UID2402GCTMG2402G/CT ARRIS Media Gateway Box

ARRIS

Click to zoom

Application Details

Equipment Class: PUB - Part 15 Unlicensed PCS Base Station
Date of Grant: Jun 18, 2013
Application Purpose: Original Equipment
Date of Application: Jun 18, 2013
Equipment Note: MG2402G/CT ARRIS Media Gateway Box
Frequency Range: 1921.53600000 - 1928.44800000
Company: ARRIS
Country: United States

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

3871 Lakefield Drive • Suwanee, GA 30024 • phone: 678-473-8400 www.arrisi.com April 30, 2013 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: UID2402GCT to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Edward R. Champion, Jr. Manager, Regulatory/Compliance ARRIS International, Inc. 3871 Lakefield Dr Suite 300 Suwanee, GA 30024

Cover Letter(s)

3871 Lakefield Drive • Suwanee, GA 30024 • phone: 678-473-8400 www.arrisi.com April 30, 20113 Federal Communications Commission Date: Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: ARRIS International, Inc. respectfully requests confidentiality of certain materials provided with the submission of the MG2402G/CT under FCC ID: UID2402GCT in accordance with FCC Regulations 0.459. The confidentiality request applies to the (1) schematic diagrams, (2) detailed block diagrams, and (3) detailed operational descriptions contained in this filing and included in the following files. 12-0437 - System Block Diagram.pdf 12-0437 - Schematics.pdf 12-0437 - Theory of Operation.pdf The MG2402G/CT has been developed at considerable effort and expense by ARRIS International, Inc.. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: Edward R. Champion, Jr.Signature: Title: Manager, Regulatory/ComplianceDate: 043020131

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 May 8, 2013 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: UID2402GCT To Whom It May Concern: The following application is submitted on behalf of our client, Arris International, Inc., for evaluation of their model MG2402G/CT for certification under FCC Part 15.247 and Part 15 Subpart D. The MG2402G/CT ARRIS Media Gateway provides a single point, triple play device to manage all content coming into the home as well as distribution of all content throughout the home. The MG2402G/CT is a composite device comprised of three technologies; WiFi, Zigbee, and DECT. The WiFi radio operates within the frequency bands 5725 to 5850 MHz and 2400 to 2483.5 MHz. The Zigbee radio operates within the frequency band 2405 to 2480 MHz. The DECT radio operates within the frequency range 1921.536 to 1928.448 MHz. The MG2402G/CT was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: UID2402GCT IC: 6670A-2402GCT FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0437 Manufacturer: Arris International, Inc. Model: MG2402G/CT Internal Photos Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 2 Figure 1: Internal Photo Figure 2: Internal Photo Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 3 Figure 3: Internal Photo Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 4 Figure 4: Internal Photo 802.11b/g/n 802.11a/n DECT Zigbee Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 5 Figure 5: Internal Photo (Shields Removed) Figure 6: Internal Photo 802.11 b/g/n (Shields Removed) Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 6 Figure 7: Internal Photo 802.11 a/n (Shields Removed) Figure 8: Internal Photo DECT (Shields Removed) Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 7 Figure 9: Internal Photo Zigbee (Shields Removed) Figure 10: Internal Photo Model: MG2402G/CTFCC ID: UID2402GCTIC: 6670A-2402GCT ACS Project: 12-0437Advanced Compliance SolutionsPage 8 Figure 11: Internal Photo

