangdong Galanz Enterprises Co., Ltd. Model tested P100N30AP-D2 (Refer to the EUT in this report) is a Microwave Oven. Specifications: Power consumption 120Vac 60Hz, 1450W(Microwave) Output 1000W Operation frequency 2450Hz Magnetron brand Galanz Magnetron number M24FC-610A Outside dimensions(HxWxD) 11 13/16×21 1/4×17 3/4 in. Cavity dimensions(HxWxD) 9 7/16×14 13/16×15 7/…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS 1. Radiation Hazard Test Setup 2. Input Power Test Setup 3. RF Output Power Test Setup 4. Operating Frequency Test Setup 5. Conducted Emission Test Setup 6. Radiated Emission Test Setup
