UHW9023004Microwave Oven

Model: P90N23AP-D2 Microwave Oven User's manual Please read these instructions carefully before installing and operating the oven. Record in the space below the SERIAL NO. found on the nameplate on your oven and retain this information for future reference. SERIAL NO. 1 1. Do not attempt to operate this oven with the door-open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. 2. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. 3. Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: a. Door (bent), b. Hinges and latches (broken or loosened), c. Door seals and sealing surfaces. 4. The oven should not be adjusted or repaired by anyone except properly qualified service personnel. CONTENT PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ...............................................................................................................................1 IMPORTANT SAFETY INSTRUCTIONS...............................................................................2 INSTALLATION GUIDE .........................................................................................................3 GROUNDING INSTRUCTIONS ............................................................................................3 UTENSILS GUIDE ................................................................................................................4 COOKING TECHNIQUES.....................................................................................................5 SPECIFICATIONS.................................................................................................................6 PART NAMES .......................................................................................................................6 CONTROL PANEL ................................................................................................................7 OPERATION INSTRUCTIONS .............................................................................................8 Setting the clock ............................................................................................................8 Setting the over timer ....................................................................................................8 Setting a cooking program ............................................................................................8 Speed defrost ................................................................................................................9 Cook by weight..............................................................................................................9 Defrost by weight.........................................................................................................10 Setting child lock .........................................................................................................10 QUICK COOK SETTINGS ..................................................................................................10 POPCORN ..................................................................................................................10 BAKED POTATO .........................................................................................................10 PIZZA ..........................................................................................................................10 BEVERAGE.................................................................................................................11 FROZEN DINNER.......................................................................................................11 REHEAT ......................................................................................................................11 CLEANING AND CARE.......................................................................................................11 P P R R E E C C A A U U T T I I O O N N S S T T O O A A V V O O I I D D P P O O S S S S I I B B L L E E E E X X P P O O S S U U R R E E T T O O E E X X C C E E S S S S I I V V E E M M I I C C R R O O W W A A V V E E E E N N E E R R G G Y Y SAVE THESE INSTRUCTIONS 2 When using electrical appliances, basic safety precautions should be followed, including the following: WARNING - To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" on page 1. 3. This appliance must be grounded. Connect only to properly grounded outlet. See "grounding instructions” on page 3. 4. Install or locate this appliance only in accordance with the provided installation instructions. 5. Some products such as whole eggs and sealed containers -for example, closed glass jars- are able to explode and should not be heated in this oven. 6. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use. 7. As with any appliance, close supervision is necessary when used by children. 8. To reduce the risk of fire in the oven cavity: a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. b. Remove wire twist-ties from paper or plastic bags before placing bag in oven. c. If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the power cord or shut off power at the fuse or circuit breaker panel. d. Do not use the cavity for sto…

Text truncated - open the document above for the full version.

Date: Dec 08, 2007 Federal communications commission Authorization and Evaluation Division FCC ID: UHW Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules,the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1. Schematics 2. Block diagram 3. Operational description The above materials contain trade secrets and proprietary information not customarily released to the public,the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Valley Wang & Guangdong Galanz Enterprise Phone : +86 0757-23612785 Fax : + 86 0757-23612537 E-Mail:[email protected]

Original Web Site: www.galanz.com 25 Ronggui Nan Rd, Shunde E-Mail:[email protected] Foshan , Guangdong, China Phone : +86 0757-23612785 FAX : + 86 0757-23612537 AGENCY AUTHORIZATION LETTER FCC ID: UHW Date: Jan Dec, 08 To whom it may concern: We,the undersigned, hereby authorize ECMG of China to act on our behalf ,as our agent ,in the following matters related to the FCC approval of our agent ,in the following matters related to the FCC approval of our products: report submittal, related correspondence,the signing of all documents relating to the matter.and any other lawful activity necessary to obtain such certification.Any act carried out by ECMG within the scope of this authorization shall have the same effecs as our own. This authorization shall expire 6 months from original date ,if you have any question regarding the authorization ,please don,t hesitate to contact us ,thank you. Sincerely, Valley Wang & Guangdong Galanz Enterprise Phone : +86 0757-23612785 FAX : + 86 0757-23612537 E-Mail:[email protected]

1 External Photo of EUT sample Photo 1- Front view of EUT Photo 2- Back view of EUT 2 Photo 3 –Top view of EUT Photo 4 –Bottom view of EUT

Label & Location Proposed FCC Label Format: Dimention：Length x width = 170mm x 30mm Specifications: Text is white or black in color and is left justified ,Labels are printed in indelible ink on permanent adhesive backing or sile-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed FCC Label Location: location FCC Warning Statement: The Device complies with part 18 of the FCC rules,Operation is subject to the following conditions: (1) This device may not cause harmful interference,and (2) this device must accept any interference received,including interference that may cause undersired operation .

