Microwave Oven Owner’s Manual MODEL P70D20AL-D4 1. READ these instructions carefully before installing and operating the oven. Keep them for further reference. 2. Record in the space below the “SERIAL NO.” found on the nameplate on your oven and retain this information for future reference. SERIAL NO.: 1 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 1. Do not attempt to operate this oven with the door-open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. 2. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. 3. Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: a) Door (bent), b) Hinges and latches (broken or loosened), c) Door seals and sealing surfaces. 4. The oven should not be adjusted or repaired by anyone except properly qualified service personnel. CONTENT PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ...................................................................................................................................................... 1 IMPORTANT SAFETY INSTRUCTIONS..................................................................................... 2 GROUNDING INSTRUCTIONS................................................................................................... 3 UTENSILS GUIDE........................................................................................................................ 4 COOKING TECHNIQUES............................................................................................................ 6 BEFORE YOU CALL FOR SERVICE.......................................................................................... 7 SPECIFICATIONS........................................................................................................................ 7 PART NAMES.............................................................................................................................. 7 CONTROL PANEL....................................................................................................................... 8 OPERATION INSTRUCTIONS..................................................................................................... 9 Setting the clock.................................................................................................................... 9 Setting the over timer ............................................................................................................ 9 Setting a cooking program .................................................................................................... 9 Speed defrost ...................................................................................................................... 10 Cook by weight.................................................................................................................... 10 Defrost by weight ................................................................................................................ 11 Setting child lock ................................................................................................................. 11 QUICK COOK SETTINGS......................................................................................................... 11 POPCORN .......................................................................................................................... 11 BAKED POTATO................................................................................................................. 12 PIZZA .................................................................................................................................. 12 BEVERAGE ........................................................................................................................ 12 FROZEN DINNER............................................................................................................... 12 REHEAT .............................................................................................................................. 12 CLEANING AND CARE............................................................................................................. 13 2 IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING - To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" on page 1. 3. This appliance must be grounded. Connect only to properly grounded outlet. See "grounding instructions” on page 3. 4. Install or locate this appliance only in accordance with the provided installation instructions. 5. Some products such as whole eggs and sealed containers -for example, closed glass jars- are able to explode and should not be heated in this oven. 6. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use. 7. As with any appliance, close supervision is necessary when used by children. 8. To reduce the risk of fire in the oven cavity: — Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. — Remove wire twist-ties from paper or plastic bags before placing bag in oven. — If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the power cord or shut off powe…

Text truncated - open the document above for the full version.

Original Web Site: www.galanz.com 25 Ronggui Nan Rd, Shunde E-Mail:[email protected] Foshan , Guangdong, China Phone : +86 0757-23612785 FAX : + 86 0757-23612537 AGENCY AUTHORIZATION LETTER FCC ID: UHW7020001 Date: Jan 28, 2007 To whom it may concern: We,the undersigned,hereby authorize Galanz of China to act on our behalf ,as our agent ,in the folloing matters related to the FCC approval of our agent ,in the folling matters related to the FCC approval of our products: report submittal, related correspondence,the signing of all documents relating to the matter.and any other lawful activity necessary to obtain such certification.Any act carried out by Galanz within the scope of this authorization shall have the same effecs as our own. This authorization shall expire 6 months from original date ,if you have any question regarding the authorization ,please don,t hesitate to contact us ,thank you. Sincerely, Valley Wang & Guangdong Galanz Enterprise Phone : +86 0757-23612785 FAX : + 86 0757-23612537 E-Mail:[email protected]

Date: Jan 28 , 2007 Federal communications commission Authorization and Evaluation Division FCC ID: UHW7020001 Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules,the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1. Schematics 2. Block diagram 3. Operational description The above materials contain trade secrets and proprietary information not customarily released to the public,the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Valley Wang & Guangdong Galanz Enterprise Phone : +86 0757-23612785 Fax : + 86 0757-23612537 E-Mail:[email protected]

1 External Photos of EUT sample Photo 1- Front view of EUT Photo 2- Back view of EUT 2 Photo 3 – Inner view of EUT

Label & Location Proposed FCC Label Format: Dimention：Length x width = 170mm x 30mm Specifications: Text is white or black in color and is left justified ,Labels are printed in indelible ink on permanent adhesive backing or sile-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed FCC Label Location: location FCC Warning Statement: The Device complies with part 18 of the FCC rules,Operation is subject to the following conditions: (1) This device may not cause harmful interference,and (2) this device must accept any interference received,including interference that may cause undersired operation .