RF Exposure Info

Test Number: 216-13R2 Issue Date: 6/18/2013 Page 283 of 294 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com 7. Measurement Data (continued) 7.11. Public Exposure to Radio Frequency Energy Levels (15.247(i) (1.1307 (b)(1)) RSS-GEN 5.5, RSS 102 Requirement: (15.247(i)) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. Devices are subject to the radio frequency radiation exposure requirements specified in 47CFR 1.1307(b), FCC 47 CFR 2.1091 and 47 CFR 2.1093, as appropriate. All equipment shall be considered to operate in a ‘‘general population/uncontrolled’’ environment. Conclusion: The device under test is meets radio frequency radiation exposure requirements specified in 47CFR 1.1307(b), § 2.1091 and § 2.1093. Measurement Results – 2.4 GHz Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) 802.11b Mode Channel Frequency (1) (2) (3) (4) (5) Result 2412 20.0 23.32 2.5 0.07595490.7595488 1 Compliant 2437 20.0 23.59 2.5 0.08088480.8088484 1 Compliant 2462 20.0 23.81 2.5 0.08510030.8510035 1 Compliant Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) 802.11g Mode Channel Frequency (1) (2) (3) (4) (5) Result 2412 20.0 21.08 2.5 0.04538280.4538285 1 Compliant 2437 20.0 20.34 2.5 0.03825440.3825438 1 Compliant 2462 20.0 20.43 2.5 0.03903850.3903849 1 Compliant Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) HT20 Mode Channel Frequency (1) (2) (3) (4) (5) Result 2412 20.0 21.73 2.5 0.05267490.5267491 1 Compliant 2437 20.0 20.34 2.5 0.03822880.3822885 1 Compliant 2462 20.0 20.31 2.5 0.03796300.3796296 1 Compliant Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) HT40 Mode Channel Frequency (1) (2) (3) (4) (5) Result 2422 20.0 20.01 2.5 0.03543550.3543550 1 Compliant 2437 20.0 19.60 2.5 0.03228360.3228365 1 Compliant 2452 20.0 19.57 2.5 0.03206040.3206043 1 Compliant Test Number: 216-13R2 Issue Date: 6/18/2013 Page 284 of 294 7. Measurement Data (continued) 7.11. Public Exposure to Radio Frequency Energy Levels (15.247(i) (1.1307 (b)(1)) RSS-GEN 5.5, RSS 102 Measurement Results – 5 GHz Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) 802.11a Mode Channel Frequency (1) (2) (3) (4) (5) Result 5745 20.0 23.09 2.5 0.07202110.7202112 1 Compliant 5785 20.0 21.49 2.5 0.04986570.4986566 1 Compliant 5825 20.0 19.14 2.5 0.02899260.2899262 1 Compliant Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) HT20 Mode Channel Frequency (1) (2) (3) (4) (5) Result 5745 20.0 23.59 2.5 0.08092250.8092253 1 Compliant 5785 20.0 21.81 2.5 0.05370270.5370272 1 Compliant 5825 20.0 19.90 2.5 0.03453620.3453618 1 Compliant Power Density MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2)(W/m2) Limit (mW/cm2) HT40 Mode Channel Frequency (1) (2) (3) (4) (5) Result 5745 20.0 23.54 2.5 0.07993250.7993247 1 Compliant 5785 20.0 22.37 2.5 0.06109700.6109701 1 Compliant Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com PD = OP + AG (4 x π x d²) PD = Power Density OP = DUT Output Power (dBm) AG = Antenna Gain (dBi) D = MPE Distance 1. Reference CFR 2.1093(b): For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the installer. All other mobile and unlicensed transmitting devices are categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use, except as specified in §§ 1.1307(c) and 1.1307(d) of this chapter. 2. Section 7.4 of this test report. 3. Data supplied by the client. 4. Power density is calculated from field strength measurement and antenna gain. 5. Reference CFR 1.1310, Table 1: Limits for Maximum Permissible Exposure (MPE), Section (B): Limits for General Population/Uncontrolled Exposure. Test Number: 216-13R2 Issue Date: 6/18/2013 Page 285 of 294 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com 7. Measurement Data (continued) 7.11. Public Exposure to Radio Frequency Energy Levels (15.247(i), (1.1307 (b)(1)) RSS-GEN 5.5, RSS 102 (cont.) Simultaneous Transmission of 2.4 GHz and 5.8 GHz WiFi Radios. The highest levels for each of the modes of operation are summed in the following table. Power Density Worse Case Mode of Operation MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2) (W/m2) Limit (mW/cm2) Mode MHz (1) (2) (3) (4) (5) Result 802.11b 2462 20.0 23.81 2.50 0.0851003 0.8510035 1 Compliant 802.11a HT20 5745 20.0 23.59 2.50 0.0809225 0.8092253 1 Compliant DECT 1921.536 20.0 