1 Internal Photos of EUT sample Photo 1- Uncovered view of EUT Photo 2- Front view of AC Power filter board 2 Photo 3 – Back view of AC Power filter board Photo 4 –Front view of Main board 3 Photo 5 – Back view of main board Photo 6 – Magnetron View

EMI Test Report On Model Name: Microwave oven Model Numbers: P90N23X-Z Brand Name: Galanz FCC ID: UHW9023004 Prepared for Guangdong Galanz Enterprises Co. Ltd According to FCC Part 18 Industrial, Scientific and Medical Equipment FCC/OST MP-5(1986) FCC methods of measurements of radio noise emission from industrial,scientific and medical equipment Test Report#: PSZ-0712-0564-FCCID Prepared by: Eddy Chen Reviewed by: Ivan Wen QC Manager: Paul Chen Test Report Released by: 2007, Dec 18 ⎯⎯⎯⎯⎯⎯⎯⎯ ⎯⎯⎯⎯⎯⎯ Paul Chen Date List Attached Files Exhibit Type File Description File Name Test Report Test Report UHW9023004 _Test report.pdf Operation Description Technical Description UHW9023004 _operation description.pdf External Photos External Photos P UHW9023004 _External Photos Internal Photos Internal Photos UHW9023004 _Internal Photos Block Diagram Block Diagram UHW9023004 _Block Diagram.pdf Schematics Circuit Diagram UHW9023004 _Schematics.pdf ID Label/Location Label and Location UHW9023004 _Label & Location.pdf User Manual User Manual UHW9023004 _User Manual.pdf Test setup photos Test setup photos UHW9023004 _Test Setup Photos Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location: Guangdong Galanz Enterprise Co. Ltd 25 South Ronggui Rd., Shunde, Foshan, Guangdong, China Tel : 86-755-23612785 Fax : 86-755-23612537 FCC Registration Number: 580210 Table of Contents GOVERNMENT DISCLAIMER NOTICE ___________________________________________ 1 REPRODUCTION CLAUSE ______________________________________________________ 1 OPINIONS AND INTERPRETATIONS_____________________________________________ 1 STATEMENT OF MEASUREMENT UNCERTAINTY ________________________________ 1 ADMINISTRATIVE DATA _______________________________________________________ 2 EUT DESCRIPTION _____________________________________________________________ 2 TYPE OF DERIVER _____________________________________________________________ 3 TEST SUMMARY _______________________________________________________________ 4 LOAD FOR MICROWAVE OVENS _______________________________________________ 5 EQUIPMENT MODIFICATION ___________________________________________________ 5 EUT SAMPLE PHOTOS FOR MODEL_____________________________________________ 6 TEST SYSTEM DETAILS _______________________________________________________10 CONFIGURATION OF TESTED SYSTEM ________________________________________10 ATTACHMENT 1 – RADIATION HAZARD TEST _________________________________11 ATTACHMENT 2 – INPUT POWER MEASUREMENT _____________________________13 ATTACHMENT 3 – RF OUTPUT POWER MEASUREMENT ________________________15 ATTACHMENT 4 – OPERATING FREQUENCY MEASUREMENT ___________________17 ATTACHMENT 5 - CONDUCTED EMISSION TEST RESULTS _____________________20 ATTACHMENT 6 - RADIATED EMISSION TEST RESULTS________________________24 Test Report #: PSZ-0712-0564-FCCID Prepared for Guangdong Galanz Enterprises Co. Ltd Prepared by ECMG Worldwide Certification Solution Inc. Page 1 of 27 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from ECMG Worldwide Certification Solution Inc., Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT). Without the permission of ECMG Worldwide Certification Solution Inc., Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. Test Report #: PSZ-0712-0564-FCCID Prepared for Guangdong Galanz Enterprises Co. Ltd Prepared by ECMG Worldwide Certification Solution Inc. Page 2 of 27 Administrative Data Test Sample : Microwave oven Model Numbers : P90N23X-Z Model Tested : P90N23AP-D2 Brand Name : Galanz Date Tested : 2007, Dec 08 Applicant : Guangdong Galanz Enterprises Co. Ltd 25Ronggui Nan Road, Shunde, Foshan, Guangdong, China. Telephone : 86-0757-23612785 Fax : 86-0757-23612537 Manufacturer : Guangdong Galanz Enterprises Co. Ltd 25Ronggui Nan Road, Shunde, Foshan, Guangdong, China. EUT Description Guangdong Galanz Enterprises Co. Ltd model tested EM923HYY (referred to the EUT in this report) is a Microwave Oven. Power Supply 120V AC , 60 Hz Rated Input Power 1350W Rated Output Power 900W Operation Frequency 2450MHz Magnetron Manufacturer Galanz Magnetron Model Number M24FB-210A Outside Dimensions (HxW×D) 12x19.2x16.1 in. Oven Capacity: 0.9cu.ft Turntable Diameter ￠12.4 inch Net Weight Approx. 34.4lbs. Test Report #: PSZ-0712-0564-FCCID Prepared for Guangdong Galanz Enterprises Co. Ltd Prepared by ECMG Worldwide Certification Solution Inc. Page 3 of 27 Type of Deriver P90N23X-Z model designations: X=L,AL,EL,SL,TL,YL,P,AP,EP,SP,TP,ASL…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS 1. AC input power measurement 2． Conducted Emission Test 3. Operation frequency measurement 4.Radiated emission measurement 5. Radiation hazard test 6. RF output power measurement