1 Internal Photos of EUT sample Photo - Front view of AC Power filter board Photo 2 – Back view of AC Power filter board 2 Photo 3 –Front view of Main board Photo 4 – Back view of main board

670 National Avenue, Mountain View, CA 94043 Tel. (650) 988-0900 Fax (650) 988-6647 www.ecmg-global.com EMI Test Report On Model Name : Microwave oven Model Numbers : P70D20X-Z Brand Names : Galanz FCC ID : UHW7020001 Prepared for Guangdong Galanz Enterprises Co., Ltd. According to FCC Part 18 Industrial, Scientific and Medical Equipment FCC/OST MP-5(1986) FCC methods of measurements of radio noise emission from industrial, scientific and medical equipment Test Report #: GUA-0604-5298-FCC Prepared by: Ravin Su Reviewed by: Ivan Wen QC Manager: Paul Chen Test Report Released by: 2007, Jan 28 ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ ⎯⎯⎯ Paul Chen Date NVLAP Lab code: 200068-0 ISO/IEC 17025:1999, ISO 9002:1994 List Attached Files Exhibit Type File Description File Name Test Report Test Report UHW7020001 _Test report.pdf Operation Description Technical Description UHW7020001 _operationdescription.pdf External Photos External Photos UHW7020001 _External Photos Internal Photos Internal Photos UHW7020001 _Internal Photos Block Diagram Block Diagram UHW7020001 _Block Diagram.pdf Schematics Circuit Diagram UHW7020001 _Schematics.pdf ID Label/Location Label Artwork and Location UHW7020001 _Label & Location.pdf User Manual User Manual UHW7020001 _User Manual.pdf Test setup photos Test setup photos UHW7020001 _Test Setup Photos Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location: Electronic Testing Building Shahe Road, Xili, Nanshan District Shenzhen 518055, P.R. China. Tel: 86-755-26703698 Fax: 86-755-26627238 Registration Number: 261302 Accreditation Bodies EMC Compliance Management Group is a fully accredited Test Laboratory for ITE, ISM, MIL-STD and Telecommunications Products. In compliance with the site registration requirements of Section 2.948 of the FCC Rules to perform EMI measurements for the general public. FCC Registration #: 894293. Accredited by the National Voluntary Laboratory Accreditation Program for the specific scope of accreditation under Lab Code # 200068-0. Table of Contents GOVERNMENT DISCLAIMER NOTICE _____________________________________ 1 REPRODUCTION CLAUSE ________________________________________________ 1 OPINIONS AND INTERPRETATIONS ______________________________________ 1 STATEMENT OF MEASUREMENT UNCERTAINTY __________________________ 1 ADMINISTRATIVE DATA _________________________________________________ 2 EUT DESCRIPTION _______________________________________________________ 2 TYPE OF DERIVER _______________________________________________________ 3 TEST SUMMARY _________________________________________________________ 4 LOAD FOR MICROWAVE OVENS__________________________________________ 5 EQUIPMENT MODIFICATION _____________________________________________ 5 EUT SAMPLE PHOTOS FOR MODEL P70D20AL-D4 ________________________ 6 TEST SYSTEM DETAILS __________________________________________________ 8 CONFIGURATION OF TESTED SYSTEM ___________________________________ 9 ATTACHMENT 1 – RADIATION HAZARD TEST ___________________________ 10 ATTACHMENT 2 – INPUT POWER MEASUREMENT _______________________ 13 ATTACHMENT 3 – RF OUTPUT POWER MEASUREMENT __________________ 16 ATTACHMENT 4 – OPERATING FREQUENCY MEASUREMENT _____________ 19 ATTACHMENT 5 - CONDUCTED EMISSION TEST RESULTS _______________ 22 ATTACHMENT 6 - RADIATED EMISSION TEST RESULTS ______________ 26-29 EMC Test Report #: GUA-0604-5298-FCC Prepared for Guangdong Galanz Enterprises Co., LTD. Prepared by EMC Compliance Management Group Page 1 of 29 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from EMC Compliance Management Group, 670 National Ave., Mountain View, CA 94043. Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT). Without the permission of EMC Compliance Management Group Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. EMC Test Report #: GUA-0604-5298-FCC Prepared for Guangdong Galanz Enterprises Co., Ltd. Prepared by EMC Compliance Management Group Page 2 of 29 Administrative Data Test Sample : Microwave Oven Model Numbers : P70D20X-Z Model Tested : P70D20AL-D4 Brand Name : Galanz Date Tested : 2007, Jan 27 th Applicant : Guangdong Galanz Enterprises Co., Ltd. 25 Ronggui Nan Rd., Shunde, Foshan, Guangdong, China. Telephone : 86-757-23612785 Fax : 86-757-23612537 Manufacturer : Guangdong Galanz Enterprises Co., Ltd. 25 Ronggui Nan Rd., Shunde, Foshan, Guangdong, China. EUT Description Guangdong Galanz Enterprises Co., Ltd. models tested P70D20AL-D4 (referred to the EUT in this report) is a Microwave Oven. S…