19.83 0.50 0.0214650 0.2146496 1 Compliant Zigbee 2405 20.0 0.68 3.00 0.0004642 0.0046423 1 Compliant SUM 20.0 N/A N/A 0.1879521 1.8795207 1 Compliant Using Directional Gain = Gant + 10 * Log10 (Nant / Nss) dBi where Nant is the number of MIMO Antennas, and Nss is the number of spatial streams (1). A consideration for Antenna Array Gain is also calculated in the following table. Power Density Worse Case Mode of Operation MPE Distance (cm) DUT Output Power (dBm) DUT Array Antenna Gain (dBi) (mW/cm2) (W/m2) Limit (mW/cm2) Mode MHz (1) (2) (3) (4) (5) Result 802.11b 2462 20.0 23.81 7.3 0.2553010 2.5530105 1 Compliant 802.11a HT20 5745 20.0 23.59 7.3 0.2427676 2.4276758 1 Compliant DECT 1921.536 20.0 19.83 0.5 0.0214650 0.2146496 1 Compliant Zigbee 2405 20.0 0.68 3.0 0.0004642 0.0046423 1 Compliant SUM 20.0 N/A N/A 0.5199978 5.19997…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Number: 265-13R2 Issue Date: 6/17/2013 Page 69 of 79 6. Measurement Data (continued) 6.12. Public Exposure to Radio Frequency Energy Levels (1.1307 (b)(1)) RSS-GEN 5.5, RSS 102 6.12.1. MPE Power Density Table Power Density Channel MPE Distance (cm) DUT Output Power (dBm) DUT Antenna Gain (dBi) (mW/cm2) (W/m2) Limit (mW/cm2) Result ANT0 (1) (2) (3) (4) (5) TX4 20 18.97 0.50 0.018 0.176 1 Compliant TX2 20 19.00 0.50 0.018 0.177 1 Compliant TX0 20 19.02 0.50 0.018 0.178 1 Compliant ANT1 TX4 20 19.83 0.50 0.021 0.215 1 Compliant TX2 20 19.83 0.50 0.021 0.215 1 Compliant TX0 20 19.82 0.50 0.021 0.214 1 Compliant Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com PD = Power Density PD = OP + AG (4 x π x d²) OP = DUT Output Power (dBm) AG = Antenna Gain (dBi) D = MPE Distance 1. Reference CFR 2.1093(b): For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. 2. Section 6.3 of this test report. 3. Data supplied by the client. 4. Power density is calculated from conducted power output measurement and antenna gain. 5. Reference CFR 1.1310, Table 1: Limits for Maximum Permissible Exposure (MPE), Section (B): Limits for General Population/Uncontrolled Exposure. Test Number: 265-13R2 Issue Date: 6/17/2013 Page 70 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com 6. Measurement Data (continued) 6.12. Public Exposure to Radio Frequency Energy Levels (1.1307 (b)(1)) RSS-GEN 5.5, RSS 102 (cont.) 6.12.2. MPE Time Averaged Power Table Frequency DUT Output Power DUT Antenna Gain Calculated Output Power Time Averaged Power Limit Result Channel (MHz) (dBm) (dBi) (mW) (mW) (mW) TX4 1921.536 18.97 0.50 88.51 3.44 100.00 Compliant TX2 1924.992 19.00 0.50 89.13 3.47 100.00 Compliant TX0 1928.448 19.02 0.50 89.54 3.48 100.00 Compliant TX4 1921.536 19.83 0.50 107.89 4.19 100.00 Compliant TX2 1924.992 19.83 0.50 107.89 4.19 100.00 Compliant TX0 1928.448 19.82 0.50 107.65 4.19 100.00 Compliant NOTE: Although the peak power is over the general exposure limit, the time averaged power is very small for DECT technology. In this case a nominal frame width of 388.8 μS repeating every 10 mS, and therefore is compliant with the general exposure requirements defined in RSS-102 Section 2.5.1. The reduction in power is calculated by 10 * LOG (0.3888 / 10) or -14.10 dB RSS-102 Section 2.5, 2.5.1 & 2.5.2 Requirements: 2.5 - All transmitters are exempt from routine SAR and RF exposure evaluations provided that output power complies with the power levels of sections 2.5.1 or 2.5.2. If the equipment under test (EUT) meets the requirements of sections 2.5.1 or 2.5.2, applicants are only required to submit a properly signed declaration of compliance (see Annex C). 2.5.1 - SAR evaluation is required if the separation distance between the user and the radiating element of the device is less than or equal to 20 cm, except when the device operates as follows: • above 1 GHz and up to 2.2 GHz inclusively, and with output power (i.e. the higher of the conducted or radiated (e.i.r.p.) source-based, time-averaged output power) that is less than or equal to 100 mW for general public use and 500 mW for controlled use 2.5.2 - RF exposure evaluation is required if the separation distance between the user and the device’s radiating element is greater than 20 cm, except when the device operates as follows: • at or above 1.5 GHz and the maximum e.i.r.p. of the device is equal to or less than 5 W.

Test Report

COMPLIANCE WORLDWIDE INC. TEST REPORT 265-13R2 In Accordance with the Requirements of Industry Canada RSS 213, Issue 2, December 2005 2 GHz License-exempt Personal Communications Service Devices (LE-PCS) Federal Communications Commission 47 CFR Part 15, Subpart D Technical Requirements for Unlicensed Personal Communication Systems (UPCS) Issued to ARRIS International, Inc. 3871 Lakefield Drive, Suite 300 Suwanee, GA 30024 For the MG2402G/CT FCC ID: UID2402GCT IC: 6670A-2402GCT Report Issued on April 29, 2013 Revision R2 Issued on June 17, 2013 Tested by This test report shall not be reproduced, except in full, without written permission from Compliance Worldwide, Inc. Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.complianceworldwide.com Test Number: 265-13R2 Issue Date: 6/17/2013 Page 2 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Table of Contents 1. Scope..................................................................................................................................................................3 2. Product Details....................................................................................................................................................3 2.1. Manufacturer............................................................................................................................................. 3 2.2. Model Number .......................................................................................................................................... 3 2.3. Serial Number ........................................................................................................................................... 3 2.4. Description ................................................................................................................................................ 3 2.5. Power Source ........................................................................................................................................... 3 2.6. Hardware Revision.................................................................................................................................... 3 2.7. Software Revision ..................................................................................................................................... 3 2.8. Modulation Type ....................................................................................................................................... 3 2.9. Operating Frequency ................................................................................................................................ 3 2.10. Emission Designator............................................................................................................................... 3 2.11. EMC Modifications .................................................................................................................................. 3 3. Product Configuration .........................................................................................................................................3 3.1. Cables....................................................................................................................................................... 3 3.2. EUT Hardware .......................................................................................................................................... 4 3.3. Support Equipment................................................................................................................................... 4 3.4. EUT Diagram ............................................................................................................................................ 4 3.5. EUT Channels & Frequencies .................................................................................................................. 5 4. Measurements Parameters.................................................................................................................................6 4.1. Measurement Equipment Used to Perform Test ....................................................................................... 6 4.2. Measurement & Equipment Setup ............................................................................................................ 7 4.3. Measurement Procedure .......................................................................................................................... 7 4.4. Measurement Uncertainty ......................................................................................................................... 7 5. Measurement Summary......................................................................................................................................8 6. Measurement Data .............................................................................................................................................9 6.1. Antenna Gain ............................................................................................................................................ 9 6.2. Type of Modulation and Access Protocol.................................................................................................. 9 6.3. Peak Transmit Power.............................................................................................................................. 10 6.4. Emission Bandwidth................................................................................................................................ 14 6.5. Spurious Emissions at the antenna terminals ......................................................................................... 19 6.6. Radiated Spurious Emissions (Harmonics) ............................................................................................ 30 …

Text truncated - open the document above for the full version.

Test Setup Photos

Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.1. Radiated Emissions – Front 150 kHz to 1 GHz Page 71 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.2. Radiated Emissions – Rear Below 30 MHz Page 72 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.3. Radiated Emissions – Rear 30 MHz to 1 GHz Page 73 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.4. Radiated Emissions – Front Above 1 GHz Page 74 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.5. Radiated Emissions – Rear 1 to 18 GHz Page 75 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.6. Radiated Emissions – Rear 18 to 40 GHz Page 76 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.7. Conducted Emissions (Front) Page 77 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com Test Number: 265-13R2 Issue Date: 6/17/2013 7. Test Images 7.8. Conducted Emissions (Rear) Page 78 of 79 Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com

Contact Information

Applicant

Antonio A Figueiredo(Manager -Regulatory/Compliance)

[email protected]678-473-5067Fax: 678-473-8712

Test Firm

Compliance Worldwide, Inc.Deb Bourbeau

[email protected]603-887-3903Fax: 603 887 6445

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15D	1.92 GHz - 1.93 GHz	96.00 mW

Confidentiality

Long Term

Grant Notes

Power output listed is peak conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except as described in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
